netwatch-sec 1.3.2

All-in-one network security dashboard: honeypots, traffic capture, OSINT, scanning, mesh alerts.

NetWatch

All-in-one network security dashboard — deploy honeypots, capture traffic, run OSINT, scan targets, block threats, and forward alerts over mesh radio. One command, one file, real-time.

sudo netwatch

NetWatch turns any Linux box into a full network security sensor. It deploys 4 honeypot services that lure and log attackers, sniffs all traffic on your interface with raw sockets and tshark, auto-enriches every IP with geolocation and threat scoring, and gives you 100+ commands to investigate, track, and block threats — all from a single terminal or browser.

Built for Raspberry Pi, Kali, Parrot OS, and any Debian-based Linux. Runs as a single Python file with no microservices, no Docker, no cloud dependency.

---

How It Works

1. Launch — sudo netwatch starts everything: 4 honeypots bind their ports, raw socket sniffer attaches to your interface, tshark begins protocol analysis, ARP monitor discovers devices, web dashboard opens on :9090
2. Capture — Every packet is parsed for source/destination IPs, ports, protocols, and DNS queries. Honeypots log credentials, commands, file uploads, and malware download attempts
3. Enrich — Each new IP is automatically scored for threat level based on port behavior, known bad ports, and scan patterns. Run OSINT commands to add geolocation, WHOIS, abuse reports, and ASN data
4. Respond — Block attackers with iptables, tag and watchlist IPs, run deep nmap scans, capture payloads, export reports. Forward critical alerts over LoRa mesh radio for off-grid monitoring
5. View — Full-screen TUI with 11 tabs, or browser dashboard with live charts, clickable IPs, 5 color themes, and CRT scanline effects

---

Architecture

┌──────────────────────────────────────────────────────────────┐
│                     NETWATCH v1.1.0                          │
├──────────────────────────────────────────────────────────────┤
│  TERMINAL UI (TUI)        │  WEB DASHBOARD (:9090)           │
│  Full-screen ANSI         │  Flask + SSE live updates        │
│  11 tabs, console mode    │  5 themes, CRT scanlines         │
│  Tab/number key nav       │  Charts, clickable IPs, API      │
├──────────────────────────────────────────────────────────────┤
│  HONEYPOTS                │  TRAFFIC MONITORING              │
│  HTTP :8080 (NVR panel)   │  Raw socket sniffer              │
│  Telnet :2323 (DVR)       │  tshark protocol analysis        │
│  FTP :2121 (bait files)   │  tcpdump PCAP recording          │
│  RTSP :8554 (camera)      │  ARP device discovery            │
├──────────────────────────────────────────────────────────────┤
│  SCANNING & RECON         │  OSINT (16 tools)                │
│  nmap integration         │  GeoIP, WHOIS, DNS enum          │
│  Port scanning            │  SSL/TLS, HTTP headers           │
│  Service detection        │  Abuse/ASN, cert transparency    │
│  Stealth (Tor) mode       │  Tech fingerprinting, speedtest  │
├──────────────────────────────────────────────────────────────┤
│  DEFENSE                  │  MESH RADIO                      │
│  iptables blocking        │  Meshtastic LoRa support         │
│  Threat scoring           │  Alert forwarding                │
│  Watchlists & tagging     │  Two-way messaging               │
└──────────────────────────────────────────────────────────────┘

Install

One-liner (fastest):

curl -fsSL https://raw.githubusercontent.com/Mattmorris-dev/netwatch-sec/main/install.sh | bash

Installs the netwatch CLI (via pipx when present), reports any missing capture tools, and prints next steps. Runs passively without root.

Quick install (from PyPI):

sudo apt install -y nmap tshark tcpdump traceroute iproute2 iptables \
                    openssl curl dnsutils whois psmisc arp-scan tor proxychains4
pipx install netwatch-sec
sudo netwatch

From source:

# System tools (one-shot — covers all commands NetWatch shells out to)
sudo apt install -y nmap tshark tcpdump traceroute iproute2 iptables \
                    openssl curl dnsutils whois psmisc arp-scan \
                    tor proxychains4

# Python deps
pip3 install -r requirements.txt

# Optional features
pip3 install graphene flask-graphql    # GraphQL API at :9090/graphql
pip3 install meshtastic                # LoRa mesh radio alerts
sudo apt install -y speedtest-cli      # `speed` command

# Install launcher system-wide
chmod +x netwatch-start.sh
sudo ln -s $(pwd)/netwatch-start.sh /usr/local/bin/netwatch

Docker (one-liner):

docker run -d --name netwatch --restart unless-stopped \
  --network host --cap-add NET_ADMIN --cap-add NET_RAW \
  -e NETWATCH_TELNET_PORT=23 -e NETWATCH_FTP_PORT=21 \
  -e NETWATCH_HTTP_PORT=80 -e NETWATCH_RTSP_PORT=554 \
  -v netwatch-logs:/app/logs \
  ghcr.io/mattmorris-dev/netwatch-sec:latest eth0

This runs headless: honeypots on standard ports (23/21/80/554) + the web dashboard on :9090. System tools (nmap, tshark, tcpdump, …) are baked into the image. Multi-arch — works on x86-64 and ARM64 (Raspberry Pi). Swap eth0 for your capture interface.

Or with Compose:

docker compose up -d        # uses docker-compose.yml
docker compose logs -f      # watch attacks

Watch the attack feed (clean JSON, one line per hit):

docker exec netwatch tail -f /app/logs/all_events.json

--network host and the NET_ADMIN/NET_RAW caps let NetWatch bind privileged ports and capture traffic. Host networking is Linux-only; on macOS/Windows drop --network host and publish ports with -p instead (capture features are limited there).

Verify your install: start NetWatch and run doctor (aliases deps/check) at the prompt — it lists every required Python package and system tool with present/missing status, flags passive (non-root) mode, and tells you what to install for anything missing.

Quick Start

# Random token each launch (default — more secure)
sudo netwatch

# Persistent token across restarts (requires NETWATCH_FIXED_TOKEN env var)
export NETWATCH_FIXED_TOKEN=$(openssl rand -hex 24)
sudo -E netwatch --fixed-token

# Specific interface
sudo netwatch eth0

On launch a redacted token preview is printed (ABCDEF…WXYZ) and the full token is written to ~/.config/netwatch/token (mode 0600). Use it to log into the web dashboard at http://<your-ip>:9090.

Both TUI and web UI launch together — one command runs everything.

Key & token rotation

From the TUI prompt:

Command	Effect
rotate-key	Generate a new Fernet key — invalidates all active web sessions. Persisted to ~/.config/netwatch/web.key.
rotate-token	Generate a new auth token — invalidates all sessions. Re-written to ~/.config/netwatch/token (0600).

Honeypot ports

Defaults bind to high ports so root isn't required: HTTP :8080, Telnet :2323, FTP :2121, RTSP :8554. Override via env to move to standard ports (needs CAP_NET_BIND_SERVICE or root):

NETWATCH_HTTP_PORT=80 \
NETWATCH_TELNET_PORT=23 \
NETWATCH_FTP_PORT=21 \
NETWATCH_RTSP_PORT=554 \
sudo -E netwatch

Persist by adding to /etc/netwatch.env and referencing in the systemd unit's EnvironmentFile=. Internet-facing scanners hit the standard ports — non-standard ports stay invisible to most drive-by traffic.

Replay tunables

Same-IP telnet attempts roll up into one aggregated session (all_<ip>) so a scanner banging your honeypot all day shows as one entry instead of fifty. Inside the timeline, ── ATTEMPT N (timestamp UTC) ── markers separate bursts. Tune the burst threshold with:

NETWATCH_TELNET_GAP_SEC=86400 sudo -E netwatch   # one marker per day (default: 300 = 5 min)

Individual per-attempt sessions remain loadable via their original <ip>_HHMMSS id for drill-down.

CrowdSec auto-ban (optional)

If cscli is installed on the host, every honeypot capture (credential, telnet, ftp, rtsp, malware_attempt, ftp_upload, telnet_cmd) automatically calls cscli decisions add with a 4h ban. The CrowdSec firewall bouncer enforces the drop via ipset, so the rule count never blows up. Same-IP events within 60s are deduped. Set NETWATCH_AUTODEFEND=0 to disable. With no CrowdSec installed, the hook silently no-ops.

Install on Debian:

curl -s https://install.crowdsec.net | sudo sh
sudo apt install -y crowdsec crowdsec-firewall-bouncer-iptables
sudo systemctl enable --now crowdsec crowdsec-firewall-bouncer

Whitelist your operator IP so you don't ban yourself — add /etc/crowdsec/parsers/s02-enrich/whitelists.yaml:

name: netwatch/operator-whitelist
whitelist:
  reason: "operator home"
  ip: ["<your-public-ip>"]

Session Replay

sudo netwatch                                          # capture starts immediately
python tools/synth_ftp_session.py 198.51.100.42        # optional — fake an attacker
# open http://localhost:9090 and click the REPLAY tab

Every captured session (FTP, Telnet, HTTP probes) is recorded as a scrubbable timeline. The web player auto-lists sessions; pick one and step through the keystrokes frame by frame. In the TUI, replay list shows recent sessions and replay <idx> drops into the player.

Player keys: space play/pause · ←/→ step · </> jump session · +/- speed · Home/End ends.

Remote Access

When cloudflared is available, NetWatch starts a quick tunnel automatically at launch. The public *.trycloudflare.com URL is printed at startup and pinned to the top of the all tab on the dashboard so you can copy it without scrolling through alerts.

Console commands (type into the prompt):

Command	Purpose
tunnel	Reprint the current trycloudflare URL + full web token
restart-tunnel	Kill cloudflared, spawn a fresh tunnel (new URL)
token	Reprint the full web token + on-disk path

# Manual fallback if cloudflared isn't on $PATH
cloudflared tunnel --url http://localhost:9090

# Or point NetWatch at a non-default cloudflared binary
NETWATCH_CLOUDFLARED_BIN=/opt/cf/cloudflared sudo -E netwatch

Public-IP access (no tunnel)

The web dashboard's IP allowlist defaults to loopback + RFC1918 + Tailscale (100.64/10) so a fresh install can't be reached from the open internet by accident. To allow your home/office IP, set NETWATCH_WEB_ALLOW to one or more CIDRs:

# Single host
NETWATCH_WEB_ALLOW=203.0.113.42/32 sudo -E netwatch

# Multiple ranges (comma-separated)
NETWATCH_WEB_ALLOW="203.0.113.42/32,198.51.100.0/24" sudo -E netwatch

Invalid CIDRs are skipped with a warning at startup. Token auth still applies — adding an IP only lets the login page render. Pair with ufw/iptables for defense in depth.

Termux / non-root (passive mode)

NetWatch runs on Termux (Android) and any non-root environment in passive mode — honeypots, OSINT, web dashboard, and nmap connect-scan still work. Features that need raw sockets or kernel access are auto-disabled:

Feature	Root	Termux / non-root
Honeypots (HTTP/Telnet/FTP/RTSP)	✓	✓
Web dashboard + OSINT	✓	✓
nmap (connect / -sV)	✓	✓
Raw-socket sniffer / traffic	✓	—
tshark / tcpdump capture	✓	—
ARP monitor	✓	—
block / unblock (iptables)	✓	—
nmap SYN scan (-sS)	✓	—

# Termux quick start
pkg install python nmap whois tor
pip install netwatch-sec
netwatch                    # passive mode — no sudo needed

Terminal UI

Three screens, hotkey-toggled. Switching screens keeps your tab and scroll position.

Screen	Hotkey	Purpose
Dashboard	F1	11 tabs, live host/protocol/honeypot view
Command Line	F2	Full-screen prompt + command output
Console	F3	Full-screen log of tool output

F1 / F2 / F3       Switch screens
1-9, 0             Jump to tab
Type anything      Open command prompt
Up/Down            History recall
PgUp / PgDn        Scrollback
Home / End         Top / bottom
ESC                Close help overlay
clear              Wipe console buffer

Tabs

all · hosts · proto · dns · honeypot · nmap · arp · alerts · osint · proxy · mesh

Web Dashboard

Browser UI on :9090 with live SSE updates, 5 themes, and CRT scanline effects.

• Themes: Terminal Classic, Matrix Green, Midnight Blue, Cyberpunk, Light Mode
• CRT Scanlines: Off, Soft, Heavy — retro terminal aesthetic
• Charts: Live traffic timeline, protocol distribution, threat breakdown
• Click any IP for context menu — scan, geo, whois, traceroute, full recon
• Resizable output panel with drag handle
• Host detail modal with ports, tags, OSINT results, honeypot activity
• Keyboard shortcuts: 1-0 for tabs, / to focus command bar, ESC to dismiss

Security

• Token auth required (auto-generated or --token <val> or env var NETWATCH_TOKEN)
• Fernet-encrypted session cookies, key persisted at ~/.config/netwatch/web.key
• Private network access by default (127/10/192.168/100.64); add public CIDRs via NETWATCH_WEB_ALLOW=cidr,cidr,...
• CSRF origin validation on all POST endpoints
• Destructive commands disabled via web
• SSRF protection on outbound OSINT (fails closed, private IP rejection)
• Rate limiting: 20 cmd/min, 3 expensive/min per IP
• CIDR max /20 on web scan commands
• Nmap target validation at function entry (regex + flag allowlist)

Commands

OSINT (16 tools)

Command	Description
geo <ip>	IP geolocation
whois <ip/domain>	WHOIS lookup
dnsinfo <domain>	DNS enumeration (A/AAAA/MX/NS/TXT/SOA/CNAME/SRV)
rdns <ip>	Reverse DNS
ssl <host> [port]	TLS certificate inspection
secheaders <url>	Security header audit + grade
techstack <url>	Web technology fingerprinting
ping <ip> [count]	Jitter analysis + TTL OS guess
health <target>	Full profile (ping + SSL + headers + tech + geo + DNS)
etrace <target>	Enriched traceroute with per-hop GeoIP
portscan <ip>	Socket-based top 1000 port scan
subnet [cidr]	Threaded ping sweep
crt <domain>	Certificate transparency search
headers <url>	HTTP response headers
asn <ip>	ASN/BGP info
abuse <ip>	IP reputation check
speed	Network speed test (download/upload/ping)
ifinfo	Local interface info + routing table

Scanning

Command	Description
scan <ip> [preset]	Nmap scan (quick/syn/udp/ping/full)
deep <ip>	All ports + vuln scripts
stealth <ip>	SYN scan through Tor
recon <ip>	Full OSINT profile
fullrecon <ip>	7-phase recon chain
sweep [cidr]	ARP + ping + port scan
banner <ip> <port>	Service banner grab
trace <ip>	Traceroute

Tracking & Capture

Requires root. Disabled automatically in passive mode.

Command	Description
track <ip> [secs]	Live packet tail (tshark)
conns <ip>	TCP conversation capture
sniff <ip> [secs]	Raw payload capture
trackdns <ip>	DNS query capture
pcap start/stop	PCAP recording

Defense

Command	Description
block <ip>	iptables DROP (root only)
unblock <ip>	Remove block (root only)
blockall attackers	Block all honeypot IPs (root only)
diffarp	ARP table change detection

System

Command	Description
status	Service info + uptime
dashboard / d	Return to dashboard screen
clear	Wipe console buffer
help	Show full reference overlay
rotate-key	New Fernet key (invalidates web sessions)
rotate-token	New web auth token (invalidates sessions)

Smart Filters

Command	Description
top [n]	Top N talkers
sus	Suspicious hosts (threat > 0)
new [mins]	Recently appeared
loud	Most ports touched
find <pattern>	Search all data
ports <port>	Hosts using port
country <CC>	Filter by country

Batch Operations

scanall [list]     reconall [list]     geoall [list]     whoisall [list]

Lists: hosts · attackers · arp · nmap · watchlist · tracked · blocked

Use @N to reference IPs by index: scan @3 scans the 3rd IP in the current list.

Proxy / Tor

proxy add socks5 127.0.0.1:9050    proxy list
proxy test                         proxy rotate
proxy start                        proxy stop

Mesh Radio

mesh send <text>     mesh status     mesh nodes     mesh alert on/off

Honeypots

Service	Port	Captures
HTTP NVR Panel	8080	Credentials, session tokens, API probes
Telnet DVR	2323	Login attempts, shell commands, malware downloads
FTP Bait Server	2121	Credentials, keystroke logs, file uploads (max 10MB)
RTSP Camera	8554	Auth probes, stream requests

All events logged to JSON with ANSI-stripped, sanitized data. Connection limits per service (50 max). FTP has path traversal protection and filename sanitization.

Session replay → GIF

Turn any FTP session log into a watchable asciinema cast and GIF:

python3 tools/replay_to_gif.py logs/ftp_session_<ip>_<ts>.log demo.gif

Real attacker cadence preserved, idle stalls compressed. Requires agg for the GIF step.

GraphQL API

Available at :9090/graphql when graphene is installed.

{ hosts(minThreat: 10, limit: 20) { ip hostname threatScore tags } }
{ honeypotEvents(service: "telnet") { time ip summary } }
mutation { runCommand(cmd: "geo 8.8.8.8") { output } }

Testing

python3 -m pytest tests/ -q
# 1900 tests, ~30s on a Pi 5

Lint (CI threshold --fail-under=9.0):

pylint $(git ls-files '*.py') --fail-under=9.0

Security Model

• All subprocess calls use argument lists, never shell=True
• Nmap target regex validation at function entry + flag allowlist
• ANSI escape stripping on all logged data (log injection prevention)
• FTP upload path traversal blocked via os.path.realpath checks
• FTP data connection synchronized with threading.Event
• Session stores bounded with TTL eviction
• Log rotation at 50MB
• SSRF protection: private IP rejection on outbound OSINT, fails closed on DNS errors
• PTR records never trusted for security decisions
• Flask secret keys randomized per startup
• Fernet-encrypted web cookies — no plaintext fallback
• Thread-safe rendering with RLock synchronization
• GraphQL query complexity limited (depth 7, aliases 10, length 4000)
• Web API rate limiting: 20 cmd/min, 3 expensive/min per IP
• CIDR max /20 on web scan commands

Requirements

Component	Details
OS	Linux (Debian, Ubuntu, Raspbian, Parrot, Kali) — also runs on Termux (Android) in passive mode
Python	3.9+
Root	Recommended (raw sockets, iptables, sub-1024 binding). Non-root and Termux run in passive mode (honeypots, OSINT, web, nmap connect-scan).
System	nmap, tshark, tcpdump, traceroute
Python	flask, requests, python-whois, dnspython, markupsafe, cryptography
Optional	graphene, flask-graphql, meshtastic, speedtest-cli

Tested on Raspberry Pi 5, Parrot OS, and Termux (Android, passive mode).

Deploy

git clone https://github.com/Mattmorris-dev/netwatch-sec.git && cd netwatch-sec
sudo apt install nmap tshark tcpdump traceroute
pip3 install -r requirements.txt

# System-wide install
sudo ln -s $(pwd)/netwatch-start.sh /usr/local/bin/netwatch

# Start on boot (optional)
sudo cp netwatch.service /etc/systemd/system/
sudo systemctl enable --now netwatch

Headless Mode

No TTY detected (SSH pipe, systemd, Docker) = headless mode. Web dashboard only on :9090. All honeypots and traffic monitoring still active.

Support

NetWatch is built and maintained solo. If it saves you time or protects your network, consider tipping — it keeps the lights on and pays for the tools that go into the next release.

License

Apache 2.0 — see LICENSE
