ocr-data-toolkit 0.1.2

A toolkit for generating synthetic data for OCR

A powerful Python toolkit for generating synthetic datasets for Optical Character Recognition (OCR) model training and evaluation. This toolkit enables generating realistic text images with configurable backgrounds, fonts, augmentations, and ground-truth labels, supporting research and production needs for OCR systems.

---

Table of Contents

• Overview
• Features
• Installation
• Quick Start
• Configuration
  • Input Config
  • Augmentation Config
• Output Images and Padding Strategy
• Output Format of Training and Testing Datasets
• Usage Examples
• Module Structure
• Extending and Customization
• Contributing
• License
• Acknowledgements

---

Overview

The OCR Data Toolkit (ocr_data_toolkit) is designed to generate high-quality synthetic data for OCR applications. It provides:

• Flexible control over text, fonts, backgrounds, and augmentations.
• Efficient multiprocessing for large-scale dataset creation.
• Ready-to-use utilities for font catalog visualization and dataset management.
• Modular design for easy extension and integration.

Synthetic data is essential for training robust OCR models, especially when annotated real-world data is scarce or expensive to collect. This toolkit helps you simulate diverse real-world scenarios, improving model generalization.

---

Features

• Text Generation: Random words, numbers, and dates with customizable probabilities.
• Font & Background Selection: Use your own font and background image collections.
• Rich Augmentations: Noise, blur, moire patterns, elastic distortions, ink bleed, perspective transforms, brightness, opacity, and more.
• Multiprocessing: Fast dataset generation using multiple CPU cores.
• Train/Test Splitting: Automatic splitting and ground-truth file creation.
• Visualization: Font catalog visualization for dataset quality checks.
• Easy Configuration: All options controlled via Python config dictionaries or dataclasses.

---

Installation

Requirements

• Python 3.7+
• Dependencies: Pillow, numpy, opencv-python, matplotlib, atpbar

Pip Installation

pip install ocr-data-toolkit

Or clone and install locally:

git clone https://github.com/NaumanHSA/ocr-data-toolkit.git
cd ocr-data-toolkit
pip install .

---

Quick Start

from ocr_data_toolkit import ODT

# Simple example: generate a single image
odt = ODT(language="en")
text, image = odt.generate_single_image()
image.save("sample.png")
print("Ground truth:", text)

---

Configuration

Input Config

Configuration is managed via the Config dataclass (see ocr_data_toolkit/common/config.py).

Parameter Reference:

Parameter	Type	Description
language	str	Language code (e.g., en). If not specified, defaults to English.
bag_of_words	List[str]	List of words for random text. If not provided, loads built-in vocabulary for the selected language.
backgrounds_path	str	Path to background images. If not set, uses built-in backgrounds shipped with the package.
fonts_path	str	Path to font files. If not set, uses built-in fonts for the selected language.
text_probs	Dict[str, float]	Probabilities for generating text, date, or number. Defaults to {text: 0.7, date: 0.1, number: 0.2}.
output_image_size	Tuple[int, int]	Output image size (width, height). If None, uses the natural size of generated images.
train_test_ratio	float	Ratio for splitting train/test sets. Default is 0.2 (20% test).
output_save_path	str	Where to save generated data. Defaults to an export folder in the project root.
augmentation_config	Dict	Augmentation settings (see below). If not provided, uses sensible defaults.
num_workers	int	Number of parallel workers for data generation. Default is 4.

Defaults and Auto-loading:

• If you do not specify backgrounds_path or fonts_path, the toolkit will automatically use built-in backgrounds and fonts for the selected language (see data/ directory).
• If you do not provide bag_of_words, the toolkit loads a built-in vocabulary file for the selected language.
• All other parameters have robust defaults to ensure out-of-the-box functionality.

Example:

from ocr_data_toolkit import ODT
config = {
    "language": "en",
    "output_image_size": (128, 32),
    "augmentation_config": {"max_num_words": 5, "num_lines": 2},
}
odt = ODT(**config)

Augmentation Config

Augmentations are controlled by the AugmentationConfig class (see ocr_data_toolkit/common/config.py). You can override any default by passing a dictionary to augmentation_config.

Detailed Augmentation Parameters:

Parameter	Type	Default	Description
max_num_words	int	5	Maximum number of words per generated text sample.
num_lines	int	1	Number of lines per image.
font_size	int	36	Font size for rendered text.
text_colors	List[str]	["#2f2f2f", "black", "#404040"]	List of possible text colors (hex or names).
letter_spacing_prob	float	0.4	Probability of applying random letter spacing.
margin_x, margin_y	Tuple[float, float]	(0.5, 1.5)	Padding factors for horizontal/vertical margins, as a multiple of character width/height.
blur_probs	Dict[str, float]	{gaussian: 0.3, custom_blurs: 0.6}	Probabilities for applying Gaussian blur and custom blurs (motion, bokeh).
moire_prob	float	0.3	Probability of overlaying a moire pattern.
opacity_prob	float	0.3	Probability of applying random opacity to the image.
opacity_range	Tuple[int, int]	(150, 210)	Range of alpha values for random opacity.
brightness_range	Tuple[float, float]	(0.7, 1.2)	Range for random brightness adjustment.
perspective_transform_prob	float	0.3	Probability of applying a random perspective transformation.
random_crop_width_range	Tuple[float, float]	(0.008, 0.01)	Range for random cropping width as a fraction of image width.
random_crop_height_range	Tuple[float, float]	(0.01, 0.1)	Range for random cropping height as a fraction of image height.
random_resize_factor_range	Tuple[float, float]	(0.9, 1.0)	Range for random resizing factor.
random_stretch_factor_range	Tuple[float, float]	(0.1, 0.3)	Range for random vertical stretch/compression.

Parameter Explanations:

• max_num_words: Controls the upper limit of words per generated sample.
• num_lines: Generates multi-line text images for more realistic OCR scenarios.
• font_size: Sets the base font size; actual rendered size may vary depending on padding and image size.
• text_colors: Randomly selects from this list for each sample.
• letter_spacing_prob: With this probability, random spacing is added between letters to simulate varied printing.
• margin_x/margin_y: Determines the amount of padding around text. For example, margin_x=(0.5, 1.5) means horizontal margins are randomly chosen between 0.5x–1.5x the character width.
• blur_probs: Controls how often Gaussian or custom (motion, bokeh) blurs are applied.
• moire_prob: Adds moire patterns to mimic scanning artifacts.
• opacity_prob/opactiy_range: Simulates faded or transparent text by randomly adjusting alpha.
• brightness_range: Randomly brightens or darkens the image.
• perspective_transform_prob: Applies perspective warping to simulate camera angles or skewed scans.
• random_crop_width/height_range: Randomly crops the image edges to simulate imperfect scans.
• random_resize_factor_range: Randomly resizes the image for scale variation.
• random_stretch_factor_range: Randomly stretches or compresses the image vertically.

Example:

augmentation = {
    "max_num_words": 8,
    "num_lines": 2,
    "font_size": 40,
    "blur_probs": {"gaussian": 0.5, "custom_blurs": 0.7},
    "moire_prob": 0.4,
}
odt = ODT(augmentation_config=augmentation)

---

Output Images and Padding Strategy

All generated images are created with the specified output_image_size (width, height). If this parameter is set to None, the image will use its natural size based on the rendered text and font. When resizing is needed, the toolkit uses a resize and pad strategy:

• The image is resized to fit within the target size while preserving the aspect ratio.
• Any remaining space is padded with zeros (black) to reach the exact output size.
• Padding is applied either at the bottom or right, depending on the aspect ratio.

This ensures that all images in your dataset have a consistent size, suitable for training deep learning models.

---

Output Format of Training and Testing Datasets

When you generate a dataset using generate_training_data, the toolkit creates:

• images/ directory: Contains all generated images (PNG format by default).
• gt.txt: Ground truth file mapping each image filename to its corresponding text label.

Example gt.txt entry:

images/000001.png	The quick brown fox
images/000002.png	13/01/2023

• The format is: <relative_path_to_image>\t<text_label> (tab-separated).
• Both train/ and test/ directories are created, each with their own images and gt.txt file, according to the train_test_ratio.

---

Usage Examples

Generate a Single Image

odt = ODT(language="en")
text, img = odt.generate_single_image()
img.save("test.png")

Generate a Full Dataset

odt = ODT(language="en", output_image_size=(128, 32), num_workers=4)
odt.generate_training_data(num_samples=1000)

Visualize Font Catalog

odt.visualize_font_catalog(save_dir="font_catalog", chunk_size=10)

Take a look at example.py for example usage.

---

Module Structure

ocr_data_toolkit/
├── odt.py                  # Main toolkit interface (ODT class)
├── generators/
│   ├── en.py               # English text-image generator (ENGenerator)
│   └── ...                 # Other language generators
├── helper/
│   ├── augmentation.py     # Augmentation operations (Augmentation class)
│   └── utils.py            # Utility functions (image, fonts, backgrounds)
├── common/
│   └── config.py           # Config and AugmentationConfig classes
├── data/                   # Sample data (backgrounds, fonts, vocabularies)
└── ...

• ODT class: Main entry point for data generation, configuration, and utilities.
• Augmentation class: Implements all augmentation methods (noise, blur, moire, distortion, etc).
• generators.py: Contains text-image synthesis logic for different languages.
• utils.py: Helper functions for resizing, font selection, backgrounds, etc.
• config.py: Centralizes default and user configuration.

---

Extending and Customization

• Add More Languages: Implement a new generator class in generators/ and update config.
• Add New Augmentations: Extend the Augmentation class with your custom method.
• Customize Pipelines: Modify or subclass ODT or ENGenerator for advanced use cases.

---

Contributing

We welcome and encourage contributions of all kinds!

• Add Multilingual Support: If you want to support a new language, simply add a new generator class in generators/ and update the config with the appropriate fonts and vocabulary.
• New Augmentations: Propose or implement new augmentation methods in helper/augmentation.py.
• Bugfixes & Improvements: If you spot a bug or have an idea for improvement, open an issue or a pull request.
• Documentation: Help us improve the docs and examples for new users.

Please:

• Fork the repo and create a branch for your feature or bugfix.
• Add tests and documentation for new features.
• Open a pull request describing your changes.

---

License

This project is licensed under the MIT License. See the LICENSE file for details.

---

Acknowledgements

• Developed by Muhammad Nouman Ahsan - LinkedIn
• Inspired by real-world OCR data challenges and research needs

---

For questions, suggestions, or support, please open an issue or contact the author at [e-mail].
