PubMatrixPython

Python port of the PubMatrixR R package.

Give it two lists of search terms. For every pair, it asks PubMed or PMC how many publications mention both, and hands back the counts as a table. Useful when you want to know which gene/disease combinations the literature has actually covered, and which nobody has looked at.

Based on: Becker et al. (2003) PubMatrix: a tool for multiplex literature mining. BMC Bioinformatics 4:61. https://doi.org/10.1186/1471-2105-4-61

What it does

Queries every combination of terms from your two lists against MEDLINE abstracts (pubmed) or full text (pmc) through the NCBI E-utilities. Results come back as a pandas.DataFrame and can be exported to CSV or ODS, where each cell links to the PubMed search that produced it.

You can restrict searches to a publication year range, pass terms directly or read them from a text file, and plot the result as a heatmap with optional clustering. Long runs show a progress bar.

Two things worth knowing for larger matrices: n_workers runs queries in parallel while staying under the NCBI rate limit, and cache_dir keeps results on disk so a re-run does not re-query terms it has already seen.

Installation

pip

pip install pubmatrixpython

uv

uv add pubmatrixpython

pixi

pixi add --pypi pubmatrixpython

For ODS export you also need odfpy:

pip install pubmatrixpython[ods]

Development setup

Requires uv. Install it with:

curl -LsSf https://astral.sh/uv/install.sh | sh

Clone and install dependencies:

git clone <repo-url>
cd PubMatrixPython
uv sync --all-groups

Running the notebooks

Run every uv command from the project root, where pyproject.toml lives. It will not resolve the environment from anywhere else.

cd /path/to/PubMatrixPython
uv run jupyter lab

The notebooks are in notebooks/.

Quick start

In the REPL

uv run python

from pubmatrix import pubmatrix, plot_pubmatrix_heatmap

A = ["WNT1", "WNT2", "CTNNB1"]
B = ["obesity", "diabetes", "cancer"]

result = pubmatrix(A=A, B=B)
print(result)

plot_pubmatrix_heatmap(result, title="WNT × Disease")

Running a script

Create a file my_analysis.py:

from pubmatrix import pubmatrix, plot_pubmatrix_heatmap

A = ["WNT1", "WNT2", "WNT3A", "WNT5A", "CTNNB1"]
B = ["obesity", "diabetes", "cancer", "inflammation"]

result = pubmatrix(
    A=A,
    B=B,
    database="pubmed",
    daterange=[2010, 2024],   # optional date filter
    outfile="results",
    export_format="csv",      # saves results.csv with PubMed hyperlinks
)

print(result)

plot_pubmatrix_heatmap(
    result,
    title="WNT Genes × Disease",
    filename="heatmap.png",   # saves to file instead of displaying
)

Run it with:

uv run python my_analysis.py

Loading terms from a file

Create terms.txt:

WNT1
WNT2
CTNNB1
#
obesity
diabetes
cancer

from pubmatrix import pubmatrix_from_file

result = pubmatrix_from_file("terms.txt")
print(result)

Blank lines are ignored. If the # is missing, or either side of it is empty, you get an error naming the file.

API reference

pubmatrix(A, B, ...)

Queries PubMed and returns a pandas.DataFrame with rows from B and columns from A.

pubmatrix(
    A,                    # list of str — column terms
    B,                    # list of str — row terms
    api_key=None,         # NCBI API key (10 req/s vs 3 req/s default)
    database="pubmed",    # "pubmed" or "pmc"
    daterange=None,       # e.g. [2015, 2024]
    outfile=None,         # base filename for export
    export_format=None,   # None | "csv" | "ods"
    n_tries=3,            # attempts per query, exponential backoff between them
    n_workers=1,          # parallel workers for concurrent queries
    timeout=30,           # HTTP request timeout in seconds
    cache_dir=None,       # directory to cache query results on disk
)

pubmatrix_from_file(filepath, ...)

Reads terms from a plain-text file, then hands them to pubmatrix() along with any other arguments you pass.

File format:

WNT1
WNT2
#
obesity
diabetes

result = pubmatrix_from_file("terms.txt", database="pubmed")

plot_pubmatrix_heatmap(matrix, ...)

Plots the co-occurrence counts, clustering rows and columns unless you turn that off. Returns (fig, ax).

fig, ax = plot_pubmatrix_heatmap(
    matrix,                                        # DataFrame from pubmatrix()
    values="raw",                                  # "raw" | "row_pct" | "relative"
    title="PubMatrix Co-occurrence Heatmap",
    cluster_rows=True,
    cluster_cols=True,
    show_numbers=True,
    color_palette=None,                            # list of hex colours
    filename=None,                                 # save to PNG if set
    width=10, height=8,
    scale_font=True,
    show=False,                                    # call plt.show() after plotting
)

values selects what each cell shows:

A warning about "relative": it is not a Jaccard index, and its numbers do not carry between runs. The totals in that formula are sums over whichever partner terms happen to be in your matrix, not the publication count for each term on its own, so adding one unrelated term shifts the value in every existing cell. A real Jaccard index would need the single-term counts, and pubmatrix() never fetches those. Compare cells within one fixed matrix and nothing beyond that.

pubmatrix_heatmap(matrix, title=..., values="raw")

Quick wrapper around plot_pubmatrix_heatmap() with all defaults. Returns (fig, ax).

Output files

Set outfile and export_format and the results are written to {outfile}.csv or {outfile}.ods. Every cell holds the publication count as a hyperlink to the search that produced it. Rows are named from B, columns from A.

ODS export needs the optional odfpy dependency. See Installation.

NCBI API key

Without a key: 3 requests/second. With a key: 10 requests/second. Get one at https://account.ncbi.nlm.nih.gov/

result = pubmatrix(A=A, B=B, api_key="YOUR_KEY_HERE")

More documentation

• Performance notes covers rate limits, retries, caching and concurrency
• Troubleshooting covers empty results, rate limiting and slow searches
• Full reference notebook walks through every parameter with output

License & citation

MIT licensed. See LICENSE.md.

If you use PubMatrixPython in your research, please cite:

Becker KG, Hosack DA, Dennis G Jr, Lempicki RA, Bright TJ, Cheadle C, Engel J. PubMatrix: a tool for multiplex literature mining. BMC Bioinformatics. 2003 Dec 10;4:61. https://doi.org/10.1186/1471-2105-4-61

Developers:

• Tyler Laird (Author, original PubMatrixR)
• Enrique Toledo (Author, maintainer)
