pygndc 1.0.0

Geographic Neural Data Cube - Read and analyze .gndc compressed geospatial time-series data

pygndc

Geographic Neural Data Cube - A Python SDK for reading and analyzing .gndc compressed geospatial time-series data.

What is GeoNDC?

GeoNDC is a neural network-based compression format for multi-dimensional geospatial raster data. A single .gndc file stores 4D spatiotemporal data (Time x Height x Width x Bands) with up to 300:1 compression ratios.

Key capabilities:

• Arbitrary time reconstruction - reconstruct data at any time point, not just original observation times
• Fast random access - query any pixel at any timestamp instantly
• Analytic gradients - compute spatial/temporal derivatives directly from the neural network
• Multi-sensor support - Sentinel-2, Landsat, MODIS, HiGLASS, and more

Online Viewer & Data

• Web Viewer: Browse .gndc files directly in the browser via WebGPU at geondc.org/viewer — no installation required, GPU-accelerated, runs entirely client-side.
• Sample Data: Download .gndc datasets from Hugging Face.

Installation

pip install pygndc

Or from source:

git clone https://github.com/jianboqi/pygndc.git
cd pygndc
pip install .

GPU support (recommended)

pip install pygndc installs CPU-only PyTorch by default. For GPU acceleration, install CUDA-enabled PyTorch first:

# Example for CUDA 12.1 (check https://pytorch.org for your CUDA version)
pip install torch --index-url https://download.pytorch.org/whl/cu121

# Then install pygndc
pip install pygndc

tiny-cuda-nn (fastest)

For best performance, install tiny-cuda-nn. This provides the optimized TCNN backend with significantly faster inference and lower memory usage.

pip install git+https://github.com/NVlabs/tiny-cuda-nn/#subdirectory=bindings/torch

Note: tiny-cuda-nn requires an NVIDIA GPU with CUDA support and a C++ compiler. If you cannot install it, pygndc will automatically fall back to pure PyTorch (torch_gpu or torch_cpu).

Optional dependencies

pip install pygndc[all]       # xarray + geopandas + scipy
pip install pygndc[xarray]    # xarray support
pip install pygndc[geo]       # geopandas + shapely

Inference modes

pygndc uses a single mode parameter to control both the backend and device:

Mode	Backend	Device	Description
auto	auto-detect	auto-detect	Default. Best available mode
tcnn_cuda	tiny-cuda-nn	GPU	Fastest. Requires tinycudann + CUDA
torch_gpu	PyTorch	GPU	No extra dependencies, requires CUDA
torch_cpu	PyTorch	CPU	Works everywhere, slowest

Quick Start

import pygndc

# Open a .gndc file (auto-detects best mode)
with pygndc.open("samples/S2_sample_2022_to_2025.gndc") as ds:
    print(ds)                                          # Shows mode, shape, CRS, etc.

    # Read a frame
    frame = ds.read(t=0)                               # (H, W, C) by index
    frame = ds.read(t="2024-06-15")                    # by date string
    frame = ds.read_at_time("2024-06-15 12:00:00")     # continuous interpolation

    # Point query (coordinates within the sample's bounds)
    series = ds.sample(lon=116.825, lat=40.486)        # (T, C) full time series
    values = ds.sample(lon=116.825, lat=40.486, t=0)   # (C,) single time

    # Pixel time series
    series = ds.pixel_series(row=140, col=140)         # (T, C)

    # Analysis
    ndvi = ds.ndvi(t=0, red_band=2, nir_band=3)       # (H, W)
    dx, dy = ds.gradient(t=0, mode="spatial")          # analytic gradients

    # Export
    arr = ds.to_numpy(t=0)                             # (H, W, C) numpy array
    ds.to_tif("frame_0.tif", t=0)                     # single frame to GeoTIFF
    ds.to_tifs("output_dir/")                          # all frames
    xds = ds.to_xarray()                               # xarray Dataset

# Specify mode explicitly
with pygndc.open("samples/S2_sample_2022_to_2025.gndc", mode="torch_cpu") as ds:
    frame = ds.read(t=0)

CLI Commands

# Show model info
pygndc info model.gndc
pygndc info model.gndc --json

# Decompress to GeoTIFF files
pygndc decompress -i model.gndc -o ./output
pygndc decompress -i model.gndc -o ./output --timestamp 2024-06-15
pygndc decompress -i model.gndc -o ./output --start 2024-01-01 --end 2024-12-31 --interval 5

# Compute NDVI
pygndc ndvi -i model.gndc -o ndvi.tif --red-band 0 --nir-band 1

# Compute spatial gradient
pygndc derivative -i model.gndc -o gradient.tif --grad-mode mag

# Point query
pygndc sample -i model.gndc --lon 116.5 --lat 39.9

# Export pixel time series to CSV
pygndc timeseries -i model.gndc --row 100 --col 200 -o series.csv

# Launch interactive viewer
pygndc viewer -i model.gndc

# All commands support --mode (auto, tcnn_cuda, torch_gpu, torch_cpu)
pygndc decompress -i model.gndc -o ./output --mode torch_cpu

Interactive Viewer

A GUI tool for visualizing .gndc files with multiple display modes, time navigation, and pixel inspection.

from pygndc import start_viewer
start_viewer()

Features:

• RGB, NDVI, temporal gradient, and spatial gradient display modes
• Time slider with date navigation
• Click-to-inspect pixel time series
• Region selection and zoom
• Export current frame or entire time series

File Format

A .gndc file is a zstandard-compressed archive containing:

Component	Description
Header	JSON metadata (dimensions, timestamps, CRS, band info)
Model Weights	Compressed neural network parameters
Mask Data	Optional validity mask (static or dynamic)
Residuals	Optional correction data for higher accuracy

API Reference

See API_Reference.md for the full API documentation.

License

MIT License

Citation

@software{pygndc,
  author = {Jianbo Qi},
  title = {pygndc: Geographic Neural Data Cube},
  year = {2024},
  url = {https://github.com/jianboqi/pygndc},
  license = {MIT}
}

Contact

• Author: Jianbo Qi
• Email: [e-mail]
• Issues: GitHub Issues
