mujoco-tools 0.1.1

A toolkit for MuJoCo simulation and visualization

MuJoCo Tools: A Toolbox For MuJoCo

English | 中文

A comprehensive toolkit for MuJoCo simulation, visualization, and data processing.

Todo List

Refactor

• [] Define the unified data format (txt npy npz)
• [] In recorder, the video that output the result of the activation is obviously not good.

Completed Features

• Basic MuJoCo model loading and simulation
• Command-line interface with comprehensive options
• 3D model motion trajectory rendering
• Multi-camera view support
• Customizable resolution (supports up to 4K)
• Adjustable playback speed and frame rate
• Joint positions (qpos) and velocities (qvel) recording
• Body positions (xpos) and orientations (xquat) recording
• Support for multiple data formats (.npy/.txt/.csv)
• Basic data analysis and processing utilities
• Initial pose configuration using model keyframes (init_qpos)

In Progress

• Add tests scripts to test the package
• Muscle activation heatmap display
• Tendon path points recording
• Sensor data recording
• Support for .mot trajectory format
• Advanced data analysis tools
• Documentation improvements
• Unit tests
• Example scripts for common use cases

Installation

# Install from source
git clone https://github.com/yourusername/mujoco_tools.git
cd mujoco_tools
pip install -e .
# Install from PyPI
pip install mujoco-tools
# Install from github
pip install git+https://github.com/ShanningZhuang/mujoco_tools.git

Project Structure

mujoco_tools/
├── mujoco_tools/          # Main package
│   ├── cli.py            # Command-line interface
│   ├── mujoco_loader.py  # MuJoCo model loading utilities
│   ├── player.py         # Visualization player
│   ├── recorder.py       # Data recording utilities
│   ├── tools.py          # General utilities
│   └── data_processor.py # Data processing utilities
├── models/               # Test models
└── examples/             # Example scripts

Usage

1. Command Line Interface

mujoco-tools -m <model.xml> [options]

Required Arguments:

• -m, --model: Path to MuJoCo XML model file
• --mode: Simulation mode (kinematics: runs mj.fwd_position, dynamics: runs mj.step) [default: kinematics]

Input Data Options:

• -d, --data: Input data type and path (e.g., "qpos data/qpos.npy ctrl data/ctrl.npy") or Directly input the path of npz
• --input_data_freq: Frequency of input data [default: 50]
• --init_qpos: Initialize first frame with key_qpos[init_qpos] from the model (integer index)

Output Path Options:

• --output_path: Output path [default: logs]
• --output_prefix: Output prefix [default: output]

Visualization Options:

• --record_video: Enable video recording
• --width: Video width in pixels [default: 1920]
• --height: Video height in pixels [default: 1080]
• --fps: Video framerate [default: 50]
• --output_video_freq: Frequency of output video [default: 50]
• --camera: Camera name [default: Free]
• --flags: Custom vision flags (e.g., "mjVIS_ACTUATOR mjVIS_ACTIVATION")

Recording Options:

• --record_data: Enable data recording
• --format: Output format (npy/txt/csv) [default: npy]
• --datatype: Data types to record (space-separated: qpos qvel xpos xquat sensor tendon) [default: qpos]
• --output_data_freq: Frequency of output data [default: 50]

2. Bash Script Usage

Create a bash script for configuration:

#!/bin/bash

# Default settings
MODEL_PATH="models/humanoid/humanoid.xml"
DATA_PATH="qpos data/qpos.npy"
MODE="kinematics"
OUTPUT="output/video.mp4"
RESOLUTION="1080p"
FPS=50
CAMERA="side"
RECORD_DATA=1
DATA_FORMAT="npy"
RECORD_TYPES="qpos qvel xpos"

# Build command
CMD="mujoco-tools \\
    -m \"$MODEL_PATH\" \\
    -d \"$DATA_PATH\" \\
    --mode \"$MODE\" \\
    -o \"$OUTPUT\" \\
    --resolution \"$RESOLUTION\" \\
    --fps \"$FPS\" \\
    --camera \"$CAMERA\""

# Add recording options
if [ "$RECORD_DATA" -eq 1 ]; then
    CMD+=" --record"
    CMD+=" --format \"$DATA_FORMAT\""
    CMD+=" --datatype \"$RECORD_TYPES\""
fi

# Execute command
eval "$CMD"

3. Python Module Usage

# Direct module import
from mujoco_tools import MujocoLoader, Player, Recorder

# Command line usage examples
# Basic usage
python -m mujoco_tools.cli -m /path/to/model.xml -d 'qpos /path/to/data.npy'

# Using initial keyframe position
python -m mujoco_tools.cli -m /path/to/model.xml --init_qpos 0 --record_video

# Advanced usage with activation visualization
mujoco-tools -m /home/zsn/research/mujoco_tools/logs/model/Arm_Hand/mj_vision_manipulation_high_cube.xml -d "act /home/zsn/research/mujoco_tools/logs/arm_hand/2025_02_08_23_07_44_HandCube_act.txt qpos /home/zsn/research/mujoco_tools/logs/arm_hand/2025_02_08_23_07_44_HandCube_qpos.txt" --mode kinematics --input_data_freq 500 --record_video --camera "record_camera_2" --width 1920 --height 1080 --output_prefix stage6 --flags "mjVIS_ACTUATOR mjVIS_ACTIVATION" --activation_map --activation_shape "10 9" --init_qpos 0

Data Format

The default output format is .npy (or .npz for multiple arrays). Data is stored in (time, data) format.

Development

Setup Development Environment

# Clone the repository
git clone https://github.com/yourusername/mujoco_tools.git
cd mujoco_tools

# Install development dependencies
pip install -e .

Publishing

The package is automatically published to PyPI when a new release is created on GitHub. To publish a new version:

1. Update version in setup.py
2. Create and push a new tag:

git tag v0.1.0  # Use appropriate version
git push origin v0.1.0

3. Create a new release on GitHub using the tag
4. The GitHub Action will automatically build and publish to PyPI

Running Tests

pytest tests/

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

To contribute:

1. Fork the repository
2. Create your feature branch (git checkout -b feature/AmazingFeature)
3. Commit your changes (git commit -m 'Add some AmazingFeature')
4. Push to the branch (git push origin feature/AmazingFeature)
5. Open a Pull Request

License

MIT License
