openframe-core 2.0.0

OpenFrame Microservice Suite - platform kernel. Contracts, testing utilities, plugin registry, and composition root.

Documentation · Quick Start · PyPI · Changelog

---

openframe-core is the foundation package of the OpenFrame Microservice Development Suite. It defines the structural contracts, telemetry primitives, and shared utilities that every other package in the ecosystem depends on.

Every package in the OpenFrame ecosystem pins openframe-core>=1.0,<2. The major version is the stability contract for the entire ecosystem.

---

What's inside

Module	Exports
openframe.core.exceptions	AdapterError · AdapterConnectionError · AdapterQueryError · AdapterNotFoundError · AdapterConfigurationError · AdapterTimeoutError
openframe.core.config	BaseAdapterSettings — Pydantic BaseSettings subclass all adapters inherit
openframe.core.ports	BaseRepository[T] · BaseProducer[T] · BaseConsumer[T] — runtime_checkable Protocols
openframe.core.health	HealthCheck — ping() and is_ready() Protocol
openframe.core.telemetry	setup_telemetry() · get_tracer() · get_meter() · record_lifecycle_event()
openframe.core.tracing	TracingProxy — zero-code async telemetry sidecar
openframe.core.middleware	TelemetryMiddleware — pure ASGI middleware
openframe.core.middleware.types	ASGIScope · ASGIMessage · Receive · Send · ASGIApp

---

Installation

pip install openframe-core

# With dev dependencies (pytest, pytest-asyncio, httpx)
pip install "openframe-core[dev]"

---

Quick start

Exceptions — single catch point across all adapters

from openframe.core.exceptions import AdapterError, AdapterNotFoundError, AdapterQueryError

# In an adapter — wrap driver exceptions before they leave
try:
    row = await conn.fetchrow(query, entity_id)
except SomeDriverError as exc:
    raise AdapterQueryError(
        "Query failed",
        adapter="postgres",
        operation="get",
        cause=exc,
    ) from exc

# In a service — one catch point regardless of which adapter is wired in
try:
    entity = await repo.get(entity_id)
except AdapterNotFoundError:
    return None
except AdapterError as exc:
    logger.error("Adapter failure: %s", exc)   # [postgres.get] message — caused by: ...
    raise

Config — env vars validated at startup, not first request

from openframe.core.config import BaseAdapterSettings

class PostgresSettings(BaseAdapterSettings):
    database_url: str     # reads DATABASE_URL — required
    pool_size: int = 10   # reads POOL_SIZE — optional, default 10

# Raises pydantic_core.ValidationError immediately if DATABASE_URL is not set
settings = PostgresSettings()

Ports — structural contracts, no inheritance required

from openframe.core.ports import BaseRepository

class PostgresItemRepository:
    async def get(self, entity_id: str) -> Item | None: ...
    async def list(self, limit: int, offset: int) -> tuple[list[Item], int]: ...
    async def create(self, entity: Item) -> Item: ...
    async def update(self, entity: Item) -> Item | None: ...
    async def delete(self, entity_id: str) -> bool: ...

# Structural — no BaseRepository inheritance needed
assert isinstance(PostgresItemRepository(), BaseRepository)   # True

Telemetry — OTel bootstrap in one call

from contextlib import asynccontextmanager
from openframe.core.telemetry import setup_telemetry, record_lifecycle_event

@asynccontextmanager
async def lifespan(app):
    setup_telemetry()                      # idempotent — safe to call multiple times
    record_lifecycle_event("cold_start")   # platform-agnostic lifecycle counter
    yield

Configure via environment variables — no vendor lock-in:

export OTEL_EXPORTER_OTLP_ENDPOINT="https://otlp.example.com"
export OTEL_EXPORTER_OTLP_HEADERS="Authorization=Basic <base64_token>"
export OTEL_SERVICE_NAME="my-service"
export OPENFRAME_ENV="prod"

Modal users: map MODAL_ENV → OPENFRAME_ENV in your configure_env_vars() helper.

TracingProxy — spans without touching service code

from openframe.core.tracing import TracingProxy

raw_repo = PostgresItemRepository(settings)
traced_repo = TracingProxy(raw_repo, prefix="repository.item")

# traced_repo.get(...)    → span "repository.item.get"
# traced_repo.create(...) → span "repository.item.create"
# The service layer never knows telemetry exists.

Safe for reconnecting adapters — the wrapped method is resolved fresh on every call, never snapshotted.

Middleware — pure ASGI, framework-agnostic

from openframe.core.middleware import TelemetryMiddleware

# FastAPI
app = FastAPI(lifespan=lifespan)
app.add_middleware(TelemetryMiddleware)

# Bare ASGI
app = TelemetryMiddleware(my_asgi_app)

Important: do not call setup_telemetry() inside the middleware. Call it once in your lifespan handler. The middleware uses get_tracer() and get_meter() directly against whatever providers are currently set.

Instruments five HTTP metrics per request: http.server.request.count, http.server.request.duration (s), http.server.active_requests, http.server.error.count, http.server.response.size. Injects x-session-id on every response.

---

Environment variables

Variable	Default	Description
OTEL_EXPORTER_OTLP_ENDPOINT	—	OTLP base URL. When absent, no-op providers are used — no errors, no export.
OTEL_EXPORTER_OTLP_HEADERS	—	Auth headers. Format: Authorization=Basic <token>
OTEL_SERVICE_NAME	openframe	Service name tag on all telemetry
OTEL_SERVICE_VERSION	1.0.0	Service version tag
OTEL_METRIC_EXPORT_INTERVAL_MS	15000	Metric export interval in milliseconds
OPENFRAME_ENV	dev	Deployment environment: dev · feat · prod

---

Running tests

pip install -e ".[dev]"
pytest tests/ -v

112 tests across 8 modules. All run in under 1 second — no network calls, no external services.

# Smoke test
python -c "from openframe.core.ports import BaseRepository; print('openframe-core OK')"

---

Design decisions

Why Adapter prefix on exceptions? ConnectionError and TimeoutError are Python stdlib built-ins. Using the same names would shadow them silently. AdapterConnectionError and AdapterTimeoutError are unambiguous.

Why super().__init__(message) only? Exception.__str__ returns a tuple repr when multiple args are passed. Passing only the message keeps str(exc) readable: [postgres.get] entity not found.

Why does TelemetryMiddleware not call setup_telemetry()? The OTel SDK's set_tracer_provider() is protected by a once-guard — subsequent calls are silently rejected. Calling setup_telemetry() inside the middleware overwrites the provider set at startup (including test fixture providers), causing spans to be dropped silently.

Why is TracingProxy safe for reconnecting adapters? The closure resolves the wrapped method via getattr(wrapped, name) on every invocation — never from a snapshot captured at first access. When a Postgres pool or Redis client replaces its own methods after reconnect, the proxy calls the new methods automatically.

---

Ecosystem

Package	Install	Description
openframe-adapters	pip install openframe-adapters[postgres]	DB + queue adapters — Postgres, Redis, Mongo, Kafka, NATS, and more
openframe-protocol	pip install openframe-protocol[sse]	WebSocket · SSE · gRPC · MCP · webhooks
openframe-infra	pip install openframe-infra[storage]	Storage · auth · secrets · observability · feature flags
openframe-ai	pip install openframe-ai[serving]	LangChain · LlamaIndex · CrewAI · model serving · training
openframe-suite	pip install openframe-suite[all]	Full platform — installs everything

All packages pin openframe-core>=1.0,<2.

---

Documentation

Full documentation — architecture, module reference, runbooks, developer guide — at:

furious-meteors.github.io/openframe-core

Section	Contents
System Overview	Seven-module model, dependency order, key design properties
Package Journey	How a request flows from template wiring through adapter to response
ADRs	Five architectural decision records
Module Reference	Every public class, method, parameter, return type, and raises
Runbooks	Six operational failure scenarios with recovery steps
Developer Guide	Quick start, how it works, first code change, debugging

---

License

MIT — see LICENSE.
