plotwave 0.1.2

Interactive audio and waveform plotting for notebooks and browsers.

plotwave

Interactive Plotly waveforms with synchronized audio playback

Live interactive demo

Click anywhere in the waveform to hear the audio while inspecting it visually.
Overlay multiple audio tracks or add additional signals (labels, predictions, segmentation, scores) on top of the waveform.

Designed for Jupyter notebooks, plotwave can also be exported to HTML, making it easy to share interactive audio visualizations or log them in tools like MLflow for experiment analysis.

Why plotwave

• Start from a path with plotwave.audio_file(...) and get an interactive waveform without manually decoding audio first.
• Click anywhere in the waveform to audition the exact moment you are inspecting.
• Click a segment label to loop that labeled region and compare it against the waveform.
• Overlay predictions, envelopes, scores, or ground-truth labels on the same timeline.
• Use the same interaction model in notebooks and exported HTML.

Install

uv add plotwave

or

pip install plotwave

Direct audio file example

import plotwave

plotwave.audio_file("voice.mp3", name="voice").plot(
    layout={"title": {"text": "Direct file-backed audio"}, "height": 460},
)

plotwave.audio_file(...) uses soundfile internally and can open any local audio format that your soundfile backend supports, including WAV and MP3. It is the quickest way to go from a local audio file to an interactive player + waveform view. Use soundfile.read(...) only when you want to derive an extra trace from the samples, like an envelope or model scores.

Audio + curve

import numpy as np
import soundfile as sf
import plotwave

wav, sr = sf.read("voice.mp3", always_2d=False)
env = np.abs(wav)

plotwave.plot(
    [
        plotwave.audio_file("voice.mp3", name="audio", color="#2563eb"),
        plotwave.series(env, sr=sr, name="envelope", color="#f97316", fill="tozeroy"),
    ],
    layout={"title": {"text": "Audio + envelope"}, "height": 520},
)

For series(...), use:

• sr=... when your values are evenly sampled
• time=... when you already have an explicit time axis

Segments and label looping

import plotwave

plotwave.plot(
    [
        plotwave.audio_file("song.mp3", name="audio"),
        plotwave.segments(
            [
                {"start": 0.0, "end": 0.7, "label": "Bm"},
                {"start": 1.0, "end": 1.6, "label": "G"},
            ],
            name="Pred",
            lane="top",
            color_map={"Bm": "#2563eb", "G": "#16a34a"},
        ),
    ]
)

segments(...) adds:

• clickable label boxes that loop the matching audio span
• colored background blocks
• hoverable segment names
• top/bottom lanes for comparisons like prediction vs ground truth

Export

plot = plotwave.plot(wav, sr=sr)
plot.save("wave.html")
html = plot.html()

By default, notebook output, html(), and save() use compressed audio. You can disable that and control the bitrate explicitly:

plot = plotwave.audio_file("voice.mp3").plot(compress_audio=False)
html = plot.html(compress_audio=True, bitrate="48k")

API

Public API:

• plotwave.plot(...)
• plotwave.audio(...)
• plotwave.audio_file(...)
• plotwave.series(...)
• plotwave.segments(...)
• plotwave.Plot

All trace types also have trace.plot(...) as a shortcut for plotwave.plot(trace, ...).

See examples/getting_started.ipynb for a full walkthrough.

Developer workflow: DEVELOPERS.md

To refresh the GitHub Pages demo locally:

uv run python scripts/build_pages_demo.py
