muraw

Python library for reading, writing, and rendering Adobe DNG (Digital Negative) raw image files. Provides both a comprehensive Python API and command-line tools for DNG manipulation, rendering, metadata handling, and multi-threaded batch processing. Performance-critical operations are implemented in C/C++ extensions, but this initial (May 1, 2026) release prioritizes rendering correctness over speed optimization.

Key Features

• DNG Read/Write: Full support for reading, writing, and modifying Adobe DNG (Digital Negative) files.
• RAW Rendering Pipeline: Complete implementation of DNG rendering pipeline (linearization, demosaicing, opcodes, color correction, tone curves). On macOS can opt between built-in renderer and Core Image renderer.
• Multiple Demosaicing Algorithms: BILINEAR, VNG, RCD (optional), EA, EA_FAST, OPENCV_EA
• XMP Support: Renderer supports Temperature, Tint, Exposure, Curves, and radial distortion from XMP metadata.
• Metadata Handling: User-friendly TIFF/EXIF/XMP tag handling with automatic type conversion
• Compression: Uncompressed, JPEG, JPEG XL support with multi-core parallel compression for tiled formats
• CLI Tools: Comprehensive command-line interface for DNG operations.
• Batch Processing: Multi-threaded batch conversion and video encoding.

Installation

From PyPI

The last published package name is still muimg. This tree installs as muraw. Use the GitHub or local-dev instructions until muraw is published.

pip install muraw

Or in pyproject.toml:

[project]
dependencies = [
    "muraw",
]

Optional Dependencies

Video Encoding & Google Photos: For video encoding and Google Photos integration:

pip install "muraw[all]"

Core Image (macOS): For macOS users, installing the Core Image dependency enables a second rendering engine that will be available at runtime alongside the built-in renderer:

pip install "muraw[coreimage]"

Combined: To install all optional features:

pip install "muraw[all,coreimage]"

Or in pyproject.toml:

[project]
dependencies = [
    "muraw[all,coreimage]",
]

From GitHub

To install the latest development version directly from GitHub:

[project]
dependencies = [
    "muraw @ git+https://github.com/mu-files/mu-image.git#subdirectory=muraw",
]

For Local Development

Clone the repository and install the package in editable mode:

git clone https://github.com/mu-files/mu-image.git
cd mu-image/muraw
pip install -e .

Note: muraw includes C/C++ extensions that are compiled during install. macOS and Linux have built-in C compilers and require no additional setup. Windows users installing from source need Microsoft C++ Build Tools. Pre-built Windows wheels are available when installing from PyPI.

API Overview

Core Classes

DngFile: Subclass of TiffFile for reading DNG files. Provides access to IFDs (Image File Directories), metadata, and raw image data.

DngPage: Subclass of TiffPage representing a single IFD within a DNG file. Can be a raw CFA page, LinearRaw RGB page, or preview/thumbnail. Provides methods to extract raw data at various pipeline stages and render to display-referred RGB.

MetadataTags: Container for TIFF/EXIF/DNG tags with type-safe tag handling.

Reading DNGs

Opening and navigating: DngFile(path) opens a DNG file. Use ifd0 property to access IFD0, get_main_page() to get the primary raw image, or get_flattened_pages() to access all IFDs including SubIFDs.

Extracting raw data: DngPage.get_cfa() extracts CFA (Color Filter Array) data at various pipeline stages (raw, linearized, post-opcodes). DngPage.get_linear_raw() extracts LinearRaw RGB data.

Rendering to RGB: DngPage.render() applies the full DNG rendering pipeline (demosaicing, opcodes, color correction, tone curves, etc.) to produce display-referred RGB. The scale parameter allows for fast preview renders at reduced resolution. decode_dng() is a convenience function that handles file opening and rendering in one call.

Metadata access: DngPage.get_tag(name) retrieves TIFF/DNG tags with automatic type conversion (e.g., get_tag("ColorMatrix1") returns a 3×3 NumPy array).

Writing DNGs

PageEncoding: Dataclass that groups compression type and codec-specific arguments. Used to specify how image data should be compressed when -writing DNGs from an array or -transcoding a DNG page. For JXL compression, compression_args=None defaults to lossless (distance=0.0, effort=4). Example: PageEncoding(compression=COMPRESSION.JPEGXL_DNG, compression_args={'distance': 0.5, 'effort': 7}).

write_dng(): The most general function to create a DNG file. Takes an IFD0 spec and optional list of SubIFD specs (each can be IfdPageSpec or IfdDataSpec). Each spec describes the page data and how to encode it.

write_dng_from_page(): Create a DNG from an existing DngPage or IfdPageSpec. Supports transformations (scaling, demosaicing), compression transcoding (e.g., uncompressed to JXL via transcode_encoding=PageEncoding(...)), preview/pyramid generation, and tag manipulation.

write_dng_from_array(): Create a DNG from an IfdDataSpec containing a NumPy raw pixel data array and metadata. Supports preview and pyramid generation with optional compression via encoding=PageEncoding(...).

Batch Processing

Pipeline control: ProcessingPipeline class provides fine-grained control over batch processing with customizable producer/consumer/writer stages that decouple file I/O operations from pixel processing (e.g., decouple reading DngFile from disk and rendering it).

Image sequences: ImageSequencePipeline is a ProcessingPipeline for processing sequences of image files and saving the results (.tiff/.jpg) to an output folder.

Video encoding: VideoEncodePipeline is a ProcessingPipeline for encoding image sequences to video files with configurable codecs, resolution, and frame rates, and saving the result to a video file (.mp4). Requires pip install muraw[all].

Parallelism: Control parallelism with --num-workers flag in CLI or num_workers parameter in API. Default is 4 workers. Adjust based on CPU cores and memory availability.

Metadata

Tag management: MetadataTags.add_tag() adds TIFF/EXIF tags with automatic type handling. DngPage.get_page_tags() returns a MetadataTags object with metadata for that page.

Type registry: TIFF_TAG_TYPE_REGISTRY provides metadata about all supported TIFF/DNG tags, including data types, valid IFDs, and enum mappings.

CLI Commands

The muraw command provides comprehensive DNG operations:

Image Format Conversion

# Convert any image format to another
muraw convert-image input.tif output.jpg

DNG Metadata

Display and filter DNG metadata:

# Show all metadata for all IFDs
muraw dng metadata input.dng

# Show specific IFD
muraw dng metadata input.dng --ifd 0

# Filter tags by pattern
muraw dng metadata input.dng --tag "Color.*" --tag "Exposure"

# Exclude tags
muraw dng metadata input.dng --exclude-tag "XMP"

# Summary only
muraw dng metadata input.dng --summary

DNG Raw Stage Extraction

Extract raw data at specific pipeline stages:

# Extract unprocessed raw data
muraw dng raw-stage input.dng output.tif raw

# Extract after OpcodeList2
muraw dng raw-stage input.dng output.tif linearized-plus-ops

# Extract demosaiced camera RGB
muraw dng raw-stage input.dng output.tif camera-rgb --demosaic VNG

# Extract from specific IFD
muraw dng raw-stage input.dng output.tif linearized --ifd subifd2

DNG Copy and Transform

Create a new DNG from source DNG with optional transformations:

# Create a new DNG file with the main page transcoded to JXL
muraw dng copy input.dng output.dng --jxl-distance 0.5

# Scale and demosaic
muraw dng copy input.dng output.dng --scale 0.5 --demosaic

# Generate preview (1/4 scale)
muraw dng copy input.dng output.dng --preview --preview-reduce 4

# Generate preview (1/2 scale)
muraw dng copy input.dng output.dng --preview --preview-reduce 2

# Strip tags
muraw dng copy input.dng output.dng --strip-tag OpcodeList2,OpcodeList3

# Add/override tags
muraw dng copy input.dng output.dng --tag "Artist=John Doe" --tag "Copyright=2026"

# Generate raw "preview" pyramid levels
muraw dng copy input.dng output.dng --pyramid-levels 3

DNG Rendering

Convert DNG to display image with adjustments:

# Basic conversion
muraw dng convert input.dng output.jpg

# With white balance and exposure
muraw dng convert input.dng output.tif --temperature 5500 --tint 10 --exposure 0.5

# 16-bit output
muraw dng convert input.dng output.tif --bit-depth 16

# Use Core Image on macOS
muraw dng convert input.dng output.jpg --use-coreimage

# Convert specific IFD
muraw dng convert input.dng output.jpg --ifd subifd1

Batch DNG Conversion

Process multiple DNGs in parallel:

# Convert folder of DNGs to TIFF
muraw dng batch-convert /path/to/dngs/ /path/to/output/ --format tif

# Control parallelism (set to 8 here, default is 4 workers)
muraw dng batch-convert /path/to/dngs/ /path/to/output/ --format tif --num-workers 8

# Use fixed rendering parameters for each image
muraw dng batch-convert /path/to/dngs/ /path/to/output/ \
  --format jxl --temperature 5500 --exposure 0.5

# From CSV with per-file settings
# CSV format: filename,Temperature,Tint,Exposure2012,orientation
muraw dng batch-convert settings.csv /path/to/output/ --format tif

# Scaled output (uses the efficient scaling rendering path)
muraw dng batch-convert /path/to/dngs/ /path/to/output/ --scale 0.5

Batch DNG to Video

Requires: pip install muraw[all] (for video encoding support)

Create video from DNG sequence:

# Basic video creation
muraw dng batch-to-video /path/to/dngs/ output.mp4

# With rendering and encoding options
muraw dng batch-to-video /path/to/dngs/ output.mp4 \
  --resolution 1920x1080 --codec hevc --crf 20 --bit-depth 10 \
  --temperature 5500 --exposure 0.5 --frame-rate 30

# Timelapse (1 frame every 2 seconds)
muraw dng batch-to-video /path/to/dngs/ timelapse.mp4 --frame-rate 0.5

# With filename overlay
muraw dng batch-to-video /path/to/dngs/ output.mp4 --overlay-txt

# From CSV with per-file settings
muraw dng batch-to-video settings.csv output.mp4 --resolution 1920x1080

Google Photos Integration

Requires: pip install muraw[all] (for Google Photos support)

Upload images to Google Photos:

# Authenticate
muraw google-photos auth --credentials credentials.json

# Upload image
muraw google-photos upload image.jpg --album "My Album"

# List albums
muraw google-photos list-albums

Examples

make_test_dng.py

Creates size-constrained test DNG files by iteratively scaling down the image resolution until it fits within a target size. All test files were generated using this code.

python examples/make_test_dng.py input.dng output.dng --target-size 1048576
python examples/make_test_dng.py input.dng output.dng --target-size 1048576 --generate-preview

Features:

• Iterative scaling by powers of 2 until target size is met
• Demosaics to LINEAR_RAW in order to scale image
• Optional JXL compression

Tests

The test suite covers DNG reading, writing, rendering, metadata handling, and CLI operations.

Running Tests

Requires: pip install muraw[all] (pytest is included in the [all] extra)

cd /path/to/mu-image/muraw
venv/bin/pytest tests/

Run specific test file:

venv/bin/pytest tests/test_dng_render.py -v

Run with detailed logging:

venv/bin/pytest tests/test_cli.py -v -s --log-cli-level=INFO

Test Categories

Note: Many tests validate results against Adobe's dng_validate tool from the DNG SDK. To use this validation:

1. Download DNG SDK from: https://helpx.adobe.com/camera-raw/digital-negative.html
2. Build the dng_validate tool (see SDK documentation)
3. Place the binary at the path specified in tests/conftest.py or update DNG_VALIDATE_PATH

Tests always use muraw's built-in validator.

Note: Test image files (~80 MB) are stored in a separate repository (mu-files/mu-image-testdata) and are automatically downloaded on the first test run.

DNG Rendering (test_dng_render.py): Tests the full rendering pipeline, including linearization, demosaicing, color correction, tone curves, and output color space conversion for a variety of real camera DNG files (scaled to download-friendly resolution) and compares results against dng_validate.

Metadata Handling (test_metadata_*.py): Tests TIFF tag reading/writing, endianness handling, XMP parsing, and Core Graphics metadata extraction on macOS.

Write Operations (test_write_dng*.py): Tests DNG creation from arrays, page copying, compression options, and tag manipulation.

Roundtrip Tests (test_*_roundtrip.py): Tests that read-modify-write operations preserve data correctly (color temperature, SubIFD structure).

CLI Commands (test_cli.py): Tests command-line interface functionality.

Preview and Pyramid (test_preview_rendering.py, test_pyramid_subifd.py): Tests thumbnail/preview generation and pyramid-level creation.

Demosaicing (test_demosaic.py): Tests various demosaicing algorithms.

Known Issues

Not Implemented

The following DNG features are not yet implemented:

• Triple-illuminant: Support for 3 calibration illuminants (ColorMatrix3, CalibrationIlluminant3)
• RGBTables: DNG version 1.6+ per-channel 1D LUTs
• ReductionMatrix: Support for cameras with >3 color channels
• SemanticMasks: DNG v1.6+ depth maps and segmentation masks
• HDR/Overrange: ProfileDynamicRange and extended dynamic range support

See docs/dng_render_pipeline.md for detailed implementation status of each pipeline stage.

Performance Notes

Demosaicing Algorithms: muraw includes several demosaicing algorithms with different quality/speed tradeoffs:

• BILINEAR: Good quality, fast (default for most operations)
• VNG: High quality, slower
• EA: Hamilton–Adams (default for convert / camera RGB)
• EA_FAST: Single-pass axis-pick green + bilinear chroma; faster, lower quality
• OPENCV_EA: OpenCV edge-aware demosaic (comparison / visualization only)
• RCD (optional, GPL-licensed): High quality, slower

The RCD (Ratio Corrected Demosaicing) algorithm is disabled by default because it's licensed under GPL v3, which is separate from muraw's BSD-3-Clause license. To enable RCD:

1. Rename c-src/demosaic/rcd.txt to c-src/demosaic/rcd.c
2. Rebuild: pip install -e .

By enabling RCD, you accept the GPL v3 license terms for that component. The RCD source is based on Luis Sanz Rodríguez's implementation.

Core Image Rendering: On macOS, Core Image provides native DNG rendering. Use --use-coreimage flag in CLI or use_coreimage_if_available=True in API.

Technical Documentation

For detailed technical documentation on the DNG rendering pipeline, including tag reference, pipeline stages, and implementation status, see:

docs/dng_render_pipeline.md

This document provides:

• Complete pipeline flowchart from raw sensor data to display RGB
• Tag reference organized by pipeline stage
• Implementation status for each stage
• Detailed explanations of color matrix calculations, tone curves, and opcode processing

License

This software is released under the BSD 3-Clause License. See LICENSE for full terms.

Third-Party Components

• Adobe DNG SDK: Adobe DNG SDK License (permissive, royalty-free)
• VNG Demosaicing: LGPL v2.1 / CDDL v1.0
• RCD Demosaicing (optional): GPL v3
