pixipix 0.1.0a4

Extract, grid-snap, and palette-lock pose-sheet artwork into real pixel sprite assets.

Tiny poses in. Tidy pixels out.

PixiPix is a deterministic, local-first command-line tool for extracting isolated visual frames from PNG source sheets, scaling them with one shared geometric ruler, converting configured pseudo-pixel cells into true logical RGBA pixels, and placing those frames on deterministic fixed-size canvases.

PixiPix is content- and source-agnostic. It never recognizes subjects or infers what a frame depicts, and it never asks how a sheet was made: hand-drawn, rendered, scanned, exported, procedurally generated, and AI-generated raster inputs all work identically.

Note: PixiPix is in active development. APIs and output contracts may change during the alpha series.

Requirements

• Python 3.12
• uv
• PNG source images

PixiPix performs no network requests, telemetry, cloud uploads, or AI inference.

Install

Clone the repository and create the locked environment:

uv sync
uv run pixipix --help

To build an installable wheel:

uv build
uv tool install dist/pixipix-0.1.0a4-py3-none-any.whl
pixipix --help

Quick start

Create pixipix.toml:

[project]
name = "sprite-source"
strict = true

[source]
format = "png"
expected_components = 2

[background]
mode = "alpha"
alpha_threshold = 8

[extract]
connectivity = 8
minimum_area = 4
maximum_area = 10000
padding = 1
row_tolerance = 2

[frames]
names = ["frame-a", "frame-b"]

[scale]
mode = "reference-frame-width"
reference_frame = "frame-a"
target_size = 24

[pixelize]
source_cell_size = 6
representative = "alpha-weighted-majority"
alpha_policy = "binary"
alpha_threshold = 128
remainder_policy = "pad-transparent"

[output]
frame_width = 48
frame_height = 48
anchor = "bottom-center"
baseline_y = 44
clip_policy = "error"

[frame_offsets.frame-b]
dx = 1
dy = -1

Inspect the source without writing files:

uv run pixipix inspect source.png --config pixipix.toml

Extract the configured frames:

uv run pixipix extract source.png \
  --config pixipix.toml \
  --output build/extracted

uv run pixipix scale build/extracted \
  --config pixipix.toml \
  --output build/scaled

uv run pixipix pixelize build/scaled \
  --config pixipix.toml \
  --output build/pixelized

uv run pixipix align build/pixelized \
  --config pixipix.toml \
  --output build/aligned

The accepted component count must match both source.expected_components and the number of configured frame names. PixiPix fails instead of guessing when they differ.

Commands

pixipix inspect

pixipix inspect INPUT --config CONFIG

Reports deterministic facts including:

• source dimensions, input mode, and alpha presence
• normalized RGBA mode
• selected background behavior and foreground bounds
• candidate, accepted, and rejected components
• component bounds, areas, rejection reasons, and deterministic order
• configured frame-name assignments when counts match
• configured source cell size when present

inspect never infers a source cell size and does not write output artifacts.

pixipix extract

pixipix extract INPUT --config CONFIG --output OUTPUT [--force]

Writes one RGBA PNG per accepted component plus versioned stage.json metadata. The output is staged and validated before it is published.

pixipix scale

pixipix scale INPUT_DIR --config CONFIG --output OUTPUT [--force]

Consumes a valid extraction-stage directory and applies one global scale factor to every frame in source pixel space. Reference modes derive the factor from one named frame and set its configured width or height target exactly. Optional, explicit per-frame multipliers are recorded and always produce warnings. Scaling uses BOX over float32 premultiplied RGBA channels, then deterministically un-premultiplies and normalizes transparent pixels to prevent dark fringes.

pixipix pixelize

pixipix pixelize INPUT_DIR --config CONFIG --output OUTPUT [--force]

Consumes a valid scale-stage directory and emits one logical RGBA pixel per configured source cell. The grid is anchored at bottom-left: incomplete space belongs to the top and right edges. Output is always at 1× logical resolution and is not aligned, palette-locked, or packed.

pixipix align

pixipix align INPUT_DIR --config CONFIG --output OUTPUT [--force]

Consumes valid pixelize-stage output and places every logical RGBA frame on the same configured transparent-black canvas. Alignment copies visible pixels exactly; it never resizes, resamples, recolors, or changes alpha. Placement, per-edge overflow, and visible source/destination rectangles are recorded in versioned metadata.

Other commands

pixipix --help
pixipix version
python -m pixipix

Configuration reference

PixiPix parses TOML strictly. Unknown keys, unsupported sections, invalid values, duplicate names, unsafe filenames, and inconsistent counts are configuration errors.

Source limits

[source]
format = "png"             # only png is supported
expected_components = 2    # optional, but recommended
max_width = 4096
max_height = 4096
max_pixels = 16777216
max_components = 128

The limits are checked before expensive image allocations where possible. max_pixels has a fixed ceiling of 16,777,216 pixels, and max_components may not exceed max_pixels; configuration cannot silently disable those resource bounds. RGB, RGBA, indexed, grayscale, and grayscale-alpha PNGs are accepted and normalized to an owned uint8 RGBA buffer. Malformed, truncated, and decoder-limit inputs fail as unsupported input.

Background modes

Transparent source:

[background]
mode = "alpha"
alpha_threshold = 8

Known solid color:

[background]
mode = "explicit-color"
color = "#f4e46a"
tolerance = 0.02
alpha_threshold = 8

Color sampled from all four corners:

[background]
mode = "corner-color"
tolerance = 0.02
alpha_threshold = 8
sample_corners = true

Color modes use normalized maximum per-channel distance. The largest absolute channel difference divided by 255 must be less than or equal to tolerance. Six-digit colors compare RGB; eight-digit colors compare RGBA. Corner mode compares RGBA samples and fails if the corners disagree beyond tolerance. Pixels below alpha_threshold are always background.

Extraction

[extract]
connectivity = 8     # 4 or 8
minimum_area = 4
maximum_area = 10000 # optional
padding = 1
row_tolerance = 2

Components smaller than minimum_area or larger than maximum_area remain visible in inspection and stage metadata as rejected components.

Frame names

[frames]
names = ["frame-a", "frame-b"]

Names are preserved unchanged in metadata and assigned only after deterministic ordering and count validation. Path separators, traversal and absolute-path syntax, controls, surrounding whitespace, trailing dots, Windows-reserved basenames, and overlong filenames are rejected. Filename normalization is deterministic, and normalized filenames must remain unique even on case-insensitive filesystems.

Global scale

Choose exactly one scale mode:

[scale]
mode = "explicit-factor"
factor = 0.75

[scale]
mode = "reference-frame-width" # or reference-frame-height
reference_frame = "frame-a"
target_size = 24                # logical pixels

Reference modes use target_size × pixelize.source_cell_size as the exact source-space target. All other dimensions use the same factor with round-half-away-from-zero; non-empty dimensions remain at least one source pixel. A reference frame cannot have an override. An exceptional non-reference correction is explicit and warned:

[frame_overrides.frame-b]
scale_multiplier = 0.96

PixiPix never infers or suggests per-frame normalization.

Logical pixelization

[pixelize]
source_cell_size = 6
representative = "alpha-weighted-majority"
alpha_policy = "binary"
alpha_threshold = 128
remainder_policy = "pad-transparent"

source_cell_size is required by pixelize and by reference scaling. Representative strategies are exact RGBA majority with first row-major tie-breaking, locked center sampling, and the default alpha-weighted-majority, which ignores transparent RGB and weights visible RGB groups by alpha. Alpha is either binary at the configured inclusive threshold or explicitly preserved as the selected-color opacity.

Remainder policies are pad-transparent (minimal top/right transparent-black padding), error, and crop-with-warning (top/right incomplete strips only). Cropping that would reduce a non-empty frame to zero dimensions is rejected.

Fixed-canvas alignment

[output]
frame_width = 48
frame_height = 48
anchor = "bottom-center"
baseline_y = 44
clip_policy = "error"

[frame_offsets.frame-b]
dx = 2
dy = -1

frame_width, frame_height, and anchor are required by align. Supported anchors are top-left, top-center, top-right, center-left, center, center-right, bottom-left, bottom-center, and bottom-right.

Canvas coordinates use a top-left origin and refer to pixel boundaries. For bottom anchors, baseline_y is the boundary where the input frame's bottom edge lands before offsets; it defaults to frame_height and may range from zero through frame_height, inclusive. Non-bottom anchors reject baseline_y.

Center placement uses mathematical floor:

floor((canvas_size - input_size) / 2)

An odd remainder leaves the extra transparent pixel on the right or bottom. The same floor rule applies to negative differences when an input is larger than its canvas. Explicit integer frame offsets apply after anchor placement. A declared offset must change at least one axis; {dx = 0, dy = 0} is rejected during configuration validation, and every valid declared offset contributes one deterministic alignment warning when alignment metadata is published.

Clipping is evaluated after offsets. Policies are:

• error (default): aggregate every clipped frame and publish nothing
• warn: publish, record findings, and add one warning per clipped frame
• allow: publish and record findings without clipping warnings

All policies retain exact leftOverflow, topOverflow, rightOverflow, and bottomOverflow counts. Metadata also records visible source and destination rectangles as x, y, width, and height; every empty rectangle uses the canonical all-zero representation.

Output

build/extracted/
├── .pixipix-output
├── frames/
│   ├── frame-a.png
│   └── frame-b.png
└── stage.json

build/scaled/
├── .pixipix-output
├── frames/
│   ├── frame-a.png
│   └── frame-b.png
└── stage.json

build/pixelized/
├── .pixipix-output
├── frames/
│   ├── frame-a.png
│   └── frame-b.png
└── stage.json

build/aligned/
├── .pixipix-output
├── frames/
│   ├── frame-a.png
│   └── frame-b.png
└── stage.json

stage.json records:

• schema and PixiPix versions
• exact-source and effective-configuration SHA-256 hashes
• normalized source and background-removal facts
• candidate, accepted, and rejected components
• ordered frame names and relative paths
• original and padded source bounds
• component areas and deterministic source order
• warnings and successful status

Public artifacts contain no timestamps, absolute machine paths, or temporary paths. Scale metadata records prior-stage identity, config hashes, the shared global factor, reference measurements, overrides, effective frame factors, dimensions, and warnings. Pixelize metadata records prior-stage identity, the bottom-left grid origin, cell size, selection and alpha policies, per-frame top/right padding or crop, logical dimensions, and warnings. Align metadata records the canvas, anchor, configured/effective baseline, clipping policy, offsets, final placement, exact overflow, explicit visible rectangles, and warnings. Frame order always comes from stage.json, never directory enumeration.

Output safety

PixiPix does not merge new files into stale output:

• a non-empty output directory is rejected by default
• an existing empty output directory is safely replaced without requiring --force
• --force replaces only output with a valid ownership marker plus a coherent, successful stage.json contract and all referenced RGBA PNG frames
• unowned directories, symlink targets, and untrusted symlink parents are not destructively replaced; the root-owned standard /tmp alias is supported
• output is built in a temporary sibling directory
• a previous owned output is restored if atomic publication fails where practical

Determinism

Component discovery scans pixels in row-major order. Four-connectivity visits up, left, right, then down. Eight-connectivity visits up-left, up, up-right, left, right, down-left, down, then down-right.

Accepted components are first sorted by top, left, ascending area, and discovery index. Each row is anchored to the top coordinate of its first component; another component joins the first existing row whose anchor differs by at most row_tolerance (inclusive). The fixed anchor prevents pairwise chaining from merging distant rows. Rows are ordered by anchor top; components within a row use left, ascending area, then discovery index.

JSON uses sorted keys, two-space indentation, UTF-8, finite numbers, Unix-style relative paths, and exactly one trailing newline. PNG output is RGBA, excludes source metadata, uses explicit compression settings, and zeroes RGB channels for fully transparent pixels.

Geometric and channel quantization use separate round-half-away-from-zero helpers. Scale BOX filtering operates on float32 premultiplied red, green, blue, and alpha channels; un-premultiplication occurs in float64 and channels are quantized once. Fully opaque input uses the equivalent native RGBA BOX path for ordinary BOX identity. Pixel representatives use fixed row-major tie rules. Sequential scale then pixelize is the canonical path; no fused implementation exists.

Exit codes

Code	Meaning
0	Success
1	Processing or output failure
2	Configuration failure
3	Unsupported or malformed input
4	Unexpected internal error

Expected domain failures do not print tracebacks.

Current limitations

• one PNG source sheet per command
• strict configuration and one shared scale factor per extracted sheet
• component filtering by minimum and optional maximum area
• explicit source-cell size; no source-cell inference or automatic frame normalization
• explicit fixed canvas and placement; no automatic canvas, anchor, baseline, or offset inference
• no palette processing, recoloring, atlas packing, final manifest/report, animation generation, or editor integration
• no end-to-end build command yet

Development

See DEVELOPMENT.md for architecture, fixture provenance, and the full verification workflow.

PixiPix is licensed under the Apache License 2.0.
