ncarnate 2.3.1

Reincarnate legacy scientific data as modern netCDF4.

ncarnate reads netCDF3, netCDF4/HDF5, and HDF4/HDF-EOS2 files and writes recompressed, CF-annotated netCDF4. It does two jobs:

• Recompress netCDF/HDF5 files — change the compression level, shuffle filter, or storage layout without changing a single stored value.
• Convert HDF4 and HDF-EOS2 granules (AMSR-E, MODIS, and kin) to netCDF4, reconstructing the CF coordinates that modern tools (xarray, QGIS, Panoply) need: grid projections become CF grid mappings with 1-D x/y and 2-D lat/lon coordinates, swath geolocation is attached as CF coordinates, and dimension-mapped (e.g. 5 km → 1 km) geolocation is interpolated through ECEF space.

Problems this solves

Reach for ncarnate if you are trying to:

• Convert HDF4 / HDF-EOS2 granules (MODIS, AMSR-E, and kin) to netCDF4 so they open cleanly in xarray, QGIS, or Panoply.
• Read an HDF-EOS2 swath or grid that has no usable lat/lon — ncarnate reconstructs CF lat/lon coordinates and grid mappings so the data is actually georeferenced, instead of an unplottable array.
• Recompress a netCDF4 / HDF5 file — change the compression level or shuffle filter without altering a single stored value.
• Shrink an archive of scientific files without risking the science: every output is verified value-for-value against its source before it replaces anything, and stored values round-trip value-identically (bit-for-bit for integer and packed data; NaN- and signed-zero-insensitive for floating point).
• Batch-convert a directory tree of legacy granules to modern netCDF4 in one command.

The fidelity contract

Converting or recompressing a file changes storage, never science data:

• Every variable's stored values are preserved value-identically — bit-for-bit for integer and packed data; for floating-point data, distinct NaN bit-patterns and -0.0/+0.0 compare equal. Packed integers stay packed; scale_factor/add_offset/_FillValue are carried across as declarations, never applied.
• Every dimension (including unlimited-ness), attribute (including its exact storage type — an NC_STRING scalar stays NC_STRING, verified via netCDF-C type inquiry), and group survives. HDF-EOS2 StructMetadata is preserved verbatim; names netCDF cannot hold are sanitized with the original recorded in a companion attribute.
• Complex-valued variables (complex64/complex128) are excluded from the fidelity guarantee: netCDF stores them as compound types, which ncarnate refuses loudly with the stable UNSUPPORTED_TYPE error rather than guessing at a lossy copy. Complex support is a later, evidence-backed feature.
• Geolocation reconstruction is strictly additive: the original information always rides along, so the conversion never becomes the only copy of the truth. Swath coordinates are attached to variables whose first two axes are the swath axes; a variable with a leading band/byte dimension is converted intact but gets no coordinates attribute (a warning says so).
• Every output is verified against the source value-for-value before it replaces anything. A source file is never destroyed by a failed run, and HDF4 sources are never replaced at all.
• Unsupported constructs (user-defined netCDF types, unverified GCTP projections, exotic swath layouts) fail loud with a named error rather than guessing — a wrong coordinate is worse than a refused conversion. --no-geolocation converts the raw payload anyway.

The details, the guarantee boundary, and how the test suite pins each clause live in docs/fidelity-notes.md.

Installation

With conda (from conda-forge):

conda install -c conda-forge ncarnate

Conda-forge supplies the native HDF4, netCDF and PROJ dependencies together. Package availability depends on the platform and Python version. Release CI checks Linux and Windows conda environments separately from pip installations.

With pip (from PyPI):

pip install ncarnate

Where compatible binary wheels are available, no separate native-library installation is needed. Building pyhdf from source requires an HDF4 library and build tools first (Debian/Ubuntu: apt install libhdf4-dev).

Windows via pip: HDF4 availability depends on the installed pyhdf runtime. The 2.3.0 candidate validation used Python 3.11 and pyhdf 0.11.7 successfully on Windows, including all five full granules in the checked-in corpus catalog. This does not qualify every Python or Windows build. If HDF4 cannot be loaded, ncarnate refuses that conversion before output creation with HDF4_RUNTIME_UNAVAILABLE; netCDF conversion remains usable. The conda-forge installation above is an alternative when the pip runtime is unavailable.

Command line usage

# Recompress a netCDF4 file in place (verified before replacement).
ncarnate observations.nc --complevel 9

# Keep the original; write observations_recompressed.nc beside it.
ncarnate --no-overwrite observations.nc

# Convert an HDF-EOS2 granule -> granule.nc with CF geolocation.
ncarnate AMSR_E_L3_SeaIce12km_B02_20020619.hdf

# Convert the raw SDS payload only (unsupported-projection escape hatch).
ncarnate --no-geolocation granule.hdf

# Recurse over a directory tree.
ncarnate -r /data/archive

Exit codes: 0 success, 1 one or more files failed, 2 bad input paths or arguments.

Audit an archive in 5 minutes

Before converting a terabyte archive, run a read-only audit: it never opens science arrays, never touches the network, and never writes to the files it inspects. It discovers files, detects formats, inspects metadata, classifies each file into a readiness taxonomy, and prints a summary by files and bytes.

# Assess an archive (recursive, read-only) and print a readiness summary.
ncarnate audit /data/archive

# Write the per-file migration manifest (JSONL is the contract; .csv gives a
# flat spreadsheet view). Add --checksum sha256 for a manifest you intend to
# execute later.
ncarnate audit /data/archive --output manifest.jsonl --checksum sha256

Each JSONL line is one versioned, schema-validated file record — path, checksum, status, blockers, and the conversion plan — designed so a later ncarnate convert --manifest (and every downstream tool) consumes it unchanged. The bare ncarnate <path> and ncarnate convert <path> forms are unchanged.

Convert exactly what the audit blessed

The golden path for an archive migration is two steps: audit an archive, then convert exactly what it blessed. convert --manifest executes the audit's manifest — it re-verifies each granule's recorded sha256 before touching it, converts only the statuses you select (ready by default), writes a mirrored output tree, and never modifies a source unless you pass --in-place.

# 1. Audit the archive, recording a per-file sha256 in the manifest.
ncarnate audit /data/archive --output manifest.jsonl --checksum sha256

# 2. Convert exactly the `ready` granules into a mirrored ./modern tree.
#    --root anchors reads to a directory you control (the manifest is untrusted
#    input, so its recorded root is not trusted as the read base by default;
#    pass --allow-manifest-root to opt into trusting it instead). A record whose
#    bytes changed since the audit (sha256 mismatch) is skipped with an error;
#    a blocker is never converted; sources are left untouched.
ncarnate convert --manifest manifest.jsonl --out-dir ./modern --root /data/archive

# Widen the selection and skip paths that already exist (without verifying them).
ncarnate convert --manifest manifest.jsonl --out-dir ./modern --root /data/archive \
    --status ready,already_modern --skip-existing

The end-of-run summary counts converted / skipped / failed with reasons. Conversion failures return nonzero. With --result-journal, an unavailable journal refuses the run before conversions (exit 2); a later reporting failure returns exit 3 while retaining the conversion summary and completed outputs.

Destination collision preflight. Before any directory or output file is created, every selected record's destination is computed up front — from the source's detected bytes, never the manifest's declared format — and any collision refuses the entire run with exit code 2 and a stable [DESTINATION_COLLISION] message on stderr listing every involved source and the contested destination. No last-writer-wins, no auto-rename, no partial proceed, and nothing is written. Refused collisions include: two records landing on one output path (e.g. an a.hdf → a.nc conversion next to a real a.nc sibling), case-fold-equivalent names (one file on NTFS/APFS), duplicate records for one source, an output tree overlapping a source tree (symlinks resolved), and a pre-existing destination unless you pass --skip-existing to skip them. This legacy flag checks existence, not successful completion. Use the prepared library API below for digest-verified resumption.

Prepared conversions and verified resume

from ncarnate import prepare, execute_prepared

# The output's parent must already exist. Preparation writes nothing.
job = prepare("input.nc", "output.nc", complevel=4)
record = execute_prepared(job, journal="completion.json", resume=True)

prepare binds the source digest, size and frozen encoding options to an explicit, separate output. prepare_batch([(source, output), ...]) checks all destinations before execution; execute_prepared_batch checkpoints each completed item in the journal. Existing outputs require a matching journal record and a matching output digest. Changed sources, changed options, damaged outputs and missing completion evidence are refused. An existing journal requires resume=True; it is never silently discarded. These APIs return handoff records.

Keep the journal descriptor together with its sibling <journal>.records directory when backing up or moving completion evidence. Each completed output gets its own atomic checkpoint, so larger batches do not repeatedly rewrite a growing journal. Each record has a 64 MiB limit; the complete journal has no aggregate byte limit. Resume loads these records into caller memory, so its memory use grows with the batch. Earlier 2.3.0 development journals migrate when resumed. Records without an output digest cannot authorize reuse. Preserve a completed output for inspection if checkpoint writing fails; retry with a fresh destination rather than assuming the existing output is resumable. Concurrent journal writers and power-loss durability are not supported.

Legacy recompress still defaults to replacing a netCDF source when no output is supplied. Legacy execute_batch remains a lazy executor of caller-owned plans; it does not inspect future destinations. The new explicit-output API is the non-destructive route. Digest checks assume a cooperative filesystem and do not prevent concurrent path replacement between checking and reading.

netCDF arrays and HDF4 SDS values copy and verify in bounded slices. To change the temporary array budget, wrap execution in with ncarnate.streaming.array_budget(bytes):. The default is 16 MiB. This is not a global process-memory limit: Python, metadata, compression and native chunk caches add memory. Native caches can hold at least one storage chunk. Variables whose names collide with a dimension use the native cache default to avoid a netCDF-C read failure. HDF-EOS geolocation reconstruction retains whole output coordinate arrays under declared-size limits; swath interpolation computes its larger temporary arrays in tiles.

For a hard limit across the conversion worker, including native allocations:

from ncarnate import prepare, execute_bounded

report = execute_bounded(prepare("input.hdf", "output.nc"),
                         memory_bytes=512 * 1024**2,
                         array_bytes=4 * 1024**2,
                         timeout_seconds=600)
record = report["result"]

This serial worker uses a Windows Job Object committed-memory limit or a Linux process address-space limit. Neither measures RSS; the calling process is outside the cap. Only a successful, verified worker output is published, exclusively to a new destination. Timeout, insufficient memory, or native failure leaves no final output. Existing outputs are refused; journals and resume remain in the prepared API. Unsupported platforms, including macOS for this API, fail before conversion with MEMORY_LIMIT_UNAVAILABLE. The ordinary conversion API remains portable. Publication needs same-filesystem hard-link support; an unavailable link fails with OUTPUT_PUBLISH_FAILED. If cleanup fails after publication, the verified result still returns with a WORKER_CLEANUP_INCOMPLETE warning naming the retained staging directory. Resource counters are diagnostics; allocation-refusal tests verify enforcement independently of those counters. The accepted 64 MiB minimum is a validation floor; imports alone may exceed it. Start with the default 512 MiB and size the limit for the input and runtime.

Audit mode is metadata-only. Handoff validation bounds nesting and record complexity. Undecodable byte attributes and lone surrogate text are refused at serialization; a conversion already committed before result read-back fails remains an intact output, with a degraded record unsuitable for materialization.

Full-granule provenance and digests are in tests/fixtures/corpus.json. For a complete small worked example, run python examples/verified_conversion.py NEW_DEMO_DIRECTORY. Run python tools/corpus.py DATA_DIRECTORY --fetch --include-references, then set NCARNATE_GRANULE_DIR and run python tools/test_full_corpus.py --junitxml full-granules.xml. This release check refuses missing or changed inputs, skipped tests and missing test cases. Ordinary pytest still skips unavailable full-size data. GitHub's manual Full-granule validation workflow runs the same strict checks and retains reports. The separately packaged, local Zarr demonstration lives under companions/zarr-demo and is excluded from ncarnate's distribution. It is not a production storage service.

Library usage

from ncarnate import (
    convert_file, recompress, audit_path, AuditOptions, convert_manifest, ConvertOptions,
)

# Lossless recompression into a separate file; returns the output path.
convert_file("observations.nc", "observations_compressed.nc", complevel = 9)

# HDF-EOS2 conversion; the .hdf source is never replaced.
convert_file("granule.hdf", "granule.nc")

# Read-only archive audit; returns an AuditReport (report.summary, report.files).
report = audit_path("/data/archive", AuditOptions(recursive=True))

# Execute an audit manifest; returns a ConvertResult (converted/skipped/failed).
result = convert_manifest("manifest.jsonl",
                          ConvertOptions(root="/data/archive", out_dir="./modern"))

convert_file() is available from 2.3.1. It requires an explicit, separate output path and leaves the source intact. Existing output files are refused; pass overwrite=True to replace an output after verification. Its parent directory must already exist. Default publication requires hard-link support so an output created during conversion cannot be overwritten; unsupported filesystems (for example FAT/exFAT) fail before conversion. Choose a filesystem with hard links, or explicitly use overwrite=True; that also permits replacing an output created during conversion. Source aliases, symbolic-link outputs and paths differing from the source only by case are refused on every platform. Keep source paths and parent directories stable while conversion runs. The legacy recompress() API and its defaults are unchanged.

Example

The AMSR-E daily 12.5 km sea-ice granule this project grew up around:

Both outputs re-read value-identically to their sources; the conversion additionally carries CF polar_stereographic grid mappings and coordinates for both hemispheric grids. The northern grid's reconstructed latitudes/longitudes agree with The HDF Group's independent conversion of the same granule to within 10⁻⁵ degrees (about a metre), the tolerance the test suite enforces.

Supported inputs

• netCDF4 / HDF5 and netCDF3 — recompressed via the netCDF4 library.
• HDF4 / HDF-EOS2 — read via the pyhdf SD API. GRID structures with GCTP polar-stereographic, geographic, and Lambert-azimuthal (EASE-Grid) projections; SWATH structures with direct or dimension-mapped geolocation. Output is always netCDF4 — HDF4 is never written.

Development

python -m pip install -e ".[test,release]" "ruff==0.15.*"
ruff check .
python -m pytest -q
python -m pytest -q tools/tests

The test suite runs entirely offline against small committed fixtures trimmed from real granules (provenance sidecars included); cross-checks against the raw multi-MB granules self-skip where the local granule store is absent. CI additionally builds documentation, checks release metadata, installs both package formats outside the checkout, and tests the separate Zarr companion. PyPI and TestPyPI publication wait for all those jobs and use the same tested artifacts. Production runs require a matching version tag and release date. See the contributor guide for local checks and the release guide for the publication sequence.

License

MIT — see LICENSE. Built by Erick Shepherd.
