pyluxel 0.2.0

Python Engine for pygame-ce and modernGL. Is not good as you might think.

PyLuxel

GPU-accelerated 2D game engine for Python
Built on pygame-ce + ModernGL

Note: PyLuxel is under active development. APIs may change between versions. Not yet recommended for production use.

---

What is PyLuxel?

PyLuxel is a 2D game engine that brings GPU rendering, HDR lighting, and modern post-processing to Python game development. It wraps pygame-ce for windowing/input and ModernGL for OpenGL rendering, giving you a powerful yet Pythonic API to build 2D games with visual effects that go way beyond what vanilla pygame can do.

---

Features

Rendering

• HDR Pipeline with RGBA16F framebuffers — values above 1.0 are preserved for bloom
• SpriteBatch with GPU instancing for fast texture rendering
• Design-space coordinates — work in virtual resolution (e.g. 1280x720), the engine scales to any window size
• Camera with smooth follow, zoom, and screen shake

Lighting & Shading

• Dynamic lighting system supporting up to 256 lights per frame
• Point lights and spotlights with configurable direction, angle, and inner cone
• Falloff modes: linear, quadratic, cubic
• Flickering: smooth, harsh, candle styles
• Normal mapping — render normal map textures and lights compute per-pixel dot(N, L)
• Ambient + light combine pass with customizable ambient color

Post-Processing

• Dual-Kawase Bloom (5 mip levels, adjustable intensity)
• Tone mapping: ACES, Reinhard, or none
• God rays — radial blur from a light source position
• Heat haze — persistent oscillating UV distortion zones
• Shockwaves — expanding UV distortion rings
• Fog — procedural fog layer with height falloff and movement
• Scene transitions: fade, dissolve, wipe, diamond

Text

• SDF Fonts — scalable signed-distance-field text, cached atlas generation
• Bitmap Fonts — per-size rasterized atlas, pixel-perfect
• FontManager singleton for centralized font management

UI

• Theme system with full color/style customization
• Widgets: Button, Toggle, Slider, LineEdit, Dropdown
• Layout: VBox, HBox containers with auto-spacing
• Focus system with keyboard/gamepad navigation
• GlyphText — inline icon + text rendering

Tilemap & World

• Tiled JSON map loader (layers, objects, properties)
• TileLayer rendering with GPU batching
• Parallax backgrounds with multi-layer scrolling

Animation

• Skeletal animation — Bone/Skeleton hierarchy with FK
• Keyframe system — Pose, Animation, Animator with loop modes
• Stickman — procedural character rendering from skeleton
• Animation presets: idle, walk, run, jump, attack
• Model I/O — save/load .model.json files
• State machine for animation blending and transitions

Networking

• P2P architecture — host/client model, no dedicated server needed
• Dual transport: raw UDP or Steam Networking Sockets
• synced() descriptor — automatic state synchronization across peers
• @rpc decorator — remote procedure calls with target selection (all, host, specific peer)
• Event bus — Net.emit() / Net.on_event() for custom network events
• Clock synchronization with Net.net_time for consistent timestamps
• Lobby system with shareable lobby codes
• Reliable & unreliable channels

Audio

• SoundManager with SFX caching and music streaming
• Spatial 2D audio — sounds attenuate based on distance from listener

Input

• Action-based input — bind logical actions to keyboard, mouse, and gamepad
• Query style: pressed(), held(), released(), axis()
• Gamepad support with deadzone and stick queries

Utilities

• Asset PAK system — bundle assets into a single encrypted file
• CLI tool — pyluxel pak <directory> to package assets
• cprint — colored console logger for debug output
• EventBus — global pub/sub event system

---

Installation

pip install pyluxel

Or install from source:

git clone https://github.com/ArcademMan/PyLuxel.git
cd PyLuxel
pip install -e .

Requirements

• Python 3.10+
• pygame-ce >= 2.4.0
• ModernGL >= 5.8.0
• NumPy >= 1.24.0

---

Quick Start

from pyluxel import App, Input
import pygame

app = App(1280, 720, "My Game")

Input.bind("quit", pygame.K_ESCAPE)

@app.on_update
def update(dt):
    if Input.pressed("quit"):
        app.quit()

@app.on_draw
def draw():
    app.draw_rect(100, 100, 50, 50, r=1, g=0, b=0)
    app.draw_text("Hello PyLuxel!", 640, 360, size=32, align_x="center")

app.run()

With Lighting

from pyluxel import App, Light, Input
import pygame

app = App(1280, 720, "Lights Demo")

Input.bind("quit", pygame.K_ESCAPE)

@app.on_update
def update(dt):
    if Input.pressed("quit"):
        app.quit()

@app.on_draw
def draw():
    app.draw_rect(400, 300, 200, 200, r=0.2, g=0.2, b=0.3)

    app.lighting.clear()
    app.lighting.add(640, 360, radius=400, color=(1.0, 0.8, 0.5))
    app.lighting.add(*Input.mouse_pos(), radius=200, color=(0.3, 0.5, 1.0))

app.fx.bloom = 0.6
app.fx.tone_mapping = "aces"
app.run()

---

Documentation

Full documentation is available in the pyluxel/docs/ directory:

Document	Description
Getting Started	Minimal setup, first window, App bootstrap
Rendering	Resolution, Renderer, SpriteBatch, Camera, PostFX
Effects	LightingSystem, FogLayer, ParticleSystem, Transitions
Text	SDFFont, BitmapFont, FontManager
UI	Theme, widgets, layouts, focus management
Animation	Skeletal animation, Stickman, state machine
World	Tilemap, parallax, map loading
Networking	P2P, synced state, RPC, lobbies, Steam transport
Events	EventBus, global pub/sub
Audio & Input	SoundManager, InputManager, gamepad
App	App bootstrap, shapes, text shortcuts
Asset PAK	Asset packaging and CLI
API Reference	Full API cheatsheet

---

Project Structure

my_game/
├── assets/
│   ├── sprites/       # PNG textures
│   ├── fonts/         # TTF font files
│   ├── sfx/           # Sound effects (WAV/OGG)
│   ├── music/         # Music tracks (OGG/MP3)
│   └── maps/          # Tiled JSON maps
├── main.py
└── ...

---

License

MIT License. See LICENSE for details.
