PinViz
Programmatically generate beautiful GPIO connection diagrams for Raspberry Pi and ESP32/ESP8266 boards in SVG format.
PinViz makes it easy to create clear, professional wiring diagrams for your microcontroller projects. Define your connections using simple YAML/JSON files or Python code, and automatically generate publication-ready SVG diagrams.
Features
- 📝 Declarative Configuration: Define diagrams using YAML or JSON files
- 🎨 Automatic Wire Routing: Smart wire routing with configurable styles (orthogonal, curved, mixed)
- 🎯 Color-Coded Wires: Automatic color assignment based on pin function (I2C, SPI, power, ground, etc.)
- ⚡ Inline Components: Add resistors, capacitors, and diodes directly on wires
- 🔌 Built-in Templates: Pre-configured boards (Raspberry Pi, ESP32, ESP8266) and common devices
- 🐍 Python API: Create diagrams programmatically with Python code
- 🤖 MCP Server: Generate diagrams from natural language with AI assistants
- 🌙 Dark Mode: Built-in light and dark themes for better visibility
- 🍞 Breadboard Layout (experimental): Draw a TMC2209 stepper driver on a solderless breadboard next to the Pi
- 📦 SVG Output: Scalable, high-quality vector graphics
- ✨ Modern CLI: Rich terminal output with progress indicators and colored messages
- 🔧 JSON Output: Machine-readable output for CI/CD integration
Example Diagram
Installation
Homebrew (macOS)
brew tap nordstad/pinviz
brew install pinviz
pip / uv (cross-platform)
uv tool install pinviz
pip install pinviz
Or as a project dependency:
uv add pinviz
Upgrading
brew upgrade pinviz
uv tool upgrade pinviz
pip install --upgrade pinviz
Or as a project dependency:
uv lock --upgrade-package pinviz && uv sync
Supported Boards
| Board | Aliases | GPIO Pins | Description |
|---|---|---|---|
| Raspberry Pi 5 | raspberry_pi_5, rpi5, rpi |
40-pin | Latest Raspberry Pi with improved GPIO capabilities |
| Raspberry Pi 4 | raspberry_pi_4, rpi4 |
40-pin | Popular Raspberry Pi model with full GPIO header |
| Raspberry Pi Pico | raspberry_pi_pico, pico |
40-pin (dual-sided) | RP2040-based microcontroller board |
| ESP32 DevKit V1 | esp32_devkit_v1, esp32, esp32_devkit |
30-pin (dual-sided) | ESP32 development board with WiFi/Bluetooth |
| ESP32-S3-DevKitC-1 | esp32_s3_devkitc1, esp32s3, esp32_s3 |
44-pin (dual-sided) | ESP32-S3 board (realistic artwork; _schematic variant available) |
| ESP8266 NodeMCU | esp8266_nodemcu, esp8266, nodemcu |
30-pin (dual-sided) | ESP8266 WiFi development board |
| Wemos D1 Mini | wemos_d1_mini, d1mini, wemos |
16-pin (dual-sided) | Compact ESP8266 development board |
All boards include full pin definitions with GPIO numbers, I2C, SPI, UART, and PWM support.
Quick Start
Try a Built-in Example
# Generate a BH1750 light sensor wiring diagram
pinviz example bh1750 -o bh1750.svg
# See all available examples
pinviz list
Create Your Own Diagram
Create a YAML configuration file (my-diagram.yaml):
title: "BH1750 Light Sensor Wiring"
board: "raspberry_pi_5"
devices:
- type: "bh1750"
name: "BH1750"
color: "turquoise" # Named color support (or use hex: "#50E3C2")
connections:
- board_pin: 1 # 3V3
device: "BH1750"
device_pin: "VCC"
- board_pin: 6 # GND
device: "BH1750"
device_pin: "GND"
- board_pin: 5 # GPIO3 (I2C SCL)
device: "BH1750"
device_pin: "SCL"
- board_pin: 3 # GPIO2 (I2C SDA)
device: "BH1750"
device_pin: "SDA"
Generate your diagram:
pinviz render my-diagram.yaml -o output.svg
Python API
from pinviz import boards, devices, Connection, Diagram, SVGRenderer
board = boards.raspberry_pi_5()
sensor = devices.bh1750_light_sensor()
connections = [
Connection(1, "BH1750", "VCC"), # 3V3 to VCC
Connection(6, "BH1750", "GND"), # GND to GND
Connection(5, "BH1750", "SCL"), # GPIO3/SCL to SCL
Connection(3, "BH1750", "SDA"), # GPIO2/SDA to SDA
]
diagram = Diagram(
title="BH1750 Light Sensor",
board=board,
devices=[sensor],
connections=connections
)
renderer = SVGRenderer()
renderer.render(diagram, "output.svg")
CLI Commands Examples
PinViz provides a modern CLI
Rendering Diagrams
# Generate diagram from YAML config
pinviz render examples/bh1750.yaml -o output.svg
Validation
# Validate diagram configuration
pinviz validate examples/bh1750.yaml
List Templates
# List all boards, devices, and examples
pinviz list
MCP Server (AI-Powered)
PinViz includes an MCP (Model Context Protocol) server that enables natural language diagram generation through AI assistants like Claude Desktop. Generate diagrams with prompts like "Connect a BME280 temperature sensor to my Raspberry Pi 5" with intelligent pin assignment, automatic I2C bus sharing, and conflict detection.
Documentation
Full documentation: nordstad.github.io/PinViz
- Installation Guide - Detailed installation instructions
- Quick Start Tutorial - Step-by-step getting started guide
- CLI Usage - Command-line interface reference
- YAML Configuration - Complete YAML configuration guide
- Python API - Programmatic API reference
- Examples Gallery - More example diagrams and configurations
- API Reference - Complete API documentation
Contributing
Contributions are welcome! Please see our Contributing Guide for details.
Adding new devices: See guides/adding-devices.md for device configuration details.
License
MIT License - See LICENSE file for details
Credits
Board and GPIO pin SVG assets courtesy of Wikimedia Commons
Author
Even Nordstad
- GitHub: @nordstad
- Project: PinViz
- Documentation: nordstad.github.io/PinViz
