A framework for processing adsorption data for porous materials

Project description

pyGAPS (Python General Adsorption Processing Suite) is a framework for adsorption data analysis written in python 3.


  • Advanced adsorption data import and manipulation
  • Routine analysis such as BET surface area, t-plot, alpha-s method
  • Pore size distribution calculations for mesopores (BJH, Dollimore-Heal)
  • Pore size distribution calculations for micropores (Horvath-Kawazoe)
  • Pore size distribution calculations using DFT kernels
  • Isotherm modelling (Henry, Langmuir, DS/TS Langmuir, etc..)
  • IAST calculations for binary and multicomponent adsorption
  • Isosteric heat of adsorption calculations
  • Parsing to and from multiple formats such as Excel, CSV and JSON
  • An sqlite database backend for storing and retrieving data
  • Simple methods for isotherm graphing and comparison


For more info, as well as a complete manual and reference visit:

Most of the examples in the documentation are actually in the form of Jupyter Notebooks which are turned into webpages with nbsphinx. You can find them for download in:


The easiest way to install pyGAPS is from the command line. Make sure that you have numpy, scipy, pandas and matplotlib already installed.

pip install pygaps

On Windows, Anaconda/Conda is your best bet since it manages environments for you. First create a new environment and use conda to install the dependencies (or start with one that already has a full instalation). Then use pip inside your environment.

conda create -n py3 python=3 numpy scipy pandas matplotlib
activate py3
pip install pygaps

Alternatively, to install the development branch, clone the repository from Github. Then install the package with setuptools, either in regular or developer mode.

git clone

# then install

python install

# or developer mode

python develop


If you have all the python environments needed to run the entire test suite, use tox. To run the all tests run:


Note, to combine the coverage data from all the tox environments run:

set PYTEST_ADDOPTS=--cov-append
PYTEST_ADDOPTS=--cov-append tox

For testing only with the environment you are currently on, run instead

python test

# or run pytest


Alternatively, you can depend on travisCI for the testing, which will be slower overall but should have all the environments required.


I’m more than happy to answer any questions. Shoot me an email at paul.iacomi@univ-amu or find me on some social media.

For any bugs found, please open an issue or, If you feel like you can do the fix yourself, submit a pull request. It’ll make my life easier

This also applies to any features which you think might benefit the project.


1.4.0 (2018-11-10)


  • Added the GAB isotherm model


  • Improved pore size distribution calculations to display cumulative pore volume when called.
  • Fixed the “all-nol” selection parameter for legend display in isotherm graphs.

1.3.0 (2018-08-13)


  • Added an excel import which can take Micromeritics or Belsorp report (.xls) files. Micromeritics code was taken from the official python repo.
  • Added an import option which can read and import Belsorp data (.DAT) files.
  • Improved plotting functions to allow for more customisation over how the graph looks.
  • The extra arguments to print_info() are now passed to the plotting function allowing for styles such as 8.

Breaking changes:

  • The unique isotherm ID is now generated only on a small subset of properties instead of all isotherm properties.
  • The isotherm ‘other_properties’ subdictionary has been removed. Instead, all isotherm properties are now direct members of the class.
  • When plotting, isotherm branches are now defined as ‘ads’, ‘des’ ‘all’ (both branches) and ‘all-nol’ (both branches without legend entry) instead of a list of branches.
  • Plot types are now universal. Any property can be plotted against any other property by specifying the x_data, y1_data and y2_data.


  • Fixed ‘source’ not being recognised as an isotherm field
  • Re-worked plot_iso color selection to avoid errors (10)
  • Re-worked plot_isp legend placement to ensure no overlap
  • Added correct common name for ethylene, propylene, methanol and ethanol in the database
  • Renamed some model parameters for consistency
  • A lot of typo fixes

1.2.0 (2018-02-19)


  • The plotting legend now works with any isotherm attribute specified
  • Changed model parent class to print out model name when displayed
  • Added Toth and Jensen-Seaton models to the IAST calculation (spreading pressure is computed numerically using scipy.integrate.quad, 7)


  • Fixed an issue where the returned IAST selectivity v pressure data would not include all pressures
  • Changed sqlite retrieval order to improve performance (2)
  • Fixed an error where IAST vle data was plotted opposite to the graph axes
  • Fixed a mistake in the Jensen-Seaton equation
  • Fixed a mistake in the FH-VST equation

1.1.1 (2018-02-11)


  • Allowed for branch selection for isosteric heat and fixed an error where this was an issue (3)


  • Fixed an issue when plotting isotherms with and without secondary data simultaneously
  • Fixed error with magnitude of polarizability of adsorbate from database in microporous PSD

1.1.0 (2018-01-24)

  • Automatic travis deployment to PyPI
  • Improved enthalpy modelling for initial enthalpy determination
  • Improved documentation

1.0.1 (2018-01-08)

  • Fixed wrong value of polarizability for nitrogen in database
  • Added a check for initial enthalpy when the isotherm is measured in supercritical mode

1.0.0 (2018-01-01)

  • Improved unit management by adding a unit/basis for both the adsorbent (ex: amount adsorbed per g, kg or cm3 of material are all valid) and loading (ex: mmol, g, kg of gas adsorbed per amount of material are all valid)
  • Separated isotherm models so that they can now be easily created by the used.
  • Added new isotherm models: Toth, Jensen-Seaton, W-VST, FH-VST.
  • Made creation of classes (Adsorbate/Sample/Isotherms) more intuitive.
  • Many small fixes and improvements

0.9.3 (2017-10-24)

  • Added unit_adsorbate and basis_loading as parameters for an isotherm, although they currently do not have any influence on data processing

0.9.2 (2017-10-24)

  • Slightly changed json format for efficiency

0.9.1 (2017-10-23)

  • Better examples
  • Small fixes and improvements

0.9.0 (2017-10-20)

  • Code is now in mostly working state.
  • Manual and reference are built.

0.1.0 (2017-07-27)

  • First release on PyPI.
