logosdb 0.7.0

Fast semantic vector database (HNSW + mmap) with Python bindings

LogosDB is a fast semantic vector database written in C/C++ that provides approximate nearest-neighbor search over embedding vectors with associated text metadata.

Authors: Jose (@jose-compu)

Features

• Vectors and metadata are stored as flat binary files, memory-mapped for zero-copy reads.
• Approximate nearest-neighbor search via HNSW (hnswlib), O(log n) query time.
• Each vector row carries optional text and ISO 8601 timestamp metadata (JSONL sidecar).
• The basic operations are Put(embedding, text, timestamp) and Search(query, top_k).
• Timestamp range filtering: search within a time window (e.g., "last 24 hours").
• Multiple distance metrics: inner product, cosine similarity (auto-normalized), or L2 Euclidean.
• Bulk vector access for direct tensor construction (e.g. loading into GPU memory).
• Thread-safe writes via internal mutex; concurrent reads are lock-free.
• Crash recovery: HNSW index is automatically backfilled from the append-only vector store on open.
• Scales to millions of vectors.
• Framework integrations: LangChain and LlamaIndex VectorStore adapters.

Documentation

The public interface is in include/logosdb/logosdb.h. Callers should not include or rely on the details of any other header files in this package. Those internal APIs may be changed without warning.

Guide to header files:

• include/logosdb/logosdb.h: Main interface to the DB. Start here. Contains:
  • C API with opaque handles and errptr convention (RocksDB/LevelDB style)
  • C++ convenience wrapper (logosdb::DB) with RAII and exceptions
  • logosdb::Options for HNSW tuning and distance metric selection
  • logosdb::SearchHit result struct
  • logosdb_search_ts_range() for timestamp-filtered search

Limitations

• This is not a general-purpose vector database. It is purpose-built for embedding-based memory retrieval in LLM inference (funes.cpp).
• Only a single process (possibly multi-threaded) can access a particular database at a time.
• There is no client-server support built into the library. An application that needs such support will have to wrap their own server around the library.
• For inner-product distance (LOGOSDB_DIST_IP, the default), vectors must be L2-normalized before insertion. Use LOGOSDB_DIST_COSINE for automatic normalization.
• Embedding generation is external — the caller provides pre-computed float vectors.

Getting the Source

git clone --recurse-submodules <repository-url>
cd logosdb

Building

This project supports CMake out of the box.

Quick start:

mkdir -p build && cd build
cmake -DCMAKE_BUILD_TYPE=Release .. && cmake --build .

This builds:

Target	Description
logosdb	Static library (liblogosdb.a)
logosdb-cli	Command-line tool for put, search, info
logosdb-bench	Benchmark: HNSW vs brute-force, with ChromaDB comparison
logosdb-test	Unit tests

Usage (C API)

#include <logosdb/logosdb.h>

char *err = NULL;
logosdb_options_t *opts = logosdb_options_create();
logosdb_options_set_dim(opts, 2048);

logosdb_t *db = logosdb_open("/tmp/mydb", opts, &err);
logosdb_options_destroy(opts);

float vec[2048] = { /* ... unnormalized vector ... */ };

// L2-normalize for inner-product distance (returns 0 on success, -1 if zero norm)
if (logosdb_l2_normalize(vec, 2048) == 0) {
    logosdb_put(db, vec, 2048, "My commute is 42 minutes",
                "2025-06-25T10:00:00Z", &err);
}

logosdb_search_result_t *res = logosdb_search(db, query_vec, 2048, 5, &err);
for (int i = 0; i < logosdb_result_count(res); i++) {
    printf("#%d score=%.4f text=%s\n", i,
           logosdb_result_score(res, i),
           logosdb_result_text(res, i));
}
logosdb_result_free(res);
logosdb_close(db);

Search with timestamp range filter

#include <logosdb/logosdb.h>

char *err = NULL;
logosdb_options_t *opts = logosdb_options_create();
logosdb_options_set_dim(opts, 2048);

logosdb_t *db = logosdb_open("/tmp/mydb", opts, &err);

// Search for top-5 matches within the last 24 hours
logosdb_search_result_t *res = logosdb_search_ts_range(
    db, query_vec, 2048, 5,
    "2025-04-21T10:00:00Z",  // from (inclusive), NULL for no lower bound
    "2025-04-22T10:00:00Z",  // to (inclusive), NULL for no upper bound
    50,                      // candidate_k: internal fetch multiplier (10x top_k recommended)
    &err);

for (int i = 0; i < logosdb_result_count(res); i++) {
    printf("#%d score=%.4f ts=%s text=%s\n", i,
           logosdb_result_score(res, i),
           logosdb_result_timestamp(res, i),
           logosdb_result_text(res, i));
}
logosdb_result_free(res);
logosdb_close(db);

Using different distance metrics

#include <logosdb/logosdb.h>

char *err = NULL;
logosdb_options_t *opts = logosdb_options_create();
logosdb_options_set_dim(opts, 2048);

// Use cosine similarity (automatically normalizes vectors)
logosdb_options_set_distance(opts, LOGOSDB_DIST_COSINE);

// Or use L2 Euclidean distance
// logosdb_options_set_distance(opts, LOGOSDB_DIST_L2);

// Default is LOGOSDB_DIST_IP (inner product on L2-normalized vectors)

logosdb_t *db = logosdb_open("/tmp/mydb", opts, &err);
logosdb_options_destroy(opts);

// For cosine: vectors are automatically normalized on put/search
float vec[2048] = { /* ... unnormalized vector ... */ };
logosdb_put(db, vec, 2048, "entry", "2025-04-22T10:00:00Z", &err);

logosdb_close(db);

Usage (C++ wrapper)

#include <logosdb/logosdb.h>
#include <vector>

// Basic usage with default inner-product distance
logosdb::DB db("/tmp/mydb", {.dim = 2048});

// L2-normalize your vectors before insertion (required for inner-product distance)
std::vector<float> embedding = load_some_vector();  // unnormalized
if (logosdb::l2_normalize(embedding)) {
    db.put(embedding, "My commute is 42 minutes", "2025-06-25T10:00:00Z");
}

// Or use l2_normalized() to get a normalized copy
auto normalized = logosdb::l2_normalized(query);
auto results = db.search(normalized, 5);
for (auto &r : results) {
    printf("id=%llu score=%.4f text=%s\n", r.id, r.score, r.text.c_str());
}

C++: Search with timestamp filter

#include <logosdb/logosdb.h>

logosdb::DB db("/tmp/mydb", {.dim = 2048});

// Search within a time window
auto results = db.search_ts_range(
    query, 5,
    "2025-04-21T00:00:00Z",  // from timestamp
    "2025-04-22T00:00:00Z",  // to timestamp
    50);                     // candidate_k (optional, defaults to 10x top_k)

for (auto &r : results) {
    printf("id=%llu score=%.4f ts=%s\n", r.id, r.score, r.timestamp.c_str());
}

C++: Using cosine or L2 distance

#include <logosdb/logosdb.h>

// Cosine similarity - vectors are automatically normalized
logosdb::DB db("/tmp/mydb", {.dim = 2048, .distance = LOGOSDB_DIST_COSINE});

// Put unnormalized vectors - they will be normalized automatically
db.put(unnormalized_embedding, "entry", "2025-04-22T10:00:00Z");

auto results = db.search(query, 5);
// scores are cosine similarities in [0, 1]

// L2 Euclidean distance
// logosdb::DB db("/tmp/mydb", {.dim = 2048, .distance = LOGOSDB_DIST_L2});

Python

LogosDB ships Python bindings built with pybind11 and scikit-build-core.

Install from PyPI (binary wheels provided for Linux x86_64/aarch64 and macOS x86_64/arm64 on CPython 3.9–3.13):

pip install logosdb

Or build from source in a clone:

pip install .

Usage:

import numpy as np
import logosdb

db = logosdb.DB("/tmp/mydb", dim=128)

v = np.random.randn(128).astype(np.float32)
v /= np.linalg.norm(v)  # Required for default inner-product distance
# Or use logosdb.DIST_COSINE for automatic normalization

rid = db.put(v, text="hello", timestamp="2025-06-25T10:00:00Z")
# rid is the row id for this vector (often 0 for the first insert).
hits = db.search(v, top_k=5)
print(hits[0].text, hits[0].score)

# Replace an existing row: first arg is that row's id (must still be "live").
# update() tombstones the old row and appends a new one; it returns the NEW id.
v2 = np.random.randn(128).astype(np.float32)
v2 /= np.linalg.norm(v2)
new_id = db.update(rid, v2, text="replaced")

# Tombstone a row by id (excluded from search). count() includes deleted rows;
# count_live() does not.
db.delete(new_id)

# After a delete, that id cannot be updated again — insert a fresh row with put().
# zero-copy bulk view over mmap-backed storage (shape: (count, dim), read-only)
vectors = db.raw_vectors()

print(db.count(), db.count_live(), db.dim)

Python: Using cosine distance (no manual normalization needed)

import numpy as np
import logosdb

# With cosine distance, vectors are automatically normalized
db = logosdb.DB("/tmp/mydb", dim=128, distance=logosdb.DIST_COSINE)

# No need to normalize - just put raw vectors
v = np.random.randn(128).astype(np.float32)
rid = db.put(v, text="unnormalized vector", timestamp="2025-04-22T10:00:00Z")

# Search also works with unnormalized queries
query = np.random.randn(128).astype(np.float32)
hits = db.search(query, top_k=5)

Run the Python tests and examples:

pip install ".[test]"
pytest tests/python/

python examples/python/basic_usage.py

# sentence-transformers demo (optional heavy dep)
pip install ".[examples]"
python examples/python/sentence_transformers_demo.py

Memory-Efficient On-Prem RAG

LogosDB is designed for memory-efficient retrieval-augmented generation (RAG) that runs entirely on your hardware.

RAM Model

LogosDB uses mmap() for zero-copy access. Your RAM usage scales with query patterns, not dataset size:

Dataset	Dim	Disk	Typical Query RAM
100K	384	153 MB	<20 MB
1M	384	1.5 GB	<100 MB
10M	384	15 GB	<200 MB

The OS caches hot index pages; cold data stays on disk. No explicit loading/unloading needed.

Quick RAG Example

import numpy as np
import logosdb
from sentence_transformers import SentenceTransformer

# 1. Load model (runs locally)
model = SentenceTransformer("sentence-transformers/all-MiniLM-L6-v2")
dim = model.get_sentence_embedding_dimension()

# 2. Create DB with cosine distance (auto-normalizes)
db = logosdb.DB("/data/knowledge", dim=dim, distance=logosdb.DIST_COSINE)

# 3. Index documents
for text in documents:
    emb = model.encode(text)
    db.put(emb, text=text)  # Auto-normalized with cosine distance

# 4. Query (only touched pages load into RAM)
query_emb = model.encode("What is HNSW?")
for hit in db.search(query_emb, top_k=3):
    print(f"{hit.score:.4f}  {hit.text}")

See docs/rag-on-prem.md for complete guide including:

• Sizing guidelines for your data
• Time-sharding for infinite retention
• External quantization patterns
• Architecture patterns for production

Run the memory-efficient RAG example:

pip install ".[examples]"
python examples/python/memory_efficient_rag.py

Python: LlamaIndex VectorStore

pip install 'logosdb[llama-index]'

from logosdb import LogosDBIndex
from llama_index.core import Document
from llama_index.core.schema import TextNode
from llama_index.core.vector_stores import VectorStoreQuery
import numpy as np

# Create the vector store
db = LogosDBIndex(uri="/tmp/mydb", dim=128)

# Add nodes with pre-computed embeddings
node = TextNode(
    text="My commute is 42 minutes",
    embedding=np.random.randn(128).astype(np.float32).tolist(),
    metadata={"timestamp": "2025-04-28T10:00:00Z"}
)
db.add([node])

# Query
query_emb = np.random.randn(128).astype(np.float32).tolist()
query = VectorStoreQuery(query_embedding=query_emb, similarity_top_k=5)
results = db.query(query)

for node, score in zip(results.nodes, results.similarities):
    print(f"Score: {score:.4f}, Text: {node.text}")

# Timestamp range filtering
results = db.query(query, ts_from="2025-04-01T00:00:00Z", ts_to="2025-04-30T23:59:59Z")

The LogosDBIndex class implements LlamaIndex's VectorStore interface, supporting:

• add(nodes) - Add nodes with embeddings
• delete(node_id) - Delete by node ID
• query(VectorStoreQuery) - Similarity search by vector
• count() / len(store) - Number of live documents
• Timestamp filtering via ts_from and ts_to kwargs

CLI

# Database info
logosdb-cli info /tmp/mydb

# Search with a binary query vector file
logosdb-cli search /tmp/mydb --query-file q.bin --top-k 5

Performance

Here is a performance report from the included logosdb-bench program. The results are somewhat noisy, but should be enough to get a ballpark performance estimate.

Setup

We use databases with 1K, 10K, and 100K vectors. Each vector has 2048 dimensions (matching typical LLM embedding sizes). Vectors are L2-normalized random unit vectors.

LogosDB:    version 0.5.0
CPU:        Apple M-series (ARM64)
Dim:        2048
HNSW M:     16, ef_construction: 200, ef_search: 50

Write performance

put (1K vectors):    ~50 µs/op   (~20,000 inserts/sec)
put (10K vectors):   ~80 µs/op   (~12,500 inserts/sec)
put (100K vectors):  ~120 µs/op  (~8,300 inserts/sec)

Each "op" above corresponds to a write of a single vector + metadata + HNSW index update.

Search performance

HNSW top-5 (1K):     ~0.1 ms/query
HNSW top-5 (10K):    ~0.3 ms/query
HNSW top-5 (100K):   ~1.2 ms/query

Brute-force top-5 (1K):    ~0.3 ms/query
Brute-force top-5 (10K):   ~2.5 ms/query
Brute-force top-5 (100K):  ~25 ms/query

HNSW maintains sub-linear scaling while brute-force grows linearly with database size. At 100K vectors, HNSW is roughly 20x faster.

Benchmark vs ChromaDB

logosdb-bench --dim 2048 --counts 1000,10000,100000

Metric	ChromaDB	LogosDB
Language	Python + C (hnswlib)	Pure C/C++
Search algorithm	HNSW	HNSW (same hnswlib)
Storage	SQLite + Parquet	Binary mmap + JSONL
Startup overhead	Python runtime + deps	Zero (linked library)
Embedding generation	Built-in (Sentence Transformers)	External (caller provides vectors)
Target use case	General-purpose vector store	Embedded LLM inference memory
Search latency (100K, dim=2048)	~5-10 ms	~1-3 ms
Memory footprint (100K, dim=2048)	~1.5 GB (Python + SQLite)	~800 MB (mmap)
Cold start	~2-5 s (Python imports)	<10 ms
Dependencies	Python, NumPy, SQLite, hnswlib	hnswlib (header-only, vendored)

LogosDB uses the same HNSW implementation as ChromaDB (hnswlib) but eliminates Python overhead, SQLite serialization, and Sentence Transformer coupling. The result is a leaner library optimized for the single use case of embedded semantic memory for LLM inference.

Repository contents

include/logosdb/logosdb.h     Public C/C++ API (start here)
src/logosdb.cpp               Core engine: wires storage + index + metadata
src/storage.h / storage.cpp   Fixed-stride binary vector file with mmap
src/metadata.h / metadata.cpp Append-only JSONL text + timestamp store
src/hnsw_index.h / .cpp       Thin wrapper around hnswlib
tools/logosdb-cli.cpp         Command-line interface
tools/logosdb-bench.cpp       Benchmark tool
tests/test_basic.cpp          C++ unit tests
tests/python/test_smoke.py    Python smoke tests (pytest)
python/src/bindings.cpp       pybind11 Python bindings
python/logosdb/               Python package (logosdb._core + stubs)
examples/python/              Python usage examples
pyproject.toml                Python build/config (scikit-build-core)
third_party/hnswlib/          Vendored hnswlib (header-only)
CHANGELOG                     Release history
LICENSE                       MIT license text

License

MIT — see LICENSE for the full text.
