ntt 0.1.5.3

Library for images and video processing.

ntt

ntt is a Python module that provides simple and consistent interfaces for common image and video processing tasks. It wraps around popular Python libraries to simplify their usage and make them interchangeable, to build complex pipelines. In particular:

• Pillow – image file handling
• OpenCV – computer vision, image and video processing
• imageio – read/write images and videos
• scikit-image – scientific image processing
• NumPy – arrays and calculations

Installation

Using venv (recommended)

1. Create a virtual environment:

python -m venv venv

2. Activate the environment:

• On macOS/Linux:

source venv/bin/activate

• On Windows:

venv\Scripts\activate

3. Install the module:

The module is available on Pypi:

pip install ntt

Or install the development version from source:

git clone
pip install -e .

Tests

import ntt
print(ntt.__version__)  # Check the version

Assuming you have cloned the repository or installed the source package, you can run tests with pytest:

$ pytest tests

Samples

To download the data samples (videos, images, sounds, etc.) used in tests and examples, clone the repository and update the .env file with the path to the cloned folder:

git clone https://github.com/centralelyon/ntt-samples.git

Alternatively, you can generate fake videos samples by running the following script:

from ntt.videos.video_generation import random_video

video = random_video(320, 240, 10, 2)

Building pipelines

An interesting use of ntt is to build complex pipelines for video and image processing. For that, we also built a separate tool, the Pipeoptz library, which provides a simple way to create and manage pipelines of functions.

The image above is generated using the code below available as a gist.

import random

from ntt.frames.frame_generation import random_frame
from ntt.frames.display import display_frame
from pipeoptz import Pipeline, Node

def random_number():
    num = random.randint(100, 600)
    return num

pipeline = Pipeline("Simple Pipeline", "Generate a random image.")

node_gen_width = Node("GenWidth", random_number)
node_gen_height = Node("GenHeight", random_number)
node_random_frame = Node(
    "random_frame", random_frame, fixed_params={"width": 10, "height": 3}
)

pipeline.add_node(node_gen_width)
pipeline.add_node(node_gen_height)
pipeline.add_node(
    node_random_frame, predecessors={"width": "GenWidth", "height": "GenHeight"}
)

outputs = pipeline.run()
display_frame(outputs[1][pipeline.static_order()[-1]])

Examples

You may look at the examples folder to see how to use ntt functions. Also a look a the tests folder to see how functions are tested. And of course, the documentation at https://ntt.readthedocs.io.

Assuming you have a crop.mp4  video in a samples folder and an output folder, here is how to use extract_first_frame function.

import os
from dotenv import load_dotenv
from ntt.frames.frame_extraction import extract_first_frame

if __name__ == "__main__":
    load_dotenv()

    output = extract_first_frame(
        video_path_in=os.environ.get("NTT_SAMPLES_PATH"),
        video_name_in="crop.mp4",
        frame_path_out=os.environ.get("PATH_OUT"),
        frame_name_out="crop-ex.jpg",
    )

    print(f"Frame successfully extracted at {output}") if output is not None else print(
        "Frame extraction failed"
    )

CircleCI

The project is configured to run tests on CircleCI. The configuration file is .circleci/config.yml.

Docker

A Dockerfile is provided to quickly set up an environment with all system dependencies (OpenCV, FFmpeg, etc.) and run tests or scripts.

Build the image

docker build -t ntt .

Run tests

By default, running the container executes the pytest test suite:

# Run tests using the code inside the container
docker run --rm ntt

During development, you can mount your local directory to run tests on your current code:

# Linux / macOS / Windows PowerShell
docker run --rm -v ${PWD}:/app ntt

# Windows Command Prompt (cmd)
docker run --rm -v "%cd%:/app" ntt

Run a custom script

You can override the default command to run a specific Python script:

docker run --rm -v ${PWD}:/app ntt python tests/test_random_strings.py

Run in interactive mode

To explore the container or run multiple commands manually, start a bash shell:

docker run --rm -it -v ${PWD}:/app ntt bash

Acknowledgments
