mdit-py-figure 1.1.0

markdown-it-py plugin to convert image paragraphs to HTML figure elements

mdit-py-figure

mdit-py-figure is a markdown-it-py plugin to parse markdown paragraphs that start with an image into HTML <figure> elements. One nice thing is it doesn't use any new markdown syntaxes.

Example markdown source:

![Picture of Oscar.](/path/to/cat.jpg)
Awesome caption about **Oscar** the kitty.

Render result:

<figure>
<img src="/path/to/cat.jpg" alt="Picture of Oscar." />
<figcaption>Awesome caption about <strong>Oscar</strong> the kitty.</figcaption>
</figure>

Multiple images are supported:

![Picture of Oscar.](/path/to/cat1.jpg)
![Picture of Luna.](/path/to/cat2.jpg)
Awesome captions about the **kitties**.

<figure>
<img src="/path/to/cat1.jpg" alt="Picture of Oscar.">
<img src="/path/to/cat2.jpg" alt="Picture of Luna.">
<figcaption>Awesome captions about the <strong>kitties</strong>.</figcaption>
</figure>

Why?

Using dedicated <figure> and <figcaption> elements makes styling images with descriptions much easier. Here is an example:

I hear they are also good for SEO.

Installation

pip install mdit-py-figure

Or with uv:

uv add mdit-py-figure

Usage

from markdown_it import MarkdownIt
from mdit_py_figure import figure_plugin

md = MarkdownIt().use(figure_plugin)

source = """
![Picture of Oscar.](/path/to/cat.jpg)
Awesome caption about **Oscar** the kitty.
"""

html = md.render(source)
print(html)

Option to add link to the image

Example:

md = MarkdownIt().use(figure_plugin, image_link=True)

Render result:

<figure>
<a href="/path/to/cat.jpg">
<img src="/path/to/cat.jpg" alt="Picture of Oscar." />
</a>
<figcaption>Awesome caption about <strong>Oscar</strong> the kitty.</figcaption>
</figure>

See tests/test_figure.py for more examples.

Option to skip images without captions

Example:

md = MarkdownIt().use(figure_plugin, skip_no_caption=True)

In case a link to an image doesn't have a caption (a line of text following it without any linebreaks in between), it won't be wrapped in a <figure>.

See test_skip_no_caption_option() in tests/test_figure.py for an example.

Changelog

See CHANGELOG.md.

LICENSE

Apache-2.0
