Open OTK (Open Ollama Toolkit)

An intelligent Python framework for local LLM orchestration, hybrid retrieval-augmented generation, automated evaluation, and pipeline composition with Ollama.

Overview

Open OTK is a research-grade framework that transforms Ollama from a simple local LLM runner into a full orchestration platform. It provides:

• Pipeline Composition Engine — DAG-based multi-step LLM workflows with parallel execution
• Hybrid RAG Engine — BM25 sparse + HNSW dense retrieval with Reciprocal Rank Fusion and LLM reranking
• LLM-as-Judge Evaluation — Automated quality assessment with statistical significance testing (t-test, bootstrap CI, Cohen's d)
• Intelligent Model Router — Task-aware model selection with epsilon-greedy learning from performance history
• Structured Output Engine — Guaranteed JSON/Pydantic output with schema validation and self-correction
• REST API Server — FastAPI server with WebSocket streaming, session management, and rate limiting
• Resource Profiler — Tokens/sec, TTFT, CPU/RAM/GPU telemetry with SQLite persistence
• Desktop GUI — Modern Tkinter application with sidebar navigation, evaluation lab, template generation, and chat interface

Everything runs fully offline with no cloud dependencies.

Architecture

flowchart TD
    %% REST API Layer
    REST[/"REST API Layer (FastAPI)"/]
    REST -->|"/v1/generate, /v1/chat, /v1/stream(WS), /v1/rag/query, /v1/pipeline/run, /v1/evaluate, /v1/structured"| CORE

    %% Core Engine
    CORE["Core Engine (otk package)"]
    CORE --> PIPE["Pipeline Composition Engine (DAG)"]
    CORE --> MODEL["Model Router (ε-greedy)"]
    CORE --> STRUCT["Structured Output Engine (JSON/Pyda)"]

    PIPE --> EVAL["Evaluation Framework (LLM Judge)"]
    MODEL --> RESOURCE["Resource Profiler (telemetry)"]
    STRUCT --> CLIENT["OllamaClient (retry, metadata)"]

    %% Hybrid RAG Engine
    CORE --> RAG["Hybrid RAG Engine"]
    RAG --> SEM["Semantic Chunker"]
    RAG --> BM25["BM25 Sparse Index"]
    RAG --> HNSW["HNSW Dense Index (or NumPy fallback)"]

    BM25 --> RRF["Reciprocal Rank Fusion (RRF)"]
    HNSW --> RRF
    SEM --> RRF

    RRF --> RERANK["LLM Reranker"]

Installation

Prerequisites

1. Install Ollama
2. Pull at least one model: ollama pull gemma4
3. Ensure Ollama is running

Install from PyPI

pip install open-otk

Install from Source

git clone https://github.com/abidhasanrafi/open-otk.git
cd open-otk
pip install -e .

Optional Dependencies

Install extras for specific features:

pip install open-otk[rag]          # HNSW vector index (hnswlib)
pip install open-otk[server]       # FastAPI REST API server
pip install open-otk[eval]         # scipy for statistical tests
pip install open-otk[structured]   # Pydantic model validation
pip install open-otk[tokenizer]    # tiktoken for accurate token counts
pip install open-otk[all]          # Everything above
pip install open-otk[dev]          # pytest, black, flake8 for development

Quick Start

Generate Text

from otk import OllamaClient

client = OllamaClient()
response = client.generate("gemma4", "Explain quantum computing in one paragraph")
print(response)

Chat Session with History

from otk import ChatSession

session = ChatSession("gemma4", system_message="You are a helpful assistant")
print(session.send("What is machine learning?"))
print(session.send("How does it differ from deep learning?"))  # remembers context

Streaming Responses

from otk import OllamaClient

client = OllamaClient()
for chunk in client.stream_generate("gemma4", "Write a short story about AI"):
    print(chunk, end="", flush=True)

Core Modules

Pipeline Composition Engine

Build multi-step LLM workflows as directed acyclic graphs. Nodes execute in topological order with automatic parallelization of independent branches.

from otk import PipelineBuilder, LLMNode, TransformNode

pipeline = (PipelineBuilder("research")
    .add_node(LLMNode("extract", model="mistral",
                       prompt_template="Extract key facts from: {input}"))
    .add_node(LLMNode("analyze", model="gemma4",
                       prompt_template="Analyze these facts: {extract.output}"))
    .add_node(TransformNode("combine",
                             func=lambda ctx: f"{ctx['extract.output']}\n\n{ctx['analyze.output']}"))
    .add_edge("extract", "analyze")
    .add_edge("analyze", "combine")
    .build())

result = pipeline.execute(input="<document text>")
print(result.outputs["combine"])

Key features:

• Topological sort via Kahn's algorithm for execution ordering
• ThreadPoolExecutor for parallel branch execution
• ConditionalNode for lambda-predicate branching
• ReduceNode for merging multiple node outputs
• Per-node timing, token count, and retry tracking

Hybrid RAG Engine

Production-grade retrieval-augmented generation combining sparse and dense retrieval with LLM reranking.

from otk import HybridRAG

rag = HybridRAG(embedding_model="nomic-embed-text", reranker_model="mistral")

rag.add_documents([
    "Python was created by Guido van Rossum in 1991.",
    "JavaScript was created by Brendan Eich in 1995.",
    "Rust was first released in 2010 by Mozilla.",
])

answer, sources = rag.query("Who created Python?", model="gemma4")
print(answer)

Components:

• RecursiveChunker — semantic text splitting respecting sentence/paragraph boundaries
• BM25Index — Okapi BM25 sparse retrieval with inverted index
• DenseIndex — HNSW approximate nearest neighbor search (falls back to brute-force NumPy if hnswlib is not installed)
• reciprocal_rank_fusion() — merges sparse and dense rankings with tunable k parameter
• LLM cross-encoder reranker for final relevance scoring

LLM-as-Judge Evaluation Framework

Automated quality assessment of LLM outputs across multiple dimensions with statistical rigor.

from otk import LLMJudge, JudgeConfig, EvaluationDimension

judge = LLMJudge(JudgeConfig(
    model="gemma4",
    dimensions=[EvaluationDimension.COHERENCE,
                EvaluationDimension.RELEVANCE,
                EvaluationDimension.FACTUALITY],
    trials=3
))

scores = judge.evaluate(
    prompt="Explain gravity",
    response="Gravity is the force that attracts objects toward each other..."
)
for dim, score in scores.items():
    print(f"{dim}: {score.mean:.1f}/5 (±{score.std:.2f})")

Statistical analysis:

• Paired t-test for mean score differences between models
• Bootstrap confidence intervals (1000 resamples)
• Cohen's d effect size
• Full EvaluationReport with export capabilities

Intelligent Model Router

Automatically selects the best local model for a given task using prompt classification and historical performance data.

from otk import ModelRouter

router = ModelRouter()
decision = router.route("Write a Python function to sort a list")
print(f"Selected: {decision.model} (task: {decision.task_type})")
response = decision.execute()

How it works:

1. TaskClassifier identifies task type (CODE, CREATIVE, FACTUAL_QA, SUMMARIZATION, etc.) using keyword boundary matching
2. CapabilityMatrix scores each model's suitability per task type
3. PerformanceHistory (SQLite-backed) tracks latency and quality over time
4. Epsilon-greedy selection balances exploration vs exploitation
5. Automatic fallback chain if the selected model fails

Structured Output Engine

Extract guaranteed JSON or typed objects from LLM responses with schema validation and self-correction.

from otk import StructuredGenerator

gen = StructuredGenerator(model="mistral")

result = gen.generate(
    prompt="Extract info: John Smith, 30 years old, engineer at Google",
    schema={"name": "str", "age": "int", "company": "str"}
)
# result = {"name": "John Smith", "age": 30, "company": "Google"}

Features:

• JSON schema validation with automatic type coercion
• Auto-retry loop: re-prompts the LLM with error context on parse failure (up to 3 retries)
• Optional Pydantic model validation when pydantic is installed

FastAPI REST API Server

Expose all OTK capabilities as a REST API with OpenAPI documentation.

# Start the server
otk-server
# or
python -m otk.server

Endpoints:

Method	Path	Description
POST	/v1/generate	Text generation with model routing
POST	/v1/chat	Chat with session management
WS	/v1/stream	WebSocket streaming responses
POST	/v1/rag/query	Hybrid RAG query
POST	/v1/rag/ingest	Add documents to RAG index
POST	/v1/structured	Structured output generation
POST	/v1/evaluate	Run evaluation suite
GET	/v1/models	List models with capability scores
GET	/v1/health	Health check
GET	/v1/metrics	Performance telemetry

Includes CORS support, token-bucket rate limiting, and session-based chat with configurable TTL.

Resource Profiler & Telemetry

Monitor inference performance and system resources.

from otk import InferenceProfiler, OllamaClient

client = OllamaClient()
profiler = InferenceProfiler()

with profiler.profile(client, "gemma4", "Hello world") as metrics:
    pass

print(f"Tokens/sec: {metrics.tokens_per_second:.1f}")
print(f"TTFT: {metrics.time_to_first_token:.3f}s")
print(f"RAM: {metrics.ram_usage_mb:.0f} MB")

All metrics are persisted to SQLite via TelemetryStore for longitudinal analysis.

Desktop GUI Application

Launch the modern Tkinter GUI with sidebar navigation:

otk                # if installed via pip
python -m otk      # always works
python otk.py      # from source

Features:

• Dashboard — Installed models count, Ollama status, quick actions
• Chat — Conversational interface with bubble messages and animated thinking indicator
• Browse Models — View and inspect all installed models
• Manage Models — Pull, delete, and manage Ollama models
• Evaluation Lab — Multi-mode benchmarking: speed benchmark, model comparison, quality evaluation (LLM-as-Judge), and A/B testing with configurable dimensions and model selection
• Templates — Interactive wizard to generate starter project files

Template Generator

Generate ready-to-run project files from the GUI or programmatically:

Template	Description
Simple Chat	Basic conversational interface
Streaming Chat	Real-time token-by-token responses
Custom Model	Hooks, callbacks, and preprocessing
Experimentation	Model comparison and benchmarking
Integration	Ready for embedding in larger applications
Tkinter GUI	Desktop chat app with bubble messages and thinking animation
Advanced Tkinter GUI	Sidebar-navigation app with system prompt editor, temperature control, and content generation

Examples

The examples/ directory contains ready-to-run scripts:

Example	Description
simple_chat.py	Basic chat interaction
streaming_chat.py	Real-time streaming responses
chat_session.py	Interactive chat with history
model_manager.py	Model management operations
embeddings.py	Generate and compare embeddings
model_comparison.py	Compare different models
advanced_model_handling.py	Response format handling
efficient_response_processing.py	Optimized response processing
creative_integrations.py	Real-world integration patterns
experimentation_playground.py	Interactive experimentation

python examples/simple_chat.py

Starter Templates

Pre-built application templates in templates/:

python templates/chatbot/simple_chatbot.py       # Complete chatbot
python templates/rag_system/simple_rag.py         # RAG question-answering
python templates/text_analyzer/text_analyzer.py   # Text analysis
python templates/code_assistant/code_assistant.py # Coding assistant

Testing

Run the full test suite (90 tests):

pip install pytest pytest-cov
python -m pytest tests/ -v

With coverage:

python -m pytest tests/ --cov=otk --cov-report=term-missing

Test structure:

File	Coverage
test_client.py	OllamaClient retry, metadata, batch embeddings
test_pipeline.py	DAG construction, execution order, parallel branches
test_rag.py	BM25 scoring, dense indexing, RRF, chunking
test_evaluation.py	LLM judge scoring, statistical analysis, reports
test_router.py	Task classification, model selection, fallback
test_structured.py	Schema validation, JSON extraction, type coercion
test_profiler.py	Metric collection, SQLite persistence

All tests use mock_ollama.py to run without a live Ollama instance.

Project Structure

open-otk/
├── otk/                        # Core Python package
│   ├── __init__.py             # Public API exports (v2.0.0)
│   ├── client.py               # OllamaClient with retry and metadata
│   ├── chat.py                 # ChatSession with token-budget trimming
│   ├── models.py               # ModelManager
│   ├── response_handlers.py    # Auto response processing for thinking models
│   ├── customization.py        # ModelBuilder, hooks, presets
│   ├── experimentation.py      # Model comparison and benchmarking
│   ├── utils.py                # Token estimation, chunking, formatting
│   ├── pipeline.py             # DAG pipeline composition engine
│   ├── rag.py                  # Hybrid RAG (BM25 + HNSW + RRF)
│   ├── evaluation.py           # LLM-as-Judge evaluation framework
│   ├── router.py               # Task-aware model router
│   ├── structured.py           # Structured output with JSON schema
│   ├── server.py               # FastAPI REST API server
│   ├── profiler.py             # Resource profiler and telemetry
│   └── __main__.py             # python -m otk entry point
├── tests/                      # Test suite (90 tests)
│   ├── conftest.py             # Shared fixtures
│   ├── mock_ollama.py          # Mock OllamaClient for offline testing
│   ├── test_client.py
│   ├── test_pipeline.py
│   ├── test_rag.py
│   ├── test_evaluation.py
│   ├── test_router.py
│   ├── test_structured.py
│   └── test_profiler.py
├── examples/                   # Ready-to-run example scripts
├── templates/                  # Starter application templates
│   ├── chatbot/
│   ├── rag_system/
│   ├── text_analyzer/
│   └── code_assistant/
├── docs/                       # Additional documentation
├── otk.py                      # Desktop GUI application
├── setup.py                    # Package configuration
├── requirements.txt            # Core dependencies
├── LICENSE                     # MIT License
└── CONTRIBUTORS.md             # Project contributors

API Reference

OllamaClient

client = OllamaClient(host="http://localhost:11434")

client.generate(model, prompt, system=None, temperature=0.7)
client.generate_with_metadata(model, prompt, ...)   # returns full Ollama response dict
client.chat(model, messages, temperature=0.7)
client.chat_with_metadata(model, messages, ...)
client.stream_generate(model, prompt)                # yields chunks
client.stream_chat(model, messages)                  # yields chunks
client.embeddings(model, text)                       # returns embedding vector
client.batch_embeddings(model, texts)                # batch embedding
client.is_running()                                  # health check

ChatSession

session = ChatSession(
    model="gemma4",
    system_message="You are helpful",
    temperature=0.7,
    max_history=50,
    max_history_tokens=4096,    # token-budget trimming
    auto_process=True           # auto-clean thinking model responses
)

session.send("Hello")                   # returns response string
session.send_stream("Tell me more")     # yields chunks
session.get_last_thinking()             # reasoning from thinking models
session.fork()                          # branch conversation
session.clear_history()
session.export_history("chat.json")
session.load_history("chat.json")

ModelManager

manager = ModelManager()

manager.list_models()
manager.pull_model("gemma4", stream=True)
manager.delete_model("old-model")
manager.model_exists("gemma4")
manager.show_model_info("gemma4")
manager.recommend_models()

Response Processing

from otk import AutoModelHandler, clean_thinking_tags, ModelBuilder, HookType

handler = AutoModelHandler()
processed = handler.process_response(raw_text, "deepseek-r1")

clean_text, thinking = clean_thinking_tags(response)

model = (ModelBuilder("gemma4")
         .with_preset("creative")
         .with_temperature(0.85)
         .with_hook(HookType.POST_PROCESS, my_logger)
         .build())

Troubleshooting

otk command not recognized:

python -m otk       # always works without PATH setup

Ollama not running:

# Windows: Start the Ollama application
# Linux/Mac: ollama serve

Model not found:

ollama pull gemma4
ollama list          # see installed models

Import errors:

pip install open-otk
# or from source:
pip install -r requirements.txt

License

MIT License — see LICENSE for details.

Author

Md. Abid Hasan Rafi

• GitHub: @abidhasanrafi
• Email: [e-mail]
• Documentations: OTK Docs

Links

• Project Repository
• Report Issues
• Ollama
