DQC — Distributed Quantum Compiler

[!WARNING] DQC is at 0.1.2 — a beta, experimental release. It is usable for research and benchmarking, but the public API may change in any minor release before 1.0.0. Pin an exact version if you depend on it, and see the CHANGELOG for what moved.

DQC (Distributed Quantum Compiler) is an open-source Python library for distributed quantum compilation. Given a quantum circuit and a network topology, it partitions the circuit across QPUs, routes inter-QPU gates, and reconstructs a distributed circuit ready for execution or further analysis.

It is built around one design goal: every stage of the pipeline — partitioning, routing, scheduling, visualization — is a swappable component, so researchers can extend the compiler with their own algorithms rather than work around it.

The library is designed to be modular and plug-and-play: researchers can run the full compilation workflow in a few lines of code, swap in different partitioning algorithms, and benchmark them against each other across circuits and network topologies.

📖 Full documentation: memq-dqc.readthedocs.io — guides, API reference, and runnable demos.

Installation

uv sync

Quick start

No circuit or network to use? The library ships a reference set, so the shortest complete run is:

from memq_dqc import Compiler
from memq_dqc.assets import circuit_path, network_path

compiler = Compiler(circuit_path("qft_n10"), network_path("10_qubits/n2_pair_nn"))
compiler.compile()

print("verified:", compiler.verify(shots=20000))

With your own files:

from memq_dqc.partition import Partitioner
from memq_dqc.builder import extract_distributed_circuit
from memq_dqc.verify import verify_distributed_circuit

# Compile
partitioner = Partitioner("network.json", "circuit.qasm")
partitioner.run()

# Extract the distributed circuit
distributed = extract_distributed_circuit(partitioner)

# Verify correctness against the original
is_valid = verify_distributed_circuit("circuit.qasm", "distributed.qasm")

For one-call access to both circuits and their DAGs:

from memq_dqc import get_verification_artifacts
from memq_dqc.verify import verify_distributed_circuit

artifacts = get_verification_artifacts("circuit.qasm", "network.json")

is_valid = verify_distributed_circuit(
    artifacts.original_program,
    artifacts.distributed_program,
)

original_qasm = artifacts.original_qasm
original_dag = artifacts.original_dag
distributed_qasm = artifacts.distributed_qasm
distributed_dag = artifacts.distributed_dag

Partitioner accepts either file paths or pre-loaded objects:

from memq_dqc.network import NetworkGraph
from memq_dqc.preprocessing.qasm.io import load_qasm_program

network = NetworkGraph("network.json")
program = load_qasm_program("circuit.qasm")
partitioner = Partitioner(network, program)

Partitioning algorithms

Pass algo= to Partitioner to select a partitioning strategy. The default is "interaction".

partitioner = Partitioner("network.json", "circuit.qasm", algo="hypergraph")

Bundled networks and circuits

memq_dqc.assets exposes a reference suite that ships inside the installed package — 40 network topologies and 10 circuits — so the full workflow runs without writing a topology first. Both accessors return a Path, which is what Compiler, Partitioner, and NetworkGraph already accept.

from memq_dqc.assets import circuit_path, list_circuits, list_networks, network_path

list_circuits()  # ['adder_n28', 'multiply_n13', 'qft_n10', ...]  4-60 qubits
list_networks()  # ['10_qubits/n2_pair_a2a', '10_qubits/n2_pair_nn', ...]

Circuits are transpiled OpenQASM 3.0 programs named <algorithm>_n<qubits>, spanning 4 to 60 qubits. Each is fully measured — a bit[n] c register and one explicit c[i] = measure q[i]; per qubit — so they work as verification inputs as well as compilation inputs. Sampling-based verify() is practical up to multiply_n13 plus adder_n28; the wide QFTs starve it, and verify exactly via method="statevector" instead. See the guide for which method covers which circuit.

Networks are grouped by the circuit size they host (10, 20, 30, 40, 60 qubits) and named n<QPUs>_<arrangement>_<variant> — for example 30_qubits/n4_hub_nn. The size is a capacity, not an exact match: a 30-qubit network hosts any circuit of 30 qubits or fewer. Arrangements cover pair, chain, ring, and hub; each comes in a nearest-neighbour (_nn) and an all-to-all (_a2a) intra-QPU variant, so you can isolate the effect of local connectivity while holding the inter-QPU arrangement fixed. Every network has a same-named Markdown file documenting it in full, reachable via network_doc_path().

See the Bundled Networks & Circuits guide for the full catalogue.

Network builder

Topology JSON gets tedious to write by hand past a few QPUs. The network builder is a local web app, shipped with the library, for drawing a network in the browser and exporting it as a topology file:

uv run network-builder

That starts a server on http://127.0.0.1:8010 and opens it in your browser. Add --port 8020 to serve somewhere else (8010 is the default so the builder does not collide with mkdocs serve on 8000), or --no-browser to start the server without opening a tab.

Draw QPUs, qubits, and links by hand, or use the generator panel to produce ring, hub, grid, all-to-all, and homogeneous-line topologies from a QPU count. Save As downloads a .json file that drops straight into the workflow:

network = NetworkGraph("my_network.json")

Installing from PyPI rather than a clone? The builder needs Flask, which ships as an optional extra:

pip install "memq-dqc[builder]"

The builder also records per-qubit coherenceTime and per-link fidelity. No current partitioner or scheduler reads these — they are carried in the format so networks built today stay useful to coherence- and fidelity-aware algorithms later.

See the Network Builder guide for details.

Visualization

memq_dqc.visualization provides SVG-based views of the compilation output:

from memq_dqc.visualization import (
    plot_distributed_circuit,  # gate layout across QPUs
    plot_partition_flow,  # qubit migration across QPUs
    plot_partition_heatmap,  # QPU assignment heatmap per window
    plot_migration_timeline,  # qubit movement timeline with EPR cost
    plot_circuit_dag,  # circuit DAG
    plot_operation_gantt,  # operation Gantt chart
    write_svg_dashboard_html,  # bundle panels into an HTML viewer
)

Animated execution playback

animate_circuit_execution plays a schedule back over the network graph, highlighting the physical qubits and links carrying each operation as the distributed circuit executes:

from memq_dqc.visualization import animate_circuit_execution

animation = animate_circuit_execution(network, scheduler.schedule)
animation.show()  # interactive window with play/pause and a scrubber
animation.save("run.gif")  # or export to .gif / .mp4 / .html

In a notebook, displaying the returned object renders an inline player.

Logging and verbosity

The main workflow APIs support per-call verbosity control:

• quiet (default): returns results without progress logging
• info: logs major phase start/completion messages and elapsed time
• debug: adds intermediate diagnostics such as chosen parameters, per-phase summaries, and mapping details

partitioner = Partitioner("network.json", "circuit.qasm")
partitioner.run(verbosity="info")

distributed = extract_distributed_circuit(partitioner, verbosity="debug")

is_valid = verify_distributed_circuit(
    "original.qasm",
    "distributed.qasm",
    verbosity="info",
)

For advanced control, configure the standard Python logger named memq_dqc:

import logging

logging.basicConfig(level=logging.DEBUG)
logging.getLogger("memq_dqc").setLevel(logging.DEBUG)

Development

This repository uses Ruff for linting and formatting and pytest for tests. All checks are wrapped via tox.

Run all checks

uv run tox

Run checks individually

uv run ruff check .          # lint
uv run ruff format --check . # format check (no modifications)
uv run ruff format .          # auto-format
uv run pytest -q              # tests

Docs

The docs site (config, API reference generation, demo notebooks) lives under docs/.

uv sync --group docs                              # install docs dependencies
uv run mkdocs serve -f docs/mkdocs.yml             # live preview at http://127.0.0.1:8000
uv run mkdocs build -f docs/mkdocs.yml --strict    # build to ./site (fails on warnings)
