Abstract

We present NablAFx, an open-source framework developed to support research in differentiable black-box and gray-box modeling of audio effects. Built in PyTorch, NablAFx offers a versatile ecosystem to configure, train, evaluate, and compare various architectural approaches. It includes classes to manage model architectures, datasets, and training, along with features to compute and log losses, metrics and media, and plotting functions to facilitate detailed analysis. It incorporates implementations of established black-box architectures and conditioning methods, as well as differentiable DSP blocks and controllers, enabling the creation of both parametric and non-parametric gray-box signal chains.

Citation

@misc{comunità2025nablafxframeworkdifferentiableblackbox,
      title={NablAFx: A Framework for Differentiable Black-box and Gray-box Modeling of Audio Effects},
      author={Marco Comunità and Christian J. Steinmetz and Joshua D. Reiss},
      year={2025},
      eprint={2502.11668},
      archivePrefix={arXiv},
      primaryClass={cs.SD},
      url={https://arxiv.org/abs/2502.11668},
}

@misc{comunità2025differentiableblackboxgrayboxmodeling,
      title={Differentiable Black-box and Gray-box Modeling of Nonlinear Audio Effects},
      author={Marco Comunità and Christian J. Steinmetz and Joshua D. Reiss},
      year={2025},
      eprint={2502.14405},
      archivePrefix={arXiv},
      primaryClass={cs.SD},
      url={https://arxiv.org/abs/2502.14405},
}

Support

To show your support please consider giving this repo a star ⭐. Thanks! 🤘

Installation

For Research & Experimentation (Recommended)

Clone the repository for full access to training scripts, configurations, and examples:

# Clone the repository
git clone https://github.com/mcomunita/nablafx.git
cd nablafx

# Create virtual environment
python3 -m venv .venv
source .venv/bin/activate  # On Windows: .venv\Scripts\activate

# Install NablaFX in editable mode
pip install -e .

# Install rational-activations (required, installed separately due to dependency conflicts)
pip install rational-activations==0.2.0 --no-deps

# Copy rational config file
python -c "
import urllib.request
from pathlib import Path
import rational
url = 'https://raw.githubusercontent.com/mcomunita/nablafx/master/weights/rationals_config.json'
target = Path(rational.__file__).parent / 'rationals_config.json'
urllib.request.urlretrieve(url, target)
print(f'✅ Config downloaded to {target}')
"

For Quick Evaluation or Using as a Library

Install from PyPI if you want to quickly test NablaFX or use its components in your own projects:

pip install nablafx
pip install rational-activations==0.2.0 --no-deps

See INSTALL.md for detailed installation instructions.

Setup for Training

Data

NablAFx is setup to work with the ToneTwist AFx Dataset, and so are the dataset classes provided in ./nablafx/data/, but you can also write your own custom class and use a different dataset.

Make data folder and either move data to that folder or create a symbolic link:

mkdir data
cd data
ln -s /path/to/TONETWIST-AFX-DATASET/

Logs

NablAFx is setup to use Weights&Biases for logging so, create an account and wandb login from terminal.

mkdir logs

Please note that if you want to save the logs to a specific subfolder, this needs to be created in advance (see cfg/trainer/trainer_bb.yaml for an example).

Frechét Audio Distance checkpoints

The checkpoints to compute Frechét Audio Distance need to be in specific folders:

mkdir checkpoints_fad

The first time you will compute FAD (which is at test time) the checkpoints are automatically downloaded and placed into subfolders.

Train

We use Lightning CLI to configure the training using separate .yaml files for data, model and trainer configurations, see examples in:

cfg/data
cfg/model
cfg/trainer

To make it super easy to start training we prepared shell scripts scripts/train_bb.sh or scripts/train_gb.sh, which look like this:

CUDA_VISIBLE_DEVICES=0 \
python scripts/main.py fit \
-c cfg/data/data-param_multidrive-ffuzz_trainval.yaml \
-c cfg/model/s4-param/model_bb-param_s4-tvf-b8-s32-c16.yaml \
-c cfg/trainer/trainer_bb.yaml

so that you just have to change the config paths to train your own model.

Test

We did the same for testing, and prepared a shell script scripts/test.sh that looks like this:

CUDA_VISIBLE_DEVICES=0 \
python scripts/main.py test \
--config logs/multidrive-ffuzz/S4-TTF/bb_S4-TTF-B8-S32-C16_lr.01_td5_fd5/config.yaml \
--ckpt_path "logs/multidrive-ffuzz/S4-TTF/bb_S4-TTF-B8-S32-C16_lr.01_td5_fd5/nnlinafx-PARAM/p362csrv/checkpoints/last.ckpt" \
--trainer.logger.entity mcomunita \
--trainer.logger.project nablafx \
--trainer.logger.save_dir logs/multidrive-ffuzz/TEST/bb_S4-TTF-B8-S32-C16_lr.01_td5_fd5 \
--trainer.logger.name bb_S4-TTF-B8-S32-C16_lr.01_td5_fd5 \
--trainer.logger.group Multidrive-FFuzz_TEST \
--trainer.logger.tags "['Multidrive-FFuzz', 'TEST']" \
--trainer.accelerator gpu \
--trainer.strategy auto \
--trainer.devices=1 \
--config cfg/data/data-param_multidrive-ffuzz_test.yaml
# --data.sample_length 480000

While it looks complicated, it is just the case of replacing the paths to: model configuration, checkpoint, logging folder.

Params, FLOPs, MACs and Real-time factor:

Scripts to measure all these metrics of a model are in the benchmarks folder. The code is not very organized and beautiful at the moment but does the job.

Pre-train MLP Nonlinearity or FIR

The script to pretrain differentiable processors (see nablafx/processors/ddsp.py) like a StaticMLPNonlinearity or a StaticFIRFilter is nablafx/scripts/pretrain.py. Examples of pretrained nonlinearities and filters are in nablafx/weights.

Contributions

There is a lot that can be done to improve and expand NablAFx, and we encourage anyone to contribute or suggest new features.

Credits

• LSTM - https://github.com/Alec-Wright/Automated-GuitarAmpModelling
• TCN - https://github.com/csteinmetz1/micro-tcn
• GCN - https://github.com/mcomunita/gcn-tfilm
• S4 - https://github.com/int0thewind/s4-dynamic-range-compressor
• dasp - https://github.com/csteinmetz1/dasp-pytorch
• rational activations - https://github.com/ml-research/rational_activations
• auraloss - https://github.com/csteinmetz1/auraloss
