Pipecat TTS Cache: Zero-Latency Audio Synthesis

Pipecat TTS Cache is a lightweight caching layer for the Pipecat ecosystem. It transparently wraps existing TTS services to eliminate API costs for repeated phrases and reduce response latency to <5ms.

See it in action: Watch the Demo Video

🚀 Key Features

• Ultra-Low Latency – Delivers cached audio in ~0.1ms (Memory) or ~1-5ms (Redis).
• Cost Reduction – Stop paying your TTS provider for common phrases like "Hello," "One moment," or "I didn't catch that."
• Universal Compatibility – Works as a Mixin with all Pipecat TTS services (Cartesia, ElevenLabs, Deepgram, Google, etc.).
• Smart Interruption – Automatically clears pending cache tasks and resets state when users interrupt the bot.
• Precision Alignment – Preserves word-level timestamps for perfect lip-syncing and subtitles, even on cached replays.

📦 Installation

# Standard installation (Memory backend only)
pip install pipecat-tts-cache

# Production installation (with Redis support)
pip install "pipecat-tts-cache[redis]"

🧩 Service Compatibility

The mixin works with any Pipecat TTSService — HTTP or WebSocket. It captures audio as it flows through the pipeline (keyed by Pipecat's per-request audio context) and replays cached audio back through that same audio context, so playback ordering is preserved even when cache hits and live synthesis are mixed in a single turn.

How much detail is preserved on a cache hit depends on what the underlying service produces:

Since Pipecat 1.0, word-timestamp support lives on the base TTSService, so provider class names are no longer meaningful for caching — the mixin adapts to whatever each service emits at runtime.

🛠️ Usage

1. Basic In-Memory Cache (Development)

The MemoryCacheBackend is perfect for local development or single-process bots. It uses an LRU (Least Recently Used) eviction policy.

from pipecat_tts_cache import TTSCacheMixin, MemoryCacheBackend
from pipecat.services.google.tts import GoogleHttpTTSService

# 1. Create a cached class using the Mixin
class CachedGoogleTTS(TTSCacheMixin, GoogleHttpTTSService):
    pass

# 2. Initialize with memory backend
tts = CachedGoogleTTS(
    settings=CachedGoogleTTS.Settings(voice="en-US-Chirp3-HD-Charon"),
    cache_backend=MemoryCacheBackend(max_size=1000),
    cache_ttl=86400,  # Cache for 24 hours
)

2. Distributed Redis Cache (Production)

For production deployments, use RedisCacheBackend. This allows the cache to persist across restarts and be shared among multiple bot instances.

from pipecat_tts_cache.backends import RedisCacheBackend

tts = CachedGoogleTTS(
    settings=CachedGoogleTTS.Settings(voice="en-US-Chirp3-HD-Charon"),
    cache_backend=RedisCacheBackend(
        redis_url="redis://localhost:6379/0",
        key_prefix="pipecat:tts:",
    ),
    cache_ttl=604800, # Cache for 1 week
)

⚠️ Security — Redis trust boundary. The Redis backend serializes cached audio with pickle, so it must be treated as trusted: use a single-tenant, authenticated, network-isolated Redis instance. Never point it at a shared/untrusted Redis — anyone who can write the keyspace could achieve code execution when an entry is read. See SECURITY.md.

Backend lifecycle. You own the backend you pass in — reuse a single instance across sessions (recommended for Redis, so its connection pool is shared) and call await backend.close() when your app shuts down. The package never closes an injected backend, so a shared one is safe.

🧠 How It Works

The system utilizes a Frame Interception Architecture to seamlessly integrate with the Pipecat pipeline:

1. Deterministic Key Gen: Before requesting audio, a unique key is generated based on the normalized text, voice ID, model, speed, and pitch. Sensitive data (API keys) is excluded.
2. Cache Check (run_tts):

• Hit: The system immediately pushes cached audio frames and timestamps to the pipeline.
• Miss: The system calls the parent TTS service.

3. Collection (push_frame): As the parent service generates audio, the Mixin intercepts the frames, aggregates them, and stores them in the backend for future use.

Interruption Handling

When an InterruptionFrame is received, the cache mixin immediately:

• Clears all pending cache write tasks.
• Resets the internal batch state.
• Ensures no partial or cut-off audio is committed to the pipeline.

📊 Management & Stats

You can monitor cache performance or clear entries programmatically.

# Check performance
stats = await tts.get_cache_stats()
print(f"Hit Rate: {stats['hit_rate']:.1%}")
print(f"Total Saved Calls: {stats['hits']}")

# Maintenance
await tts.clear_cache() # Clear all
await tts.clear_cache(namespace="user_123") # Clear specific namespace

⚡ Performance

Running the Example

Prerequisites

# Install with example dependencies
pip install "pipecat-tts-cache[examples]"

# Optional: Install with Redis support
pip install "pipecat-tts-cache[examples,redis]"

# Set environment variables
export DEEPGRAM_API_KEY=your_key
export CARTESIA_API_KEY=your_key
export GOOGLE_API_KEY=your_key

# Optional: For Redis backend
export USE_REDIS_CACHE=true
export REDIS_URL=redis://localhost:6379/0

Option 1: Daily Bots (Recommended)

# Start the bot server
python examples/basic_caching.py --host 0.0.0.0 --port 7860

# Connect via Daily Bots or your Daily room

Option 2: Local WebRTC

# Run with local WebRTC transport
python examples/basic_caching.py -t webrtc --host localhost --port 8765

Compatibility

Requires Python ≥ 3.11.

For Pipecat 0.0.91–0.0.101, use pipecat-tts-cache 0.0.3.
