Sunrise is a package for all-around fermionic state preparation and simulation on quantum computers. It holds no qubits, but only physical information, making it efficient for storage and manipulation.

Tequila chemistry extension package.

Installation

Sunrise is compatible with macOS and Linux operating systems. PySCF is not supported on Windows. Please, install the package along with all required dependencies:

conda create -n myenv python=3.10
conda activate myenv

cd project-sunrise
pip install -e .

You can install sunrise directly with pip over:

pip install git+https://github.com/tequilahub/sunrise.git

Install from devel branch (most recent updates):

pip install git+https://github.com/tequilahub/sunrise.git@devel

Fermionic Backends

To see the supported fermionic backends:

import sunrise as sun  # First time might take some seconds
sun.show_supported_modules()

FQE

Install with:

pip install fqe

TenCirChem - Next Generation (TCC-NG)

The package's specified installation command is erroneous and deploys the prior version (plain TCC). However, the implementation on sunrise has been built over the existing ng package, waiting to be fixed. In the mean time, we recomend to install it as:

pip install git+https://github.com/davibinco/TenCirChem-NG.git

Note that the link above is not the original repo but our own fork, fixing this bug until implemented on the code.

Fermionic Circuit

The FCircuit has been developed in order to preserve abstract fermionic layers. This circuit consists of two main parts, the initial_state and the circuit itself. The initial_state relies on a tequila QubitWaveFunction, whose states are checked to be particle conserving. It can be set through any way of creating a tq.QubitWaveFunction, either with a FCircuit or QCircuit with already mapped variables, or the options available in QubitWaveFunction.convert_from(). It is important to take into account that both fqe and tcc work with initial_states in upthendown, therefore we are keeping here that as mandatory. In order to create the circuit itself, some gates have been already defined at sunrise.gates.

A representative example could be:

from sunrise import gates
U = sun.FCircuit()
U.initial_state = '1*|11001100>'
U += gates.UR(0,1,"a") + gates.UR(2,3,"b")
U += gates.UC(1,2,'c') + gates.UC(0,3,'d')
U += gates.FermionicExcitation([(0,4),(1,5)],'e')
print(U)

They can also be created with the Fermionic Molecule:

geom = "H 0.0 0.0 0.0\nH 0.0 0.0 1.6\nH 0.0 0.0 3.2\nH 0.0 0.0 4.8"
mol = sun.Molecule(geometry=geom,basis_set='sto-3g',nature='f')
U = mol.make_ansatz('UpCCSD')
print(U)

Finally, they can be employed in a similar way to tequila QCircuit or converted to them:

U = ...
#The expectation value object is explained bellow
E = sun.Braket(U=U,backend='tcc',mol=mol)
res = sun.minimize(E,silent=True)
print(sun.simulate(U,variables=res.variables))
print('Energy ',res.energy)
print('Variables ',res.variables)
opt = sun.optimize_orbitals(molecule=mol,circuit=U,backend='fqe',silent=True)

or compiled to qubit and being employed as in regular tequila:

mol = sun.Molecule(geometry=geom,basis_set='sto-3g',nature='tequila')
print(U)
U = U.to_qcircuit(mol)
print(U)

Fermionic Expectation Value

Fermionic Expectation Value, interface with FQE, TCC and TQ. Created in a similar form to tequila BraKet.

#If not especified, the default operator is the molecular Hamiltonian
E = sun.Braket(molecule=mol,U=U,backend='tcc')
ov = sun.Braket(bra=U1,ket=U2,operator='I',backend='fqe')
#It can alse be employed qustom operators
from openfermion import FermionOperator
op = FermionOperator('0^ 1^ 1 0',0.5)
r = sun.Braket(bra=U1,ket=U2,op)
res = sun.simulate/minimize/...

Hybrid Molecule

Create your Hybrid Molecule.

Example:

import sunrise as sun
import tequila as tq

molecule  = sun.Molecule(geometry="H 0. 0. 0. \n Li 0. 0. 1.5",basis_set="sto-3g",select="BBFBF",nature='h')
print(molecule.select)

Which can be also initialized as:

import sunrise as sun
from sunrise.molecules import HyMolecule
import tequila as tq
molecule  = HyMolecule(geometry="H 0. 0. 0. \n Li 0. 0. 1.5",basis_set="sto-3g",select={2:"F",4:"F"})
print(molecule.select)

Construct your circuit

The SPA circuit (and all the automatically built circuits) are already adapted to your encoding.

Uspa = molecule.make_ansatz("SPA",edges=[(0,1)])

However, one can also build its own circuits:

U = tq.QCircuit() # see more on https://github.com/tequilahub/tequila-tutorials/
# Prepare the reference HF state if any other provided
U += molecule.prepare_reference()
# Paired 2e excitation from MO 0 to MO 2
U += molecule.UC(0,2,angle=(0,2,"a"))
# Two One-electron excitation: MO 2_up->4_up + 2_down->4_down TAKE CARE ENCODING
U += molecule.UR(2,4,angle=(2,4,"UR"))
# Generic excitation
U += molecule.make_excitation_gate(indices=[(0,4),(1,8)],angle=tq.Variable('a'))

Minimize the Energy of the Circuit Expectation Value

# The molecular Hamiltonian for a given Encoding is automatically built.
# For custom Hamiltonians please check tutorial above
H = molecule.make_hamiltonian()
exp = tq.ExpectationValue(H=H,U=U) #Create the Expectation Value Object
# Minimize the energy. You can provide initial variables
mini = tq.minimize(objective=exp,silent=False,initial_values={})
print('Minimized Angles:\n',mini.angles)
print('Minimized Energy: ', mini.energy)

Optimize your Orbitals

Molecular orbitals can be optimized taking advantage of this Hybrid Encoding.

result = sun.optimize_orbitals(molecule=molecule,circuit=Uspa,initial_guess='random')
#Since random guess, may take some time
omol = result.molecule
print("Opt SPA Energy = ",result.energy)
print("Select: ",omol.select)

Please, note that the present example can be found in the test file.

HCB measurement optimization

Optimize the measurement procedure of a molecule energy by using the HCB encoding and multiple rotations.

Example using quantum circuit (Scenario II):

import tequila as tq
import sunrise as sun
import numpy as np

# Create the molecule
mol = tq.Molecule(geometry="h 0.0 0.0 0.0\nh 0.0 0.0 1.5\nh 0.0 0.0 3.0\nh 0.0 0.0 4.5", basis_set="sto-3g").use_native_orbitals()
fci = mol.compute_energy("fci")
H = mol.make_hamiltonian()

# Create circuit
U0 = mol.make_ansatz(name="SPA", edges=[(0,1),(2,3)])
UR1 = mol.UR(0,1,angle=np.pi/2) + mol.UR(2,3,angle=np.pi/2) + mol.UR(0,3,angle=-0.2334) + mol.UR(1,2,angle=-0.2334)

UR2 = mol.UR(1,2,angle=np.pi/2) + mol.UR(0,3,angle=np.pi/2)
UR2+= mol.UR(0,1,angle="x") + mol.UR(0,2,angle="y") + mol.UR(1,3,angle="xx") + mol.UR(2,3,angle="yy") + mol.UR(1,2,angle="z") + mol.UR(0,3,angle="zz")
UC2 = mol.UC(1,2,angle="b") + mol.UC(0,3,angle="c")
U = U0 + UR1.dagger() + UR2 + UC2 + UR2.dagger()

variables = {((0, 1), 'D', None): -0.644359150621798, ((2, 3), 'D', None): -0.644359150621816, "x": 0.4322931478168998, "y": 4.980327764918099e-14, "xx": -3.07202211218271e-14, "yy": 0.7167447375727501, "z": -3.982666230146327e-14, "zz": 1.2737831353027637e-13, "c": -0.011081251246998072, "b": 0.49719805420976604}
E = tq.ExpectationValue(H=H, U=U)
full_energy = tq.simulate(E, variables=variables)
print(f"Energy error: {(full_energy-fci)*1000:.2f} mE_h\n")

# Create rotators
graphs = [
    [(0,1),(2,3)],
    [(0,3),(1,2)],
    [(0,2),(1,3)]
]
rotators = []
for graph in graphs:
    UR = tq.QCircuit()
    for edge in graph:
        UR += mol.UR(edge[0], edge[1], angle=np.pi/2)
    rotators.append(UR)

# Apply the measurement protocol
result = sun.measurement.rotate_and_hcb(molecule=mol, circuit=U, variables=variables, rotators=rotators, target=full_energy, silent=False)
print(result) # the list of HCB molecules to measure and the residual element discarded

# Compute the energy
energy = 0
for i,hcb_mol in enumerate(result[0]):
    expval = tq.ExpectationValue(U=U+rotators[i], H=hcb_mol.make_hamiltonian())
    energy += tq.simulate(expval, variables=variables)

print(f"Energy of the accumulated HCB contributions: {energy}")
print(f"Error: {energy-full_energy}")

Hybridization

Automated framework for the generation of ansatz-specific optimized molecular orbitals. Given the Molecule Geometry it identifies atomic hybridization states in order to construct an orbital coefficient matrix and generate a edge list of electron pairings and bond assignments. Currently only implemented with Sunrise Molcules (nature = 'hybrid' and 'fermionic')

import sunrise as sun
import tequila as tq

geometry = """    O 0.000000 0.000000 0.000000\n H 0.757000 0.586000 0.000000\nH -0.757000 0.586000 0.000000"""

mol = sun.Molecule(geometry=geometry, basis_set='sto-3g',nature='h').use_native_orbitals()
initial_guess = mol.get_spa_guess()
edges = mol.get_spa_edges()
U = mol.make_ansatz(name="HCB-SPA", edges=edges)
opt = sun.optimize_orbitals(molecule=mol, circuit=U, initial_guess=initial_guess.T)

You can check the resulting orbitals with the plot_MO function. See bellow

Currently implementation works only for sto-3g and s,p orbitals

If further orbitals hybridization / basis set is desired, similar orbitals can be achieved as indicated on sunrise.orbitals.CLPO.

plot_MO

Interface with the PYSCF cubegen tool. It generates the orbital '.cube' files. They may be visualized with many chemical visualizing programs such as VESTA or Avogadro.

mol = opt.molecule
sun.plot_MO(molecule=mol,filename="water")

The cubefile generation may take some time. Here we provided a tq.Molecule but it also accepts any molecule class with mol.parameters and mol.integral_manager

Circuit Visualizer

Improved circuit visualizer which creates the circuit qpic file with improved circuit structures in common chemistry building blocks as the electronic excitation gates. It creates gates in molecular orbitals picture, halving the number of qubits displayed.

Automatized way

import tequila as tq
import sunrise as sun

mol = tq.Molecule(geometry="H 0. 0. 0. \n H 0. 0. 1.",basis_set="sto-3g")
U = tq.QCircuit()
U += tq.gates.Y(2) # Generic gate
U += mol.make_excitation_gate(indices=[(0,2),(1,3)],angle="a") # Double excitation
U += mol.make_excitation_gate(indices=[(4,6)],angle="b") # Single excitation
U += tq.gates.QubitExcitation(target=[5,7],angle="c") # Qubit excitation
U += tq.gates.Trotterized(generator=mol.make_excitation_generator(indices=[(0,2)]),angle="d") # Trotterized rotation
U += mol.make_excitation_gate(indices=[(4,6)],angle="b")
U += mol.make_excitation_gate(indices=[(5,7)],angle="b") # Paired single excitation
U += mol.UR(0,1,1) # Orbital rotator
U += mol.UC(1,2,2) # Pair correlator

visual_circuit = sun.graphical.GCircuit.from_circuit(U, n_qubits_is_double=True) # Translate tq.QCircuit in renderable Circuit

visual_circuit.export_qpic("from_circuit_example") # Create qpic file
visual_circuit.export_to("from_circuit_example.pdf") # Create pdf file
visual_circuit.export_to("from_circuit_example.png") # Create png file

Similarly, the same protocol can be followed for FCircuits.

Manual way

import tequila as tq
import sunrise as sun
from sunrise import graphical as g

circuit = g.GCircuit([
    # Initial state gate, qubits are halved
    g.GenericGate(U=tq.gates.X([0,1,2,3]), name="initialstate", n_qubits_is_double=True),

    # Singe excitation, i,j correspond to Spin Orbital index --> ((i,j))
    g.SingleExcitation(i=1,j=7,angle=1),

    # Double excitation, i,j,k,l correspond to Spin Orbital index --> ((i,j),(k,l))
    g.DoubleExcitation(i=0,j=4,k=1,l=7,angle=2),

    # Generic gate in the middle of the circuit, qubits are not halved
    g.GenericGate(U=tq.gates.Y([0, 3]), name="simple", n_qubits_is_double=False),

    # Orbital rotator (double single-excitation), i,j correspond to Molecular Orbital index --> ((2*i,2*j),(2*i+1,2*j+1))
    g.OrbitalRotatorGate(i=0,j=1,angle=3),

    # Pair correlator (paired double excitation), i,j correspond to Molecular Orbital index --> ((2*i,2*j),(2*i+1,2*j+1))
    g.PairCorrelatorGate(i=1,j=3,angle=4)
])

circuit.export_to("test.png") # Create png file
circuit.export_to("test.pdf") # Create pdf file

Which can be latter exported to tequila circuit:

U = circuit.construct_circuit()
U += tq.gates.X(1)
print(U)
