Polish

Polish is a declarative architecture language for people and LLMs. Describe pages, services, data stores, and infrastructure in a .polishd file, check their relationships, then run request scenarios against the resulting graph.

This repository contains version 0.14: a Python compiler and deterministic functional simulator. It does not provision infrastructure or send real network requests.

Problems Polish helps solve

Reuse an architecture when the use case changes

You have been vibe coding an ecommerce app with an LLM and refining its architecture along the way. Now you want to reuse that design for a ticketing site: keep the account and checkout flows, replace the catalog with events, and change the storage and access rules.

A .polishd file gives you and the LLM an explicit starting point. Copy the specification, change the components and relationships, then rerun the scenarios. The compiler checks the declared relationships; simulations show whether requests still reach the intended services and data stores under the new assumptions. Keep scenarios for behavior that must survive the change, such as preventing a regular user from reaching an admin page.

Polish currently checks specifications you or an LLM write. It does not extract architecture from application code, generate the application, or verify that a deployment matches the specification.

Catch an infrastructure choice that conflicts with the design

You add path-based routing for /api/*, then discover that your load balancer is an AWS Network Load Balancer. Polish rejects path rules on its NLB profile at compile time:

load_balancer Ingress {
  provider = aws
  product = nlb
  route "/api/*" to Apps
}

With Apps declared in the surrounding architecture, this produces E_VENDOR: NLB cannot inspect HTTP paths; use routes_to. One solution is to change the component to product = alb, configuring TLS termination if it accepts HTTPS. Another is to keep the NLB forwarding traffic and put the path rules in an HTTP router behind it. AWS documents the listener capabilities for ALBs and NLBs.

Test capacity assumptions before provisioning

Declare a workload and compare it with your capacity assumptions: request rate, CPU cost, instance counts, connection limits, database throughput, or queue consumer rate. Scenarios can expose a service that needs more instances, a queue whose backlog grows, or a data store whose declared request budget is exceeded. Change the design and rerun the same workload to compare outcomes. See scaling, resource budgets, and AWS processing for examples.

These are deterministic models of declared assumptions, not cloud benchmarks. A passing scenario means the modeled request satisfies the modeled constraints; it does not establish production performance or reliability.

Start here

• New to Polish? Follow Run it for a deterministic simulation; no API key is needed.
• Comparing architecture changes? See the recommendation walkthrough for an offline comparison followed by an optional Jev choice.
• Inspect a completed example: decision-model report, with linked JSON evidence. Download/open the HTML locally; GitHub's source view does not render it as a report.
• Troubleshooting your first run? See the new-user guide, including virtual environments, credentials, exit codes, and reading reports.

Run it

Requires Python 3.11 or newer.

python3 -m venv .venv
source .venv/bin/activate
python -m pip install -e '.[dev]'

polish check examples/shop.polishd
polish simulate examples/shop.polishd
polish simulate examples/shop.polishd --scenario "Product page calls the API end to end"
polish simulate examples/shop.polishd --json
pytest -q

After installing, without activating the virtual environment, use .venv/bin/polish and .venv/bin/python -m pytest. python -m polish is also supported.

If editable installation is unavailable in your environment, use a regular installation (python -m pip install .). When editing the compiler, use .venv/bin/python -m polish from the project root to run the current source, or reinstall with python -m pip install . to refresh the installed polish command.

Commands return exit code 0 when checks or scenario expectations pass, and 1 for compilation errors, failed expectations, unreadable input, or no matching scenarios. An expected denial or expected TLS error is a passing scenario. --json emits a single JSON object with ok, diagnostics, and results.

Example

architecture CatalogSite {
  artifact_store Assets { kind = object_store tls = true }

  frontend Site {
    rendering = static
    loaded_from Assets
    page Product
    Product invokes Catalog.get_product
  }

  cdn Edge {
    tls_termination = true
    route "/api/*" to Balancer
  }
  load_balancer Balancer { routes_to Servers }
  compute_pool Servers { instances = 2..10 }

  service Catalog {
    hosted_on Servers
    operation get_product {
      method = GET
      path = "/api/products/*"
      reads Products.Items
    }
  }

  database Products {
    kind = relational
    read_replicas = 2
    hosted_on Storage
    table Items { id: uuid primary_key name: string }
  }
  database_cluster Storage { engine = postgres replicas = 2 }
}

scenario "Load product details" {
  request {
    entry = Site.Product
    action = Catalog.get_product
    via = Edge
    protocol = https
    method = GET
    path = "/api/products/123"
  }
  expect {
    outcome = success
    reaches Catalog.get_product
    accesses Products.Items
  }
}

This scenario loads the page from its artifact store, checks that the page may invoke the operation, and traverses the API route to the database access. Page loading alone does not automatically invoke every service the page is allowed to use. action selects an operation and via selects its network entry point.

See the ecommerce example for navigation, checkout, authorization, key-value storage, and nine executable scenarios. The invalid example demonstrates the compiler rejecting two loading sources.

Language rules

Each file contains one architecture Name { ... } followed by zero or more scenario "Name" { ... } blocks. Identifiers are case-sensitive. Properties use =, relationships use named verbs, and comments start with // or #. Values include quoted strings, bare symbols, numbers, booleans, and inclusive integer ranges such as 2..10. General variables, expressions, imports, and user-defined types are not implemented yet.

Component kinds are built in. Nesting means containment: a page belongs to a frontend; it does not inherit from the frontend as a class. Pages inherit their frontend's rendering settings, loading source, and access restrictions.

Component	Allowed children	Selected properties
frontend	page	rendering = static or server
service	operation	tls
database	table for relational; document or collection for document storage; keyspace for KV	kind, read_replicas, partitions, durability and replication settings
artifact_store	none	kind = object_store or artifactory, tls
cdn	none	tls, tls_termination, upstream_protocol, request_collapsing, shielding, rate_limiting, bot_mitigation
gateway	none	tls, tls_termination, upstream_protocol, rate_limiting
load_balancer	none	tls, tls_termination, upstream_protocol
cache	none	tls, tls_termination, upstream_protocol, ttl
compute_pool	none	instances = 2..10, tls
database_cluster	none	engine, replicas, partitions, copies, failure_domains, storage, tls
keyspace	none	key_type, value_type
role	none	none

An operation can declare method and path together to expose an HTTP endpoint. Methods are GET, POST, PUT, PATCH, DELETE, HEAD, and OPTIONS. A service without HTTP operations can serve as a page renderer or a logical service dependency. Fields support uuid, string, decimal, integer, boolean, datetime, and json, with optional primary_key metadata. No records or queries are executed.

Relationships

Product navigates_to Cart
Product invokes Catalog.get_product

Inside a component, omit the source to refer to that component:

service Catalog {
  hosted_on Servers
  operation get_product { reads Products.Items }
}

References resolve from the enclosing scope outward, then at the architecture root. Use qualified names such as Site.Product or Catalog.get_product in scenarios.

Relationship	Source → target
navigates_to	page → page
invokes	frontend, page, service, operation → service, operation
reads, writes	service, operation → database, table, document, collection, keyspace, cache
loaded_from	frontend, page → artifact store for static rendering; service or load balancer for server rendering
hosted_on	service, self-hosted cache, self-hosted gateway → compute pool; database → database cluster
routes_to	CDN, gateway, load balancer, cache → network component, compute pool, service, operation, artifact store, database, database cluster

Each frontend needs exactly one loading source. A page can override its inherited source with exactly one local source. Two local sources are an error, even if they point to the same component. Each service, database, and self-hosted cache needs exactly one compatible host. Managed cache profiles omit the host. Services cannot invoke frontends; returning a response is implicit and does not require an invocation edge.

route "/api/*" to Gateway is a path-specific routing edge. Patterns use shell wildcards (*, ?, [abc]), with * also matching slashes. The route with the longest literal prefix wins; equally specific matches fail as ambiguous. routes_to Target is a fallback used when no explicit route matches.

At a compute pool, the simulator selects an operation from its hosted services using the request method and path. An exact endpoint match wins over wildcard matches; multiple remaining matches fail. Explicit routing to an operation selects that operation directly.

Access and TLS

page Checkout { requires authenticated }
page AdminPanel { requires role Admin }

Requirements also work on frontends, services, and operations. Parent requirements apply to children. Role requirements need both authenticated = true and the matching actor. Requests are anonymous by default; specifying a role alone does not authenticate a request. All declared requirements must be satisfied. Only one actor role is supported per request.

Network components accept HTTP by default. HTTPS requires tls = true or tls_termination = true. A forwarding component that terminates TLS defaults to HTTP upstream; upstream_protocol = https starts another TLS connection. Without termination, HTTPS is preserved; changing it to HTTP causes TLS_TERMINATION_REQUIRED. TLS support must be declared on every modeled receiver of an HTTPS network hop.

Scenarios

A request can describe one of three flows:

• A network request: entry = Edge, method = GET, path = "/api/products/123".
• Navigation: entry = Site.Landing, destination = Site.Checkout.
• A frontend action: entry = Site.Product, action = Catalog.get_product, via = Edge, plus the HTTP method and path.

protocol defaults to https, method to GET, and path to /. Navigation finds an authorized path through declared links and loads the pages along it. Actions and navigation are separate scenarios in this version.

Expectations require outcome = success, denied, or error. Optionally specify an exact error code with error = TLS_UNSUPPORTED. Add reaches Component and accesses Database.Table assertions to check the trace. Assertions also apply to expected-error scenarios: they are not skipped on failure.

Service and database connections

Service and operation dependencies traverse a connection path before execution. Use an optional block on invokes, reads, or writes:

invokes Inventory.reserve { via = InternalLB protocol = https }
reads Products.Items {
  via = DataLB
  protocol = tls
  path = "/products"
  read_from = replica
  consistency = strong
}
writes Orders.Purchases { protocol = tls durability = replicated }

via starts the connection at a gateway, load balancer, or another permitted network entry. Routing must reach the target workload or its declared host; reaching a different host fails with WRONG_DESTINATION. Calls without via connect directly to the target's host. The compiler still accepts existing bare relationships: service calls default to http, database calls to tcp.

Service calls accept http or https; database calls accept tcp or tls (encrypted TCP). Both the receiving host and workload must declare TLS support when encryption reaches them. Forwarders can terminate TLS and optionally re-encrypt upstream. Protocol families cannot change from HTTP to TCP or vice versa. CDN and gateway nodes only support HTTP-family connections.

Connection path selects an infrastructure route. For service calls it defaults to the target operation's declared path, otherwise /. For database connections it is a logical routing label, not a SQL query or an actual TCP URL. Dependency routing targets the named operation, rather than redispatching the caller's HTTP method/path against the callee. A service target executes its service-level requirements and dependencies; name an operation to execute that operation.

Each connection has its own routing-cycle check, so two services can legitimately share a pool. Recursive execution still fails with REQUEST_CYCLE. Calls retain the scenario identity. Service-level dependencies run before operation-level ones, in declaration order, and an error stops subsequent execution. Data access is only recorded after transport and read/write requirements pass.

See storage.polishd for a checkout that calls inventory through an internal load balancer, then uses all three database kinds. It also contains expected failures for missing TLS, inconsistent replica reads, and insufficient write durability:

python -m polish simulate examples/storage.polishd

Scale, storage, and durability

These properties define Polish contracts, not vendor-specific guarantees.

Database kind	Data children	Partitioning
relational	table	Optional count or managed
document	document, collection	Optional count or managed
key_value	keyspace	Optional count or managed

A keyspace requires key_type (string, integer, uuid) and value_type (string, integer, decimal, boolean, json, bytes). The compiler rejects children incompatible with their database kind. A database may also be accessed directly without declaring children.

database Sessions {
  kind = key_value
  partitions = managed
  replication_factor = 3
  read_replicas = 2
  replication = asynchronous
  durability = disk
  hosted_on SessionStorage
  keyspace Tokens { key_type = string value_type = json }
}
database_cluster SessionStorage {
  storage = persistent
  replicas = 2
  copies = 3
  partitions = managed
}

• instances accepts a positive count or ordered positive range. partitions accepts a positive count or managed; omission means unspecified.
• replication_factor counts all copies per partition, including the primary. It defaults to 1 + read_replicas. read_replicas defaults to zero and cannot exceed the total copies minus the primary. Copies need not all serve reads.
• Host replicas is read-replica capacity; host copies is total copy capacity per partition. Explicit host counts bound the database's requested counts. Managed partition counts are opaque and are not compared numerically.
• Database failure_domains declares the number of distinct placement domains. It cannot exceed the copy count or an explicitly declared host domain capacity. It does not promise survival under a particular failure; placement and quorum availability are not simulated.
• durability = memory (the default) promises no persistent write acknowledgement. disk requires storage = persistent on the host.
• durability = replicated requires persistent host storage, at least two copies, replication = synchronous, and write_ack = quorum or all. Quorum means floor(copies / 2) + 1 acknowledgements; all means every copy. primary is the default acknowledgement policy. Quorum/all policies require synchronous replication and at least two copies even when durability is not replicated.
• backups = true requires a positive backup_retention_days. Retention without enabled backups is an error. This validates a backup policy; it does not execute backup or restore jobs or guarantee an RPO/RTO.

A write may require a minimum durability using writes Store { durability = disk }. The simulator checks the ordering memory < disk < replicated and traces the number of configured acknowledgements. Copies alone do not imply persistent storage, synchronous replication, or successful backup.

Reads default to read_from = primary and consistency = eventual. A replica read requires at least one declared read replica. In this simplified contract, consistency = strong on a replica requires synchronous replication; a primary read is accepted. This models a declared capability, not a proof of database linearizability, transactions, isolation, or actual replication lag.

Missing host capacity means unspecified, not zero. Checks apply per database; shared-host resource reservations and aggregate capacity are not modeled yet.

AWS CPU capacity scenarios

Run .venv/bin/python -m polish simulate examples/scaling.polishd to see both service and PostgreSQL overloads, with explicit arithmetic in the trace. Add --json for structured per-resource capacity results.

The initial AWS catalog in polish/config/vendors/aws/ec2.json supports EC2 m7i.large, m7i.xlarge, and m7i.2xlarge. vCPU and memory figures are sourced from AWS's instance specifications. These EC2 profiles support services and self-managed PostgreSQL. RDS uses separate db.* profiles described below. There is no AWS account access, deployment, pricing, or region-availability lookup. Memory specifications also support the optional service memory model below.

compute_pool AppPool {
  provider = aws
  instance_type = "m7i.large"
  instances = 1..4
  cpu_utilization = 0.7
}

Declare cpu_ms = 10 on an operation, or on its service as a fallback. An operation cost replaces its service fallback; it does not add to it. This represents total vCPU-milliseconds per invocation, not elapsed request latency. Explicit zero is allowed; an omitted cost is not silently assumed to be zero.

In the scenario request, set rate_rps = 200 and optionally scale = minimum or maximum. The default is minimum: a 1..4 pool uses one running instance. Maximum evaluates the same workload with four instances, without simulating autoscaling decisions or startup delays. Fixed instance counts are unchanged.

demand   = requests_per_second × CPU_ms_per_request
capacity = running_instances × vCPUs_per_instance × 1000 × cpu_utilization
required_instances = ceil(demand / capacity_per_instance)

For the example: 200 × 10 = 2000 CPU-ms/s, while one 2-vCPU instance at a 70% budget provides 1 × 2 × 1000 × 0.7 = 1400 CPU-ms/s. One fails; two suffice under the model; four pass. cpu_utilization defaults to 0.7, a configurable modeling assumption rather than an AWS guarantee. CPU budgets apply per pool.

Every executed operation and service dependency is charged once per execution per root request. Costs aggregate across services sharing a compute pool and across multiple reads/writes using the same database role. Scenarios run in isolation; multiple traffic classes, probabilistic branches, retries, variable fan-out, and background traffic are not combined automatically.

For PostgreSQL, declare an AWS profile on the database_cluster, use engine = postgres, and put cpu_ms on each reads/writes relationship:

reads Products.Items { read_from = replica cpu_ms = 20 }
writes Products.Items { cpu_ms = 20 }

Replica reads share read_replicas running instances. The host's replicas property is a capacity ceiling, not a count of active readers. Primary reads and writes share exactly one primary. Increasing replicas can fix read overload but cannot fix primary overload; use a larger instance or reduce workload/cost. Primary required_instances is a CPU-equivalent count only, accompanied by horizontal_scaling = false. This version requires a dedicated host cluster per database for workload simulation; DB partitioning does not multiply capacity.

Without rate_rps, existing scenarios remain functional checks. With it, every executed service/database workload needs an AWS host profile and explicit CPU cost; incomplete models fail with SCALING_MODEL_INCOMPLETE. Database CPU scaling currently supports PostgreSQL relational stores only. Static-only traffic is not modeled. Overload returns CAPACITY_EXCEEDED; expected overloads can be passing tests. Capacity is evaluated after functional traversal, before returning success.

The calculation assumes perfectly balanced, parallelizable CPU work and constant costs. Measure those costs for your application and chosen machine profile. vCPU count alone is not a performance benchmark. Disk IOPS, locks, network bandwidth, replication overhead, and tail latency are not calculated; memory and connection budgets are optional models described below; include known CPU overhead in the declared cost. This is a steady-state feasibility model, not a throughput guarantee or a latency simulator. Arithmetic formulas are implemented by the simulator; .polishd currently supplies their numeric inputs rather than supporting general expressions.

Memory and database connection budgets

Run python -m polish simulate examples/budgets.polishd for five scenarios covering CPU overload, connection-pool oversubscription, memory overload, and scale-out. JSON output includes a budgets array alongside CPU capacity records.

These checks opt in through declarations and run on scenarios with rate_rps. Existing CPU-only and functional scenarios retain their previous behavior.

service Checkout {
  hosted_on Apps
  base_memory_mib = 512
  connection_pool_size = 20
  operation buy {
    method = POST path = "/buy"
    cpu_ms = 10
    duration_ms = 100
    memory_per_request_mib = 2
    writes Products.Items { cpu_ms = 0.1 }
  }
}

Memory uses the following steady-state estimates:

concurrent requests = rate_rps × duration_ms / 1000
inflight memory     = concurrent requests × memory_per_request_mib
base memory         = instances × sum(resident services' base_memory_mib)
available memory    = instances × instance_memory_GiB × 1024 × memory_utilization

Set memory_utilization on the compute pool (default 0.8 when the model is enabled) to reserve headroom for the operating system and other overhead. The model counts base memory for every resident service, including services not called in the scenario, assuming one process of every resident service on every pool instance. Every resident must declare base_memory_mib when memory modeling is enabled; place unsupported resident types such as caches in separate pools.

Operations declare duration_ms and memory_per_request_mib, or inherit those values from their service. Duration is elapsed time, separate from cpu_ms. Explicit zeros are allowed. Inflight costs sum across executed operations; each invocation's memory footprint must also fit a single instance alongside resident base memory. Missing required inputs fail explicitly. The model assumes balanced traffic and fixed costs, and does not predict peak concurrency, garbage collection, allocator fragmentation, leaks, or PostgreSQL's internal memory usage.

For connections, set database max_connections and optional reserved_connections (default zero). Set each calling service's connection_pool_size, interpreted as a maximum per application instance per database role. A role is the primary or the read-replica group.

potential connections = sum(calling service instances × connection_pool_size)
available per DB instance = max_connections − reserved_connections

Repeated reads/writes from the same service to the same role reuse the same pool budget. Different services add to the budget. Replica pools are assumed perfectly balanced across readers: each reader needs ceil(total / read_replicas) slots. The primary has one budget shared by primary reads and writes. Only services whose database edges execute in the scenario contribute pools; background or idle pools outside that path must be accounted for through reserved connections or separate scenarios. This does not model PgBouncer or multiplexing.

The example has 200 database slots, with 20 reserved. Four application instances with pools of 20 need at most 80 slots. Twenty instances need 400 slots and fail with CONNECTION_BUDGET_EXCEEDED, even though their CPU budget now suffices. Reducing the pool size to 9 brings that budget to 180 and passes the model.

This is a conservative potential oversubscription check, not observed runtime connection exhaustion: it assumes configured pools could fill. Actual open connections, checkout wait time, and connection-hold duration are not simulated. CPU feasibility is evaluated first, followed by memory and connection budgets; a CPU failure can therefore stop the scenario before budget results are emitted.

Cloud vendor catalogs and AWS products

Vendor-specific definitions live under their own folders, separate from the core language definitions:

polish/config/
  vendors.json
  vendors/
    aws/
      ec2.json       # EC2 instance hardware
      rds.json       # RDS PostgreSQL and db.* instance classes
      dynamodb.json  # Managed storage and capacity-unit rules
      elb.json       # ALB/NLB protocol and routing capabilities

vendors.json lists the product files to load for each vendor. Custom config directories must include that manifest and its referenced files. The old root aws.json has been removed; migrate custom copies to the new layout. Catalogs ship with the Python package. AWS, self-hosted software, Kong, and Fastly profiles are implemented; adding another folder alone does not implement its behavior. Instance sizes, product properties, defaults, restrictions, and capacity-unit constants are data; execution remains in the simulator. Product profiles apply when both provider = aws and a matching product are declared.

Run the complete example:

python -m polish simulate examples/aws-products.polishd

RDS PostgreSQL

database_cluster Rds {
  provider = aws
  product = rds_postgres
  instance_type = "db.m7i.large"
  multi_az = true
}

Supported classes initially include db.m7i.large and db.m7i.xlarge, sourced from AWS RDS hardware specifications. EC2 names cannot be substituted for RDS classes, and RDS classes cannot host compute pools. Engine defaults to postgres, storage to persistent, and TLS support to true. Hosted relational databases default to TLS support and disk durability. Explicit TLS settings still determine whether a modeled request passes. Existing PostgreSQL CPU and connection-budget checks apply.

multi_az represents the Multi-AZ DB instance deployment, not an Aurora or Multi-AZ DB cluster. Its standby adds no modeled read or write capacity. AWS documents this distinction in its Multi-AZ DB instance guide. Declare read_replicas separately on the database. These default to asynchronous replication; this profile rejects synchronous read-replica declarations. Failover, standby replication cost, availability guarantees, engine versions, region support, and service quotas are not simulated.

DynamoDB

database Sessions {
  kind = key_value
  partitions = managed
  hosted_on DynamoTable
  keyspace Tokens { key_type = string value_type = json }
}
database_cluster DynamoTable {
  provider = aws
  product = dynamodb
  capacity_mode = provisioned
  read_capacity_units = 100
  write_capacity_units = 50
}

Here database_cluster represents a managed product endpoint, not a machine you provision. One such host and its logical database represent one DynamoDB table's capacity budget. Nested keyspaces/collections are schema views within that table, not independently provisioned AWS tables. Use separate database/host pairs for separate DynamoDB tables. Both key-value and document database kinds are supported. Partitions are managed; instance types, CPU budgets, connection limits, and user-managed replicas are rejected. Transport defaults to HTTPS. This version models managed persistence at Polish's disk durability level; it does not model DynamoDB replication internals or global tables.

reads Sessions.Tokens { item_bytes = 4096 consistency = strong }
writes Sessions.Tokens { item_bytes = 1500 }

Each edge models one nontransactional item operation per root request. Supply the complete item size in bytes, including attribute-name overhead. Size must be between 1 and 409600 bytes. For a scenario with rate_rps:

strong read units/sec   = rate_rps × ceil(item_bytes / 4096)
eventual read units/sec = strong_read_units × 0.5
write units/sec         = rate_rps × ceil(item_bytes / 1024)

These constants follow AWS DynamoDB capacity rules. Thus 30 writes/sec of 1500-byte items consume 60 write units/sec and exceed a 50-unit provisioned budget. Demand aggregates across repeated accesses to the same database; read and write budgets are separate. item_bytes is required for workload simulation; cpu_ms and read_from are not valid on DynamoDB edges.

For capacity_mode = on_demand, omit provisioned capacities and optionally declare max_read_units and max_write_units. A rate-based scenario requires an explicit maximum for whichever operation it exercises. This bounds the simulation; it does not assume immediate or unlimited scaling. Burst capacity, ramp-up, hot partitions, indexes, transactions, scans, conditional-write behavior, retries, and billing are not modeled. Throttling is a deterministic aggregate-budget failure, not a precise prediction of which individual AWS requests would throttle.

AWS load balancers

load_balancer PublicALB {
  provider = aws
  product = alb
  tls_termination = true
  route "/api/*" to Apps
}
load_balancer InternalNLB {
  provider = aws
  product = nlb
  tls = true
  routes_to Rds
}

ALB accepts modeled HTTP/HTTPS traffic and path routes. HTTPS must terminate at the ALB. NLB rejects path routes and forwards using routes_to; TCP/TLS and HTTP payloads over those transports are supported by this simplified model. tls = true without termination represents encrypted passthrough. It does not mean NLB inspects HTTP paths. UDP, QUIC, listener ports, target groups, health checks, certificates, LCUs, and load-balancer capacity limits are not modeled yet. See AWS ALB listeners and AWS NLB listeners.

No AWS resources are created or queried while compiling or simulating.

Caches, GraphQL, gateways, databases, and AWS processing

Both validation and executable models are provided for the products below. Models are deliberately explicit: declared throughput limits are workload measurements or planning assumptions, never invented vendor benchmarks.

Component and product	Deployment	Executable checks
cache, redis / memcached	provider = self_hosted, required compute host	Hit/miss paths, fallback calls, dataset size, operations/sec
cache, elasticache_redis / elasticache_memcached	provider = aws, no compute host	Same cache model with managed hosting
database_cluster, cockroachdb	provider = aws or self_hosted	Relational schema, transport, declared cluster operations/sec
database_cluster, mongodb	provider = aws or self_hosted	Document schema, transport, declared cluster operations/sec
gateway, graphql	provider = self_hosted, required compute host	HTTP routing, declared query-depth/cost limits
gateway, gateway	provider = kong, required compute host	HTTP routing, request-rate and burst budgets
gateway, api_gateway	provider = aws	HTTP routing, request-rate and burst budgets
cdn, cdn	provider = fastly	Edge routing, request-rate and burst budgets
gateway, signal_sciences or next_gen_waf	provider = fastly	Inline policy routing, request-rate and burst budgets
stream, msk	provider = aws	Broker/replication constraints, message throughput, backlog growth
queue, sqs	provider = aws	Standard/FIFO configuration, message throughput, backlog growth
batch_cluster, emr	provider = aws	Spark/Hadoop configuration, worker CPU capacity

AWS CockroachDB/MongoDB profiles describe software deployed on AWS, not AWS-native managed database products. They do not imply Atlas or CockroachDB Cloud support. Signal Sciences is exposed under Fastly, consistent with Fastly's Next-Gen WAF documentation. The WAF node abstracts an inline policy check; attack detection and vendor agent deployment are not reproduced. GraphQL is an HTTP layer, not a cloud vendor.

python -m polish simulate examples/platforms.polishd
python -m polish simulate examples/aws-processing.polishd

Caches and self-hosted hardware

compute_pool Local {
  provider = self_hosted
  vcpus = 4
  memory_gib = 16
  instances = 2
}
cache Redis {
  provider = self_hosted
  product = redis
  hosted_on Local
  capacity_mib = 512
  dataset_mib = 100
  max_ops_rps = 1000
  invokes API.backend
}

Services access caches with reads Redis or writes Redis. Use scenario cache_result = hit to serve a hit, or miss (the default) to execute the cache's invokes fallback. A miss without a fallback fails explicitly. Hits skip fallback CPU and database work; repeated cache accesses add operations to the cache budget. Writes record access but do not mutate persistent state across scenarios. Cache edges accept transport settings, not database consistency or durability options.

capacity_mib is the usable logical cache allocation, not raw instance RAM. dataset_mib defaults to zero (an undeclared dataset), and exceeding the allocation fails before fallback. A rate-based scenario requires max_ops_rps. These are aggregate cache budgets, not inferred Redis/Memcached performance. Eviction, TTL expiry, serialized keys, warming, cluster hashing, persistence, and inferred hit ratios are not modeled. The selected hit/miss applies to all cache reads in that scenario. Redis and Memcached share this intentionally generic cache model. For ElastiCache, select the AWS product and omit hosted_on; capacity is still an explicit assumption. See AWS's engine comparison.

Self-hosted compute pools use explicit vcpus and memory_gib, not an AWS instance name. Existing service CPU and memory math applies. Database and cache declared capacity budgets remain separate; the model does not infer their throughput from CPU specifications or aggregate cache allocation against colocated service RAM.

MongoDB and CockroachDB

database_cluster Documents {
  provider = self_hosted
  product = mongodb
  nodes = 3
  max_ops_rps = 100
}

Attach a document database to MongoDB, or a relational database to CockroachDB. nodes validates deployment size. max_ops_rps is a measured whole-cluster budget; increasing nodes does not automatically multiply it. Each executed read or write adds the scenario rate to the host's demand, including accesses from different logical databases. Exceeding the budget fails. Wire-level query plans, distributed transactions, MongoDB write concern, CockroachDB range placement, replication protocols, elections, and hot shards are not simulated. Generic Polish storage declarations do not prove those vendor-specific semantics. Their concepts are described in CockroachDB deployment documentation and MongoDB replication documentation.

Gateways, GraphQL, and rate limits

Set limit_rps for steady-state offered load and burst_limit for an instantaneous burst. Scenarios supply rate_rps and optional burst_requests. Repeated traversal of a policy node adds offered load. Exceeding either limit returns RATE_LIMITED with outcome denied before the downstream request runs. At the limit, traffic passes. No requests are partially admitted: an overloaded workload fails as a whole.

For GraphQL, set max_query_depth and/or max_query_cost; the scenario must supply the corresponding query_depth/query_cost. Excess returns GRAPHQL_LIMIT_EXCEEDED. The layer forwards to a service operation; that operation declares resolver-like dependencies using invokes and data access edges. Polish does not parse GraphQL documents, infer cost, validate a GraphQL schema, implement federation, or infer N+1 fan-out. Gateway host requirements validate topology; the gateway's own CPU overhead is not automatically charged to its host.

These common policy checks are not exact replicas of vendor algorithms. In particular AWS API Gateway uses token buckets and best-effort throttling, while Kong offers multiple rate-limiting plugins. This iteration checks steady-rate and burst budgets independently; token refill, time windows, distributed counters, per-identity quotas, and vendor licensing or plan availability are outside the model.

MSK, SQS, and EMR workload math

Services and operations may publishes_to / consumes_from a stream or queue, or submits_to a batch cluster. Each edge represents one message/job per root request. SQS/EMR use modeled HTTPS connections; MSK uses TLS. Missing throughput inputs in a rate-based scenario fail rather than imply infinite capacity.

stream Events {
  provider = aws product = msk
  brokers = 3 partitions = 6 replication_factor = 3
  max_messages_rps = 100
  consumer_rate_rps = 80
  max_backlog = 1000
}
queue Jobs {
  provider = aws product = sqs queue_type = standard
  max_messages_rps = 100
  consumer_rate_rps = 5
  max_backlog = 20
}
batch_cluster Analytics {
  provider = aws product = emr framework = spark
  workers = 2 worker_vcpus = 2 cpu_utilization = 0.7
}

MSK replication cannot exceed broker count. MSK/SQS max_messages_rps is a declared aggregate throughput budget applied separately to publishing and consuming; it is not an AWS service quota. consumer_rate_rps declares background drain; explicit consumes_from edges add modeled consumption demand. Effective drain is capped at max_messages_rps. Starting with an empty backlog:

backlog = max(0, publish_rate − effective_consume_rate) × window_seconds

The scenario's window_seconds defaults to 1. max_backlog is optional; if supplied, exceeding it fails. A consume-only scenario tests capacity without requiring stored messages. Partitions do not automatically multiply cluster throughput. Visibility timeout, retention, queue type, and replication count are configuration metadata; delivery order, duplicates, retries, actual consumer groups, retention expiry, and Kafka offsets are not simulated. SQS standard queues can deliver duplicates and out-of-order messages; see AWS SQS documentation.

An EMR submission supplies submits_to Analytics { job_cpu_ms = 1000 }:

batch demand   = rate_rps × job_cpu_ms
batch capacity = workers × worker_vcpus × 1000 × cpu_utilization

At 3 jobs/sec, that is 3000 CPU-ms/sec. Two 2-vCPU workers at 70% offer 2800, so the scenario fails; three workers pass. Default utilization is 0.7. This assumes perfect parallelism and excludes driver overhead, Spark stages, shuffle, storage, memory, startup, and job scheduling. It is a workload feasibility model for an EMR-style processing cluster, not execution of a Spark/Hadoop job. All scenario state and budgets reset between runs.

Boundaries of this version

The simulator proves declared functional paths under the model's assumptions. It does not prove production availability, security, or performance. In particular:

• CPU capacity is modeled for explicitly declared workloads. Autoscaling timing, latency and physical failures are not simulated; queue backlog uses the aggregate model below. Storage configuration capacity is checked per database, not aggregated across tenants.
• CDN protection features, cache TTL, database engines, schema fields, and primary keys are typed or recorded metadata. Bot detection, caching, request collapsing, query semantics and version compatibility are not simulated. Explicit rate-policy budgets and cache hit/miss paths are simulated as described below.
• TLS checks cover request routing, page loading, service calls, and database connections. Certificates, TLS versions, real wire handshakes, and network ACLs are not modeled.
• Responses return implicitly. HTTP status codes, payloads, retries, queues, sessions, transactions, conditional branches, and reverse response paths are not modeled.
• Server rendering through a compute pool requires exactly one renderer service in that pool. Hybrid rendering can override settings per page, but streaming and hydration behavior are not modeled.
• There is no deployment backend, LLM integration, custom class inheritance, or persistent compiled artifact yet. JSON diagnostics provide an integration surface for an LLM to inspect and repair a specification.

Implementation

Language definitions live in polish/config/ and ship with the installed package:

File	Definitions
databases.json	Database kinds and allowed children, database properties, storage enums, positive integer settings
services.json	Service and operation properties and containment
hosts.json	Host properties and permitted hosting pairs
frontend.json	Frontend/page properties, rendering sources, artifact store kinds
network.json	CDN, gateway, load balancer, and cache properties
relationships.json	Allowed source/target types, connection options and protocols
language.json	Boolean properties, field types, HTTP methods, shared enums and integer settings
vendors.json	Vendor catalog manifest
vendor_schema.json	Vendor profile metadata validation contracts
vendors/aws/*.json	AWS EC2, RDS, DynamoDB, and ELB profiles, capabilities, and source metadata
errors.json	Compiler, storage, simulator, and CLI error codes, message templates, and failure outcomes
diagnostics.json	Model diagnostic details, required input bindings, and display labels
model_inputs.json	Model field mappings and optional numeric defaults
rules.json, rules/*.rules	Executable model formulas, conditions, defaults, and validation rules

For example, databases.json declares the storage kinds and their child types:

"database_kinds": {
  "relational": ["table"],
  "document": ["document", "collection"],
  "key_value": ["keyspace"]
}

The compiler loads definitions on each compilation. The grammar's component and relationship keywords come from these files too. To use a separate configuration, copy the whole directory and pass it explicitly:

cp -R polish/config /tmp/my-polish-config
python -m polish check examples/shop.polishd --config-dir /tmp/my-polish-config
python -m polish simulate examples/storage.polishd --config-dir /tmp/my-polish-config

The Python API accepts compile_source(source, config_dir=...). Custom directories replace the bundled configuration completely; there is no implicit working-directory override. Missing files and malformed definitions produce E_CONFIG diagnostics. Run python -m polish from the repository to use edited source configuration, or reinstall the package to refresh the installed CLI's bundled copy.

JSON configuration defines vocabulary, permitted declarations, and input bindings. The files in config/rules/ define executable model behavior: formulas, conditions, defaults, routing, TLS, durability, replication, and capacity checks. Python parses architecture definitions, supplies graph/data operations, and interprets the rules. Adding a property alone still does not invent behavior: define how the relevant rule consumes it. New host capabilities require interpreter support.

Error definitions use stable rule identifiers. For example:

"TLS_UNSUPPORTED": {
  "code": "TLS_UNSUPPORTED",
  "phase": "simulation",
  "message": "'{node_name}' does not accept TLS.",
  "parameters": ["node_name"],
  "outcome": "error"
}

Edit code or message to customize diagnostics. Simulation outcome may be error or denied; failures cannot be changed into successes. Rule identifiers with suffixes such as _2 distinguish different checks that share an emitted error code. Keep identifiers, parameter contracts, and phases unchanged. Templates support named placeholders and !r/!s, without attribute access, indexing, format specifications, or executable expressions. A message may omit parameters.

The simulator retains the catalog from compilation, including custom --config-dir definitions. If you change an emitted error code, update any scenario expect { error = ... } assertions that reference it. Existing scenario definitions remain in .polishd files. The conditions that detect errors still live in config/rules/; the error catalog describes their diagnostics, while rule files define executable checks. E_CONFIG is a built-in fallback so a broken or missing error catalog can itself be reported.

Diagnostic wording can also belong to the component or vendor product that defines an object. Resolution is product override → component override → shared catalog. For example, the EMR definition in vendors/aws/messaging.json contains:

"diagnostics": {
  "BATCH_CPU_INPUTS": {
    "message": "{component} '{name}' using {provider}/{product} requires {missing_fields} for {model}."
  }
}

When only worker CPU capacity is missing, this produces:

Incomplete scaling model: batch_cluster 'Analytics' using aws/emr requires worker_vcpus for batch_cpu.

The same override can live on components.batch_cluster in hosts.json as a class default. Overrides may target detail rules in diagnostics.json or complete error rules such as TLS_UNSUPPORTED in errors.json. They change wording, not error codes, failure outcomes, or the conditions that trigger checks. Object-level errors resolve the object's product, or its parent/host product when applicable; architecture-level errors use the shared catalog.

Detail templates and overrides accept plain named placeholders from their parameter contract plus name, component, provider, product, model, and missing_fields. Unlike the original error catalog, these templates do not allow format conversions. Invalid templates and input contracts produce E_CONFIG. Custom config directories must include diagnostics.json.

Named input contracts describe fields and labels separately from message text. Component and product overrides can replace an inputs binding by semantic name, while retaining its scope. Platform capacity calculations consume these bindings for batch CPU, cache memory, and cache/database/message throughput. Renamed fields must also be declared in the component/product property schema. This is not a general mechanism for renaming every language field. For other models or changes to their algorithms, edit the corresponding configured rule file.

Compiler diagnostics and simulation JSON include structured context identifying the object, component, provider/product, rule, and template origin. Missing-input diagnostics additionally list the specific missing fields. Planner findings retain simulation diagnostics and classify incomplete models by stable rule identifiers, so changing a public error code does not change their classification.

Platform calculations resolve numeric DSL fields through configuration too. For example, model_inputs.json maps the backlog model's semantic input background_consumption to consumer_rate_rps, and the traffic model's rate to rate_rps. Rate and burst limits, GraphQL depth/cost, cache dataset size, batch worker counts/utilization, partition counts, and backlog windows/limits use the same mechanism. Required capacity bindings remain in diagnostics.json so their calculations and missing-input messages share one definition.

A component or product can override a mapping using model_inputs. For example, an SQS product with a declared, nonnegative drain_rps property could define:

"model_inputs": {
  "message_backlog": {
    "background_consumption": {
      "scope": "node",
      "field": "drain_rps",
      "default": 0
    }
  }
}

The simulator then uses drain_rps in the actual backlog calculation: max(0, arrivals - min(capacity, consumers + background_consumption)) × window. Precedence is product → component → shared model inputs. Missing optional fields use the configured default; missing required numeric inputs produce a diagnostic. Model names, semantic input names, scopes, and optionality are fixed contracts; unknown models, invalid mappings, and invalid numeric defaults produce E_CONFIG. Custom config directories must include model_inputs.json.

Input bindings are consumed by rules/platforms.rules; model names such as rate_policy and traffic, and formula variables such as demand, live there too. CPU, connection, storage, broadcast, and vendor models have their own rule files. Declare new scenario fields in language.json under request_properties, and add validation and execution rules that consume them.

Executable model rules

rules.json maps stable engine hook modules to files in config/rules/:

Rule file	Owns
platforms.rules	Rate/burst limits, GraphQL checks, cache and message throughput, backlog, batch capacity
scaling.rules	CPU demand, hardware selection, instance counts, scaling validation
budgets.rules	Memory feasibility and database connection pools
cache_connections.rules	Client pool distribution and per-node cache connection budgets
runtime_resources.rules	Broadcast connections, retention, local volumes, external service budgets
vendors.rules, cloud_products.rules	Vendor contracts, defaults, cross-product constraints, DynamoDB capacity
storage.rules	Durability, replicas, storage and connection contracts
simulator.rules	Request traversal, routing, TLS, authorization, dependency invocation, assertions
compiler_contracts.rules	Architecture and scenario semantic validation

For example, the backlog formula is configured in platforms.rules:

consumed = min(self.message_limit(node), self.loads.get((name, "consume"), 0) + inputs.get("background_consumption"))
backlog = max(0, arrivals - consumed) * window

Changing this formula in a custom configuration changes the simulated result; no edit to platforms.py is required. That Python module is now a lifecycle adapter. The same applies to the other model adapters. Existing .polishd files keep their syntax and behavior with the bundled rules.

Rule files use a restricted Python-shaped syntax, interpreted by rule_engine.py rather than imported or passed to Python eval/exec. Supported operations include arithmetic, comparisons, conditionals, loops, local functions, collections, and registered graph/model/diagnostic operations. Imports, private attribute access, arbitrary host calls, and unsupported syntax are rejected. Execution has an instruction budget and guards against oversized numeric and sequence operations. Rule failures produce E_CONFIG; a broken rule does not count as a passing scenario even when an error was expected.

Keep exported hook names and signatures unchanged. Model names, field bindings, formulas, thresholds, and conditions inside those hooks belong to configuration. Custom config directories must include rules.json and every referenced rule file; these are also included in the wheel. A compiled architecture retains its rules, so simulation and planning use the same configuration that was validated.

• polish/grammar.lark: formal syntax, parsed using Lark.
• polish/model.py: typed component graph, fields, diagnostics, scenarios.
• polish/compiler.py: parsing, name resolution, type and constraint validation.
• polish/simulator.py: request traversal and scenario assertions.
• polish/storage.py: database contracts and connection-option validation.
• polish/cli.py: terminal and JSON output.
• tests/test_polish.py: positive and negative integration tests.

CloudFront, Cloudflare, S3, and ECR

See delivery.polishd for ten executable success and failure scenarios. Profiles live in config/vendors/aws/delivery.json and config/vendors/cloudflare/edge.json inside the polish package.

artifact_store Assets {
  provider = aws product = s3
  max_requests_rps = 100
}
cdn Edge {
  provider = aws product = cloudfront
  limit_rps = 200
  routes_to Assets
}
frontend Shop { rendering = static loaded_from Edge }

Use provider = cloudflare product = cdn for Cloudflare. Both profiles default to TLS termination with HTTPS upstream and support routing, TLS checks, limit_rps, and burst_limit. These limits are explicitly declared scenario policies, not vendor quotas. Every simulated request reaches the origin; CDN cache hits, shielding, geographic latency, and cache eviction are not modeled.

S3 defaults to a REST endpoint. With endpoint = website, TLS defaults to false, HTTPS fails, and only GET/HEAD requests succeed. Configure a CDN's upstream_protocol = http to reach that endpoint. See the AWS endpoint comparison. A rate scenario reaching S3 requires max_requests_rps:

origin demand = scenario rate_rps × visits to that origin
failure when origin demand > declared max_requests_rps

This is an aggregate request budget, not an estimate of S3's actual performance. Object existence, bucket permissions, CloudFront OAC, and S3 durability are not simulated in this iteration.

ECR is a container image registry, so use a service's image_from relationship:

artifact_store Images { provider = aws product = ecr max_pulls_rps = 5 }
service Api {
  hosted_on Apps
  image_from Images { authorized = true }
  operation get { method = GET path = "/" cpu_ms = 1 }
}

A service may have one image source. Registries cannot be used as frontend origins. The simulator checks HTTPS and workload authorization once per executed service per scenario. authorized defaults to false and represents the declared pull permission; it is independent of the request user's authentication. An optional scenario image_pulls_rps models startup pull traffic, independently of HTTP rate_rps. It requires max_pulls_rps; demands from distinct executed services using the same registry are summed. These checks represent a deployment precondition, not a fresh pull per application request. IAM evaluation, image layers/tags, network transfer time, and registry storage capacity are not modeled.

License

Polish is licensed under the MIT License.

Change-impact analysis and suggestions

Compare an existing architecture with a proposed design:

polish plan examples/plan-before.polishd --proposed examples/plan-after.polishd
polish plan examples/plan-before.polishd --proposed examples/plan-after.polishd --json

The example raises service instances from 2 to 8 without changing the connection pool. Polish identifies an introduced failure: 8 × 50 = 400 potential database connections against a budget of 300. It suggests comparing smaller per-instance pools with connection pooling. Changing the pool size to 30 gives 240 potential connections; rerun the plan to verify that proposal against the scenarios. The proposed example intentionally fails its success requirement, so this command returns exit code 1.

The planner compares component properties, requirements, fields, and relationships (including edge options). It follows relationships in both directions, containment, and explicit via references across both versions. Impact paths are conservative: sharing a connected graph means a component may be affected, not that it must change. Line-number changes do not count as architecture changes; renames appear as removal and addition. JSON output includes the diff and a path to each potentially affected component.

Both the baseline and proposed scenarios are evaluated against both designs. Identical scenarios are deduplicated; altered workloads or expectations are retained as separate requirements. Deleting or weakening a baseline scenario therefore does not erase the original requirement. --scenario NAME explicitly narrows evaluation. Results are classified as introduced, persists, resolved, or unchanged_pass according to whether the scenario's expectations pass. An expected denial or error can be a passing requirement. persists means the requirement fails in both designs; the underlying error may have changed, so inspect the before/after evidence.

Findings distinguish required fixes from missing information and include suggestions from polish/config/decisions.json. Custom config directories must include this file when running plan. Ordinary check and simulate do not require decision rules. Compiler-invalid designs receive diagnostics and advice without being simulated. Cross-design scenarios with incompatible references receive explicit diagnostics.

The default planner provides textual advice, not edited candidate architectures. Suggestions are not automatically applied, ranked, or proven to resolve a failure; edit a proposal and rerun the plan to test it. Optional candidate recommendations add objective-based selection among supplied alternatives. There is no cost model or migration execution engine. Simulations stop at the first runtime failure, and unobserved affected components are reported as needing information. Exit code 0 means all selected requirements pass on the proposed design, not that all possible impacts have been tested. Hard constraints currently come from the compiler rules and scenario expectations.

Optional decision-model recommendations (Jev or local Laya)

plan --candidates FILE --objective TEXT --decision-provider jev evaluates explicit candidate specifications against the baseline and proposal requirements, then uses Jev to choose among passing alternatives. The original plan result and exit status remain unchanged; recommendations never apply edits. Omit the provider for offline candidate checks. Install the optional HTTP client with pip install '.[jev]'.

See three executable examples and live results for connection pools, CPU scaling, and streaming retention. Reports separate uncalibrated choice probabilities from optional evidence-based historical accuracy intervals (--choice-evaluation). No confidence interval is invented for a single model response. The existing rule engine and ordinary simulations remain deterministic.

For offline inference, use --decision-provider laya --laya-checkpoint PATH. The optional laya extra installs the runtime; --laya-python can select a separate ML environment. No key or automatic download is used. See local Laya setup and commands for checkpoint preparation, device selection, timeout behavior, and model identity. The checkpoint comparison records both local runs: neither selected the objective-aligned alternative in the connection-pool example. Treat these runs as integration evidence, not a quality guarantee.

Cache connections and failure behavior

The radio catalog example models an API depending on Memcached and demonstrates connection overload, a cache miss fallback, and a cache error propagating to the API:

polish simulate examples/radio-catalog.polishd

Describe a reusable client pool on each cache reads or writes relationship:

reads StationCache {
  pool_size = 50
  pool_scope = worker
  pool_distribution = per_node
  on_miss = fallback
  on_error = fail
}

Worker-scoped pools require workers_per_instance on the source service. pool_scope = instance instead models one pool per service instance. All edges from a service to the same cache describe one shared pool and must agree on the three pool properties. Repeated reads/writes count that pool once; distinct services add to the same cache budget. These checks run even without rate_rps because pool limits do not depend on request throughput.

The cache declares max_connections_per_instance and optional reserved_connections_per_instance (default 0). Self-hosted caches get node counts from their host's instances; managed ElastiCache products require nodes for this model. Scenario scale selects minimum/maximum host counts as for other budgets. A supplied client pool requires a server limit, and a server limit requires client pool settings; missing values produce an incomplete-model error.

For 20 API instances and 8 workers per instance:

Distribution	Calculation	Potential connections per cache node
per_node	20 × 8 × 50	8,000, regardless of cache node count
cluster_even, 3 cache nodes	ceil(20 × 8 × 50 / 3)	2,667

cluster_even explicitly assumes an even distribution. It is not automatic sharding inference and does not model hotspots or skew. When multiple services share the cache, their rounded per-node budgets are added conservatively.

These numbers describe worst-case configured pool capacity, not observed sockets. The budget reports CACHE_CONNECTION_BUDGET_EXCEEDED if demand exceeds the limit minus reserved connections. It does not infer a timeout or predict when pools fill. Client creation per request, socket lifetime, retries, and deadline propagation are not modeled in this iteration. Redis and Memcached use the same declared pool math; Redis-specific primary/replica connection distribution is not inferred.

The scenario's cache_result is hit, miss (default), or error and applies to all cache accesses in that scenario. Reads honor hit/miss; writes ignore hit/miss. Both reads and writes honor error. Client policies are:

• on_miss = fallback (default): execute the cache's existing invokes fallback.
• on_miss = fail: report CACHE_MISS.
• on_error = fail (default): report CACHE_UNAVAILABLE, propagating to the caller.
• on_error = fallback: execute the cache's invokes fallback, including its downstream workload checks. An explicit fallback policy requires that relationship.

This error injection models a failed cache access; it does not bypass TLS or other architecture validation. Connection-budget overload remains a budget failure even if error fallback is configured. Multiple invokes fallbacks all execute, following the existing dependency semantics.

For planning, keep a success expectation for the catalog request and compare API instance counts. polish plan will identify a new cache-budget violation and suggest reviewing pool size, workers, and connection distribution. The radio example instead expects the overloaded scenario to fail, so all four demonstration scenarios pass. Fastly edge-cache traffic reduction and an automatic before/after cache migration model are not included yet.

Additional AWS and GCP products

polish simulate examples/multicloud.polishd

The ten scenarios cover successful requests and overloaded resources. New profiles live in polish/config/vendors/aws/events.json and polish/config/vendors/gcp/.

Provider / product	Component	Validation and simulation
aws / sns	topic	Standard/FIFO topic selection, SNS-to-SQS relationships, topic throughput and destination budgets
aws / kinesis	stream	Provisioned/on-demand contracts, declared shard capacity, consumption and backlog budgets
gcp / pubsub_topic	topic	Topic publishing, fan-out to subscriptions, declared publish capacity
gcp / pubsub_subscription	queue	Exactly one source topic, pull subscription, independent consumption and backlog
gcp / memorystore_redis	cache	Managed placement, dataset size, measured operation throughput, client connection budgets, miss/error policies
gcp / cloudsql_postgres	database_cluster	Relational storage, TLS, asynchronous read-replica consistency, measured aggregate operation throughput, database connection budgets

Topic delivery

topic Updates {
  provider = gcp product = pubsub_topic max_messages_rps = 100
  delivers_to Indexing
  delivers_to Analytics
}
queue Indexing {
  provider = gcp product = pubsub_subscription delivery = pull
  max_messages_rps = 80 consumer_rate_rps = 10 max_backlog = 50
}
queue Analytics {
  provider = gcp product = pubsub_subscription
  max_messages_rps = 100 consumer_rate_rps = 100 max_backlog = 200
}

Services use publishes_to Updates and consumes_from Indexing. Each publication delivers one message to every declared subscription. At 20 publications/s over six seconds, Indexing accumulates max(0, 20 - 10) × 6 = 60 messages, exceeding its 50-message budget, while Analytics has no growth. Backlog starts at zero for each scenario. consumer_rate_rps is background consumption; explicit consumes_from traffic adds to it. Declared capacity bounds publishing and consumption separately.

SNS uses the same topic syntax with provider = aws product = sns and topic_type = standard or fifo; its delivers_to targets must be AWS SQS queues. Standard SNS topics cannot target FIFO SQS queues. Pub/Sub subscriptions require exactly one incoming Pub/Sub delivers_to relationship; publishing directly to a subscription is rejected. Topics have publish budgets, not consumer backlogs.

These are aggregate messaging scenarios: a destination overload makes the scenario fail, not a claim that the real asynchronous publisher receives a synchronous error. Delivery latency, retries, IAM, filtering, message ordering/deduplication, and exactly-once guarantees are not simulated. Pub/Sub push/export subscriptions and SNS HTTP/email endpoints are outside this iteration.

Kinesis capacity

stream Events {
  provider = aws product = kinesis capacity_mode = provisioned
  shards = 2 messages_per_shard_rps = 50
  consumer_rate_rps = 100 max_backlog = 200
}

Provisioned capacity is shards × messages_per_shard_rps: this example supports a declared 100 messages/s. The per-shard rate is a measured assumption supplied by the user, not a built-in AWS quota. On-demand mode omits both shard settings and uses an explicit max_messages_rps bound. on_demand abstracts AWS on-demand variants; autoscaling history, warm capacity, hot keys, byte limits, and enhanced fan-out are not modeled. Read and write rates use the same declared bound independently. Kinesis connections use HTTPS, while MSK retains its TLS transport model.

GCP cache and database budgets

Memorystore reuses the Redis dataset, operation-rate, and connection-pool models. Use nodes as the number of modeled client-facing cache nodes, not a claim that standbys add serving capacity. High availability, tier-specific placement, Redis Cluster slot routing, failover, and replica endpoints are not modeled.

Cloud SQL uses a database hosted on database_cluster with provider = gcp product = cloudsql_postgres. Declare max_ops_rps on the cluster as measured aggregate capacity. Replica count does not automatically multiply that budget. Read replicas must be asynchronous and cannot satisfy strong-consistency replica reads. Optional service connection_pool_size and database max_connections/reserved_connections are evaluated as with the other connection budgets. This is an operation-rate model, not a Cloud SQL machine-type or HA model; instance_type and cpu_utilization are rejected for this profile.

The example uses explicitly sized self-hosted application compute; it does not imply that GCP Compute Engine machine types or Cloud Run execution are supported yet. All new rate limits are declared modeling inputs, not provider performance promises.

Product references: SNS FIFO, Kinesis capacity modes, Pub/Sub subscriptions, Memorystore for Redis, and Cloud SQL replication.

Local runtimes, mounted storage, and live streams

polish simulate examples/streaming-runtime.polishd

This synthetic example covers eight success/failure cases. Its capacity values are illustrative assumptions. It introduces:

• stream with provider = self_hosted product = redis_stream, hosted on a singleton compute_pool. Each consumer has an independent cursor; reads do not remove messages. This differs from competing queue consumers.
• request.concurrent_connections for concurrent long-lived listeners, separate from HTTP rate_rps. Multiple consumed streams share their host's declared max_stream_connections, minus optional reserved_stream_connections. Each consumer edge uses one connection per client unless connections_per_client declares another positive integer. These are declared connection assumptions, not client-library socket measurements. Existing reusable cache pools and these stream budgets are separate; reserve capacity for other Redis usage explicitly.
• consumer_lag_seconds compared with retention_messages and declared source_rate_rps. Required history is ceil(lag × source_rate); delivery demand is concurrent_connections × source_rate. A declared source rate requires a max_messages_rps delivery bound when evaluating listeners. Readers must supply concurrency for rate-based scenarios. Functional runs can omit capacity inputs.
• Proxy supports_streaming, response_buffering, and optional max_client_connections. A concurrent-stream scenario rejects explicit lack of support or enabled buffering. Omitted proxy settings do not prove streaming compatibility. Client limits are logical declared capacities, not a direct translation of a proxy's worker/file-descriptor settings.
• volume with storage = persistent or ephemeral. Services declare mounts Media { access = read_only } or read_write; their operations may reads Media / writes Media. Missing mounts fail compilation and writes through read-only mounts fail simulation. Optional used_mib/capacity_mib check declared occupancy; rate-based access requires max_ops_rps. No file data is created and writes do not automatically grow modeled occupancy.
• external_service for API dependencies without a modeled local host. Use invokes Provider { protocol = https }; TLS must be declared on the provider. Rate scenarios require its measured/contractual max_requests_rps. Provider response content, failure branches, tokens, costs, and retry timing are not modeled.
• Service/operation reads and writes to object stores, with transport checks and a max_requests_rps bound for rate scenarios. Container registries still use image_from. S3 website endpoints reject writes.

LocalStack profiles (provider = localstack, product = sqs or s3) use HTTP explicitly and remain separate from AWS profiles. They model API dependencies and declared budgets, not emulator durability, redrive, visibility renewal, or cloud parity. Existing MSK and Kinesis streams retain managed placement; Redis streams require a compute host. self_hosted database-cluster profiles now include postgres, elasticsearch, and opensearch, with relational/document contracts, appropriate TCP/TLS or HTTP/HTTPS transports, and declared max_ops_rps budgets. They do not simulate query plans, index semantics, or transaction isolation.

Self-hosted Redis cache declarations may omit capacity_mib for functional checks with no dataset or request rate. Capacity scenarios still require the missing measurements; omission does not mean infinite memory or throughput.

The live-stream model is steady-state and deterministic. It does not calculate end-to-end latency, audio timing, byte bandwidth, proxy idle timeout, retries, backpressure, failover, or graceful connection draining. Redis approximate trimming is represented by an explicit conservative retention bound. A connection-budget failure identifies a violated assumption, not the time of a predicted outage.

CockroachDB as a separate vendor

Use provider = cockroachdb with product = cockroachdb (self-managed) or cockroachdb_cloud (managed). The dedicated JSON catalog models relational SQL/TLS connections, declared operations and connection budgets, synchronous quorum writes, backup policy, isolation declarations, and minimum region/replica survival constraints. The existing self_hosted / cockroachdb profile remains compatible.

.venv/bin/python -m polish simulate examples/cockroachdb.polishd

See the CockroachDB configuration guide for settings, custom configuration, five executable scenarios, upstream references, and limitations. Topology counts do not prove outage resilience; transaction execution, follower reads, CDC, and query/index behavior are not simulated.
