Static facts for Python services (Django, Django REST framework, Flask, SQLAlchemy), emitted in the isthmus bridge-facts exchange format.

pythograph is the Python member of a family of static-analysis CLIs (tsograph for TypeScript/JavaScript, cartograph for Swift, kartograph for Kotlin, dartograph for Dart, gartograph for Go, rustograph for Rust, schemagraph for SQL). Each tool reports only what it observes in its own language; isthmus joins the documents.

The analyzed project is parsed with the standard-library ast only. It is never imported or executed, and pythograph has no runtime dependencies and uses no network. The only program it starts is git at the project root, to read revision for graph, reach, and impact; git runs without the filter commands that the repository's git configuration defines, never fetches the objects that a partial clone lacks, and never runs inside submodules (see Security).

Status

isthmus-cli 0.10.0 (npm) is the first release that accepts platform: "python" http documents (server route-decl including registration-order, and client route-call), persistence documents, and python language-traversal analyses (see isthmus compatibility).

Requirements and installation

• Python 3.10 or newer (Django 5.x needs 3.10+, and pythograph parses the analyzed code with the running interpreter, so run it with the same or a newer Python than the project).

Install from PyPI:

uv tool install pythograph
# or
pipx install pythograph

pythograph --version

To try unreleased changes, install from GitHub (uv tool install git+https://github.com/ictechgy/pythograph, or pin a release tag such as @v0.1.0). A wheel built from a checkout (uv build) installs the same way: uv tool install dist/pythograph-<version>-py3-none-any.whl. The release steps are in RELEASING.md (Korean).

pythograph routes --role server

pythograph routes --role server --project <root> [--service <name>] [--include-tests]
                  [--framework auto|django|flask] [--settings <module>]
                  [--dispatch specificity] [--generated-at <timestamp>] [--format json]

Writes a bridge-facts v1 document to stdout: platform: "python", target: "http", roles: ["server"], dispatch, sourceSets, and one route-decl fact per (route, HTTP method).

• --project (required): the project root. project is its POSIX realpath and every location.path is relative to it.
• --framework: auto (default) detects Django (a DJANGO_SETTINGS_MODULE default in manage.py, wsgi.py, or asgi.py, or --settings) and Flask (a Flask(...) or Blueprint(...) object). A project with both is a usage error until you pick one.
• --settings: the Django settings module when the entry files do not name it.
• --include-tests: also emit routes declared in test sources (test_*.py, *_test.py, tests.py, conftest.py, files under tests/ or test/) with testSource: true and sourceSets.tests: "included".
• --dispatch specificity: declare specificity for a Django project and omit order (see Decisions).
• --generated-at: a fixed generatedAt for byte-identical output.
• Exit codes: 0 success (zero facts is still success, not proof of completeness), 2 unreadable project, more than 100,000 facts, output over 16 Mi characters, or an internal error (the message states the cause and a fix, never source text or absolute paths), 64 usage error. 1 is reserved.

Example (synthetic, compacted; the real output is key-sorted JSON with two-space indentation):

{
  "dispatch": "registration-order",
  "facts": [
    {
      "channel": "/catalog/items/{}/edit/",
      "dynamic": false,
      "kind": "route-decl",
      "location": { "column": 10, "line": 20, "path": "catalog/urls.py" },
      "method": "POST",
      "order": { "group": "django:shop.urls", "index": 7 },
      "paramConstraints": [{ "kind": "int", "segment": 2 }],
      "pathAnchor": "root",
      "symbol": { "qualifiedName": "catalog/views.py#ItemEditView.post", "usr": "catalog/views.py#ItemEditView.post" },
      "trailingSlash": "strict"
    }
  ],
  "format": "bridge-facts",
  "platform": "python",
  "roles": ["server"],
  "target": "http",
  "tool": { "name": "pythograph", "version": "0.2.0" },
  "version": 1
}

What is modeled

Every rule was checked against the installed package sources (Django 5.2.17, djangorestframework 3.18.1, Flask 3.1.3, Werkzeug 3.1.9). The full table with source files is in docs/HTTP-ROUTES.md (Korean).

• Django: ROOT_URLCONF from the settings module (star imports of project settings modules are followed), urlpatterns built with lists, +, +=, .append, .extend, .insert, path(), re_path(), include() (module strings, module objects, lists, (patterns, app_name) tuples, nested), default and registered path converters, re_path regular expressions converted from their syntax tree when possible, function views (ANY, narrowed by require_http_methods/require_GET/require_POST/require_safe/ api_view), class views (as_view(), handlers along the class chain, http_method_names), and the registration order (first match wins).
• Django REST framework: SimpleRouter/DefaultRouter (trailing_slash, use_regex_path, lookup settings, @action with detail, methods, url_path, and .mapping), the DefaultRouter API root and format-suffix variants, format_suffix_patterns, APIView, generic views, and viewsets.
• Flask: Flask(...) and Blueprint(...) objects at module level or in app factories, @route, @get/@post/@put/@delete/@patch, add_url_rule, register_blueprint (nested, url_prefix), MethodView/View, Werkzeug converters (string, int, float, uuid, path, any, custom), strict_slashes, and merge_slashes.

How facts are built

• channel: the canonical path template. A parameter filling a whole segment is {}, a partial segment keeps its literal skeleton (/files/{}.json), a final parameter that can match / is {**}, and anything else that cannot be proven (a segment with two parameters, a middle catch-all, lookarounds, unanchored regular expressions) is dynamic with a route-coverage: limitation. Literals are in the decoded path space, so non-pchar characters are UTF-8 percent-encoded and % becomes %25.
• method: uppercase verbs or ANY. HEAD next to GET and automatic OPTIONS are not emitted (isthmus matches them with head-as-get and options-any); an explicitly declared OPTIONS is. Verbs outside the exchange method set (GET, HEAD, POST, PUT, PATCH, DELETE, OPTIONS, TRACE), such as PURGE in Flask methods or Django http_method_names, are not emitted and not turned into ANY; the registration gets a route-coverage: limitation scoped to its templates when they are proven.
• paramConstraints: int, slug, uuid, path (for {**}), or regex with the pattern. The informational pattern is left out when the regular expression text contains characters the exchange format forbids (control characters, U+2028/U+2029, or an unpaired surrogate).
• trailingSlash: Django and strict Flask rules are strict; /? in a regex and Flask strict_slashes=False are optional; omitted after {**}.
• order (Django): {group: "django:<ROOT_URLCONF>", index: <depth-first position>}.
• location: the route string argument (Django path()/re_path(), Flask decorator or add_url_rule), the router.register() prefix for DRF routes, or the @action decorator for extra actions; 1-based line and 1-based UTF-8 byte column.

Symbol ids

symbol.usr is <project-relative POSIX path>#<lexical dotted name>, outermost declaration first and without <locals>: catalog/views.py#item_list, blog/__init__.py#create_app.index, catalog/views.py#ItemEditView.get, orders/views.py#OrderViewSet.list. Class handlers are named after the class registered in the URL even when the method is inherited; the call graph (pythograph graph) has an inherited-member node with the same id. Views defined outside the project have no usr and are counted under missing-route-usrs:.

Limitations

When a value cannot be proven, pythograph does not guess: it emits dynamic, pathAnchor: "base", or a limitation with one of the contract's prefixes, and adds limitationScopes only when it can prove an upper bound. Examples: conditional registrations (if settings.DEBUG:) become route-coverage: scoped to their templates; unresolved includes and third-party URL modules are scoped to their include prefix; the Django admin, static(), django.contrib.staticfiles, and Flask static files are framework-provided-routes: with prefix scopes (Flask static also with GET/HEAD); FORCE_SCRIPT_NAME, i18n_patterns, and blueprints whose registration is not visible use a base anchor with unresolved-route-prefix:; a project that does not pin Django 5, DRF 3, or Flask 3 gets route-framework-version-unknown:. A module constant or setting that is not provable (see Bounded source scanning: bound twice, +=, assigned inside an if, loop, try, with, or match block, rebound through global, or changed in place such as INSTALLED_APPS.append(...)) is unknown: a route string built from it is dynamic, a method list from it leaves the view with its known methods or ANY and a scoped route-coverage:, a conditional FORCE_SCRIPT_NAME gives the base anchor, and an INSTALLED_APPS changed this way gives an unscoped framework-provided-routes: limitation. A Flask app or blueprint bound to such a name may be a different object at run time, so the rules and blueprint registrations that go through that name get the base anchor with unresolved-route-prefix:.

Decisions

• Django is registration-order, Flask is specificity, as verified from the sources. isthmus releases before f9dcd1d reject registration-order; --dispatch specificity declares specificity for Django and omits order. That approximation can only produce false matches (a shadowed pattern matched), never false errors, because isthmus filters by method first and reports a method mismatch only when no candidate accepts the method, which is also when Django answers 405.
• Shadowed patterns are still declarations; shadowing is the consumer's judgement from order.
• Conditional registrations are scoped limitations, not declarations.

pythograph routes --role client

pythograph routes --role client --project <root> [--wrappers <file>] [--service <name>]
                  [--include-tests] [--generated-at <timestamp>] [--format json]

Writes a bridge-facts v1 document with platform: "python", target: "http", roles: ["client"], and one route-call fact per HTTP request expression. The full rule table with the verified library sources, the oracle recording, and the end-to-end trace is in docs/HTTP-CLIENTS.md (Korean).

• Libraries (resolved by name, never by a same-named project function): requests 2.34 (top-level functions and Session), httpx 0.28 (top-level functions, Client/AsyncClient with base_url), aiohttp 3.x (ClientSession with base_url, aiohttp.request), and urllib.request.urlopen (with Request(method=) and data). Clients are followed through single-assignment locals, with/async with, module variables, instance fields and class attributes whose every assignment is a client, client-typed annotations, and project subclasses of a client class.
• Base joins use the isthmus style names: httpx-base-url (the base always ends in / and every leading / of the path is stripped, so /x stays under the base path), aiohttp-base-url (RFC 3986: /x replaces the base path; path-bearing bases and relative paths need aiohttp 3.11+, absolute URLs on a base session need 3.12+, proven from the project's lock/requirement files), and none for requests and urllib. urllib.parse.urljoin has no vector yet, so only its absolute-URL and /-rooted forms are claimed.
• URL strings: f-strings, +, % formatting, str.format, provable module constants (bound exactly once, never rebound, no global or module-attribute writes, no same-named attribute write on an unknown receiver such as sys.modules[__name__].API_ROOT = …, and not in a module that calls globals() or module-level vars()/locals()), class attributes and __init__ fields with one literal value, and proven query-tail locals. An interpolation becomes {} only when it fills a whole segment; otherwise the fact is dynamic with a masked channelPrefix (channel is null, so no raw URL text leaves the tool). A literal host gives root plus authority; a dynamic host or an unknown base gives base.
• Wrappers (--wrappers, isthmus http-wrappers v1): "language": "python" entries; owner is a pythograph class id (api/client.py#Gateway) for methods and constructors (name: "__init__", dataclasses included) or a module path (api/net.py) for module functions. label is a keyword argument, index a positional argument (receiver excluded). Unknown fields and malformed entries exit 64; declarations that match nothing report http-wrapper-unresolved:. A wrapper's service goes on its facts in place of --service. When it differs from --service, the document-level service is omitted (isthmus rejects a fact service that differs from the document's) and --service stays on the other facts.
• symbol.usr is the enclosing function, method, class body, or module id — the same ids as graph/reach/impact.
• Limitations: route-call-coverage: (unmodeled request APIs such as urllib3, http.client, send/build_request, URL literals passed to receivers whose client type is unknown, scan gaps), ambiguous-base-join:, http-wrapper-undeclared: (functions that pipe a parameter into a request URL), and http-wrapper-unresolved:.

pythograph schema

pythograph schema --project <root> [--include-tests] [--settings <module>] [--generated-at <timestamp>] [--format json]

Writes a bridge-facts v1 document with platform: "python", target: "persistence" (or null when there are no facts), and one relation-use fact per observed relation or column reference. isthmus joins it with a platform: "sql" document (schemagraph facts --document <catalog>) under the persistence rules of docs/GRAPH-EXCHANGE.md. The full rule table with source files is in docs/PERSISTENCE.md (Korean).

• Django: model classes (abstract, proxy, multi-table inheritance, Meta inheritance) → tables (<app_label>_<model> truncated by truncate_name for the backend's max_name_length, or Meta.db_table), fields → columns (db_column, <name>_id for foreign keys, many-to-many tables and their columns), app labels from INSTALLED_APPS/AppConfig, the DATABASES backend, and django.contrib models. Uses: managers and QuerySet chains, lookups (author__profile__city, reverse relations, attname, pk), values/order_by/F/Q/aggregates, create/update keywords, related managers and forward relations on proven instances, raw(), RawSQL, extra(tables=), and cursor SQL.
• SQLAlchemy 2.x / Flask-SQLAlchemy 3: Declarative classes (DeclarativeBase, declarative_base(), db.Model with its snake_case names), mixins, single- and joined-table inheritance, __table_args__/MetaData schemas, Core Table, ForeignKey("t.c"), relationship(secondary=). Uses: statement entities (select, insert, update, delete, session.query, session.get, join), Model.column, Model.relationship, Model.query, filter_by, constructors, table.c.name, and text().
• SQL text: the family's shared lexical extractor (the same vectors as tsograph, dartograph, cartograph, and kartograph) for explicit SQL arguments, and uppercase SQL literals elsewhere (docstrings are skipped). Following the rules shared by the persistence producers, an unqualified name that is a CTE of the same ;-separated statement, the operand of a FROM inside function arguments (EXTRACT(YEAR FROM created_at), TRIM, SUBSTRING; a subquery there still counts), and the operand of IS [NOT] DISTINCT FROM are not relation uses. The rules apply as written: a CTE named like a real table also hides that table in the same statement (the users read by WITH users AS (SELECT * FROM users …), an INSERT INTO users target), and a DML FROM in parentheses after a word that is not a clause keyword (COPY (DELETE FROM t …)) reads as a function argument.
• channel is the relation name as written or mapped (schema.table only when qualified; no default schema is guessed), method is the column, and symbol.usr is the enclosing function, method, or model class with the same ids as routes. A name that depends on an unknown backend, app label, or Flask-SQLAlchemy version, an unresolved model or lookup, a module constant that is not provable (db_table = TABLE after TABLE += ..., a __tablename__ built from a conditionally reassigned prefix), a Core Table object reached through a name that is not provable (select(users), __table__ = users, or secondary=users when users is reassigned), and SQL built at runtime become dynamic facts with a dynamic-relation-names: limitation instead of guesses; such a constant passed to execute() is counted under unresolved-sql-arguments:.
• Test sources (unless --include-tests) and migrations (Django migrations/, Alembic versions/) are not scanned; migrations describe past schemas.

pythograph graph / reach / impact

pythograph graph  --project <root> [--include-tests] [--revision <id>] [--generated-at <timestamp>]
pythograph reach  --project <root> [--dispatch direct|bound|candidates] [--max-depth <n>] [--max-reached <n>]
                  [--roots-from <file|->] [--include-tests] [--revision <id>] [--generated-at <timestamp>] [--] <id>...
pythograph impact (same options as reach)

Builds the project's Python call graph with the standard-library ast. graph writes pythograph's own snapshot (pythograph-graph v1); reach writes the symbols the roots depend on (dependencies) and impact the symbols that depend on them (dependents) as isthmus language-traversal v1. Ids are the same strings as symbol.usr in routes and schema. The full rules are in docs/GRAPH.md (Korean).

• Nodes: modules (<path>#<module>), functions, methods, classes, nested definitions, and inherited members (<registered class>.<member>, for view handlers and for inherited members called on exact receivers).
• Edges: call, new (the project __init__, else the class), callback, reference, decorator, attribute (class-body attributes), inherit, and dispatch/framework (framework dispatch). Resolution follows imports (absolute, relative, aliases, __init__ re-exports, *), module attributes, constructors, self and super() through the C3 MRO of project classes, annotated and return-annotated receivers, module-level instances, and properties.
• Evidence tiers: statically resolved edges are direct; overrides in project subclasses for self, cls, and annotated receivers are candidate. A method call on a receiver of unknown or overridable type gets bound edges (followed by --dispatch bound) only when every value observed flowing into the receiver is a project class instance: constructors, module-level instances, attributes assigned in __init__ from constructor parameters (DI), function parameters whose call sites are all in the project, and factory return values. Open slots get no bound edge: public functions, classes, and module globals of a library (a project root with setup.py/setup.cfg or a pyproject.toml [project]/[tool.poetry] table), framework-invoked entry points (functions passed as values, decorated functions, classes with framework bases), computed getattr/setattr and module namespaces, *args/ **kwargs spreads, wrapping decorators, monkeypatching writes whose value is unknown, self/cls, and test sources (a separate program). Values that leave through library code and computed-name writes to receivers of unknown type are not modeled (reported under bound-assumptions:). The default stays direct: bound linked no calls in the four dogfood apps. Module globals and class-body attributes are exact receivers only when nothing rewrites them.
• No guessing: calls without a known target are counted by reason (parameter, untyped-receiver, dynamic-attribute, getattr, dynamic-callee, unresolved-import, framework-callback, …) as each symbol's unresolvedCalls. A method call on an untyped receiver is proven external only when no project class, module, or attribute write defines that name.
• Framework dispatch: a table read with ast from the installed Django 5.2.17, DRF 3.18.1, and Flask 3.1.3 sources links the project hooks that the as_view() dispatch path (dispatch, initial, permission checks, __init__) and framework implementations (ModelViewSet.retrieve → get_object → get_queryset, ModelSerializer.save → create) call. Objects the framework builds from class attributes (serializer_class, permission_classes) count as framework-callback unresolved calls.
• Snapshot size: the graph snapshot is not an isthmus input, so it may be up to 256 Mi characters (about 2 bytes of extra memory per output character while encoding); reach and impact keep the 16 Mi isthmus input limit. The encoding is unchanged, so raising the cap alone changes no snapshot under 16 Mi characters.
• Traversal documents: a dispatch declaration, per-root lower-bound evidence, unresolvedCalls, one multi-root pass (compared with a per-root oracle on random graphs), --max-depth/--max-reached truncation, and rootsTruncated. Roots that are not graph nodes are listed without symbol; the document is written and the command exits 64. revision is --revision or git HEAD when the work tree is clean (omitted, with a revision-unverified: limitation in the snapshot and the traversal documents, when a clean tree cannot be checked without running the repository's git configuration: a work tree with submodules, or a partial clone that lacks objects the check reads, see Security); graphRevision is a SHA-256 of the graph content.

Validation

The oracle harness in experiments/oracle/ imports the synthetic fixtures in a scratch virtual environment and compares pythograph's facts with Django's resolver traversal, DRF routers, and Flask's url_map (tests/test_fixtures.py replays the recorded results offline):

Dogfooding on four public apps (Django-Styleguide-Example, babybuddy, microblog, and netbox, cloned only into a scratch directory) measured route precision against each framework's resolver, relation-use join rates through schemagraph and isthmus, handler-to-relation reachability, unresolved-call reasons, and runtime; the results and the fixed issues are in DOGFOOD.md (Korean).

The isthmus shared conformance vectors (conformance/, vendored from isthmus 2954375 and locked in conformance.lock) pass 100% of the producer and producer:pythograph cases (135: template.grammar, template.normalize, scope.validate, scope.applies, dispatch.validate, and 57 url-compose cases for query tails, interpolation, normalization, stripping, masking, the rfc3986/httpx-base-url/aiohttp-base-url joins, and wrapper argument binding); the dispatch.validate checker also runs on the routes golden output.

Client mock-server oracle. experiments/client_oracle/ runs the synthetic client fixtures/client/shop-client in a scratch environment against a local http.server on 127.0.0.1 (name resolution and connects are redirected, no external traffic) and records what requests, httpx, aiohttp, and urllib actually send. Recorded 2026-09-30: 35 scenarios, 31 matches, 4 dynamic, 0 mismatches (tests/test_client_oracle.py replays it offline).

Python client × Django server trace. experiments/client_e2e/ joins a synthetic Python client (fixtures/e2e/py-client) with the Phase 6 Django server recording through isthmus trace (main 3a45450): all four selected routes attach the Python call site (exact match) to the server handler, reach the calling screen functions, and continue to the relation uses and tables (tests/test_client_e2e.py).

Phase 6 exit criterion (Django backend × iOS/Android chain). experiments/e2e/ joins a synthetic Django + DRF server (fixtures/e2e/shop-api), a schemagraph catalog of its Django DDL, and route-calls plus reverse traversals of synthetic iOS (cartograph) and Android (kartograph) clients with isthmus trace (workspace). The expected paths of the three questions match: (a) API → DB tables + DB dependents, (b) API → client call sites → affected client symbols, and (c) table → API → client. The Android recording needs kartograph 4c09d91 or later (Retrofit route-call usrs and baseUrl joins), which attaches the Android order and checkout calls to the chain. tests/test_e2e_trace.py re-checks the recorded inputs and outputs offline (the table is in docs/GRAPH.md).

Persistence naming vectors (fixtures/persistence-naming/vectors.json) are recorded by importing synthetic models with the real ORMs in a scratch environment (experiments/persistence/run_naming.py): Django 5.2.17 _meta names quoted by each backend's connection.ops (sqlite3, postgresql, mysql, oracle), and SQLAlchemy 2.0.54 / Flask-SQLAlchemy 3.1.1 mappers. pythograph matches 100% (Django 136/136 model-backend pairs, SQLAlchemy 9/9 and Flask-SQLAlchemy 10/10 classes, all tables and columns). Joining pythograph schema output for the two persistence fixtures with schemagraph catalogs of the DDL the ORMs create (experiments/persistence/run_e2e.py) gives no isthmus errors (41 and 20 matches).

isthmus compatibility

isthmus-cli 0.10.0 (npm, npm install --global isthmus-cli@0.10.0) is the released version that accepts platform: "python": http route-decl facts (Django's registration-order and order, with shadowing diagnostics), client route-call facts (routes --role client), persistence relation-use facts, and python forward/reverse analyses (language-traversal v1) in trace. Earlier isthmus releases reject python route-decl and route-call documents as input errors. --dispatch specificity remains for those older releases.

Bounded source scanning

Source reads request at most 4 MiB plus one overflow byte. Directory enumeration consumes at most 200,000 entries plus one overflow entry, with a maximum depth of 64. An oversized directory is omitted as a whole rather than selecting an arbitrary filesystem-order subset; files from previously completed directories remain available. Unreadable directory entries are counted in limitations for routes, schema, and graph output, and prevent closed-world bound proofs that would otherwise rely on missing modules. A successful command with these limitations is still an incomplete analysis.

File paths become every fact's location.path and symbol id, so a Python file whose project-relative path is not valid UTF-8 or contains characters the exchange format forbids (C0/C1 control characters including NEL, U+2028, or U+2029) is not analyzed. It is counted in limitations instead (scan-incomplete: for graph, route-coverage: or route-call-coverage: for routes, unreadable-sources: for schema) rather than producing a document that isthmus rejects as a whole.

Directories that contain manage.py are module roots, because Django puts them on sys.path: imports resolve against them (shallowest first), then the project root, then src/, and a module is named from the deepest of these roots that contains it. At most 256 manage.py directories, the shallowest by depth and then path, become module roots. Imports that only the remaining directories would resolve are treated as external, so those directories are counted in limitations (scan-incomplete: for graph, route-coverage: or route-call-coverage: for routes, scan-truncated: for schema) and prevent closed-world bound proofs; pass a narrower --project to analyze them. Each module root's entries are read once, so resolving a name touches the filesystem only under roots that contain its first component.

Modules whose syntax tree nests deeper than 128 levels for graph, reach, and impact, or 256 levels for routes and schema (whose analysis recurses less), for example very long operator, attribute, call, or subscript chains, or long elif ladders, are not analyzed, so that one generated or crafted file cannot exhaust Python's recursion limit and abort the whole command. They are reported like files that fail to parse — unparsed-files: in graph output, route-coverage: for routes, unreadable-sources: for schema — with the reason "source nesting too deep to parse". Public packages rarely nest beyond 100 levels. Python 3.10's parser crashes the process on extremely long chains instead of raising an error, so on 3.10 a file with a logical line of more than 50,000 chain tokens (binary operators, ., (, [) is reported the same way without being parsed, even when the line is a flat list. Chains inside f-string replacement fields count toward their line (every chain character of the f-string is counted). String annotations (forward references such as "Mapped[str]" or "Client | None") are parsed under the same limits; one that cannot be parsed (including one with a NUL character) or that nests too deeply is treated as an unknown annotation.

One run parses at most 64 MiB of Python source in total, counting only the modules it parses successfully. A module that would push the total past this budget is not parsed and is reported like a file that fails to parse (unparsed-files: in graph output, route-coverage: or route-call-coverage: for routes, unreadable-sources: for schema) with the reason "the run's total parsed source would exceed its 64 MiB budget; pass a narrower --project"; the command still succeeds with the other modules. Each command parses in a fixed order (path order, with modules reached through imports parsed when first needed), so the same input skips the same modules on every run. Parsed syntax trees stay in memory until the command ends, because name resolution can return to any module: ordinary code peaks at about 30–55 bytes of memory per source byte (graph on sympy, 26 MB of source in 1,532 files, takes about 1 GB), so a run at the budget needs about 2–4 GB. A module whose syntax tree has more than 1,000,000 nodes (counting context and operator leaves) is not kept either: it is reported the same way with the reason "syntax tree larger than 1,000,000 nodes". Among the large files measured in installed packages (sympy, torch, NumPy, SciPy, faker, and others) and the standard library, the largest real module has about 200,000 nodes, while a 4 MiB module of x = 1 lines has about 2.8 million and kept about 0.9 GB. So one module keeps at most about 0.45 GB, and parsing one module peaks at about 2–3 GB, bounded by the 4 MiB file limit. Literal-heavy modules below the node limit (large list literals, generated tables, thousands of x = 1 lines) still keep about 220–350 bytes per source byte, so a crafted repository that spreads such data over many modules can still use 15–25 GB within the budget; pythograph does not bound that case yet. Analyze untrusted repositories under an operating-system memory limit (a cgroup or container memory limit, or ulimit -v on Linux).

Constant evaluation follows f-strings, +, list literals, and module constants for route strings, settings, SQL text, and client URLs. A short chain that references the same constant many times (B = f"{A}{A}…", C = f"{B}{B}…") would otherwise grow exponentially, so repeated references are expanded once, values built this way are capped at 64 KiB (characters for strings; elements plus their characters for lists), and client URL expressions at 4,096 parts. A larger value is treated as unknown: a dynamic route or route-call fact, an unread setting, or for SQL text a skipped-sql-literals: limitation. A single string literal is limited only by the 4 MiB file limit. Route strings longer than 8 KiB (4 times the 2,048-character template limit; Flask rules after merging slashes, Django path() and re_path() strings joined with their include prefixes), and shorter ones whose literal characters alone (outside Flask converters, outside Django path() converters, outside re_path groups) exceed the template limit, are not converted and become dynamic facts like any over-long template.

Route strings, settings, SQL text, and schema names follow only provable module constants, by the same binding rule as the call graph's stable globals and routes --role client: a name bound more than once at module level (+=, a second assignment, a loop variable, an import), bound inside an if/try/for/while/with/match block, declared global in a function, or defined in a module that calls globals() (or module-level vars()/locals()) is unknown even when it also has an unconditional assignment. They also treat a name changed in place anywhere in its module (NAME.append(...), NAME[k] = ...) as unknown and check every module on an import, star-import, or module-alias chain, so a settings module that changes a star-imported setting (from .base import * followed by INSTALLED_APPS += [...]) makes that setting unknown.

Class hierarchies (view classes for routes and graph, SQLAlchemy mappings for schema) are followed at most 32 levels deep, and each class is analyzed once per depth, so a diamond-shaped hierarchy costs time proportional to its classes rather than to its exponentially many paths. A static inheritance cycle, which Python itself cannot build, makes the result depend on the path taken; when one view class would need more than 1,024 such re-linearizations, its remaining bases are treated as unknown. Flask blueprint registrations that close a cycle (Flask fails to register them) are not followed and count as route-coverage:. Registering the same blueprints along many paths is expanded per path as Flask does, up to 200,000 nested registrations (route-coverage: beyond that); the expansion stops early once more than 100,000 route-decl facts make the document impossible, ending with the usual fact-limit error (exit code 2).

Flask-SQLAlchemy 2's automatic table name rule (([A-Z]+)(?=[a-z0-9]), kept exactly as Flask-SQLAlchemy writes it) backtracks over a long run of capitals in time quadratic in the class name's length, so it is not applied to class names longer than 1,000 characters. When major version 2 is a candidate (declared, or the version is not limited to one major), such a class's automatic table name becomes a dynamic fact with a flask-sqlalchemy-naming-unverified: limitation; set __tablename__ to name it. The linear Flask-SQLAlchemy 3 rule applies at any length.

Every project-relative path component is checked for symbolic links, including module/package resolution and dependency manifests. Links to locations inside the project are rejected too; the skipped-link count counts each encountered path once. The directory walk counts only links whose name could hide sources it would otherwise read, judged from the name alone without touching the target: links named *.py (including broken ones) and extensionless links with a name the walk would enter. Links such as CLAUDE.md -> AGENTS.md, README.md, or .venv therefore do not become limitations, and the count never depends on what exists on the analyzing machine. A directory link with an extension (conf.d) is not counted and an extensionless file link (LICENSE) is. Links met during module resolution or manifest reads always count. On systems supporting descriptor-relative O_NOFOLLOW, directory scans and source reads open each component without following links, and verify the opened file before reading. Other systems recheck components and file identity before reading, but those checks are not atomic. Analyze a stable project tree; this is not a filesystem snapshot or a sandbox against concurrent changes to the filesystem. The analyzed Python code is never imported or executed.

Security

pythograph starts one external program: git, only to read the revision of graph, reach, and impact when --revision is not given and the project root has .git (git config, git ls-files, git status, and git rev-parse, run at the project root). It runs the first git in an absolute PATH entry and skips one that lives inside the project or directly in the current directory. A .git directory that arrives with an archive or a copy can define commands that git runs while it reads the work tree (see "SECURITY" in git(1)). pythograph closes the ways it knows these git calls can reach such commands:

• Right before each call, pythograph lists the filter drivers and promisor settings git sees (git config -z --includes --get-regexp for filter.<driver>.clean, smudge, and process, extensions.partialClone, and remote.<name>.promisor and partialCloneFilter, which covers the repository, its includes, your own configuration, and the system configuration) and overrides each driver with empty clean, smudge, and process commands and required=false, so git runs none of them. This holds for drivers named in .gitattributes and in .git/info/attributes.
• It never lets git fetch missing objects. A partial clone (a repository with a promisor remote) fetches objects it lacks on demand, and that fetch follows the remote's configuration (remote.<name>.uploadpack, core.sshCommand, and so on). Every call sets GIT_NO_LAZY_FETCH=1, and when the listing shows a promisor setting, every call except the listing itself also passes --no-lazy-fetch. Both need git 2.45 or later: an older git ignores the variable but rejects the option before it starts, so it reads no partial clone.
• It turns off core.fsmonitor, the untracked cache, log.showSignature, and optional locks (GIT_OPTIONAL_LOCKS=0, so the index is never rewritten). pythograph runs no git diff or git log.
• It never starts git inside a submodule: git status runs with --ignore-submodules=all, and does not run at all when the index has a submodule.
• When these settings cannot be listed, or a driver name contains =, a control character, or bytes that are not UTF-8 (git's -c splits at the first =, so such a driver cannot be overridden), no other git command runs.

What this changes:

• A file that a filter normalizes (git-lfs and the like) is compared as raw content. When git's stat cache is stale for it (a copied or extracted tree, a touched file), the work tree counts as changed and no revision is recorded, rather than claiming a clean HEAD that could not be verified. In a checkout you trust, run git status first to refresh git's stat cache.
• A work tree with submodules gets no automatic revision: pythograph also analyzes the sources inside them, and git cannot tell whether they are clean without following each submodule's own configuration. A driver name that cannot be overridden stops git altogether. Both cases add a revision-unverified: limitation to the graph snapshot and to the reach and impact documents.
• A partial clone is read only from the objects it already has. When git needs a missing object to check the work tree, or is older than 2.45, no revision is recorded and the same revision-unverified: limitation says why. A partial clone that has every object the check reads keeps its revision with git 2.45 or later.
• The rest of the git configuration still decides what git reports (for example core.worktree), and pythograph trusts every setting outside the paths above, so an automatic revision is only as trustworthy as the .git directory. For a tree whose .git you do not trust, pass --revision <id>: git then does not run at all.

Development

uv sync
uv run ruff check src tests && uv run ruff format --check src tests
uv run mypy
uv run pytest --cov          # line and branch coverage gate: 90%
uv run python scripts/verify_cli_contract.py

The framework hook table is regenerated from a scratch virtual environment with Django 5.2.17, DRF 3.18.1, and Flask 3.1.3 installed: python experiments/graph/dump_framework_hooks.py --site-packages <path> (--check compares only).

Analyze an actual change

Run pythograph change-impact --project . --base HEAD~1 --head HEAD, or omit --head for working-tree edits. Before/after source captures retain deleted callers and separate propagation paths, with content digests, file seed reasons, connected review/test candidates, unmapped files and limits. Results are always incomplete; they do not predict failures or authorize skipping tests. Existing impact <id> is unchanged. Nested traversals preserve the original project's canonical identity. Test candidates use the same filename policy as ordinary graphs; capture omissions keep source uncertainty open, and working reads and Git output are checked while reading. These boundaries and explicit omissions are documented below. Captures use Git-selected inputs; bound assumes those selected sources form the whole program. Ignored runtime writers may therefore change ordinary graph results. Materialization rejects paths that alias on the destination filesystem instead of merging their identities. See change analysis for the capture budget and remaining framework gaps.

License

MIT
