patchutils

patchutils provide utilities for making patches from directories and applying patches to directories. If you like the library and use it in your project, please consider giving us a star ⭐

Made with ❤️ by Contributers

Usage

Installation

from pip:

pip install patchutils -U

from latest repo

git clone xcodz-dot/patchutils
pip install poetry
poetry install

do not use poetry until you know how it works

API Documentation

You can check the steps to build documentation by doing this:

>>> import patchutils
>>> help(patchutils)

For your convinience all documentation is pre-built under the docs directory.

Concept

There are three things to be noted:

• directory information
• patch
• update files

Directory Information

Directory Information is a simple dictionary object containing 3 fields:

• files

  Files is a list that contain relative paths for all the files for the provided directory.

• directories

  Directories is a list that contain relative paths for all the subdirectories for the provided directory.

• hash

  Hash is a dictionary with key as file names and values as SHA-256 checksums for the respective files.

Here is a Sample Directory Information:

{
    "files": [
        "my_file_1.txt",
        "folder1/myfile2.txt",
        "folder2/another_folder/myfile3.txt"
    ],
    "directories": [
        "folder1",
        "folder2",
        "folder2/another_folder",
        "empty_folder"
    ],
    "hash": {
        "my_file_1.txt": "blablablablbalbalblblablblblblblblbl some sha hash blahblabla",
        "folder1/myfile2.txt": "blablablablablablablablablabla hash is in a hexdigest format",
        "folder2/another_folder/myfile3.txt": "blablablablbalbalblablg7ty913griubkeda"
    }
}

Patch

Patch is a dictionary that tells what changes have been made in comparision to two different Directory Informations. It consists of the following feilds:

• files_added

  List of Files added in comparision to the old directory information

• files_removed

  List of Files removed in comparision to the old directory information

• files_modified

  List of Files modified in comparision to the old directory information

• directories_added

  List of directories added including empty directories

• directories_removed

  List of directories removed including all their content within them

Here is an example patch:

{
    "files_added": ["new_file.txt"],
    "files_removed": ["i_hate_python.txt"],
    "files_modified": ["why_i_like_python.txt"],
    "directories_added": ["Temp"],
    "directories_removed": [".Temp"],
    "hash": {
        "new_file.txt": "blablablablbalbalbalbblablbablablbalbblabla",
        "why_i_like_python.txt": "blablablablablablablablablalbalgialbdblablbla"
    }
}

Update Files

Update files are simple uncompressed zip archives that are made using patch. Here is a typical workflow of a server and a client requesting updates:

• Clients gives their version number to the server.
• Server checks the version number and loads up stored directory information for that version.
• Server creates a patch using the latest directory information and that specific version directory information.
• Server creates an uncompressed update file and starts streaming it to the client OR alternatively server sends the patch in json format and client starts querying the server for different files listed in the patch and applies the patch to required positions.
• If the client recieved the update file instead of patch information then the client applies the update file to the required positions.

Alternatively to above if their is no version specifications then the workflow might look like this:

• Client generates directory information from local filesystem and sends it to the server
• Server creates a patch using client provided directory information and latest server directory information.
• And from this point on the process of updating is same as in above example

Contributers

xcodz-dot 💻 📖 🚇 ⚠️ 🚧
