pathsim-rf 0.1.1

RF Engineering Blocks for PathSim

RF engineering blocks for PathSim

Documentation • PathSim Homepage • GitHub

---

PathSim-RF extends the PathSim simulation framework with blocks for RF and microwave engineering. All blocks follow the standard PathSim block interface and can be connected into simulation diagrams.

Blocks

Block	Description	Key Parameters
RFNetwork	N-port network from S-parameter data (Touchstone) via vector fitting	ntwk, auto_fit
TransmissionLine	Lossy delay-based transmission line (scattering domain)	length, er, attenuation, Z0
RFAmplifier	Amplifier with optional IP3 nonlinearity	gain [dB], IIP3 [dBm], P1dB [dBm], Z0
RFMixer	Ideal frequency converter (time-domain multiplication)	conversion_gain [dB], Z0

Install

pip install pathsim-rf

License

MIT
