powerio 0.0.1

Lossless power system case file IO, format conversion, and sparse matrix and graph views

PowerIO

PowerIO reads power system case files into a typed Network, writes them back, converts between common formats, and builds the sparse matrices and graph views used by analysis and solver code. It aspires to be "the pandoc for power systems."

Supported formats:

• MATPOWER .m
• PSS/E .raw revision 33
• PowerWorld .aux
• PowerModels.jl network data JSON
• egret ModelData JSON
• GridFM .parquet (WIP)
• surge .surge.json (WIP)

When writing back to the source format, PowerIO returns the original file exactly when the parser retained it. Cross format conversion obeys sane defaults, and emits Conversion::warnings for fields the target format cannot represent.

Packages

powerio          parser, Network model, source retaining writers, converters
powerio-matrix   sparse matrices, DC sensitivity factors, graph views
powerio-cli      the `powerio` command and ratatui TUI
powerio-py       PyO3 extension for the Python `powerio` package
powerio-capi     C ABI for C, C++, Julia, and other foreign function interfaces
PowerIO.jl       Julia bindings over the C ABI

API docs: https://eigenergy.github.io/powerio/. Language API map: docs/languages.md.

Install

cargo add --git https://github.com/eigenergy/powerio powerio
cargo add --git https://github.com/eigenergy/powerio powerio-matrix
cargo install --git https://github.com/eigenergy/powerio powerio-cli

pip install powerio
pip install 'powerio[all]'   # scipy, numpy, networkx, polars extras
pip install 'powerio[gridfm]'  # polars for Parquet inspection
pip install 'powerio[pandas]'  # pandas, pyarrow compatibility reads (Python 3.10+)

julia -e 'using Pkg; Pkg.add(url="https://github.com/eigenergy/PowerIO.jl")'

Use

PowerIO is implemented in Rust and features a low-level C ABI. This lets PowerIO talk to many of your favorite languages. Any language with a C foreign function interface can call it.

Rust

use powerio::{TargetFormat, parse_file};

let net = parse_file("case14.m")?;
let conv = net.to_format(TargetFormat::PowerModelsJson);

for warning in &conv.warnings {
    eprintln!("conversion warning: {warning}");
}

std::fs::write("case14.json", conv.text)?;

Python

import powerio as pio

case = pio.parse_file("case9.m")
bprime = case.bprime()            # scipy.sparse, needs powerio[matrix]
raw, warnings = pio.convert_file("case9.m", "psse")

Julia

using PowerIO

case = parse_file("case9.m")
text = to_matpower(case)
json, warnings = to_format(case, "powermodels-json")

Command line interface (CLI)

powerio convert tests/data/case14.m --to psse -o case14.raw
powerio verify tests/data/case30.m --kind bdoubleprime
powerio dcopf tests/data/case30.m -o out
powerio sensitivities tests/data/case30.m -o out
powerio gridfm tests/data/case14.m -o out
powerio

Current Format Fidelity

reader / writer	MATPOWER	PowerModels JSON	PSS/E	PowerWorld	egret JSON
MATPOWER	original text	full	partial	partial	partial
PowerModels JSON	partial	original text	partial	partial	partial
PSS/E	full	full	original text	partial	partial
PowerWorld	full	full	partial	original text	partial
egret JSON	partial	full	partial	partial	original text

partial means the target lacks fields present in the source. The writer reports those cases in Conversion::warnings. Known limits are documented in docs/format-fidelity.md.

Matrices

powerio-matrix derives an IndexedNetwork with dense bus indices and builds:

• B' and B'' DCPF and FDPF matrices
• Nodal admittance matrix
• LACPF block matrix
• Signed incidence, weighted Laplacian, and flow map matrices
• PTDF and LODF sensitivity matrices
• Matrix Market bundle for DC OPF solvers
• Adjacency matrix and petgraph view

Current conventions for signs, taps, phase shifts, per unit scaling, reference buses, and DC susceptance are documented in docs/matrices.md.

Normalized View

Network::to_normalized derives a solver oriented copy of a case with sane defaults. Powers are provided in per unit, voltage phase angles are in radians, inactive elements are removed, tap == 0 replaced with 1, surviving buses are reindexed to a dense 1-based id space, and bus types are made consistent with generator placement and reference buses. Computing it carries no retained source text, so writing the normalized network emits the derived model rather than the original file.

Python exposes the normalized view as case.to_normalized(), the C ABI as pio_to_normalized, and Julia as to_normalized(case).

Special features

GridFM

PowerIO supports the GridFM framework. The command powerio gridfm <case> -o <dir> writes the Parquet tables consumed by gridfm-datakit and gridfm-graphkit: bus_data, gen_data, branch_data, and y_bus_data under <dir>/<case>/raw/. A case file is one scenario. Passing several compatible cases stacks them by scenario id.

C ABI

powerio-capi exposes parse, query, conversion, JSON transport, normalization, and numeric table extraction through pio_* functions. The public header is powerio-capi/include/powerio.h. Build with --features arrow to enable pio_export_arrow over the Arrow C Data Interface.

MCP Server

The Python package includes an optional MCP server with convert_case and case_summary tools. Interoperability with the PowerAgent project is planned.

pip install 'powerio[mcp]'
powerio-mcp

Validation

The Rust test suite covers parsers, writers, format conversion, matrix builders, and normalization; the C ABI crate carries its own tests (it is outside the default members, so it needs an explicit -p powerio-capi), and pytest covers the Python bindings. The benchmark validation suite compares selected outputs against PowerModels.jl, egret, ExaPowerIO.jl, and pandapower.

cargo fmt --all --check
cargo test
cargo test -p powerio-capi
cargo clippy --all-targets
pytest python/tests
bash benchmarks/run_validation.sh

Benchmark method, environment, and current tables are documented in benchmarks/RESULTS.md.

License

PowerIO is distributed under either of:

• Apache License, Version 2.0
• MIT license
