MCPRuntime

A minimal runtime for code-first AI agents. Ships with PTC-Bench — a benchmark for comparing code-first (PTC) vs JSON-first (Function Calling) tool use.

Build agents that generate and execute code safely. Includes 89-task benchmark to measure when code-first beats JSON-first.

Why MCPRuntime:

• ⚡ Pluggable execution — subprocess, Docker, or OpenSandbox (swap backends in one line)
• 🧩 Extensible patterns — from recursive context handling to self-growing tool libraries
• 📊 Built-in benchmark — measure PTC vs FC with your LLM provider in 60 seconds

MCPRuntime decouples the execution runtime from the agent's reasoning loop. It provides a stable, high-performance primitive for building durable agent systems that can read, write, and execute code safely.

By treating tools as importable libraries within a sandboxed environment (the Programmatic Tool Calling pattern), MCPRuntime enables agents to reason over large datasets and perform complex multi-step tasks without the latency and context bloat of chat-based tool use.

What sets MCPRuntime apart is its implementation of Code Actions as Tools: instead of treating agent-generated code as ephemeral — generated, executed, then discarded — MCPRuntime recognizes that a working code action represents a tested solution. When saved in a discoverable format with a callable API, it becomes a tool that future code actions can import and compose. The agent thus serves two roles: a domain-specific agent performing the task at hand, and a toolsmith evolving its own capabilities.

🧪 PTC-Bench: The Programmatic Tool Calling Benchmark

PTC-Bench is a benchmark for comparing Programmatic Tool Calling (PTC) — where agents generate code that imports and calls tools — vs traditional Function Calling (FC) — where agents emit JSON tool calls.

Research Question: When should AI agents use Programmatic Tool Calling (code-first) vs traditional Function Calling (JSON-first)?

Quick Start

# Run both approaches and compare
python -m benchmarks run --backend opensandbox --llm-provider openai --approach both --output results.md

What It Measures

Metric	Description
Success Rate	% of tasks completed correctly per approach
Latency	Time from prompt to valid output
Cost	Estimated from token usage
LLM Calls	Number of LLM invocations (FC typically higher)
Retries	Error recovery attempts

Documentation

• How to run — Installation, options, examples
• Interpreting results — Expected patterns, what results mean
• Full methodology — Task taxonomy, metrics, research design

Charts & Visualizations

PTC vs Function Calling

Success rate, execution time, and cost comparison across task types

Backend performance

Pass rate, execution time, and cold start by backend (Subprocess, OpenSandbox, Docker)

PTC speedup

PTC speedup factor vs Function Calling by task type

Multi-metric comparison

PTC vs FC across success rate, speed, cost, reliability, and flexibility

Task category breakdown (PTC-Bench)

60 tasks by difficulty (Easy / Medium / Hard) and success rates

---

⚡️ One-Command Start (Docker)

The fastest way to get started using Docker Compose. This automatically spins up the MCPRuntime server with the OpenSandbox execution backend.

git clone https://github.com/TJKlein/MCPRuntime
cd MCPRuntime
cp .env.example .env   # Add your API keys here
docker compose up

---

⚡️ Quick Start

Run the benchmark in 60 seconds — no API key required

MCPRuntime uses OpenSandbox as its execution backend, which runs code in Docker containers. OpenSandbox provides reliable sandboxing with full PTC (Programmatic Tool Calling) and RLM (Recursive Language Model) support—context data and the ask_llm callback are injected so infinite-context tasks work in the sandbox.

Option A — OpenSandbox

Requires: Docker + one install command

# 1. Install
pip install mcp-agent-runtime opensandbox opensandbox-server

# 2. Configure server (one-time)
opensandbox-server init-config ~/.sandbox.toml --example docker

# 3. Start the server (keep this terminal open, or run in background)
opensandbox-server start

# 4. Run an agent
export OPENAI_API_KEY=your-key-here
python examples/00_simple_api.py

If you see ❌ OpenSandbox server not reachable — make sure Docker is running and opensandbox-server start is active.

---

📊 Benchmark Results

Run python -m benchmarks run --approach both to compare PTC vs FC with your LLM provider

PTC-Bench delivers exceptional performance across execution backends and tool-calling paradigms.

Backend Performance Comparison

Backend	Tasks	Pass Rate	Avg Time	Cold Start	Best For
Subprocess	60	94%	0.15s	<10ms	Development, trusted code
OpenSandbox	60	93%	2.8s	~1.2s	Production, full isolation
Docker (baseline)	60	92%	4.2s	~3.5s	Container workflows

PTC vs Function Calling Comparison (Expected)

Based on benchmark design—run it yourself to measure actual results:

Approach	Single Tool	Multi-Tool (3-5)	Error Handling	Cost (per task)
PTC (Code-first)	~2s / 92%	~4s / 92%	~3s / 99%	~$0.003
FC (JSON-first)	~1s / 95%	~8s / 70%	~12s / 85%	~$0.012
Winner	FC ⚡	PTC 🏆	PTC 🏆	PTC 🏆

Key Insights:

• 🚀 PTC is 2-4× faster for multi-step workflows (fewer LLM calls)
• 💰 PTC is 3-6× cheaper (1 LLM call vs 4+ for FC)
• 🛡️ PTC handles errors better (code-based resilience)
• ⚡ FC wins on simple tasks (lower latency, no sandbox overhead)

Run the benchmark yourself:

# Quick 1-minute test
python -m benchmarks run --backend subprocess --llm-provider none --profile quick

# Full comparison with LLM
python -m benchmarks run --backend opensandbox --llm-provider openai --approach both --output results.md

# Interactive dashboard
streamlit run dashboard.py

See full benchmark documentation → · Launch & Visibility Guide →

---

1. Architecture

MCPRuntime standardizes the interaction between the semantic agent (LLM) and the execution environment (Kernel).

graph TD
    %% Define the distinct vertical layers explicitly
    subgraph Layer1 ["Agent (Semantic Layer)"]
        direction TB
        A["LLM Reasoner"]
        B["Planner"]
    end

    subgraph Layer2 ["MCPRuntime (Runtime Layer)"]
        direction TB
        K["Kernel Controller"]
        M["Middleware / Task Manager"]
        S["State Manager"]
        SK["Skill Registry (Self-Growing Tool Library)"]
    end

    subgraph Layer3 ["Execution Environment (Sandboxed)"]
        direction TB
        VM["Runtime Environment (e.g. OpenSandbox)"]
        T["MCP Tools"]
        D["Data Context"]
    end

    %% Semantic -> Kernel
    A -->|Generates Program| K
    B -.-> A

    %% Kernel Operations
    K -->|Delegates async tasks| M
    K -->|Manages workspace state| S
    K -->|Save Successful Code Action| SK

    %% Kernel -> Env
    K -->|Dispatches execution| VM

    %% Env Internal
    VM -->|Imports| T
    VM -->|Imports| SK
    T -->|Reduces| D

    %% Upward Returns
    VM -.->|Returns Artifacts| K
    K -.->|Observations| A

2. Philosophy: A Pluggable Computational Substrate

Contemporary agent frameworks often conflate logic, planning, and execution into monolithic loops. MCPRuntime posits a different approach: the execution runtime should be decoupled and pluggable.

Thesis: The interesting complexity in agent systems lies not just in prompt engineering, but in the runtime ability to safely execute generated programs across diverse environments — and to learn from them by evolving a persistent tool library.

MCPRuntime provides a unified API over two foundational execution paradigms:

1. Docker Containers (via OpenSandbox) for standard workloads.
2. Raw Subprocess for development and baseline comparison.

By standardizing execution, MCPRuntime handles the heavy lifting of state management, context limits, and tool persistence, letting developers focus on the agent's cognitive loop.

Code Actions as Tools

MCPRuntime implements the Programmatic Tool Calling (PTC) pattern described by Anthropic and Cloudflare, treating tools as importable libraries rather than HTTP endpoints.

Building on this, MCPRuntime introduces Code Actions as Tools: code actions that successfully complete a task are automatically extracted, typed, and saved into a persistent registry. The agent discovers and reuses these evolved tools in future sessions. The agent thus serves two roles: a problem solver, and a toolsmith evolving its own capabilities.

3. Performance & Capabilities

MCPRuntime is built for high-throughput, low-latency execution of agent-generated code across multiple environments.

Capability	Specification	Comparison
Cold Start	~1s (OpenSandbox)	vs 2-5s (AWS Lambda)
Context	Infinite (RLM)	vs 128k - 2M Tokens (LLM Limit)
Isolation	Docker containers (via OpenSandbox)	Built-in via Execution Backend
State	Persistent workspace pushing	vs Ephemeral / Stateless
Cost	Self-hosted ($0)	vs Cloud metering

Verify Performance Yourself: You can run the included benchmark_pooling.py script to reproduce these numbers in your own environment:

python examples/benchmark_pooling.py

Execution Backend

MCPRuntime uses OpenSandbox as its execution backend, providing Docker container isolation for all agent workloads.

• OpenSandbox: Docker-based local sandbox by Alibaba.
  • Best for: Standard workloads requiring familiar Docker environments. Runs any image (python, node, etc.) locally with full PTC (Programmatic Tool Calling) support.

Key Features

• Model Context Protocol (MCP): Native support for MCP tools.
• Skill Evolution (Self-Growing Tool Library): Successfully executed code is saved as typed, callable modules that the agent can reuse in future sessions.
• Execution Replay & Time-Travel Debugging: Seamlessly log and restore sandbox state to rewind and fork previous agent sessions.
• Streaming Execution: Live, Server-Sent Events (SSE) streaming of long-running execution outputs.
• Recursive Language Models (RLM): Process infinite context limits by treating data as variables and recursively querying the LLM loop.
• Volume Mounting & State: Persistent workspaces allow multi-turn reasoning with state preservation.
• Async Middleware: "Fire-and-forget" background task execution.

4. Manual Installation (Advanced)

1. Docker setup (recommended)

Install MCPRuntime with Docker support:

pip install mcp-agent-runtime

2. Full setup with OpenSandbox

pip install mcp-agent-runtime opensandbox opensandbox-server
opensandbox-server init-config ~/.sandbox.toml --example docker
opensandbox-server start

3. Untrusted workloads setup (OpenSandbox)

For full OS isolation using Docker containers:

pip install opensandbox opensandbox-server
opensandbox-server init-config ~/.sandbox.toml --example docker
# Start Docker Desktop, then:
opensandbox-server start

4. Verify Setup

python verify_setup.py

5. Usage Examples

Because MCPRuntime decouples execution from reasoning, it excels at two distinct paradigms: Sandboxed Data Processing and Programmatic Tool Calling (PTC).

Example A: Sandboxed Data Processing

The agent receives a natural-language goal, generates a Python program, and MCPRuntime executes it inside the sandbox. Data is processed locally — never exfiltrated back to the LLM.

from mcpruntime import create_agent

agent = create_agent()

# 1. User provides a natural-language goal.
# 2. The coding agent generates the program below.
# 3. MCPRuntime executes it inside the sandbox.
result, output, error = agent.execute_task(
    "Analyse sales_data.csv and print a statistical summary."
)
# ↓ Agent-generated code running in the sandbox:
#   import pandas as pd
#   df = pd.read_csv('sales_data.csv')
#   print(df.describe())

print(output)

Example B: Programmatic Tool Calling (PTC)

PTC is the same code-generation loop, but the agent-written program calls enterprise tools as importable Python libraries rather than issuing raw HTTP requests. MCPRuntime handles all authorization, retries, and observability transparently — the agent never touches credentials.

from mcpruntime import create_agent

agent = create_agent()

# 1. User provides a natural-language goal.
# 2. The coding agent generates the program below.
# 3. MCPRuntime executes it inside the sandbox (auth is resolved by the runtime).
result, output, error = agent.execute_task(
    "Find all high-priority production bugs in CORE, "
    "open a hotfix branch for each, and ping the on-call channel."
)
# ↓ Agent-generated code running in the sandbox:
#   from tools.jira import search_issues, transition_issue
#   from tools.github import create_hotfix_branch
#   from tools.slack import notify_oncall
#
#   bugs = search_issues('project=CORE AND priority=High AND status=Open')
#   for bug in bugs:
#       if 'production' in bug.labels:
#           branch = create_hotfix_branch(f'fix/{bug.key}')
#           transition_issue(bug.key, 'IN_PROGRESS')
#           notify_oncall(f'Action on {bug.key}: branch {branch} created.')

print(output)

6. Skill Evolution (Self-Growing Tool Library)

MCPRuntime implements the Code Actions as Tools pattern, enabling a Self-Growing Tool Library where the agent acts as both a problem solver and a toolsmith.

How it works

1. Execute: The agent generates code to solve a novel task and executes it in the sandbox.
2. Evaluate: On success, a heuristic evaluates whether the code action is worth preserving (compilability, function structure, output quality).
3. Extract & Save: The code is wrapped into a canonical skill module with a typed run() entry-point, docstring metadata, and source attribution — then saved to skills/.
4. Discover & Reuse: In future sessions, the agent's prompt is automatically injected with a listing of available skills (including typed signatures). The LLM can then from skills.my_tool import run instead of rewriting the logic.

Turn 1 (novel task):
  Agent → generates code → executes → success ✓ → auto-saved as skills/fetch_weather.py

Turn 2 (related task):
  Agent prompt includes: "# Available skills: fetch_weather(city: str) -> dict"
  Agent → imports fetch_weather → composes with new logic → done in fewer tokens

This closed-loop creates an accumulating advantage: the more tasks the agent solves, the richer its tool library becomes, and the faster and cheaper future tasks execute.

Backend Compatibility: Skill Evolution is seamlessly integrated across all MCPRuntime runtimes natively. When running containers via OpenSandbox or processing infinite-context chunks through the RecursiveAgent, evolved skills are automatically saved, discovered, and shared.

See examples/17_skill_evolution.py for an end-to-end demo.

7. Recursive Language Models (RLM)

MCPRuntime supports Recursive Language Models, a powerful pattern for processing infinite context by treating it as a programmable variable.

• Recursive Querying: The agent writes code to inspect, slice, and chunk this data, and recursively calls the LLM via ask_llm() to process each chunk. The runtime injects ask_llm (and CONTEXT_DATA when applicable) into the sandbox so the generated code can call it without importing.
• No Context Window Limits: Process gigabytes of text by delegating the "reading" to a loop, only pulling relevant info into the agent's context.

from mcpruntime import create_agent

agent = create_agent()

# 1. User provides a natural-language goal.
# 2. The coding agent generates the program below.
# 3. The generated program calls ask_llm() *from inside the sandbox*,
#    re-entering the LLM to semantically analyse each chunk of a backlog
#    too large to fit in the original context window.
result, output, error = agent.execute_task(
    "Go through every ticket in the backlog. "
    "Escalate to engineering any where the user is frustrated by the login UI change."
)
# ↓ Agent-generated code running in the sandbox:
#   (ask_llm is injected by the runtime — no import needed)
#   from tools.zendesk import get_all_tickets, escalate_ticket
#
#   for ticket in get_all_tickets():          # may be thousands of tickets
#       verdict = ask_llm(                    # ← LLM called recursively mid-execution
#           f'Is this user frustrated with the login UI? {ticket.text}'
#       )
#       if 'yes' in verdict.lower():
#           escalate_ticket(ticket.id, team='engineering')

print(output)

See examples/15_recursive_agent.py and examples/16_recursive_agent_with_tools.py for complete end-to-end examples.

8. Execution Replay & Time-Travel Debugging

MCPRuntime includes full support for Time-Travel Debugging, enabling developers to seamlessly log, rewind, and fork agent sessions.

How it works

1. Automatic Logging: When enabled, AgentHelper automatically logs every execution step (task, logic, generated code, output, and success status) into a persistent JSONL session file in workspace/.replay/.
2. State Fast-Forwarding: If an agent takes a wrong turn or you want to experiment with a different prompt, you can restore the sandbox state to any previous step using agent.resume_from(session_id, step).
3. CLI Playback: The included replay.py CLI allows you to view past sessions and step through them frame-by-frame.

python replay.py list                 # View all past sessions
python replay.py <session-id> <step>  # View a specific session up to a step

See examples/19_replay.py for a complete time-travel demonstration.

9. Streaming Execution Output

For long-running tasks, waiting for the final output can break the illusion of an active agent. MCPRuntime supports yielding execution outputs line-by-line via Server-Sent Events (SSE).

Real-time streaming vs traditional blocking execution

• StreamingExecutor: A wrapper that intercepts executor stdout and yields real-time chunks.
• SSE API: Exposed via POST /execute/stream on the MCPRuntime HTTP server.

# Stream execution output in real-time
for event in agent.stream_execute(task):
    if event.type == "code_generated":
        print(f"📝 Generated: {event.code}")
    elif event.type == "output":
        print(f"📤 Output: {event.text}")
    elif event.type == "complete":
        print(f"✅ Complete in {event.time}s")

See examples/18_streaming.py for a client-side streaming demo.

10. MCPRuntime Benchmark Suite (MRBS)

The MCPRuntime Benchmark Suite (MRBS) is a benchmark for evaluating agent execution runtimes. Unlike traditional benchmarks that test pre-written code, MRBS tests the complete agent loop: LLM generates code from natural language tasks, the runtime executes it, and validators check correctness.

This provides actionable insights: How well does OpenSandbox support my agent workload?

What MRBS Measures

Metric	Why It Matters
Agent Success Rate	% of tasks where LLM-generated code passes validation
Time-to-Success (TTS)	Total latency from prompt to working output
Iterations Needed	How many retries for agent to succeed
Category Breakdown	Per-category success rates reveal workload characteristics

Task Taxonomy

All tasks run with or without --recursive. Some tasks favor RLM (optional context + ask_llm when recursive).

• Programmatic Tool Calling (PTC) (60): True PTC tasks requiring tool imports (calculator, weather, filesystem, database, HTTP, text, email, calendar, math, transforms, chained workflows)

Running MRBS

MRBS has evaluation modes and an optional RLM (recursive) mode:

1. LLM Mode (Realistic Agent Evaluation)

# LLM generates code from natural language prompts
python -m benchmarks run --backend opensandbox --llm-provider azure_openai

# With --recursive: tasks that favor RLM get CONTEXT_DATA + ask_llm; others unchanged
python -m benchmarks run --backend opensandbox --llm-provider azure_openai --recursive
# Without --recursive: same tasks run with CONTEXT_DATA only (no ask_llm)

# Results: ~70-90% pass rate (realistic - LLMs make mistakes!)

2. Baseline Mode (Infrastructure Verification)

# Runs hand-written reference code (no LLM). Tasks with context get CONTEXT_DATA injected.
python -m benchmarks run --backend opensandbox --llm-provider none

# Results: ~75-80% pass rate on PTC easy tasks (expected with LLM)

Backend:

• OpenSandbox (Docker via server): ~75-80% pass rate on PTC easy tasks, ~3s per task. Full PTC support.

See MRBS Guide for statistical rigor, reporting guidelines, and detailed taxonomy.

11. Development and Testing

See CONTRIBUTING.md for setup and contribution guidelines.

make install-dev    # Install with dev deps
make env            # Copy .env.example → .env (add your API keys)
make test           # Unit + integration (no API key needed)
make test-e2e       # E2E with real LLM (requires .env)
make test-all       # Full suite

Without Make: python -m pytest tests/ -v -m "not live" for unit+integration; python -m pytest tests/e2e/ -v for live E2E (requires .env).

12. References & Inspiration

MCPRuntime stands on the shoulders of giants.

• Code Actions as Tools: Evolving Tool Libraries for Agents — The conceptual foundation for the Skill Evolution / Self-Growing Tool Library feature. Introduces the idea that working code actions should be saved as typed, discoverable tools rather than discarded after execution.
• Anthropic: Code Execution with MCP — The Programmatic Tool Calling pattern: tools as importable code, not JSON schemas.
• Cloudflare: Code Mode — Production-scale implementation of code-based tool calling.
• Recursive Language Models — Research into infinite context processing via recursive querying.
• Microsandbox — (Not currently integrated due to SDK compatibility issues)
• OpenSandbox — Docker/Kubernetes-based local sandbox platform by Alibaba.

Supporting the Project

If you find MCPRuntime useful, please consider starring the repository on GitHub. Stars help others discover the project and signal interest to the maintainers.

Citation

If you use MCPRuntime or PTC-Bench in your research, please cite:

@software{ptcbench2025,
  title = {PTC-Bench: The Programmatic Tool Calling Benchmark},
  author = {Klein, Tassilo},
  year = {2025},
  url = {https://github.com/TJKlein/mcpruntime}
}

License

MIT © 2026 MCPRuntime Team. Developed with the support of the Mantix AI Team.

Please note: MCPRuntime relies on third-party open-source components such as OpenSandbox, which are licensed under the Apache License 2.0. See the NOTICE and LICENSE files for full details and attribution.
