parallax-kernel 0.1.1

Parallax: Parameterized Local Linear Attention kernels (Triton, Helion, CuTeDSL). Imports as `parallax`.

Parallax: Parameterized Local Linear Attention

This repository provides the official implementation of Parallax from the following paper:

Parallax: Parameterized Local Linear Attention for Language Modeling.
Yifei Zuo, Dhruv Pai, Zhichen Zeng, Alec Dewulf, Shuming Hu, and Zhaoran Wang. arXiv preprint, 2026.

Parallax is an upgrade to Softmax Attention. It is a scalable form of Local Linear Attention (LLA), a mechanism with provable theoretical advantages over Softmax Attention (see FlashLLA for the LLA kernels). Parallax and LLA are not linear complexity attention mechanisms. They share the computational structure of Softmax Attention and require KV cache for decoding. Optimizations such as sliding window and block-sparsity are structurally compatible with Parallax.

Integrations

• Flash-Linear-Attention: Parallax kernels available in the fla library.
• Modded-NanoGPT-plx: Parallax for the Modded-NanoGPT speedrun.

Install

Triton and Helion each provide training (dense + varlen) and decode kernels.
CuTeDSL provides the decode kernel only.

Triton kernels and the fp32 reference:

pip install parallax-kernel

Add the Helion kernels (experimental):

pip install 'parallax-kernel[helion]'

Add the SM90 CuTeDSL decode kernels (pins torch 2.9.1 / triton 3.5.1):

pip install 'parallax-kernel[cutedsl]'

For development or the bench and parity harnesses, install from source:

git clone https://github.com/Yifei-Zuo/Parallax.git
cd Parallax

uv sync                # core; add --extra helion / --extra cutedsl as needed
uv sync --group bench  # bench harness: pinned stack + FA2 + pytest

Quickstart

Note: our current kernels are developed and tested on NVIDIA Hopper GPUs. A reference PyTorch implementation is provided in parallax/reference.py for correctness verification and as a starting point for custom implementations on other hardware.

Training (Triton)

import torch
from parallax import parallax_func

B, H, L, D = 2, 8, 1024, 128
q = torch.randn(B, H, L, D, device="cuda", dtype=torch.bfloat16, requires_grad=True)
r = torch.randn(B, H, L, D, device="cuda", dtype=torch.bfloat16, requires_grad=True)
k = torch.randn(B, H, L, D, device="cuda", dtype=torch.bfloat16, requires_grad=True)
v = torch.randn(B, H, L, D, device="cuda", dtype=torch.bfloat16, requires_grad=True)

o = parallax_func(q, r, k, v) # (B, H, L, D), causal
o.float().pow(2).mean().backward()

Decoding (CuTeDSL)

import math
import torch
from parallax import parallax_decode

B, H, D = 4, 8, 128
kv_len = 4096
q = torch.randn(B, 1, H, D, device="cuda", dtype=torch.bfloat16)
r = torch.randn_like(q)
k = torch.randn(B, kv_len, H, D, device="cuda", dtype=torch.bfloat16)
v = torch.randn_like(k)

o = parallax_decode(q, r, k, v, qk_scale=1.0 / math.sqrt(D)) # (B, 1, H, D)

Helion kernels (experimental)

Helion implementations of all three kernels — autotuned, compiled to Triton — live under parallax.helion with the same entry-point names and signatures:

from parallax.helion import parallax_func, parallax_varlen_func, parallax_decode

On H100 (full autotune + CUDA-graph replay) vs the Triton kernels above: training step (fwd+bwd) 0.84× geomean latency across a 17-shape grid, varlen 0.53×, decode 1.8–6.4× faster. Precision: q50 max-norm relative error < 1e-2 vs the fp32 reference for the output and all four gradients (scripts/test_*_helion.py).

Helion autotunes on first call per shape — minutes per new shape with HELION_AUTOTUNE_EFFORT=full (cached via HELION_CACHE_DIR), immediate but slower with =none. For production, pin tuned configs — see Helion's deployment docs.

Benchmark

scripts/bench_decode.py benchmarks the decode kernel against FA2 and FA3 with combined speed + precision reporting:

python scripts/bench_decode.py                       # example sweep
python scripts/bench_decode.py --include-fa3         # add the FA3 column
python scripts/bench_decode.py --parallax-grid \
                               --csv runs/bench.csv  # 216-shape grid, save to CSV

The numbers below are measured on a single NVIDIA H200 SXM (132 SMs) with bf16 inputs and head dimension D = 128. Latency is the q50 over a CUDA-graph replay sweep (q05 and q95 are within ±1% on every row). Accuracy is the worst per-element relative error against the fp32 torch reference (parallax.parallax_reference).

Small batch (B = 1, H = 8, D = 128)

L	FA2 (µs)	FA3 (µs)	Parallax (µs)	Parallax max-rel-err
512	8.38	10.64	5.79	2.1e-3
1024	9.45	9.10	6.48	4.0e-3
4096	17.07	11.90	8.61	2.0e-3
16384	29.82	24.46	21.53	2.7e-3

Large batch (B = 32, H = 8, D = 128)

L	FA2 (µs)	FA3 (µs)	Parallax (µs)	Parallax max-rel-err
512	27.73	23.48	24.02	3.6e-3
1024	99.73	39.16	39.55	3.4e-3
4096	384.90	281.64	279.96	3.6e-3
16384	1574.94	1096.76	1094.37	3.2e-3

Reproduce the small-batch table with:

python scripts/bench_decode.py --include-fa3 \
    --shape 1,512,8,128  --shape 1,1024,8,128 \
    --shape 1,4096,8,128 --shape 1,16384,8,128 \
    --warmup 100 --iters 50 --trials 20

Reproduce the large-batch table with:

python scripts/bench_decode.py --include-fa3 \
    --shape 32,512,8,128  --shape 32,1024,8,128 \
    --shape 32,4096,8,128 --shape 32,16384,8,128 \
    --warmup 100 --iters 50 --trials 20

Citation

@misc{zuo2026parallaxparameterizedlocallinear,
      title={Parallax: Parameterized Local Linear Attention for Language Modeling},
      author={Yifei Zuo and Dhruv Pai and Zhichen Zeng and Alec Dewulf and Shuming Hu and Zhaoran Wang},
      year={2026},
      eprint={2605.29157},
      archivePrefix={arXiv},
      primaryClass={cs.LG},
      url={https://arxiv.org/abs/2605.29157},
}

License

MIT. See LICENSE.
