matcalc 0.4.1

Calculators for materials properties from the potential energy surface.

Introduction

MatCalc is a Python library for calculating and benchmarking material properties from the potential energy surface (PES). The PES can come from DFT or, more commonly, from machine learning interatomic potentials (MLIPs).

Calculating material properties often requires involved setups of various simulation codes. The goal of MatCalc is to provide a simplified, consistent interface to access these properties with any parameterization of the PES.

MatCalc is part of the MatML ecosystem, which includes the MatGL (Materials Graph Library) and MAML (MAterials Machine Learning) packages, the MatPES (Materials Potential Energy Surface) dataset, and the MatCalc (Materials Calculator).

Documentation

The API documentation and tutorials are available at https://matcalc.ai.

Outline

The main base class in MatCalc is PropCalc (property calculator). All PropCalc subclasses should implement a calc(pymatgen.Structure | ase.Atoms | dict) -> dict method that returns a dictionary of properties.

In general, PropCalc should be initialized with an ML model or ASE calculator, which is then used by either ASE, LAMMPS or some other simulation code to perform calculations of properties. The matcalc.PESCalculator class provides easy access to many foundation potentials (FPs) as well as an interface to MAML for custom MLIPs such as MTP, NNP, GAP, etc.

Basic Usage

MatCalc provides convenient methods to quickly compute properties, using a minimal amount of code. The following is an example of a computation of the elastic constants of Si using the TensorNet-MatPES-PBE-v2025.1-PES universal MLIP.

import matcalc as mtc
from pymatgen.ext.matproj import MPRester

mpr = MPRester()
si = mpr.get_structure_by_material_id("mp-149")
c = mtc.ElasticityCalc("TensorNet-MatPES-PBE-v2025.1-PES", relax_structure=True)
props = c.calc(si)
print(f"K_VRH = {props['bulk_modulus_vrh'] * 160.2176621} GPa")

The calculated K_VRH is about 102 GPa, in reasonably good agreement with the experimental and DFT values.

You can easily access a list of universal calculators (not comprehensive) using the UNIVERSAL_CALCULATORS enum.

print(mtc.UNIVERSAL_CALCULATORS)

While we generally recommend users to specify exactly the model they would like to use, MatCalc provides useful (case-insensitive) aliases to our recommended models for PBE and r2SCAN predictions. These can be loaded using:

import matcalc as mtc
pbe_calculator = mtc.load_fp("pbe")
r2scan_calculator = mtc.load_fp("r2scan")

At the time of writing, these are the TensorNet-MatPES-v2025.1 models for these functionals. However, these recommendations may updated as improved models become available.

MatCalc also supports trivial parallelization using joblib via the calc_many method.

structures = [si] * 20

def serial_calc():
    return [c.calc(s) for s in structures]

def parallel_calc():
    # n_jobs = -1 uses all processors available.
    return list(c.calc_many(structures, n_jobs=-1))

%timeit -n 5 -r 1 serial_calc()
# Output is 8.7 s ± 0 ns per loop (mean ± std. dev. of 1 run, 5 loops each)

%timeit -n 5 -r 1 parallel_calc()
# Output is 2.08 s ± 0 ns per loop (mean ± std. dev. of 1 run, 5 loops each)
# This was run on 10 CPUs on a Mac.

MatCalc also supports chaining of PropCalc. Typically, you will start with a relaxation calc, followed by a series of other calculators to get the properties you need. For example, the following snippet performs a relaxation, followed by an energetics calculation and then an elasticity calculation. The final results contain all properties computed by all steps. Note that the relax_structure should be set to False in later PropCalc to ensure that you do not redo the relatively expensive relaxation.

import matcalc as mtc
import numpy as np
calculator = mtc.load_fp("pbe")
relax_calc = mtc.RelaxCalc(
    calculator,
    optimizer="FIRE",
    relax_atoms=True,
    relax_cell=True,
)
energetics_calc = mtc.EnergeticsCalc(
    calculator,
    relax_structure=False  # Since we are chaining, we do not need to relax structure in later steps.
)
elast_calc = mtc.ElasticityCalc(
    calculator,
    fmax=0.1,
    norm_strains=list(np.linspace(-0.004, 0.004, num=4)),
    shear_strains=list(np.linspace(-0.004, 0.004, num=4)),
    use_equilibrium=True,
    relax_structure=False,  # Since we are chaining, we do not need to relax structure in later steps.
    relax_deformed_structures=True,
)
prop_calc = mtc.ChainedCalc([relax_calc, energetics_calc, elast_calc])
results = prop_calc.calc(structure)

Chaining can also be used with the calc_many method, with parallelization.

CLI tool

A CLI tool provides a means to use FPs to obtain properties for any structure. Example usage:

matcalc calc -p ElasticityCalc -s Li2O.cif

Benchmarking

MatCalc makes it easy to perform a large number of calculations rapidly. With the release of MatPES, we have released the MatCalc-Benchmark.

For example, the following code can be used to run the ElasticityBenchmark on TensorNet-MatPES-PBE-v2025.1-PES FP.

import matcalc as mtc

calculator = mtc.load_fp("TensorNet-MatPES-PBE-v2025.1-PES")
benchmark = mtc.benchmark.ElasticityBenchmark(fmax=0.05, relax_structure=True)
results = benchmark.run(calculator, "TensorNet-MatPES")

The entire run takes ~ 16mins when parallelized over 10 CPUs on a Mac.

You can even run entire suites of benchmarks on multiple models, as follows:

import matcalc as mtc

tensornet = mtc.load_fp("TensorNet-MatPES-PBE-v2025.1-PES")
m3gnet = mtc.load_fp("M3GNet-MatPES-PBE-v2025.1-PES")

elasticity_benchmark = mtc.benchmark.ElasticityBenchmark(fmax=0.5, relax_structure=True)
phonon_benchmark = mtc.benchmark.PhononBenchmark(write_phonon=False)
suite = mtc.benchmark.BenchmarkSuite(benchmarks=[elasticity_benchmark, phonon_benchmark])
results = suite.run({"M3GNet": m3gnet, "TensorNet": tensornet})
results.to_csv("benchmark_results.csv")

These will usually take a long time to run. Running on HPC resources is recommended. Please set n_samples when initializing the benchmark to limit the number of calculations to do some testing before running the full benchmark.

Docker Images

Docker images with MatCalc and LAMMPS support are available at the Materials Virtual Lab Docker Repository.

Citing

A manuscript on matcalc is currently in the works. In the meantime, please see citation.cff or the GitHub sidebar for a BibTeX and APA citation.
