matid 2.1.6

MatID is a Python package for identifying and analyzing atomistic systems based on their structure.

MatID is a Python package for identifying and analyzing atomistic systems based on their structure.

Documentation

For more details and tutorials, visit the documentation at: https://nomad-coe.github.io/matid/

You can find even more details in the following open-access articles:

• Automated identification of bulk structures, two-dimensional materials, and interfaces using symmetry-based clustering
• Materials structure genealogy and high-throughput topological classification of surfaces and 2D materials

Example: Surface detection and analysis

import ase.io
from ase.visualize import view

from matid.clustering import SBC
from matid.symmetry import SymmetryAnalyzer

# Load structure from a file
system = ase.io.read('data/system.xyz')

# Find interesting substructures using Symmetry-based Clustering (SBC)
sbc = SBC()
clusters = sbc.get_clusters(system)

# Analyze each found cluster printing out the indices of the atoms belonging to
# this cluster and visualizing the conventional cell from which the cluster was
# built from.
for cluster in clusters:

    # Get the indices of the atoms belonging to this cluster
    indices = cluster.indices
    print(indices)

    # Get the dimensionality of the cluster
    dimensionality = cluster.get_dimensionality()
    print(dimensionality)

    # Get the cell from which the cluster is constructed from. The periodicity
    # of this cell indicates in which directions the unit cell has been found to
    # be repeated in (at least once, possibly infinitely).
    cell = cluster.get_cell()
    n_repeated_directions = sum(cell.get_pbc())
    print(n_repeated_directions)

    # Analyze some symmetry properties of the underlying cell to better identify
    # the material from which the cluster has been constructed from.
    analyzer = SymmetryAnalyzer(cell, symmetry_tol=0.5)
    conv_sys = analyzer.get_conventional_system()
    view(conv_sys)

Installation

pip

pip install matid

From source

git clone https://github.com/nomad-coe/matid.git
cd matid
pip install .
