🧩 PolyQR: QR Codes as Polygons

PolyQR is a small library that turns a message into a QR code where each contiguous black region is drawn as one merged polygon, not a grid of tiny squares. This eliminates hideous hairline gaps between modules that appear with naive approaches (an example is shown later) and also minimizes the number of points per polygon to keep the output compact.

PolyQR can generate:

• TikZ code with full styling support (e.g. rounded corners)
• SVG paths that are fully minimized to save space

The pytest-based test suite with 100% coverage (for both TikZ and SVG) is defined in the tests directory.

📦 Installation

This package is available on PyPI and can be installed with pip:

pip install polyqr

🖼️ TikZ Output

PolyQR provides the command-line tool polyqr_tikz, which can be called as follows:

polyqr_tikz "1mm" "rounded corners=0.25mm" "https://github.com/KurtBoehm/polyqr"

This prints a tikzpicture environment of the following form to stdout:

\begin{tikzpicture}[x=1mm, y=1mm, qrpoly/.style={fill=black, draw=none, even odd rule, rounded corners=0.25mm}]
  % \draw commands to draw a QR code representing https://github.com/KurtBoehm/polyqr
\end{tikzpicture}

If the optional argument --full-size is added, the size parameter (1mm in the previous example) does not specify the size of each module (as it does by default), but the size of the entire QR code.

Because each connected component is rendered as a single polygon, TikZ styles such as rounded corners apply only to the outer boundary of each contiguous region. This also eliminates visible gaps between modules, which can be seen when comparing to a basic version that draws each module as a separate rectangle (full-screen viewing is advised):

Basic	PolyQR	PolyQR with rounded corners

The LaTeX file used to generate these examples is at docs/tikz.tex.

TikZ code can also be generated directly from Python:

from polyqr import QrCodePainter

painter = QrCodePainter("https://github.com/KurtBoehm/polyqr")

print(painter.tikz(size="1mm", style="rounded corners=0.25mm", full_size=False))

🖼️ SVG Output

PolyQR can also generate highly minimized SVG paths:

• The entire QR code (or each contiguous area) becomes a single <path> element using fill-rule="evenodd" to handle holes.
• All segments are axis-aligned and therefore encoded using only M, H, V, and Z commands.
• For every move/line, absolute vs. relative commands are chosen based on which textual form is shorter.

SVG generation is available programmatically:

from polyqr import QrCodePainter

painter = QrCodePainter("https://github.com/KurtBoehm/polyqr")

# Full SVG document as a string
svg_doc = painter.svg

# Single <path> element covering the full QR code
svg_path = painter.svg_path

# Generator over <path> elements, one per contiguous region
for path in painter.svg_paths:
    print(path)

qrcode, which PolyQR uses to generate the underlying module matrix, can also output SVG via qrcode.svg.SvgPathImage (among others). SvgPathImage avoids gaps by collecting all modules into a single <path>, but its output is much larger.

For the message https://github.com/KurtBoehm/polyqr:

• SvgPathImage output: ≈ 6.4 kB (docs/svg-qrcode.svg)
• QrCodePainter.svg output: ≈ 1.7 kB (docs/svg-polyqr.svg)

That is a size reduction of more than 70% with identical geometry.

🧠 Algorithm Overview

PolyQR converts a message into merged polygons in three main stages:

1. QR code generation:
   • Uses qrcode to build a Boolean module matrix for the input message.
2. Connected components and boundary extraction:
   • Runs a 4-neighbour BFS flood fill on the module grid to find connected black regions.
   • For each module in a component, its four unit-square edges are added to a Counter in canonical (sorted-endpoint) form.
   • Any edge seen exactly once lies on the region’s boundary (outer boundary or hole).
3. Cycle tracing and polygon simplification:
   • Builds an undirected adjacency graph from the remaining boundary edges.
   • For each connected component of this boundary graph, traces a single “wall-hugging” cycle:
     • At each step, the walk prefers making a turn over going straight, producing visually pleasing outlines around holes when rounded corners are used.
     • If the initial cycle does not visit every vertex of the component, it is iteratively extended by following any remaining unused edges (again preferring turns) until the component is fully covered.
   • Each resulting cycle is simplified by removing collinear vertices.

The result is a small set of rectilinear polygons that exactly cover the QR modules.

🧪 Testing

PolyQR includes pytest-based tests that cover the entire code base with a 100% code coverage.

The development dependencies can be installed via the dev optional group:

pip install .[dev]

All tests (including coverage reporting using pytest-cov) can then be run from the project root:

pytest --cov

The TikZ tests are relatively slow, as they require pdflatex to compile a LaTeX document to PDF, which is then rasterized via PyMuPDF. To keep test times reasonable, the dev dependencies include pytest-xdist, so tests can be executed in parallel:

pytest --cov -n auto  # or a fixed number of workers

📜 License

This library is licensed under the terms of the Mozilla Public License 2.0, provided in License.
