openioe 0.1.3

Open IoE

Open IoE

Open IoE is a simple IoT platform to operate IoT devices.

There are two options available,

1. API creation and Consumption (REST APIs)
2. Python Library (Client)

---

1. API Creation for IoT Device and Its Consumption

Users are expected to take these steps,

1. Add device using Link <Add Device>
2. (Optional) Verify device data or API using Link <Verify Device>
3. Embed the API in your application using Client Code/API

Visit the OpenIoE 1.0 web portal at https://v3.openioe.in

API List:

No	API	Description	Type	Example
1	showvalue	To get hardware value from web service.	http get	<endpoint>/showvalue/2/433
2	updatevalue	Update the hardware value passed as a parameter	http get	<endpoint>/updatevalue/2/433/2
3	showjson	To get hardware JSON from web service.	http get	<endpoint>/showjson/2/433
4	updatejson	Update the hardware JSON passed as parameter	http post	<endpoint>/updatejson/2/433 <Data>
5	showxml	To get hardware XML file from web service.	http get	<endpoint>/showxml/2/433
6	updatexml	Update the hardware XML passed as parameter	http post	<endpoint>/updatexml/2/433 <Data>

---

2. Python Library

Users are expected to take these steps,

1. Install Python Library
   pip install openioe
2. Write the client code using the following methods

Method List:

No	Method	Description	Example
1	ReadAPI	To read the sensor data from multiple nodes	from openioe.openioe_apis import * oi=openioe_apis() oi.UserIDPinAPIKeys=[[2, 433], [3, 986]] SensorData,ResposeCode=oi.ReadAPI() print(SensorData) print(ResposeCode)
2	WriteAPI	To modify the control signal at multiple nodes	from openioe.openioe_apis import * oi=openioe_apis() oi.UserIDPinAPIKeys=[[2, 433], [3, 986]] <p>oi.Data=[1,2] Confirmation,ResposeCode=oi.ReadAPI() print(Confirmation) print(ResposeCode)
3	Developer	To display the developer information	from openioe.openioe_apis import * oi=openioe_apis() oi.Developer()

---

Developers

Thanks and Regards,

Venkataswamy R

Assistant Professor,

Department of Electrical and Electronics Engineering,

School of Engineering and Technology,

Christ (Deemed to be University),

Bengaluru-560074, India

080-4012-9961 (O)   [phone]  venkatswamy.in
