PyBRAID 1.0.5

Block Resolution and Annotation of Integrated DNA

BRAID

Block Resolution and Annotation of Integrated DNA

Analyze phased VCF data to predict variant effects on protein sequences for each haplotype.

Overview

BRAID is a bioinformatics tool designed to go beyond isolated mutations annotation. By utilizing phased VCF data, this tool reconstructs the combination of mutations present on each chromosome (haplotype) to predict the actual protein sequence produced.

This allows for the detection of complex effects, such as:

• Compound Heterozygosity: Understanding how multiple mutations on the same haplotype interact.
• Haplotype-specific LOF: Determining if a combination effect of mutations leads to a Loss of Function.
• Protein Structure Changes: Visualizing the exact amino acid sequence changes.

Installation & Requirements

BRAID is a software that requires standard bioinformatics libraries.

Prerequisites:

• Python >= 3.8
• pysam
• biopython

installation

Dowload via pip

pip install pybraid

Dowload via conda

conda install -c bioconda braid

Dowload via wget

wget https://github.com/YuefanHuang1998/BRAID/archive/refs/tags/v1.0.5.tar.gz
tar -xvf v1.0.5.tar.gz
cd BRAID-1.0.5/
pip install .

Dowload via git

git clone https://github.com/YuefanHuang1998/BRAID.git
cd BRAID
pip install .

To verify the installation was successful, run:

braid test

Usage

Run the script from the command line by providing the GFF3 annotation, Reference Genome, and Phased VCF.

braid -r reference.fa -g annotation.gff3 -v phased_variants.vcf.gz

Example for test dataset

braid -r test.fasta -g test.gff3 -v test.vcf.gz

You should have three output files and one log file:
variant_analysis_output.tsv
variant_analysis_output.alignment.txt
variant_analysis_output.sample.txt
variant_analysis_output.log

Arguments Parameter Table

Short	Long	Description
-g	--gff	Path to the GFF3 annotation file.	Required
-r	--reference	Path to the Reference Genome FASTA (must be indexed: .fai).	Required
-v	--vcf	Path to the Phased VCF file (must be indexed: .tbi/.csi).	Required
-o	--output	Output file name (default: variant_analysis_output.tsv).	Optional
-s	--sample	Path to file containing specific sample IDs to analyze (one per line, no header).	Optional
	--gene	Path to file with specific gene IDs to analyze (one per line, no header).	Optional
	--lof-threshold	Custom threshold for Loss-of-Function classification (e.g., 0.1; default: 0.2).	Optional
	--force-unphased	Skip phasing check (forces run on unphased VCF).	Optional
	--ignore-intron	Ignore variants marked strictly as intronic.	Optional

Output Files Explaination

BRAID generates three main files to assist in your analysis.

1. Summary Table

A comprehensive table detailing the protein changes for every haplotype (default: variant_analysis_output.tsv).

Example View:

Gene_ID	Haplotype_ID	mRNA	Haplotype_Count	Frequency	Variant_Type	Protein_Changes	Haplotype_Mutations	Sample_Sources	Ref_Protein	Alt_Protein	Ref_CDS	Alt_CDS	Aligned_Ref	Comparison_String	Aligned_Alt
gene1	transcript1:REF	transcript1	.	.	NoLOF(non_identity_rate:0.00%,non_identical_AAs:0,total_ref_AAs:27) |||||||||||||||||	.	.	.	MSLASSANDMIDRSIDRSIDRSIDRS*	MSLASSANDMIDRSIDRSIDRSIDRS*	ATGAGCTTAGCTAGCTCAGCTAACGATATGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGTGA	ATGAGCTTAGCTAGCTCAGCTAACGATATGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGTGA	MSLASSANDMIDRSIDRSIDRSIDRS*	|||||||||||||||||||||||||||	MSLASSANDMIDRSIDRSIDRSIDRS*
gene1	transcript1:1	transcript1	4	0.500000	NoLOF(non_identity_rate:3.70%,non_identical_AAs:1,total_ref_AAs:27)|||deletion ||||||||||||||	Del(5)S	1:17_CTTAG>C[CDS,EXON];1:27_T>TT[CDS,EXON]	sample1(Hap2);sample2(Hap1);sample3(Homo)	MSLASSANDMIDRSIDRSIDRSIDRS*	MSLASANDMIDRSIDRSIDRSIDRS*	ATGAGCTTAGCTAGCTCAGCTAACGATATGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGTGA	ATGAGCCTAGCTTCAGCTAACGATATGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGATCGTGA	MSLASSANDMIDRSIDRSIDRSIDRS*	|||| ||||||||||||||||||||||	MSLA-SANDMIDRSIDRSIDRSIDRS*

Explanation for each column

Column	Example	Explanation
Gene_ID	gene1	The gene to which this haplotype belongs.
Haplotype_ID	transcript1:REF;transcript1:1	transcript:REF indicates the reference haplotype; others (e.g. transcript1:1) are alternative haplotypes.
mRNA	transcript1	The transcript to which this haplotype belongs.
Haplotype_Count	4	Number of samples carrying this haplotype.
Frequency	0.500000	Population frequency of this haplotype.
Variant_Type	LOF/NoLoF (Please see the detailed information below.)	Functional classification of the haplotype and indicates LOF status.
Protein_Changes	Del(5)S	Protein-level consequence HGVS format description.
Haplotype_Mutations	1:17_CTTAG>C[CDS,EXON]; 1:27_T>TT[CDS,EXON]	List of variants defining the haplotype.
Sample_Sources	sample1(Hap2);sample2(Hap1); sample3(Homo)	Samples carrying this haplotype, including haplotype phase (Hap1, Hap2) or homozygous status (Homo).
Ref_Protein	MSLASSANDIDRSIDRS*	Reference protein sequence.
Alt_Protein	MSLASANDIDRSIDRS*	Alternative protein sequence.
Ref_CDS	ATGAGCTTAGCTAGCTCAGCTAACGATATCG ATCGATCGATCGATCGATCGTGA	Reference CDS sequence.
Alt_CDS	ATGAGCCTAGCTTCAGCTAACGATATCG ATCGATCGATCGATCGATCGTGA	Haplotype-specific CDS sequence.
Aligned_Ref	MSLASSANDIDRSIDRS*	Aligned reference protein, protein alignment string for visualization: - → Gap (insertion or deletion).
Comparison_String	MSLASANDIDRSIDRS*	Alignment comparison symbols: * → Different amino acid, | → Same amino acid.
Aligned_Alt	MSLASANDIDRSIDRS*	Aligned alternative protein, shows amino acid changes: - → Gap (insertion or deletion).

Detail information for Variant_Type

Column	Explanation
LOF_Info	LOF indicates haplotypes predicted to cause protein loss of function, whereas NoLOF indicates haplotypes without LOF effects. non_identity_rate represents the proportion of amino acid differences between ALT and REF proteins; non_identical_AAs is the corresponding count, and total_ref_AAs denotes the length of the REF protein. e.g., NoLOF(non_identity_rate:5.56%,non_identical_AAs:1,total_ref_AAs:18).
missense	A nucleotide variant that results in the substitution of one amino acid by another in the protein sequence.
insertion	An insertion of one or more nucleotides that alters the coding sequence and may affect the resulting protein sequence.
deletion	A deletion of one or more nucleotides from the coding sequence, potentially altering the protein sequence or reading frame.
complex_indel	A combined insertion and deletion event that cannot be represented as a simple insertion or deletion and may cause complex changes to the coding sequence.
exon_skip	A splicing event in which one or more exons are completely skipped in the transcript, leading to an altered mRNA and protein sequence.
skipped_exons_detail	Detailed information specifying which exon is skipped in the exon-skipping event, SITE_PRESERVED, SITE_SHIFT, SITE_DESTROYED. e.g., SkippedExon:[1:51-77|SITE_SHIFT].
intron_retention	A splicing event in which one or more introns are retained in the mature transcript, potentially disrupting the coding sequence.
retained_introns_detail	Detailed information specifying which intron(s) are retained in the intron-retention event, SITE_PRESERVED, SITE_SHIFT, SITE_DESTROYED. e.g., RetainedIntron:[1:78-90|SITE_DESTROYED].
start_codon_loss	A variant that disrupts the canonical start codon, potentially preventing translation initiation.
stop_loss	A variant that removes or alters the stop codon, resulting in translational read-through and an extended protein.
No_start_codon_for_reference	The reference transcript or protein sequence lacks an annotated start codon.
same_as_other_transcript	The variant effect on this protein is identical to that observed in another transcript's protein of the same gene.
protein_loss	The variant or variant combination results in the complete loss of the predicted protein product.
ref_protein_empty	The reference transcript does not produce a protein sequence (e.g., non-coding or incomplete annotation).
alignment_failed	The reference and alternative protein sequences could not be reliably aligned, preventing accurate variant effect annotation.

Log information for splice sites mutations

SITE_PRESERVED: The splice site is unaltered, with both its position and sequence conserved; normal splicing is expected.

[transcript1] (strand +) Splice site 'GT' at 39 PRESERVED by mutation 1:39_GTCG>G.
  - Original Window Seq  : GATGTCGTTAAG     - Mutated Window Seq  : GATGTTAAG.

SITE_SHIFT: The splice site may move to a nearby position due to the variant, potentially altering the exon–intron boundary.

WARNING - [transcript1] Splice site may SHIFT for mutation 1:44_TAAGTA>A.
  - Splice Site          : 'AG' (Original genomic pos: 49)
  - Mutation             : TAAGTA -> A (Genomic pos: 44)
  - Window               : 1:42-53
  - Original Window Seq  : GTTAAGTAGATG
  - Mutated Window Seq   : GTAGATG

SITE_DESTROYED: The splice site is disrupted or abolished by the variant, likely preventing normal splicing at this site.

[transcript1] (strand +) Splice site 'GT' at 78 DESTROYED by mutation 1:50_GATGATCGATCGATCGATCGATCGATCGG>GG. It was 'GT', became 'AT'.
  - Original Window Seq  : TCGGTCGATCGA     - Mutated Window Seq  : TCGATCGA

2. Alignment Visualization (.alignment.txt)

A text file showing the pairwise alignment of the Reference vs. Alternative protein. Use the Haplotype_ID to match the haplotype in the summary table.

Example View:

Haplotype_ID: transcript1:1
Gene: gene1 | mRNA: transcript1
Haplotype_Mutations: 1:17_CTTAG>C[CDS,EXON];1:27_T>TT[CDS,EXON]
Variant_Type: NoLOF(non_identity_rate:3.70%,non_identical_AAs:1,total_ref_AAs:27)|||deletion||||||||||||||
Protein_Changes: Del(5)S
Alignment:
  Ref: MSLASSANDMIDRSIDRSIDRSIDRS*
       |||| ||||||||||||||||||||||
  Alt: MSLA-SANDMIDRSIDRSIDRSIDRS*

3. Sample Matrix (.sample.txt)

A matrix format ideal for heatmaps or downstream programmatic analysis.

Example View:

Gene_ID	mRNA_ID	Ref_ID	Alt_IDs	sample1	sample2	sample3
gene1	transcript1	transcript1:REF	transcript1:1	0|1	1|0	1|1

Gene_ID  mRNA_ID      Ref_ID           Alt_IDs         sample1 sample2 sample3
gene1    transcript1  transcript1:REF  transcript1:1	  0|1	    1|0     1|1

Column	Explanation
Gene_ID	The identifier of the gene being analyzed.
mRNA_ID	The identifier of the specific transcript of that gene.
Ref_ID	Reference haplotype ID, labeled as transcript:REF.
Alt_IDs	Alternative haplotype IDs observed in the samples, with numbering to distinguish multiple haplotypes.
samples	The haplotype presence/absence in each sample. Each entry corresponds to the Ref or Alt haplotype. 0 represents REF.

Citation

If you use BRAID in your research, please cite our paper:
