make-a-gif 0.2.0

Make gifs in python.

make-a-gif

A (very) simple package for generating gifs using matplotlib.

Installation

pip install make-a-gif

or just copy across the make_a_gif.py file to your project.

Usage

For a full suite of examples, see the examples directory - note that make-a-gif works well with Jupyter notebooks.

import matplotlib.pyplot as plt
from make_a_gif import gif


# define a function that generates a plot for a given frame
def plotting_func(i: int) -> None:
    xs = range(i + 1)
    ys = [x**2 for x in xs]
    plt.plot(xs, ys, "-o", clip_on=False, zorder=10)
    # make sure the limits are always the same
    plt.xlim(0, 10)
    plt.ylim(0, 100)


# create the gif
gif(plotting_func, frames=range(11), fps=2, save_to="squared.gif")

Documentation

The only object exported by make-a-gif is the gif function.

gif(
    frames: Iterable[Frame],
    function: Callable[[Frame], None | str | Path | Figure],
    save_to: str | Path | None = None,
    fps: float = 10,
    css: dict[str, str] | None = None,
    savefig_kwargs: dict[str, Any] | None = None,
) -> HTML | None:
    ...

Description:

Generate a GIF from a sequence of frames.

Based on the return type of the function, the following happens:

• None: assume that the currently active matplotlib figure has been contains the desired image. Use this figure for the next frame, and then close the figure.
• str or Path: assume that this points to an image file. This gets used as the next image in the gif.
• plt.Figure: use the current content of the matplotlib figure as the next image in the gif. The figure is not closed.

The function is called for each frame, and the return values are used to generate images for the gif in order. In pseudocode:

images = []

for frame in frames:
    ret = function(frame)
    if isinstance(ret, str | Path):
        images.append(Image.open(ret))
    elif isinstance(ret, Figure):
        images.append(ret.savefig())
    elif ret is None:
        images.append(plt.savefig())

return gif(images)

Parameters:

• frames is an iterable of arbitrary objects. These are passed in order, and one-by-one to the function.
• function takes an arbitrary frame object as input, and generates a single image for the gif. There are several behaviours here, depending on the return type of function:
  • None: assume that a matplotlib plot has been generated. This is then used as the next image in the gif. The figure is closed automatically after each frame.
  • plt.Figure: uses the current content of the figure as the next image in the gif. The figure is not closed.
  • str or Path: assume that this points to an image file. This gets used as the next image in the gif.
• save_to is the path to save the gif to. If not provided, the gif is not saved.
• fps is the frames per second of the gif, by default 10
• css is the CSS to apply to the HTML returned by the function.
• savefig_kwargs are the keyword arguments to pass to plt.savefig when saving the figure to a file. The default is {"bbox_inches": "tight", "transparent": True}.
• loop is the loop mode of the gif:
  • "infinite": loop the gif indefinitely
  • "once": play the gif once
  • "bounce": play the gif forwards and then backwards indefinitely

Returns:

gif returns an IPython.display.HTML object. This contains a base64 encoded version of the gif, and so is independent of the file system - you can e.g. share notebooks that display this object as a standalone file and the gif will still work.
