macquerel

A quantum state-vector simulator targeting Apple Silicon's unified-memory architecture.

Features

• CPU backend — pure NumPy reference implementation using the tensordot reshape trick
• MLX backend — Apple Silicon GPU acceleration via MLX, with graceful fallback on other platforms
• Gate fusion compiler — greedy left-to-right fusion of adjacent gates (up to 4 qubits) into composite unitaries
• Gate classification — automatically classifies gates as diagonal, permutation, or dense for optimized dispatch
• Full gate library — I, H, X, Y, Z, S, T, Rx, Ry, Rz, P, CNOT, CZ, SWAP, CP
• Noise channels / density matrices — Kraus-operator channels (bit/phase flip, depolarizing, amplitude/phase damping, arbitrary) on a DensityMatrixSimulator that runs the vectorized density matrix over the same backends

Installation

Requires Python 3.11+.

uv sync

To enable the MLX backend on Apple Silicon:

uv sync --extra mlx

Usage

from macquerel import Circuit, Simulator

# Bell state
circuit = Circuit(2)
circuit.h(0).cx(0, 1).measure_all()

sim = Simulator()               # defaults to CPU backend
counts = sim.run(circuit, shots=1000)
print(counts)  # Counter({'00': ~500, '11': ~500})

# Statevector (no measurement)
circuit = Circuit(2)
circuit.h(0).cx(0, 1)

sv = sim.statevector(circuit)
print(sv)  # [0.707+0j, 0+0j, 0+0j, 0.707+0j]

# Apple Silicon GPU backend
sim = Simulator(backend="mlx")

# Noisy simulation: Kraus channels + density matrix
from macquerel import DensityMatrixSimulator

circuit = Circuit(2)
circuit.h(0).cx(0, 1).depolarizing(0, 0.05).measure_all()

dm = DensityMatrixSimulator()
counts = dm.run(circuit, shots=1000)   # noisy counts with 01/10 leakage
rho = dm.density_matrix(circuit)       # full (2**n, 2**n) density matrix

Available gates

Builders return self for chaining.

Architecture

macquerel/
├── gates.py         # Gate matrices + classify()
├── circuit.py       # Circuit / Gate / MeasureOp dataclasses
├── compiler.py      # Gate fusion (fuse_gates)
├── simulator.py     # Simulator — statevector() and run()
└── backends/
    ├── cpu.py       # NumPy backend
    └── mlx_backend.py  # MLX backend (Apple Silicon)

Running tests

uv run pytest

MLX backend tests are automatically skipped when MLX is not installed.

Benchmarks

Quick smoke run (completes in a few seconds):

uv run python benchmarks/bench_versions.py --versions latest --backends cpu --qubits 6 8 --depth 8 --reps 1

Full benchmark commands:

# Install plotting and framework-comparison dependencies first.
uv sync --extra bench

# On Apple Silicon, include macquerel's optional GPU backends too:
uv sync --extra bench --extra mlx --extra metal

# macquerel CPU/MLX/Metal vs Qiskit Aer and Qulacs
uv run python benchmarks/bench_statevector.py \
  --json benchmarks/data/framework_comparison.json \
  --plot benchmarks/data/framework_comparison.png

# Fusion-width sweep
uv run python benchmarks/bench_fusion_width.py \
  --json benchmarks/data/fusion_width.json \
  --plot benchmarks/data/fusion_width.png

# Released-version regression comparison for CPU/MLX/Metal
uv run python benchmarks/bench_versions.py \
  --versions latest --json benchmarks/data/version_regression.json \
  --plot benchmarks/data/version_regression.png

The framework benchmark prints every backend it discovers at startup. Optional frameworks and Apple-only backends are reported as skipped when they are unavailable. Qulacs currently may need a Python version with a prebuilt wheel, or local C++/Boost build prerequisites.

Requirements

• Python ≥ 3.11
• numpy ≥ 1.24
• mlx ≥ 0.3.0 (optional, Apple Silicon only)
