PythonSCAD

Script-based 3D modeling app which lets you use Python as its native language.

PythonSCAD is a script-based 3D modeling application with a full GUI. Write parametric, engineering-oriented models in Python, preview them live, and export to STL and other formats for 3D printing and manufacturing.

It is built on OpenSCAD's geometry engine and adds native Python support plus PythonSCAD-specific features. New to programming? Immediate visual feedback and printable output make PythonSCAD a rewarding way to learn.

Try it now, no install required: run PythonSCAD directly in your browser at the Playground (powered by WebAssembly).

• PythonSCAD
  • When to not use PythonSCAD
  • Difference to OpenSCAD
  • Intentional language limitations of OpenSCAD
  • Solids as 1st class objects
  • Additional methods in PythonSCAD
  • Python
  • PythonSCAD -> functional language, OpenSCAD -> descriptive Language
  • Installing
  • Example code
    • Documentation
    • Building PythonSCAD from source
  • Prerequisites
  • Getting the source code
  • Contributing Changes
  • Building for macOS
  • Building for Linux/BSD
  • Building for Linux/BSD on systems with older or missing dependencies
  • Building on Nix
  • Building for Windows
  • Windows SmartScreen certificate
  • Building for WebAssembly

When to not use PythonSCAD

If you need to create complex organic shapes, animate models, or produce visual effects, PythonSCAD is not the ideal choice. You will probably be much happier using Blender or similar tools, especially for creative, visual, and animation tasks.

PythonSCAD is optimized for script-based, parametric, and engineering-oriented modeling. If you prefer a point-and-click style design approach you might want to try FreeCAD.

Difference to OpenSCAD

PythonSCAD is a direct fork of OpenSCAD and thus includes all functionality from OpenSCAD and it is closely kept in sync with it's upstream project.

This section should help you decide whether OpenSCAD or PythonSCAD is better suited for your needs.

Intentional language limitations of OpenSCAD

OpenSCAD has some intentional limitations:

• variables are immutable
• file i/o is limited (you can include other OpenSCAD scripts or import graphics files for example)
• the number of iterations is limited

The intention is to prevent scripts to do bad things like reading arbitrary data from the filesystem, overwriting user files, leaking data via the internet, etc. so the script-sharing culture could be safe.

Using Python as the scripting language on the one hand lifts those limitations, but it also comes with the responsibility to carefully check code you have not written yourself.

On the plus side you have the whole Python ecosystem at your disposal. You could host your code on PyPI and use libraries developed by other people, you could use your favorite IDE, use linting tools, etc..

If you already know how to program in Python, you don't need to learn yet another domain-specific language and will feel right at home from the start.

All of this however doesn't make OpenSCAD inferior in any way. The choice to have a safe scripting language is a valid one. PythonSCAD just uses a slightly different route towards the same goal: Making 3D design fully scriptable and more accessible.

Without all the efforts and contributions of the team and the open source community towards OpenSCAD, PythonSCAD would not be possible and the authors and contributors of PythonSCAD are very grateful for that.

Solids as 1st class objects

In PythonSCAD all solids are 1st class objects and they can easily be a function parameter or return value. Any object doubles as a dictionary to store arbitrary data. If you like object oriented programming, just do so, you can even easily subclass the openscad type.

Additional methods in PythonSCAD

There are many additional methods over OpenSCAD, for example fillets or the possibility of accessing single model vertices. Arrays of Objects are implicitly unioned. Together with Python's List comprehension, you can very effectively duplicate variants of your model detail in one readable line.

Finally just export your model (or model parts) by script into many supported 3D model formats.

Python

One obvious difference is that you can use Python when programming in PythonSCAD. While part of the Python support has been merged to OpenSCAD already, not all of it is in there yet, so you probably will have a better experience when using PythonSCAD for writing models in Python.

This is especially beneficial if you have some experience in programming with Python or even other languages.

PythonSCAD -> functional language, OpenSCAD -> descriptive Language

PythonSCAD follows a functional language model while OpenSCAD is closer to a descriptive language. Both have their pro's and con's.

Installing

Pre-built binaries are available at https://www.pythonscad.org/downloads.

You could also build PythonSCAD from source.

Example code

PythonSCAD ships two top-level modules:

• pythonscad — the recommended import for new PythonSCAD designs. It is a strict superset of openscad and is the home for PythonSCAD-only features.
• openscad — kept for designs that should also be runnable by upstream OpenSCAD's Python integration. It mirrors the OpenSCAD-compatible API surface.

You can switch existing designs from from openscad import * to from pythonscad import * without changing any other code.

from pythonscad import *

c = cube([10, 20, 30]).color("Tomato")

show(c)

The same example using the OpenSCAD-compatible import (still fully supported):

from openscad import *

c = cube([10, 20, 30]).color("Tomato")

show(c)

Documentation

Have a look at the PythonSCAD documentation for a hands-on tutorial.

Building PythonSCAD from source

To build PythonSCAD from source, follow the instructions for the platform applicable to you below.

Prerequisites

To build PythonSCAD, you need some libraries and tools. The version numbers in brackets specify the versions which have been used for development. Other versions may or may not work as well.

If you're using a newer version of Ubuntu, you can install these libraries with the built in package manager. If you're using Mac, or an older Linux/BSD, there are build scripts that download and compile the libraries from source.

Follow the instructions for the platform you're compiling on below.

• A C++ compiler supporting C++17
• cmake (3.5 ->)
• Qt (5.12 ->)
• QScintilla2 (2.9 ->)
• CGAL (5.4 ->)
• GMP (5.x)
• MPFR (3.x)
• boost (1.70 ->)
• curl (7.58 ->)
• OpenCSG (1.4.2 ->)
• GLEW (1.5.4 ->)
• Eigen (3.x)
• glib2 (2.x)
• fontconfig (2.10 -> )
• freetype2 (2.4 -> )
• harfbuzz (0.9.19 -> )
• libzip (0.10.1 -> )
• Bison (2.4 -> )
• Flex (2.5.35 -> )
• pkg-config (0.26 -> )
• double-conversion (2.0.1 -> )

For the test suite, additional requirements are:

• Python3 (3.8 -> )
• Ghostscript (10.x ->)
• Catch2 (3.0 ->)

Getting the source code

Install git onto your system. Then run a clone:

git clone https://github.com/pythonscad/pythonscad.git

This will download the latest sources into a directory named pythonscad.

To pull the various submodules (incl. the MCAD library), do the following:

cd pythonscad
git submodule update --init --recursive

Contributing Changes

You can create an issue to plan and discuss your change by visiting https://github.com/openscad/openscad/issues.

If you want to work on an existing issue and plan to contribute changes via a PR later, you can assign the issue to yourself by commenting:

/assign-me

in a comment on the issue.

Building for macOS

Prerequisites:

• Xcode
• automake, libtool, cmake, pkg-config, wget, meson, python-packaging (we recommend installing these using Homebrew)

Install Dependencies:

After building dependencies using one of the following options, follow the instructions in the Compilation section.

1. From source

   Run the script that sets up the environment variables:

   source scripts/setenv-macos.sh


   Then run the script to compile all the dependencies:

   ./scripts/macosx-build-dependencies.sh


2. Homebrew (assumes Homebrew is already installed)

   ./scripts/macosx-build-homebrew.sh


Building for Linux/BSD

First, make sure that you have git installed (often packaged as 'git-core' or 'scmgit'). Once you've cloned this git repository, download and install the dependency packages listed above using your system's package manager. A convenience script is provided that can help with this process on some systems:

sudo ./scripts/get-dependencies.py --profile pythonscad-qt5

After installing dependencies, check their versions. You can run this script to help you:

./scripts/check-dependencies.sh

Take care that you don't have old local copies anywhere (/usr/local/). If all dependencies are present and of a high enough version, skip ahead to the Compilation instructions. These are as simple as:

mkdir build
cd build
cmake ..
make
make test
sudo make install

Building for Linux/BSD on systems with older or missing dependencies

If some of your system dependency libraries are missing or old, then you can download and build newer versions into $HOME/openscad_deps by following this process. First, run the script that sets up the environment variables.

source ./scripts/setenv-unibuild.sh

Then run the script to compile all the prerequisite libraries above:

Note that huge dependencies like gcc, qt, or glib2 are not included here, only the smaller ones (boost, CGAL, opencsg, etc). After the build, again check dependencies.

./scripts/check-dependencies.sh

After that, follow the Compilation instructions below.

Building on Nix

A development Nix shell is included for local, incremental compilation.

mkdir build
cd build
cmake ..
make
make test
sudo make install

Building for Windows

PythonSCAD for Windows is usually cross-compiled from Linux. If you wish to attempt an MSVC build on Windows, please see this site: https://en.wikibooks.org/wiki/OpenSCAD_User_Manual/Building_on_Windows

MSVC build support has been added to OpenSCAD. For instructions on how to build it, refer to building with MSVC.

To cross-build, first make sure that you have all necessary dependencies of the MXE project (listed at https://mxe.cc/#requirements). Don't install MXE itself, the scripts below will do that for you under $HOME/openscad_deps/mxe

Then get your development tools installed to get GCC. Then after you've cloned this git repository, start a new clean bash shell and run the script that sets up the environment variables.

source ./scripts/setenv-mingw-xbuild.sh 64

Then run the script to download & compile all the prerequisite libraries above:

./scripts/mingw-x-build-dependencies.sh 64

Note that this process can take several hours, and tens of gigabytes of disk space, as it uses the MXE system to cross-build many libraries. After it is complete, build OpenSCAD and package it to an installer:

    ./scripts/release-common.sh mingw64

For a 32-bit Windows cross-build, replace 64 with 32 in the above instructions.

Windows SmartScreen certificate

The code signing certificate for Windows is kindly provided by nomike aka Michael Postmann.

Building for WebAssembly

PythonSCAD builds headless for WebAssembly with Emscripten (CPython is cross-compiled into the bundle), so the full kernel runs in the browser. You can try the result without building anything at the Playground.

The build runs inside Docker (no host Emscripten toolchain needed). The web variant produces build-wasm-web/pythonscad.{js,wasm,data}:

./scripts/wasm-base-docker-run.sh emcmake cmake -B build-wasm-web \
  -DWASM_BUILD_TYPE=web -DCMAKE_BUILD_TYPE=Release -DEXPERIMENTAL=1
./scripts/wasm-base-docker-run.sh cmake --build build-wasm-web -j"$(nproc)"

See doc/wasm-build.md for the full guide (node vs web variants, local testing with wasm-test/serve.py, and the JavaScript API), and the website's Building for WebAssembly page for a user-facing overview.
