maple-oss 1.1.1

Multi Agent Protocol Language Engine - Advanced Multi-Agent Communication Protocol Framework

MAPLE - Multi Agent Protocol Language Engine

Creator: Mahesh Vaijainthymala Krishnamoorthy (Mahesh Vaikri)

The autonomous agentic AI framework with production-grade infrastructure. MAPLE combines LLM-powered autonomous agents with resource-aware messaging, type-safe error handling, cryptographic security, and distributed state — capabilities no other framework offers together.

---

Why MAPLE

Most agent frameworks give you either infrastructure (messaging, security, fault tolerance) or autonomy (LLM reasoning, tool use, memory). MAPLE is the first to provide both in a single, cohesive framework.

	Infrastructure	Autonomy
LangGraph / CrewAI / AutoGen	Basic	Yes
Google A2A / MCP / FIPA ACL	Yes	No
MAPLE	Yes	Yes

What this means in practice: Your autonomous agents get resource negotiation, circuit breakers, cryptographic link security, priority message queuing, distributed state, and fault-tolerant task scheduling — out of the box, not bolted on.

---

Key Features

Autonomous Agentic AI (v1.1.1)

• ReAct Reasoning Loop — Agents think, act, and reflect autonomously. Built-in backtracking when approaches fail.
• Pluggable LLM Providers — OpenAI, Anthropic Claude, or any compatible API (vLLM, Ollama, Together AI).
• Tool Framework — Register custom tools with JSON Schema parameters. Built-in tools for inter-agent communication, state read/write, resource checks, and secure link establishment.
• Three-Tier Memory — Working memory (context window), episodic memory (task history), semantic memory (learned facts). LLM-assisted summarization when context fills up.
• Multi-Agent Orchestration — Form teams by capability, execute via supervisor delegation or consensus voting.
• MCP Tool Discovery — Discover and use tools from any MCP server as native MAPLE tools.
• Observability — Full decision traces, agent snapshots, token usage tracking.

Production Infrastructure

• Result<T,E> Error Handling — Rust-inspired type-safe results. No silent failures, no uncaught exceptions. Chain with .map(), .and_then(), .map_err().
• Resource-Aware Messaging — Agents declare CPU, memory, and bandwidth requirements as first-class protocol features.
• Link Identification Mechanism (LIM) — Cryptographic channel verification using AES-256-GCM between agents.
• Distributed State — Shared state across agents with configurable consistency levels and change listeners.
• Circuit Breakers & Retry — Automatic failure detection, exponential backoff, and circuit breaker patterns.
• Priority Message Queuing — Messages routed by priority with health-aware routing.
• Task Management — Task queue, scheduler (capability matching + load balancing), fault-tolerant execution, result collection with 7 aggregation strategies.
• Agent Discovery — Auto-registration, capability matching, health monitoring, failure detection.
• 10 Protocol Adapters — Native interop with A2A, MCP, FIPA ACL, AutoGen, CrewAI, LangGraph, OpenAI SDK, IBM ACP, S2.dev, n8n.

---

Integrations

MAPLE ships with 10 adapters in maple/adapters/ for bridging to external protocols and frameworks.

Adapter	File	What It Does
Google A2A	a2a_adapter.py	Translate MAPLE messages to/from A2A Agent-to-Agent protocol. Maps MAPLE resources to A2A task metadata, bridges agent discovery via A2A Agent Cards.
Anthropic MCP	mcp_adapter.py	Bridge MCP tool servers into MAPLE. Discover MCP tools and register them as native MAPLE Tool objects. MAPLE agents call MCP tools via the ReAct loop.
FIPA ACL	fipa_acl_adapter.py	Convert MAPLE messages to FIPA Agent Communication Language format. Supports performatives (inform, request, propose) and maps MAPLE priority to FIPA protocol fields.
AutoGen	autogen_adapter.py	Wrap MAPLE agents as AutoGen-compatible participants. Run AutoGen group chats backed by MAPLE's broker, security, and resource management.
CrewAI	crewai_adapter.py	Register MAPLE agents as CrewAI crew members. Map CrewAI tasks to MAPLE's task scheduler with fault tolerance and result collection.
LangGraph	langgraph_adapter.py	Expose MAPLE agents as LangGraph nodes. Run LangGraph state machines over MAPLE's message broker with distributed state sync.
OpenAI SDK	openai_sdk_adapter.py	Make MAPLE agents callable via OpenAI's Assistants/Chat API format. Translates tool calls and function results between OpenAI and MAPLE conventions.
IBM ACP	acp_adapter.py	Bridge to IBM Agent Communication Protocol. Maps MAPLE resource specifications to ACP capabilities and translates message formats.
S2.dev	s2_adapter.py	Durable streaming via s2.dev. S2Broker provides persistent message delivery (per-agent and per-topic streams). S2StateBackend provides append-only state with full audit history. Install: pip install maple-oss[s2]
n8n	n8n-integration/	3 visual workflow nodes (Agent, Coordinator, Resource Manager) for building multi-agent AI pipelines in n8n without code.

All adapters follow MAPLE's Result<T,E> pattern and work with the existing security, resource, and broker infrastructure.

---

Installation

pip install maple-oss

With LLM support (for autonomous agents):

pip install maple-oss[llm]

From source:

git clone https://github.com/maheshvaikri-code/maple-oss.git
cd maple-oss
pip install -e ".[llm]"

All optional dependency groups:

pip install maple-oss[llm]          # OpenAI + Anthropic providers
pip install maple-oss[s2]           # S2.dev durable streaming
pip install maple-oss[security]     # Cryptography + JWT
pip install maple-oss[performance]  # uvloop + orjson + msgpack
pip install maple-oss[dev]          # Testing + linting tools

Verify:

python -c "from maple import Agent, AutonomousAgent, Message, Config; print('MAPLE ready')"

---

Quick Start

1. Basic Agent Communication

from maple import Agent, Message, Priority, Config, SecurityConfig

# Create an agent
config = Config(
    agent_id="worker_agent",
    broker_url="memory://local",
    security=SecurityConfig(
        auth_type="token",
        credentials="secure_token",
        require_links=True
    )
)
agent = Agent(config)
agent.start()

# Send a typed message with Result<T,E>
message = Message(
    message_type="PROCESS_DATA",
    receiver="analysis_agent",
    priority=Priority.HIGH,
    payload={"task": "sentiment_analysis", "data": ["review_1", "review_2"]}
)

result = agent.send(message)
if result.is_ok():
    print(f"Sent: {result.unwrap()}")
else:
    print(f"Failed: {result.unwrap_err()['message']}")

agent.stop()

2. Autonomous Agent with Tools

from maple import (
    Config, AutonomousAgent, AutonomousConfig,
    LLMConfig, Tool, Result,
)

# Define a custom tool
def calculator(expression: str = "") -> Result:
    allowed = set("0123456789+-*/.() ")
    if not all(c in allowed for c in expression):
        return Result.err({"error": "Only basic math allowed"})
    return Result.ok({"result": eval(expression)})

calc_tool = Tool(
    name="calculator",
    description="Evaluate a math expression like '2 + 3 * 4'",
    parameters={
        "type": "object",
        "properties": {
            "expression": {"type": "string", "description": "Math expression"},
        },
        "required": ["expression"],
    },
    handler=calculator,
)

# Create an autonomous agent
agent = AutonomousAgent(
    Config(agent_id="math-agent", broker_url="memory://local"),
    AutonomousConfig(
        llm=LLMConfig(provider="openai", model="gpt-4", api_key="sk-..."),
        max_reasoning_steps=10,
    ),
)
agent.register_tool(calc_tool)

# Pursue a goal — the agent reasons, uses tools, and reflects
result = agent.pursue_goal("What is (15 * 37) + 42?")
if result.is_ok():
    goal = result.unwrap()
    print(f"Answer: {goal.result}")
    print(f"Reasoning steps: {len(goal.reasoning_trace)}")

3. Multi-Agent Team

from maple import Config, AutonomousAgent, AutonomousConfig, LLMConfig
from maple.autonomy.orchestrator import AgentOrchestrator, TeamMember

# Create specialized agents
llm = LLMConfig(provider="openai", model="gpt-4", api_key="sk-...")

supervisor = AutonomousAgent(
    Config(agent_id="supervisor", broker_url="memory://local", capabilities=["planning"]),
    AutonomousConfig(llm=llm),
)
researcher = AutonomousAgent(
    Config(agent_id="researcher", broker_url="memory://local", capabilities=["research"]),
    AutonomousConfig(llm=llm),
)
coder = AutonomousAgent(
    Config(agent_id="coder", broker_url="memory://local", capabilities=["coding"]),
    AutonomousConfig(llm=llm),
)

# Form team and execute
orchestrator = AgentOrchestrator()
team_id = orchestrator.form_team("dev-team", members=[
    TeamMember(agent=supervisor, role="supervisor", capabilities=["planning"]),
    TeamMember(agent=researcher, role="worker", capabilities=["research"]),
    TeamMember(agent=coder, role="worker", capabilities=["coding"]),
]).unwrap()

# Supervisor decomposes goal, assigns sub-tasks to workers
result = orchestrator.execute_supervised(team_id, "Build a data processing pipeline")

4. Result<T,E> Error Handling

from maple import Result

def process_data(data) -> Result:
    if not data:
        return Result.err({
            "errorType": "VALIDATION_ERROR",
            "message": "Empty data",
            "recoverable": True,
        })
    return Result.ok({"processed": len(data), "status": "complete"})

# Chain operations safely — no exceptions, no silent failures
result = (
    process_data(input_data)
    .map(lambda data: enrich(data))
    .and_then(lambda enriched: validate(enriched))
    .map_err(lambda err: log_error(err))
)

5. Resource-Aware Communication

from maple.resources.specification import ResourceRequest, ResourceRange, TimeConstraint

request = ResourceRequest(
    compute=ResourceRange(min=4, preferred=8, max=16),
    memory=ResourceRange(min="8GB", preferred="16GB", max="32GB"),
    bandwidth=ResourceRange(min="100Mbps", preferred="1Gbps"),
    time=TimeConstraint(timeout="120s"),
    priority="HIGH",
)

message = Message(
    message_type="HEAVY_COMPUTATION",
    receiver="compute_agent",
    priority=Priority.HIGH,
    payload={"task": "train_model", "resources": request.to_dict()},
)

6. Secure Links (LIM)

# Establish cryptographically verified communication channel
link_result = agent.establish_link("partner_agent", lifetime_seconds=3600)

if link_result.is_ok():
    link_id = link_result.unwrap()
    secure_msg = Message(
        message_type="SENSITIVE_DATA",
        receiver="partner_agent",
        payload={"data": "confidential"},
    ).with_link(link_id)
    agent.send_with_link(secure_msg, "partner_agent")

7. Distributed State

from maple.state import StateStore, ConsistencyLevel

store = StateStore(consistency=ConsistencyLevel.STRONG)
store.set("mission_status", {"phase": "active", "agents": 5})

result = store.get("mission_status")
if result.is_ok():
    print(result.unwrap())

# Watch for changes
store.add_listener(lambda key, entry: print(f"Changed: {key}"))

8. Pub/Sub and Handlers

# Register message handlers
@agent.handler("TASK_REQUEST")
def handle_task(message):
    print(f"Received task: {message.payload}")
    return Message(
        message_type="TASK_RESULT",
        receiver=message.sender,
        payload={"result": "done"},
    )

# Topic-based pub/sub
agent.subscribe("notifications")

@agent.topic_handler("notifications")
def handle_notification(message):
    print(f"Notification: {message.payload}")

# Publish to topic
agent.publish("notifications", Message(
    message_type="ALERT",
    payload={"level": "info", "text": "System healthy"},
))

---

Architecture

maple/
├── agent/            Agent lifecycle, config, message handlers, auto-registration
├── autonomy/         AutonomousAgent, ReAct loop, tools, memory, orchestrator, observability
├── broker/           Message routing (in-memory + NATS), priority queue, health-aware routing
├── core/             Message, Result<T,E>, type system, serialization
├── communication/    Streaming, pub/sub, request-response patterns
├── discovery/        Agent registry, capability matching, health monitoring, failure detection
├── error/            Circuit breaker, retry with backoff, error types and severity
├── llm/              LLM provider abstraction (OpenAI, Anthropic, compatible APIs)
├── resources/        Resource specification, allocation, negotiation
├── security/         Authentication, authorization, Link ID Mechanism, AES-256-GCM encryption
├── state/            Distributed state store, synchronization, consistency models
├── task_management/  Task queue, scheduler, fault tolerance, result collection, optimization
└── adapters/         A2A, MCP, FIPA ACL, AutoGen, CrewAI, LangGraph, OpenAI SDK, ACP, S2

Autonomy Architecture

┌─────────────────────────────────────────────────────┐
│                  AutonomousAgent                     │
│  ┌──────────┐  ┌──────────┐  ┌──────────────────┐  │
│  │ LLM      │  │ Tool     │  │ Memory           │  │
│  │ Provider  │  │ Registry │  │ (Working/Episodic│  │
│  │ (OpenAI/ │  │ (Custom +│  │  /Semantic)       │  │
│  │ Anthropic)│  │ Built-in)│  │                  │  │
│  └────┬─────┘  └────┬─────┘  └────────┬─────────┘  │
│       │              │                 │             │
│       └──────────────┼─────────────────┘             │
│                      │                               │
│              ┌───────▼───────┐                       │
│              │  ReAct Loop   │                       │
│              │ Think → Act → │                       │
│              │   Reflect     │                       │
│              └───────┬───────┘                       │
│                      │                               │
│  Inherits: Agent (messaging, security, resources)    │
└──────────────────────┼───────────────────────────────┘
                       │
          ┌────────────▼────────────┐
          │   AgentOrchestrator     │
          │  (Supervisor/Consensus) │
          └─────────────────────────┘

---

How MAPLE Compares

Feature	MAPLE	LangGraph	CrewAI	AutoGen	Google A2A	MCP
Autonomous agents (ReAct)	Built-in	Built-in	Built-in	Built-in	No	No
Resource specification in protocol	Built-in	No	No	No	Via payload	No
Result<T,E> error handling	Built-in	No	No	No	No	No
Circuit breakers & fault tolerance	Built-in	No	No	No	No	No
Cryptographic link security (LIM)	Built-in	No	No	No	OAuth	Platform
Distributed state management	Built-in	Checkpointer	No	No	No	No
Agent discovery & health monitoring	Built-in	No	No	No	Agent Cards	No
Priority message queuing	Built-in	No	No	No	No	No
Task scheduling & load balancing	Built-in	No	No	No	No	No
Multi-agent orchestration	Built-in	Built-in	Built-in	Built-in	No	No
Tool framework	Built-in	Built-in	Built-in	Built-in	No	Built-in
Memory system	Built-in	Partial	Partial	No	No	No
MCP tool discovery	Built-in	No	No	No	No	Native
Protocol adapters	9 adapters	No	No	No	No	No

Where MAPLE excels: Production infrastructure + autonomous reasoning in one framework. If your agents need resource awareness, security, fault tolerance, AND autonomous decision-making — MAPLE provides all of these as first-class features.

Where others are stronger: LangGraph has deeper graph-based workflow primitives. CrewAI has simpler role-based setup. A2A and MCP have broader language support and larger ecosystems. AutoGen has mature human-in-the-loop patterns.

---

n8n Integration

MAPLE ships with first-class n8n integration — 3 visual workflow nodes for building multi-agent AI pipelines without code.

Node	Purpose
MAPLE Agent	LLM integration, smart processing, resource-aware execution
MAPLE Coordinator	Workflow orchestration, task distribution, result aggregation
MAPLE Resource Manager	Dynamic allocation, cost optimization, scaling

Pre-built workflows included: AI Research Assistant, Content Creation Pipeline, Customer Service Bot.

See n8n-integration/ for setup and usage.

---

Testing

# Run all tests
python -m pytest tests/ -v

# Run with coverage
python -m pytest tests/ --cov=maple --cov-report=term-missing

# Run specific modules
python -m pytest tests/autonomy/ -v       # Autonomous agent tests
python -m pytest tests/llm/ -v            # LLM provider tests
python -m pytest tests/discovery/ -v      # Discovery tests
python -m pytest tests/task_management/ -v # Task management tests
python -m pytest tests/security/ -v       # Security tests
python -m pytest tests/broker/ -v         # Broker tests

Current status: 818 tests passing, 80% code coverage.

---

Examples

Example	Description
examples/hello_autonomous_agent.py	Create an autonomous agent with custom tools, pursue a goal using ReAct
examples/multi_agent_team.py	Form a team with supervisor + workers, execute goals, share memory
example/helloworld.py	Basic agent communication hello world
demo_package/	Full demo suite with web dashboard and benchmarks
demo/adapters_demo/	Protocol adapter performance comparison
demo/autogen/	AutoGen integration multi-agent coding team

---

Documentation

• Getting Started — Installation and first steps
• API Reference — Complete API documentation
• Type System — MAPLE's rich type system
• Protocol Specification — Formal protocol definition
• Protocol Comparison — Detailed comparison with A2A, MCP, FIPA ACL
• Result<T,E> Details — Deep dive into type-safe error handling
• Best Practices — Production deployment guidelines
• Industry Applications — Real-world use cases
• Troubleshooting — Common issues and solutions
• Changelog — Version history

---

Project Structure

maple-oss/
├── maple/                   Core framework (70 Python modules)
│   ├── agent/               Agent lifecycle and configuration
│   ├── autonomy/            Autonomous agent, tools, memory, orchestrator
│   ├── broker/              Message routing and delivery
│   ├── core/                Message, Result<T,E>, types, serialization
│   ├── communication/       Streaming, pub/sub, request-response
│   ├── discovery/           Registry, capability matching, health monitoring
│   ├── error/               Circuit breaker, retry, error types
│   ├── llm/                 LLM provider abstraction layer
│   ├── resources/           Resource specification and negotiation
│   ├── security/            Auth, encryption, Link ID Mechanism
│   ├── state/               Distributed state management
│   ├── task_management/     Scheduling, fault tolerance, optimization
│   └── adapters/            9 protocol adapters
├── tests/                   818 tests across all modules
├── docs/                    Comprehensive documentation
├── examples/                Autonomous agent and team examples
├── demo_package/            Interactive demos and web dashboard
├── n8n-integration/         Visual workflow nodes for n8n
├── pyproject.toml           Package configuration
├── setup.py                 Legacy setup script
└── VERSION                  Current version (1.1.1)

---

Contributing

git clone https://github.com/maheshvaikri-code/maple-oss.git
cd maple-oss
pip install -e ".[dev,llm]"
python -m pytest tests/ -v

Contributions welcome in:

• Core protocol and infrastructure enhancements
• LLM provider implementations (Gemini, Mistral, Cohere, etc.)
• Tool ecosystem expansion
• Adapter implementations for new protocols
• Test coverage expansion
• Documentation improvements

---

License

MAPLE - Multi Agent Protocol Language Engine Copyright (C) 2025 Mahesh Vaijainthymala Krishnamoorthy (Mahesh Vaikri)

Licensed under the GNU Affero General Public License v3.0 (AGPL-3.0).

• Free to use, study, modify, and share
• Derivative works must remain open source
• Network use requires source disclosure

See LICENSE for complete terms.

---

MAPLE - Multi Agent Protocol Language Engine Creator: Mahesh Vaijainthymala Krishnamoorthy (Mahesh Vaikri)

• Email: [e-mail]
• GitHub: github.com/maheshvaikri-code/maple-oss
• Issues: Report bugs or request features
• Website: mapleagent.org
