mikeio1d 0.6.1

A package that uses the DHI MIKE1D .NET libraries to read res1d and xns11 files.

MIKE IO 1D: Read MIKE 1D in python

Read res1d and xns11 files.

For other MIKE files (Dfs0, Dfs1, Dfs2, Dfsu,...) use the related package MIKE IO

Requirements

• Windows operating system (Support for Linux is experimental)
• Python x64 3.6, 3.7 or 3.8
• VC++ redistributables (already installed if you have MIKE)

Installation

From PyPI:

pip install mikeio1d

Or development version:

pip install https://github.com/DHI/mikeio1d/archive/main.zip

For MIKE IO 1D to work .NET runtime environment (version 3.1 and above) is needed. On Linux operating systems this is not available per default. For example, on Ubuntu distribution to get .NET 7.0 runtime call:

sudo apt install dotnet-runtime-7.0

Where can I get help?

• New ideas and feature requests - GitHub Discussions
• Bugs - GitHub Issues
• General help, FAQ - Stackoverflow with the tag mikeio

Examples

Read Res1D file Return Pandas DataFrame

>>>  from mikeio1d.res1d import Res1D, QueryDataReach
>>>  df = Res1D(filename).read()

>>>  query = QueryDataReach("WaterLevel", "104l1", 34.4131)
>>>  df = res1d.read(query)

For more Res1D examples see this notebook

Read Xns11 file Return Pandas DataFrame

>>>  import matplotlib.pyplot as plt
>>>  from mikeio1d import xns11
>>>  # Query the geometry of chainage 58.68 of topoid1 at reach1
>>>  q1 = xns11.QueryData('topoid1', 'reach1', 58.68)
>>>  # Query the geometry of all chainages of topoid1 at reach2
>>>  q2 = xns11.QueryData('topoid1', 'reach2')
>>>  # Query the geometry of all chainages of topoid2
>>>  q3 = xns11.QueryData('topoid2')
>>>  # Combine the queries in a list
>>>  queries = [q1, q2, q3]
>>>  # The returned geometry object is a pandas DataFrame
>>>  geometry = xns11.read('xsections.xns11', queries)
>>>  # Plot geometry of chainage 58.68 of topoid1 at reach1
>>>  plt.plot(geometry['x topoid1 reach1 58.68'],geometry['z topoid1 reach1 58.68'])
>>>  plt.xlabel('Horizontal [meter]')
>>>  plt.ylabel('Elevation [meter]')
