OPNsense API Client

This is a Python3 client for interacting with the official OPNsense API.

It enables easy management and automation of OPNsense firewalls.

The base-code is a Fork of this OPNsense Ansible-Collection that was refactored for use within raw Python.

This can be useful if you want to automate your Infrastructure and do not use Ansible.

An interactive CLI interface might be added later on.

Install

pip install oxl-opnsense-client

Get to know the available modules:

• Documentation
• Module list
• Ansible Docs

Contribute

The codebase of this library will be automatically synced with the upstream code of the OPNsense Ansible-Module!

Thus, new features (and feature-requests) should be made there.

Feel free to report issues/bugs, take part in discussions and add/extend tests.

Note: Only the API-enabled functionalities can be implemented.

Usage

Documentation, Ansible OPNsense-Collection Docs

from oxl_opnsense_client import Client

with Client(
    firewall='192.168.10.20',
    port=443,  # default
    credential_file='/tmp/.opnsense.txt',
    # token='0pWN/C3tnXem6OoOp0zc9K5GUBoqBKCZ8jj8nc4LEjbFixjM0ELgEyXnb4BIqVgGNunuX0uLThblgp9Z',
    # secret='Vod5ug1kdSu3KlrYSzIZV9Ae9YFMgugCIZdIIYpefPQVhvp6KKuT7ugUIxCeKGvN6tj9uqduOzOzUlv',
) as c:
    c.test()
    # True

    ### CHECK SUPPORTED MODULES ###
    c.list_modules()
    # ['acme_account', 'acme_action', 'acme_certificate', 'acme_general', 'acme_validation', 'alias', 'alias_multi', 'alias_purge', 'bind_acl', 'bind_blocklist', 'bind_domain', 'bind_general', 'bind_record', 'bind_record_multi', 'cron', 'dhcp_controlagent', 'dhcp_general', 'dhcp_reservation', 'dhcp_subnet', 'dhcrelay_destination', 'dhcrelay_relay', 'dnsmasq_boot', 'dnsmasq_domain', 'dnsmasq_general', 'dnsmasq_host', 'dnsmasq_option', 'dnsmasq_range', 'dnsmasq_tag', 'frr_bfd_general', 'frr_bfd_neighbor', 'frr_bgp_as_path', 'frr_bgp_community_list', 'frr_bgp_general', 'frr_bgp_neighbor', 'frr_bgp_peer_group', 'frr_bgp_prefix_list', 'frr_bgp_redistribution', 'frr_bgp_route_map', 'frr_diagnostic', 'frr_general', 'frr_ospf3_general', 'frr_ospf3_interface', 'frr_ospf3_network', 'frr_ospf3_prefix_list', 'frr_ospf3_redistribution', 'frr_ospf3_route_map', 'frr_ospf_general', 'frr_ospf_interface', 'frr_ospf_network', 'frr_ospf_prefix_list', 'frr_ospf_redistribution', 'frr_ospf_route_map', 'frr_rip', 'gateway', 'group', 'hasync_general', 'hasync_service', 'ids_action', 'ids_general', 'ids_policy', 'ids_policy_rule', 'ids_rule', 'ids_ruleset', 'ids_user_rule', 'interface_bridge', 'interface_gif', 'interface_gre', 'interface_lagg', 'interface_loopback', 'interface_vip', 'interface_vlan', 'interface_vxlan', 'ipsec_auth_local', 'ipsec_auth_remote', 'ipsec_cert', 'ipsec_child', 'ipsec_connection', 'ipsec_general', 'ipsec_manual_spd', 'ipsec_pool', 'ipsec_psk', 'ipsec_vti', 'list', 'monit_alert', 'monit_service', 'monit_test', 'nat_one_to_one', 'nat_source', 'neighbor', 'nginx_general', 'nginx_upstream_server', 'openvpn_client', 'openvpn_client_override', 'openvpn_server', 'openvpn_static_key', 'openvpn_status', 'package', 'postfix_address', 'postfix_domain', 'postfix_general', 'postfix_headercheck', 'postfix_recipient', 'postfix_recipientbcc', 'postfix_sender', 'postfix_senderbcc', 'postfix_sendercanonical', 'privilege', 'raw', 'reload', 'route', 'rule', 'rule_interface_group', 'rule_multi', 'rule_purge', 'savepoint', 'service', 'shaper_pipe', 'shaper_queue', 'shaper_rule', 'snapshot', 'syslog', 'system', 'unbound_acl', 'unbound_dnsbl', 'unbound_dot', 'unbound_forward', 'unbound_general', 'unbound_host', 'unbound_host_alias', 'user', 'webproxy_acl', 'webproxy_auth', 'webproxy_cache', 'webproxy_forward', 'webproxy_general', 'webproxy_icap', 'webproxy_pac_match', 'webproxy_pac_proxy', 'webproxy_pac_rule', 'webproxy_parent', 'webproxy_remote_acl', 'webproxy_traffic', 'wireguard_general', 'wireguard_peer', 'wireguard_server', 'wireguard_show']

    ### CHECK MODULE ARGUMENTS / SPECS ###
    c.module_specs('route')
    # {'specs': {'gateway': {'type': 'str', 'required': True, 'aliases': ['gw'], 'description': 'Specify a valid existing gateway matching the networks ip protocol'}, 'network': {'type': 'str', 'required': True, 'aliases': ['nw', 'net'], 'description': 'Specify a valid network matching the gateways ip protocol'}, 'description': {'type': 'str', 'required': False, 'aliases': ['desc']}, 'match_fields': {'type': 'list', 'required': False, 'elements': 'str', 'description': "Fields that are used to match configured routes with the running config - if any of those fields are changed, the module will think it's a new route", 'choices': ['network', 'gateway', 'description'], 'default': ['network', 'gateway']}, 'reload': {'type': 'bool', 'required': False, 'default': True, 'aliases': ['apply'], 'description': 'If the running config should be reloaded/applied on change - will take some time'}, 'state': {'type': 'str', 'required': False, 'choices': ['present', 'absent'], 'default': 'present'}, 'enabled': {'type': 'bool', 'required': False, 'default': True}}}
    c.module_specs('wireguard_show', stdout=True)
    # prints in pretty-JSON

    ### CREATE ENTRY ###

    c.run_module('syslog', params={'target': '192.168.0.1', 'port': 5303})
    # {'error': None, 'result': {'changed': True, 'diff': {'after': {'uuid': None, 'rfc5424': False, 'enabled': True, 'target': '192.168.0.1', 'transport': 'udp4', 'facility': [], 'program': [], 'level': ['alert', 'crit', 'emerg', 'err', 'info', 'notice', 'warn'], 'certificate': '', 'port': 5303, 'description': ''}}}}
    c.run_module('list', params={'target': 'syslog'})
    # {'error': None, 'result': {'changed': False, 'data': [{'target': '192.168.0.1', 'enabled': True, 'transport': 'udp4', 'program': [], 'level': ['alert', 'crit', 'emerg', 'err', 'info', 'notice', 'warn'], 'facility': [], 'certificate': '', 'port': 5303, 'rfc5424': False, 'description': '', 'uuid': '32b1ce94-93d0-4d20-93a2-4fff12d12a54'}]}}

    ### UPDATING ENTRY ###

    c.run_module('syslog', params={'target': '192.168.0.1', 'port': 9941, 'match_fields': ['target']})
    # {'error': None, 'result': {'changed': True, 'diff': {'before': {'uuid': '4930e797-5111-4825-b5bb-c8e60f9d21d5', 'rfc5424': False, 'enabled': True, 'target': '192.168.0.1', 'transport': 'udp4', 'facility': [], 'program': [], 'level': ['alert', 'crit', 'emerg', 'err', 'info', 'notice', 'warn'], 'certificate': '', 'port': 5304, 'description': ''}, 'after': {'uuid': '4930e797-5111-4825-b5bb-c8e60f9d21d5', 'rfc5424': False, 'enabled': True, 'target': '192.168.0.1', 'transport': 'udp4', 'facility': [], 'program': [], 'level': ['alert', 'crit', 'emerg', 'err', 'info', 'notice', 'warn'], 'certificate': '', 'port': 9941, 'description': ''}}}}
    c.run_module('list', params={'target': 'syslog'})
    # {'error': None, 'result': {'changed': False, 'data': [{'target': '192.168.0.1', 'enabled': True, 'transport': 'udp4', 'program': [], 'level': ['alert', 'crit', 'emerg', 'err', 'info', 'notice', 'warn'], 'facility': [], 'certificate': '', 'port': 9941, 'rfc5424': False, 'description': '', 'uuid': '4930e797-5111-4825-b5bb-c8e60f9d21d5'}]}}

    ### DELETING ENTRY ###

    c.run_module('syslog', params={'target': '192.168.0.1', 'port': 5303, 'state': 'absent', 'match_fields': ['target']})
    # {'error': None, 'result': {'changed': True, 'diff': {'before': {'uuid': '2500dadc-ce43-4e23-994e-860516b0ef45', 'rfc5424': False, 'enabled': True, 'target': '192.168.0.1', 'transport': 'udp4', 'facility': [], 'program': [], 'level': ['alert', 'crit', 'emerg', 'err', 'info', 'notice', 'warn'], 'certificate': '', 'port': 5303, 'description': ''}}}}
    c.run_module('list', params={'target': 'syslog'})
    # {'error': None, 'result': {'changed': False, 'data': []}}
    c.run_module('syslog', params={'target': '192.168.0.1', 'port': 5303, 'state': 'absent'})
    # {'error': None, 'result': {'changed': False, 'diff': {}}}

    ### CHECK MODE (DRY-RUN) ###

    c.run_module('syslog', check_mode=True, params={'target': '192.168.0.1', 'port': 5303})
    # {'error': None, 'result': {'changed': True, 'diff': {'before': {'uuid': '7f3aba31-07ca-4cb9-b93d-dc442a5291c7', 'rfc5424': False, 'enabled': True, 'target': '192.168.0.1', 'transport': 'udp4', 'facility': [], 'program': [], 'level': ['alert', 'crit', 'emerg', 'err', 'info', 'notice', 'warn'], 'certificate': '', 'port': 5303, 'description': ''}}}}
    c.run_module('list', params={'target': 'syslog'})
    # {'error': None, 'result': {'changed': False, 'data': []}}
    c.run_module('syslog', params={'target': '192.168.0.1', 'port': 5303, 'state': 'absent'})
    # {'error': None, 'result': {'changed': False, 'diff': {}}}

Credentials

from oxl_opnsense_client import Client

# use the API credentials-file as downloaded from the WebUI
c = Client(firewall='<IP>', credential_file='/home/<YOU>/.opnsense.txt')

# use the token/key pair directly
c = Client(firewall='<IP>', token='<TOKEN>', secret='<SECRET>')

SSL Verification

from oxl_opnsense_client import Client

# provide the path to your custom CA public-key
c = Client(
    firewall='<IP>',
    credential_file='/home/<YOU>/.opnsense.txt',
    ssl_ca_file='/home/<YOU>/ca.crt',
)

# ONLY USE FOR TESTING PURPOSES => you can disable the certificate-verification
c = Client(
    firewall='<IP>',
    credential_file='/home/<YOU>/.opnsense.txt',
    ssl_verify=False,
)

Debug Output

This will show you the performed API calls and their JSON payload.

from oxl_opnsense_client import Client
c = Client(
    firewall='<IP>',
    credential_file='/home/<YOU>/.opnsense.txt',
    debug=True,
)

c.run_module('syslog', params={'target': '192.168.0.1', 'port': 5303})
# INFO: REQUEST: GET | URL: https://172.17.1.52/api/syslog/settings/get
# INFO: RESPONSE: '{'status_code': 200, '_request': <Request('GET', 'https://172.17.1.52/api/syslog/settings/get')>, '_num_bytes_downloaded': 123, '_elapsed': datetime.timedelta(microseconds=194859), '_content': b'{"syslog":{"general":{"enabled":"1","loglocal":"1","maxpreserve":"31","maxfilesize":""},"destinations":{"destination":[]}}}'}'
# INFO: REQUEST: POST | URL: https://172.17.1.52/api/syslog/settings/addDestination | HEADERS: '{'Content-Type': 'application/json'}' | DATA: '{"destination": {"rfc5424": 0, "enabled": 1, "hostname": "192.168.0.1", "transport": "udp4", "facility": "", "program": "", "level": "alert,crit,emerg,err,info,notice,warn", "certificate": "", "port": 5303, "description": ""}}'
# INFO: RESPONSE: '{'status_code': 200, '_request': <Request('POST', 'https://172.17.1.52/api/syslog/settings/addDestination')>, '_num_bytes_downloaded': 64, '_elapsed': datetime.timedelta(microseconds=61852), '_content': b'{"result":"saved","uuid":"ed90d52a-63ac-4d7c-a35b-4f250350f85d"}'}'
# INFO: REQUEST: POST | URL: https://172.17.1.52/api/syslog/service/reconfigure | HEADERS: '{}'
# INFO: RESPONSE: '{'status_code': 200, '_request': <Request('POST', 'https://172.17.1.52/api/syslog/service/reconfigure')>, '_num_bytes_downloaded': 15, '_elapsed': datetime.timedelta(microseconds=657156), '_content': b'{"status":"ok"}'}'

This information is also logged to files:

ls /tmp/opnsense_client/
# api_calls.log  syslog.log

The module-specific logs contain performance-profiling.
