PyGamLab

PyGamLab is a scientific Python library for researchers, engineers, and students who need powerful tools for nanostructure generation, alloy design, material data exploration, and AI-driven analysis. Designed for simplicity, clarity, and usability.

📌 Overview

PyGamLab stands for Python GAMLAb tools, a collection of scientific tools and functions developed at the GAMLab (Graphene and Advanced Material Laboratory) by Ali Pilehvar Meibody under the supervision of Prof. Malek Naderi at Amirkabir University of Technology (AUT).

• Main Author: Ali Pilehvar Meibody
• Supervisor: Prof. Malek Naderi
• Co-Author: Danial Nekoonam
• Contributor: Shokoofeh Karimi
• Affiliation: GAMLab, Amirkabir University of Technology (AUT)

📦 Modules

PyGamLab consists of several core modules, each focused on materials modeling, nanoscience, and data-driven discovery.

🧱 Structure

Provides tools to generate, manipulate, and analyze nanoscale and bulk materials.

Key Features:

• Generate 0D (clusters, nanoparticles), 1D (nanowires, nanotubes), 2D (nanosheets, thin films), and bulk crystals.
• Automated builders for nanoclusters, nanotubes, and supercells.
• Geometric operations: rotation, translation, scaling, merging, slicing, and symmetry analysis.
• Supports formats: .cif, .xyz, .pdb, .vasp, .json, etc.
• Integration with ASE and Pymatgen via built-in converters.

🎨 GAMVis

Internal visualization engine for interactive 2D and 3D visualization of molecules, nanostructures, and crystals.

Capabilities:

• Real-time 2D/3D visualization
• Graphical representation of bonds, surfaces, and charge distributions
• Export publication-quality figures and animations

🤖 Ai_core

Integrates machine learning workflows into materials research.

Highlights:

• Automated regression, classification, and clustering workflows
• Access to 140+ pre-trained models
• Fine-tuning and inference on user data
• Predict material properties: band gap, formation energy, hardness
• Built-in tools for data splitting, validation, and evaluation

🧬 databases

Provides seamless access to multiple materials databases.

Supported Databases:

• Materials Project (MP)
• AFLOW
• JARVIS
• Crystallography Open Database (COD)

Available Data:

• Mechanical, electronic, thermodynamic properties
• Structural and crystallographic information
• Chemical composition and symmetry

A universal class GAM_Explorer unifies data retrieval across databases.

📊 Data_Analysis

Tools for data preprocessing, analysis, and visualization.

Main Features:

• Read and preprocess data from files or DataFrames
• Filtering, normalization, and feature extraction
• Publication-ready plots: line, scatter, histogram, heatmap
• 68+ experimental analysis tools (NMR, XPS, XRD, UV-Vis, Raman)
• Scientific constants, unit converters, and utilities

🔹 Constants.py

Includes comprehensive scientific constants in physics, chemistry, and engineering.

Examples: Planck's constant, Boltzmann constant, speed of light, universal gas constant, density and melting points of metals.

🔹 Convertors.py

Contains unit conversion functions that follow the format:
FirstUnit_To_SecondUnit()

Examples:

• Kelvin_To_Celsius(k)
• Celsius_To_Kelvin(c)
• Meter_To_Foot(m)
• ...and many more standard conversions used in science and engineering.

🔹 Functions.py

This module provides a wide collection of scientific formulas and functional tools commonly used in engineering applications.

Examples:

• Thermodynamics equations
• Mechanical stress and strain calculations
• Fluid dynamics formulas
• General utility functions

📦 Requirements

To use PyGamLab, make sure you have the following Python packages installed:

• numpy
• pandas
• scipy
• matplotlib
• seaborn
• scikit-learn
• ase
• plotly
• PyQt5
• jarvis
• mp_api
• aflow

You can install all dependencies using:

pip install numpy pandas scipy matplotlib seaborn scikit-learn json scipy ase plotly PyQt5

🚀 Installation

To install PyGAMLab via pip:

pip install pygamlab

or

git clone https://github.com/APMaii/pygamlab.git

📖 Usage Example

import PyGamLab





#--------------Constants-----------------------
import PyGamLab.Constants as gamcn

print(gamcn.melting_point_of_Cu)
print(gamcn.melting_point_of_Al)
print(gamcn.Fe_Tm_Alpha)
print(gamcn.Fe_Tm_Gama)

print(gamcn.Boltzmann_Constant)
print(gamcn.Faraday_Constant)


#----------Converters------------------------
import PyGamLab.Converters as gamcv

print(gamcv.Kelvin_to_Celcius(300))           # Convert 300 K to °C
print(gamcv.Coulomb_To_Electron_volt(1))      # Convert 1 Coulomb to eV
print(gamcv.Angstrom_To_Milimeter(1))         # Convert 1 Å to mm
print(gamcv.Bar_To_Pascal(1))                 # Convert 1 bar to Pascal

#-----------Functions------------------------
import PyGamLab.Functions as gamfunc

# Gibb's Free Energy: G = H0 - T*S0
H0 = 100  # Enthalpy in kJ/mol
T = 298   # Temperature in Kelvin
S0 = 0.2  # Entropy in kJ/mol·K
print(gamfunc.Gibs_free_energy(H0, T, S0))


# Electrical Resistance: R = V / I
voltage = 10         # in Volts
current = 2          # in Amperes
print(gamfunc.Electrical_Resistance(voltage, current))

# Hall-Petch Relationship: σ = σ0 + k / √d
d_grain = 0.01       # Grain diameter in mm
sigma0 = 150         # Friction stress in MPa
k = 0.5              # Strengthening coefficient in MPa·mm^0.5
print(gamfunc.Hall_Petch(d_grain, sigma0, k))




#-----------Data_Analysis--------------------
import PyGamLab.Data_Analysis as gamdat
import pandas as pd

df= pd.read_csv('/users/apm/....../data.csv')
gamdat.Stress_Strain1(df, 'PLOT')
my_uts=gamdat.Stress_Strain1(df, 'UTS')


data=pd.read_csv('/users/apm/....../data.csv')
my_max=gamdat.Xrd_Analysis(data,'max intensity')
gamdat.Xrd_Analysis(data,'scatter plot')
gamdat.Xrd_Analysis(data,'line graph')






#-----------Structures--------------------

from PyGamLab.structures.Generators import Nano_ZeroD_Builder

builder=Nano_ZeroD_Builder(material='Au', crystal_structure='fcc', lattice_constant=2.14)

Au_atoms=builder.get_atoms()

from PyGamLab.structures.gamvis import Molecular_Visualizer

Molecular_Visualizer(Au_atoms,format='gamvis')

Molecular_Visualizer(Au_atoms,format='ase')

Molecular_Visualizer(Au_atoms,format='matplotlib')







from PyGamLab.structures.GAM_architectures import Nano_ZeroD_Builder

builder=Graphene(lattice_constant=2.46, width=10, length=82, edge_type='zigzag' )

graphene_atoms=builder.get_atoms()

from PyGamLab.structures.gamvis import Molecular_Visualizer

Molecular_Visualizer(graphene_atoms,format='gamvis')

Molecular_Visualizer(graphene_atoms,format='ase')

Molecular_Visualizer(graphene_atoms,format='matplotlib')




#-----------databases--------------------

from PyGamLab.databases.Main_DB import GAM_Explorer



explorer=GAM_Explorer(backend='aflow',timeout=60,max_results=5,batch_size=10)


explorer.search_materials(formula='SiO2')


mechanical_properties=explorer.fetch_mechanical_properties()


electronic_properties=explorer.fetch_electronic_properties()


#--------------Ai Core--------------------
from PyGamLab.ai_core import Gam_Ai_Workflow


workflow=Gam_Ai_Workflow('Graphene-armchair-rf')

workflow.summary()

workflow.predict(range(0,100))


workflow.evaluate_regressor()

📚 Documentation

For detailed documentation, please visit the official PyGamLab Documentation.

📁 Project Structure

🔹 High-Level Overview

pygamlab/
├── Constants.py
├── Convertors.py
├── Functions.py
├── Data_Analysis.py
├── contributors.md
├── structures/
├── io/
├── databases/
└── ai_core/

🔍 Detailed Structure

pygamlab/
├── init.py
├── Constants.py
├── Convertors.py
├── Functions.py
├── Data_Analysis.py
└── contributors.md
├── structures/
│ ├── Primatom/
│ │ ├── init.py
│ │ ├── gam_universe.py
│ │ └── gam_molecule.py
│ ├── Generators/
│ │ ├── init.py
│ │ ├── zero_d.py
│ │ ├── one_d.py
│ │ ├── two_d.py
│ │ └── auto_bulk.py
│ ├── GAM_architectures/
│ │ ├── init.py
│ │ ├── GAM_Graphene.py
│ │ ├── GAM_phosphorene.py
│ │ ├── GAM_sillicene.py
│ │ ├── GAM_nano_particles.py
│ │ └── GAM_nanotubes.py
│ └── gamvis/
│   ├── init.py
│   ├── gamvis.py
│   └── gamvis_engine.py
├── io/
│ ├── init.py
│ ├── read.py
│ ├── export.py
│ ├── checker.py
│ └── conversions.py
├── databases/
│ ├── init.py
│ ├── Main_DB.py
│ ├── COD.py
│ ├── Material_projects.py
│ ├── Jarvis.py
│ └── Aflow.py
└── ai_core/
│ ├── init.py
│ ├── gam_ai.py
│ └── gam_models/
│   ├── init.py
│   ├── files.gam_ai
│   └── ...

🤝 Contributing

Contributions are welcome! Here's how to get started:

Fork the repository. Create your feature branch

git checkout -b feature/my-feature

Commit your changes

git commit -am 'Add some feature'

Push to the branch

git push origin feature/my-feature

Create a new Pull Request. Please make sure to update tests as appropriate and follow PEP8 guidelines.

📄 License

This project is licensed under the MIT License — see the LICENSE.txt file for details

🙏 Acknowledgements

This project is part of the scientific research activities at GAMLab (Generalized Applied Mechanics Laboratory) at Amirkabir University of Technology (AUT).

Special thanks to:

• Prof. Malek Naderi – For his guidance, mentorship, and continuous support.
• Ali Pilehvar Meibody – Main developer and author of PyGamLab.
• Danial Nekoonam – Co-Author of PyGamLab.
• Shokoofeh Karimi - For her Contribution of verify and testing most functions
• GAMLab Research Group – For providing a collaborative and innovative environment.
• Hossein Behjoo – For his guidance in taking the AI courses and his creative work in the development of the logo.

We would also like to thank all the students who participated in the GAMLab AI course and contributed to the growth and feedback of this project. Their names are proudly listed in the contributors.md file.

This project was made possible thanks to the powerful Python open-source ecosystem:
NumPy, SciPy, Pandas, Matplotlib, Seaborn, Scikit-learn, and many more.
