nextSSR 🚀
nextSSR is a next-generation, high-performance, standalone Simple Sequence Repeat (SSR / microsatellite) identification and PCR primer design platform written in Python. It provides ultra-fast parallel CPU multi-processing, optional CUDA GPU hardware acceleration, low-memory streaming, automated PCR primer design, and complete FAIR compliance (W3C RO-Crate JSON-LD provenance and Sequence Ontology GFF3 annotations).
🌟 Key Features
- ⚡ High-Throughput Parallelism: Scalable multi-core CPU process pool and optional CUDA GPU hardware acceleration (
--gpu). - 💾 Low Memory Footprint: Streaming FASTA generator allows analyzing multi-gigabyte genomes with minimal RAM usage.
- 🧬 Automated PCR Primer Design: Integrated thermodynamic primer design engine (SantaLucia 1998 Nearest-Neighbor & C-Primer3 support) for designing $T_m$-optimized primer pairs ($100-300\text{ bp}$ amplicons) ready for laboratory synthesis.
- 🏷️ Weber (1990) & Motif Classification: Categorizes SSRs by unit size (mono to hexanucleotide) and Weber structure (Perfect, Imperfect, Compound Perfect, and Compound Disrupted).
- 🌐 FAIR Compliant (Findable, Accessible, Interoperable, Reusable): Produces Sequence Ontology (
SO:0000289andSO:0001061) annotations in GFF3 and full W3C RO-Crate (ro-crate-metadata.json) execution provenance. - 🎨 Rich Terminal UI & Artifact Management: Interactive progress bars, formatted summary tables, YAML configuration support (
nextssr init-config), and structured output artifact folders. - 🔬 Reproducibility & Replicability: Includes Dockerfile and Apptainer/Singularity manifests for 100% deterministic workflow execution in HPC and Cloud environments.
📦 Installation
Option 1: Via PyPI
pip install nextssr
Option 2: Via Conda / Bioconda
conda install -c bioconda nextssr
# or using mamba
mamba install -c bioconda nextssr
Option 3: From Source (GitHub)
git clone https://github.com/LaBiOmicS/nextSSR.git
cd nextSSR
# Install in editable mode
pip install -e .
Option 4: Docker Container
docker build -t nextssr .
docker run --rm -v $(pwd):/data nextssr /data/genome.fasta -o /data/results
Option 5: Apptainer / Singularity (HPC Environments)
apptainer build nextssr.sif Apptainer.def
apptainer run nextssr.sif genome.fasta -o results/
🚀 Quick Start & Usage
Basic Execution
# Run SSR identification and primer design on a FASTA file
nextssr genome.fasta -o results/
# Or run using Python module syntax
python -m nextssr genome.fasta -o results/
Advanced Execution Options
# Run with 16 parallel CPU workers and custom primer parameters
nextssr genome.fasta -o results/ --threads 16 --opt-tm 60.0 --min-product-size 100 --max-product-size 250
# Run with GPU hardware acceleration
nextssr genome.fasta -o results/ --gpu
# Generate default YAML configuration file
nextssr init-config -o nextssr.yaml
# Run using custom YAML configuration file
nextssr genome.fasta -c nextssr.yaml -o results/
🧬 In Silico e-PCR Simulation
Validate PCR primers electronically against target genomes or transcriptomes with mismatch detection and amplicon sizing:
# Test a specific pair of Forward and Reverse primers against a target genome
nextssr epcr -f genome.fasta -F GATTACAAGCTACG -R ACGTACGTACGT -o epcr_amplicons.tsv
# Or test all primers designed in a nextSSR TSV report allowing up to 2 mismatches
nextssr epcr -f genome.fasta -p results/primers/nextssr_primers.tsv -m 2 -o epcr_batch.tsv
📂 Project Structure
nextSSR/
├── pyproject.toml # Packaging, metadata & dependencies (PEP 621)
├── MANIFEST.in # Package distribution manifest
├── README.md # Documentation
├── LICENSE # MIT License
├── Dockerfile # Containerized reproducible execution
├── Apptainer.def # HPC Singularity / Apptainer definition
├── recipe/ # Conda / Bioconda packaging recipe
│ ├── build.sh
│ └── meta.yaml
├── .github/ # GitHub workflows & templates
│ ├── workflows/
│ │ ├── ci.yml # GitHub Actions CI matrix
│ │ ├── pypi-publish.yml # Automatic PyPI release workflow
│ │ └── conda-build.yml # Conda build verification workflow
│ ├── ISSUE_TEMPLATE/
│ └── PULL_REQUEST_TEMPLATE.md
├── nextssr/ # Main package source
│ ├── __init__.py
│ ├── __main__.py # Package execution entrypoint (python -m nextssr)
│ ├── cli.py # Rich CLI interface (Click + Rich)
│ ├── config.py # Configuration management (YAML / JSON / INI)
│ ├── models.py # Dataclasses (SSRItem, CompoundSSR, SequenceAnalysisResult)
│ ├── finder.py # Core multi-parallel SSR detection engine
│ ├── compound.py # Compound microsatellite grouping logic
│ ├── primer.py # PCR Primer Design engine
│ ├── gpu.py # GPU hardware acceleration module (CuPy/CUDA)
│ ├── artifacts.py # Artifact Manager for structured output directory
│ ├── utils.py # Memory-efficient FASTA streaming utilities
│ ├── provenance.py # FAIR RO-Crate JSON-LD exporter
│ └── outputs/ # Output formatters
│ ├── __init__.py
│ ├── gff3.py # Sequence Ontology compliant GFF3 exporter
│ ├── tsv.py # Tab-delimited TSV exporter
│ └── json_fmt.py # JSON exporter
└── tests/ # Unit & integration test suite
⚙️ Configuration File (nextssr.yaml)
nextSSR can be configured via a clean YAML file generated with nextssr init-config:
nextssr:
version: 0.1.0
ssr_criteria:
unit_min_repeats:
'1': 10
'2': 6
'3': 5
'4': 5
'5': 5
'6': 5
max_compound_distance: 100
performance:
threads: 16
use_gpu: false
batch_size: 1000
primer_design:
enabled: true
flank_length_bp: 150
optimal_tm_celsius: 58.0
min_tm_celsius: 50.0
max_tm_celsius: 65.0
min_product_size_bp: 100
max_product_size_bp: 300
fair_and_outputs:
output_gff3: true
output_tsv: true
generate_ro_crate: true
🧬 Supported Classifications
1. Motif Size Classification (Motif_Class)
mononucleotide(1 bp)dinucleotide(2 bp)trinucleotide(3 bp)tetranucleotide(4 bp)pentanucleotide(5 bp)hexanucleotide(6 bp)
2. Weber (1990) Structural Classification (Weber_Classification)
Perfect: Uninterrupted repeat of a single motif (e.g.,(AC)8).Imperfect: A single motif repeat containing 1-3 mismatching bases.Compound Perfect: Two distinct motifs immediately adjacent with 0 bp gap (e.g.,(AC)5(AT)6).Compound Disrupted: Two distinct motifs separated by a gap of 1 to $N\text{ bp}$.
📁 Output Artifacts Directory Layout
Every nextSSR run produces a structured artifact directory:
results/
├── annotations/
│ └── nextssr_results.gff3 # Sequence Ontology GFF3 annotation
├── primers/
│ └── nextssr_primers.tsv # TSV report with PCR Primers & Weber classes
├── provenance/
│ └── ro-crate-metadata.json # W3C RO-Crate FAIR JSON-LD metadata
├── summary/
│ └── nextssr_summary_statistics.txt # Summary text report
└── run_manifest.json # Global execution JSON manifest
🌐 FAIR Compliance & Sequence Ontology
nextSSR output complies with FAIR (Findable, Accessible, Interoperable, Reusable) principles:
- GFF3 Annotations: Uses official Sequence Ontology (SO) terms:
SO:0000289(microsatellite)SO:0001061(compound_microsatellite)
- Execution Provenance: Generates W3C RO-Crate (
ro-crate-metadata.json) recording input file SHA-256 hash, configuration hash, environment details, and execution timestamp.
🧪 Testing Suite
Run end-to-end integration tests using pytest:
pytest -v
✉️ Author & Contact
- Author: Fabiano Menegidio
- Email: labiomics@bioinformatica.com.br
- GitHub: https://github.com/LaBiOmicS/nextSSR
📜 Citation
If you use nextSSR in your research or software pipelines, please cite the repository:
@misc{menegidio2026nextssr,
author = {Menegidio, Fabiano},
title = {nextSSR: High-Performance & FAIR-Compliant Simple Sequence Repeat Mining Engine},
year = {2026},
publisher = {GitHub},
howpublished = {\url{https://github.com/LaBiOmicS/nextSSR}}
}
📄 License
Distributed under the MIT License. See LICENSE for more information.
