philiprehberger-state-machine

Lightweight finite state machine with guards, callbacks, and visualization.

Installation

pip install philiprehberger-state-machine

Usage

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["pending", "confirmed", "shipped", "delivered"],
    initial="pending",
    transitions=[
        ("pending", "confirmed", "confirm"),
        ("confirmed", "shipped", "ship"),
        ("shipped", "delivered", "deliver"),
    ],
)

sm.trigger("confirm")
print(sm.state)  # "confirmed"

Checking Available Transitions

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["pending", "confirmed", "shipped"],
    initial="pending",
    transitions=[
        ("pending", "confirmed", "confirm"),
        ("confirmed", "shipped", "ship"),
    ],
)

sm.can("confirm")  # True
sm.can("ship")     # False

# All events that can fire from the current state (deduped)
sm.available_events()  # ["confirm"]

# (event, to_state) pairs, for the current state or any other state
sm.transitions_from()             # [("confirm", "confirmed")]
sm.transitions_from("confirmed")  # [("ship", "shipped")]

transitions_from() follows the same resolution as trigger(): exact-match transitions first, then wildcards for events not already handled. Guards are not evaluated.

Final States

Mark terminal states with final_states. A final state may not have outgoing transitions, and wildcard transitions and timeouts never fire from it.

from philiprehberger_state_machine import InvalidTransitionError, StateMachine

sm = StateMachine(
    states=["pending", "delivered", "cancelled", "error"],
    initial="pending",
    transitions=[
        ("pending", "delivered", "deliver"),
        ("pending", "cancelled", "cancel"),
        ("*", "error", "fail"),
    ],
    final_states=["delivered", "cancelled"],
)

sm.trigger("cancel")
print(sm.is_final)  # True

try:
    sm.trigger("fail")  # wildcards do not apply to final states
except InvalidTransitionError:
    print("already finished")

Unknown final states, or transitions and timeouts defined from a final state, raise ValueError. Final states are included in snapshot(), checked by restore(), filled gray in to_dot(), and drawn as state --> [*] in to_mermaid().

Callbacks

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["pending", "confirmed", "shipped"],
    initial="pending",
    transitions=[
        ("pending", "confirmed", "confirm"),
        ("confirmed", "shipped", "ship"),
    ],
)

sm.on_enter("confirmed", lambda state, event: print(f"Entered {state} via {event}"))
sm.on_exit("pending", lambda state, event: print(f"Left {state} via {event}"))

sm.trigger("confirm")
# Left pending via confirm
# Entered confirmed via confirm

Guard Conditions

Guards are optional callables that receive a context dict and must return True to allow the transition. If a guard returns falsy, InvalidTransitionError is raised.

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["draft", "published"],
    initial="draft",
    transitions=[],
)

sm.add_transition("draft", "published", "publish", guard=lambda ctx: ctx.get("has_title", False))

sm.trigger("publish", context={"has_title": True})   # succeeds
print(sm.state)  # "published"

Transition Context

Pass a context dict to trigger() to share data with guards and callbacks.

sm.trigger("confirm", context={"user": "alice", "approved": True})

If no context is provided, an empty dict is passed to guards.

Wildcard Transitions

Use "*" as the source state to define a transition that can fire from any state.

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["idle", "running", "paused", "error"],
    initial="idle",
    transitions=[
        ("idle", "running", "start"),
        ("running", "paused", "pause"),
        ("*", "error", "fail"),
    ],
)

sm.trigger("start")
print(sm.state)  # "running"

sm.trigger("fail")
print(sm.state)  # "error"

Wildcard transitions are checked after exact state matches, so a specific transition always takes priority.

Global transition hook

Register a listener that fires after every successful transition. Useful for logging, metrics, or auditing.

import logging
from philiprehberger_state_machine import StateMachine

log = logging.getLogger(__name__)

sm = StateMachine(
    states=["pending", "confirmed", "shipped"],
    initial="pending",
    transitions=[
        ("pending", "confirmed", "confirm"),
        ("confirmed", "shipped", "ship"),
    ],
)

unsubscribe = sm.on_transition(
    lambda fr, to, ev, ctx: log.info("transition %s -> %s via %s", fr, to, ev)
)

sm.trigger("confirm")
sm.trigger("ship")

unsubscribe()  # remove the listener

The callback receives (from_state, to_state, event, context). Listeners fire in registration order, after on_exit and on_enter callbacks. Listeners do not fire when a guard rejects a transition.

Transition History

Track all past transitions with timestamps using transition_history.

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["pending", "confirmed", "shipped"],
    initial="pending",
    transitions=[
        ("pending", "confirmed", "confirm"),
        ("confirmed", "shipped", "ship"),
    ],
)

sm.trigger("confirm")
sm.trigger("ship")

for record in sm.transition_history:
    print(f"{record.from_state} -> {record.to_state} via {record.event} at {record.timestamp}")
# pending -> confirmed via confirm at 1711929600.123
# confirmed -> shipped via ship at 1711929600.456

History and Reset

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["pending", "confirmed", "shipped"],
    initial="pending",
    transitions=[
        ("pending", "confirmed", "confirm"),
        ("confirmed", "shipped", "ship"),
    ],
)

sm.trigger("confirm")
sm.trigger("ship")
print(sm.history)  # ["pending", "confirmed"]

sm.reset()
print(sm.state)    # "pending"
print(sm.history)  # []

Timeout-Based Automatic Transitions

Define transitions that fire automatically after a state has been active for a given number of seconds.

from philiprehberger_state_machine import StateMachine
import time

sm = StateMachine(
    states=["idle", "processing", "timeout_state"],
    initial="idle",
    transitions=[("idle", "processing", "start")],
)

sm.add_timeout("processing", "timeout_state", seconds=5.0)

sm.trigger("start")
print(sm.state)  # "processing"

time.sleep(6)
print(sm.state)  # "timeout_state"

Snapshot and Restore

Capture and restore the machine's state and history for serialization or checkpointing.

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["a", "b", "c"],
    initial="a",
    transitions=[("a", "b", "go"), ("b", "c", "go")],
)

sm.trigger("go")
snap = sm.snapshot()
print(snap)  # {"state": "b", "history": ["a"]}

sm.trigger("go")
print(sm.state)  # "c"

sm.restore(snap)
print(sm.state)  # "b"

Visualization Export

Export the state machine as a DOT (Graphviz) or Mermaid diagram string.

from philiprehberger_state_machine import StateMachine

sm = StateMachine(
    states=["pending", "confirmed", "shipped"],
    initial="pending",
    transitions=[
        ("pending", "confirmed", "confirm"),
        ("confirmed", "shipped", "ship"),
    ],
)

print(sm.to_dot())
# digraph StateMachine {
#     rankdir=LR;
#
#     "pending" [shape=doublecircle];
#     "confirmed" [shape=circle];
#     "shipped" [shape=circle];
#
#     "pending" -> "confirmed" [label="confirm"];
#     "confirmed" -> "shipped" [label="ship"];
# }

print(sm.to_mermaid())
# stateDiagram-v2
#     [*] --> pending
#     pending --> confirmed : confirm
#     confirmed --> shipped : ship

API

Function / Class	Description
StateMachine(states, initial, transitions, final_states=None)	Create a state machine with given states, initial state, transitions, and optional terminal states
StateMachine.state	Current state (read-only property)
StateMachine.is_final	Whether the current state is a final state (read-only property)
StateMachine.final_states	Configured final states in declaration order (read-only property)
StateMachine.history	List of past states (read-only property)
StateMachine.transition_history	List of TransitionRecord objects with timestamps (read-only property)
StateMachine.trigger(event, context=None)	Execute a transition or raise InvalidTransitionError (also raised from a final state). Pass optional context dict to guards.
StateMachine.can(event)	Return whether the event is valid from the current state
StateMachine.available_events()	List of events (deduped) that can fire from the current state, including wildcards
StateMachine.transitions_from(state=None)	List of (event, to_state) pairs that can fire from a state (defaults to current), including wildcards
StateMachine.add_transition(from_state, to_state, event, guard=None)	Add a transition with an optional guard callable. Use "*" as from_state for wildcard.
StateMachine.on_enter(state, callback)	Register a callback for entering a state
StateMachine.on_exit(state, callback)	Register a callback for exiting a state
StateMachine.on_transition(callback)	Register a global listener fired after every successful transition with (from_state, to_state, event, context). Returns an unsubscribe closure.
StateMachine.remove_transition_listener(callback)	Remove a previously registered transition listener. Returns True if removed.
StateMachine.reset()	Reset to initial state and clear history
StateMachine.add_timeout(state, target, seconds)	Define an automatic transition after seconds in state
StateMachine.snapshot()	Return a serializable dict of current state and history (plus final_states when configured)
StateMachine.restore(snapshot)	Restore the machine from a snapshot dict
StateMachine.to_dot()	Return a DOT/Graphviz string of the state machine
StateMachine.to_mermaid()	Return a Mermaid state diagram string
TransitionRecord	Frozen dataclass with from_state, to_state, event, and timestamp fields
InvalidTransitionError	Raised on invalid transitions; has .state and .event attributes

Development

pip install -e .
python -m pytest tests/ -v
