Manhattan Reasoning Gym

Python SDK and CLI (mrg) for hardware design: iterate locally with fast synthesis / place-and-route feedback, run untrusted agents in a sandbox, and program real cloud FPGAs — all from one package.

Cloud FPGA access requires an allowlisted API key (mrg login). Local synth/PnR and sandboxing need only Docker — no toolchain to install.

Install

pip install manhattan-reasoning-gym

For local synth/PnR and sandboxing, pull the pinned toolchain image once (the SDK runs it for you — you never install yosys/nextpnr/LiteX):

docker pull ghcr.io/manhattanreasoning/mrg-sandbox:latest

If your system Python is broken or externally managed, the robust path is uv venv && uv pip install manhattan-reasoning-gym.

Agent quickstart (headless)

Copy-paste path for coding agents and CI — no browser, no prompts:

export MRG_API_KEY=...        # or: mrg login --github-token <no-scope PAT>
mrg synth examples/design.py  # JSON report on stdout, ~seconds
mrg pnr   examples/design.py  # JSON report (fmax_mhz, timing_met), ~tens of seconds
mrg run   examples/app.py     # programs a real FPGA, ~2-3 min first time
mrg reset 0                   # free the board when done (async, ~1 min)

• All bus addresses are byte addresses: word n in your design's register map is byte address 4*n for app.read/app.write and mrg read/mrg write.
• After mrg run the board stays reserved to you — reuse it with mrg run --no-program / mrg read / mrg write, and release it with mrg reset <fpga_id> when done. Reset is an async queued job that reflashes the base SoC (~1 min); poll mrg status --json rather than expecting instant idle.
• mrg synth / mrg pnr print machine-readable JSON on stdout and exit non-zero when the build fails; mrg status --json, mrg jobs --json, and mrg job --json emit the raw orchestrator response — parse JSON, don't scrape tables. A build in flight has no board yet (see below), so mrg jobs is the only way to find its job_id without already having it.
• Rough time budget: synth seconds · pnr tens of seconds · mrg run ~2-3 min for the first program · --no-program seconds · reset ~1 min.
• mrg login with no flags is an interactive GitHub device flow. Headless, prefer $MRG_API_KEY, or mrg login --github-token <PAT> (also reads $GITHUB_TOKEN) with a no-scope PAT — it's only used to read your username. If you must run the device flow from a non-tty context, relay the printed URL + code to a human.

Local feedback — mrg.build

import manhattan_reasoning_gym as mrg

rep = mrg.build.synth("examples/design.py")   # fast: resource utilization
rep = mrg.build.pnr("examples/design.py")     # full SoC: real Fmax + timing
print(rep.fmax_mhz, rep.timing_met, rep.util.dsp.used)

CLI: mrg synth design.py · mrg pnr design.py [--sys-clk-mhz N] [--timing-target-mhz N] (--sys-clk-mhz re-clocks the SoC; --timing-target-mhz is the constraint PnR optimizes against and timing_met is graded on, defaulting to the sys clock; --target-mhz stays as a legacy alias for both).

synth is the cheap "is it getting bigger?" signal (core-only util); pnr places & routes the full SoC for the truthful system-clock Fmax and timing.

Sandboxed agents — mrg.Sandbox

Run untrusted agent code in a locked container (--network none, no key) that iterates locally and promotes vetted candidates to silicon:

import manhattan_reasoning_gym as mrg

result = mrg.Sandbox(files=["examples/design.py", "examples/agent.py"]).run("agent.py")
for promo in result.promotions:
    print(promo)

The container never holds a key or touches the network; the promote is a file handoff the trusted host brokers to silicon. No promote gating by default — the agent gates itself; pass guard= for an opt-in host-side check. With no API key, silicon resolves to a no-op backend; set one (and silicon="cloud") for real hardware.

Real silicon — mrg.cloud

import manhattan_reasoning_gym as mrg

app = mrg.cloud.App("my_design", design="examples/design.py")
with app:                    # programs the FPGA on first use, releases on exit
    app.write(0x0, 3)        # byte address: word n in the design => 4*n
    print("read:", app.read(0x8))

read/write calls go over one WebSocket that the SDK opens on the first call, reuses for every call after it, and closes after 25 s without a call (the next call reopens it). On a network that blocks WebSockets, use HTTP instead: App(..., transport="http"), MRG_TRANSPORT=http, or --transport http on mrg run / mrg read / mrg write. HTTP works anywhere but is much slower: each call is a queued job (about 0.5 s or more).

Or drive it from the CLI with a file that defines an App and an @app.local_entrypoint() — see examples/app.py, which exercises the example MAC design end-to-end:

mrg run examples/app.py

Name your registers by subclassing mrg.RegisterMap (byte addresses).

Board lifecycle: the with app: form releases the board on exit, but mrg run does not — the reservation persists so you can keep iterating with mrg run --no-program, mrg read, and mrg write. Free the board with mrg reset <fpga_id> (an async job that reflashes the base SoC, ~1 min — poll mrg status).

Authentication (cloud only)

API requests authenticate with an opaque API key sent as X-API-Key. You obtain one by exchanging a GitHub identity — the orchestrator verifies you against its allowlist and mints a key.

mrg login       # GitHub device flow (or paste a no-scope PAT), then you're set

The key is saved to ~/.config/mrg/credentials.json (mode 0600, keyed by orchestrator URL). Every command resolves the key in this order:

1. --api-key flag
2. $MRG_API_KEY
3. the stored login (mrg login)

mrg logout revokes the key on the server and clears it locally.

Tutorials

Two runnable notebooks in examples/notebooks/:

• 01_build_and_run — local synth/pnr feedback → program a real FPGA.
• 02_sandboxing — run an agent in a locked sandbox that promotes to silicon.

The shared examples/design.py is a tiny tunable multiply-accumulate; tweak its WIDTH and watch DSP/Fmax move. examples/agent.py is the sandboxed agent, and examples/app.py is the mrg run app that drives the MAC on real silicon.

CLI reference

mrg login | logout
mrg synth <design.py>                       # local synthesis report
mrg pnr   <design.py> [--sys-clk-mhz N] [--timing-target-mhz N] [--target-mhz N]
                                            # local full-SoC place & route
mrg run   <file.py> [--no-program [--fpga-id N]]   # --fpga-id only meaningful with --no-program:
                                                     # a fresh build is never pinned to a board
mrg status [fpga_id] [--json]
mrg jobs [--status queued|running|complete|failed|cancelled]
         [--type build|run|reset|all] [-n N | --all] [--json]
                                            # default: your 10 most recent builds
mrg job <job_id> [--json]
mrg logs | cancel <job_id>
mrg reset <fpga_id>
mrg read  <fpga_id> <addr> [--count N]
mrg write <fpga_id> <addr> <value>

Human-readable mrg status output includes the server commit from /health. A package built with local changes is marked modified source. Older servers or builds without commit metadata show unknown; an unavailable health endpoint shows unavailable without suppressing board status. mrg status --json keeps its existing board-only output and does not make the extra health request.

Development

pip install -e ".[dev]"
ruff check . && pytest -q

License

MIT — see LICENSE.

Multi-file cloud designs

Provide the top-level design file. The SDK automatically finds local Python imports, Verilog module instances, literal include headers, and literal $readmemh/$readmemb data files under the design's folder:

app = mrg.App("my_design", design="project/design.v")

Discovery follows dependencies recursively and uploads only the files it finds. It reads source text without running your code. Python dependencies already installed on the server, such as Amaranth, are not uploaded or installed again.

Alternatively, provide a directory containing the supporting files:

app = mrg.App(
    "my_design",
    design="project/design.v",
    include_dir="support",
)

include_dir is relative to the design file's folder (or can be absolute). All supported source files in that directory and its subdirectories are uploaded, together with the main design. Use a directory containing only the files needed for the build. Directory contents become the bundle root; a main file outside that directory is placed at the root, while a main file inside it keeps its relative path. For example, use include_dir=".." when a design in project/rtl/top.v needs files elsewhere under project/.

The directory option also works with Python/Amaranth designs and from the CLI: mrg run client.py --include-dir support. Paths are relative to the design, not the client script. Hidden entries, symlink directories, __pycache__, node_modules, build, and dist are not scanned.

For precise control, sources=["rtl/child.v", "include/constants.vh"] replaces automatic discovery and directory collection with that exact file list. Paths are relative to include_dir when supplied, otherwise the design's folder. Repeatable mrg run client.py --source rtl/child.v uses this explicit mode too. sources=[] opts out of discovery. Do not list the main file again.

Automatic discovery supports ordinary static imports and Verilog instances; it is not a full language preprocessor. Dynamic Python imports and generated file names need directory or explicit-file mode. Macro-based Verilog includes request one of those modes. Duplicate module definitions or ambiguous include names require an explicit selection or qualified include path. Missing Verilog modules are still checked by the compiler. Textually included .v files with literal include names are kept out of the separate compilation list.

Supported files: .py, .v, .vh, .mem, .hex. Use simple path names (letters, digits, _, -, ., /); source symlinks and dependencies escaping the selected root are rejected. Bundles are limited to 128 files, 8 MiB compressed and 16 MiB expanded including metadata. Discovery scans at most 4096 directory entries and 16 MiB of source text; choose a smaller directory or an explicit list if necessary. A design without local dependencies keeps the single-file upload format. This requires the matching cloud API/build-image update; local mrg synth/mrg pnr remain single-file commands. See the example.

Status durations

mrg status shows HELD FOR (time since the current reservation began) and JOB AGE (time since submission of the job currently assigned to the board). When logged in, it also lists your queued/running builds, including those with no board yet, with elapsed time and the latest stage when available. That extra lookup has a three-second timeout; a failure does not hide the board table. Anonymous status requests do not fetch private jobs.

Durations are snapshots in HH:MM:SS; run the command again to refresh them. Job age includes queueing, building, and flashing—it is not billable build time. mrg jobs and mrg job also show elapsed time; completed, failed, or cancelled jobs use their last-update timestamp as the end instead of continuing to tick. Older servers/sessions without start timestamps show -, as do invalid dates. Client clock skew can affect active durations; negative values are clamped to zero.

mrg jobs lists your 10 most recent builds by default, with a footer counting what's hidden. Every HTTP app.read()/app.write() is its own run job, so --type all is mostly those. -n N shows more and --all shows everything. --json is always the raw, unfiltered server response. JSON output retains the API response shape without adding computed duration fields.
