pytol 0.5.0

Mission generation for VTOL VR with python.

Pytol - VTOL VR Mission Generation Library

Pytol is a Python library for procedurally generating missions for the VR flight game VTOL VR. It provides tools to:

• Load and analyze VTOL VR custom map data (.vtm files).
• Calculate terrain height, surface normals, and object placements.
• Query map features for tactically relevant locations (e.g., hidden positions, observation posts, landing zones, choke points).
• Generate paths following terrain, roads, or avoiding threats.
• Construct and save valid VTOL VR mission files (.vts) and campaign files (.vtc).
• Create multiplayer missions and campaigns.

This enables automation in mission creation, allowing for more dynamic and complex scenarios. 🗺️✈️

⚠️ Disclaimer ⚠️

This library is a work in progress, some features will not work as intended yet. Reading the Known Issues section is recommended.

---

Features

• Terrain Analysis: Accurately calculate height and surface normals based on map heightmaps.
• Object Processing: Identify and process procedural cities, roads, and static prefabs placed in the map editor.
• Smart Placement: Place units correctly on terrain, roads, or building rooftops.
• Base Spawn Points: Database of precise hangar, helipad, and facility locations for airbase prefabs - works on any map with these bases.
• Tactical Queries: High-level functions to find locations based on mission needs (e.g., line-of-sight checks, hidden spots, flat areas, choke points).
• Pathfinding: Generate road paths, terrain-following flight paths, and covert insertion routes.
• Formation Generation: Create points for standard unit formations (line, wedge, circle).
• Mission Building: Construct .vts files programmatically, adding units, objectives, triggers, waypoints, and briefing notes.
• Campaign Support: Create .vtc campaign files with multiple missions, including multiplayer campaigns.
• Scenario Primitives: Helpers for generating common scenario setups like CSAR or base defense.
• 2D Visualization (optional): Lightweight static mission maps and clean overviews using matplotlib - perfect for mission briefings.
• 3D Visualization (optional): Interactive visualization of terrain and complete missions using PyVista.
• Event Sequences & Random Events: Script ordered event chains (EventSequences) with looping and conditional logic, and define weighted random actions (RandomEvents) with per-action conditional graphs. Supports full nested conditional graphs for both features.
• Conditional Graphs: All conditionals (including those in EventSequences and RandomEvents) support full graph emission, including methodParameters as nested blocks for VTS compatibility.
• Trigger/Proximity Improvements: Proximity triggers only emit waypoint = null if no waypoint is provided, matching in-game editor output.

---

Installation

There are two ways to install Pytol:

1. From PyPI (Recommended for users)

If you just want to use the library, you can install the latest stable release directly from the Python Package Index (PyPI):

pip install pytol

Optional: Visualization Modules

For 2D visualization (lightweight static maps with matplotlib):

pip install pytol[viz-light]

For 3D visualization (interactive PyVista visualizations):

pip install pytol[viz]

For both 2D and 3D visualization:

pip install pytol[all]

See Visualization Guide for details on both systems.

2. From Source (For development)

1. Clone the repo

git clone [https://github.com/Fran-98/pytol](https://github.com/Fran-98/pytol)  # Replace with your actual repo URL
cd Pytol

2. Install in editable mode

# This allows you to make changes to the source code and have them reflected immediately
pip install -e .

You also need to ensure the VTOL VR game directory is accessible on both methods, either by setting the VTOL_VR_DIR environment variable or by providing paths directly during initialization.

Documentation

📚 Mission Creation Guide - Complete guide to creating missions with Pytol
🎯 Campaign Creation Guide - Create multi-mission campaigns and multiplayer missions
🗺️ Terrain Behavior - How terrain height sampling works and accuracy expectations
🎨 Visualization Guide - Both 2D static maps and 3D interactive visualization

---

Getting Started

Here's a basic example of loading a map, finding a location, adding a unit, and saving a mission:

import os
from pytol import TerrainCalculator, MissionTerrainHelper, Mission

# --- 1. Setup ---
# Set VTOL VR directory (replace with your actual path or use environment variable)
VTOL_VR_PATH = "C:/Program Files (x86)/Steam/steamapps/common/VTOL VR"
MAP_NAME = "hMap2" # Example map ID

# --- 2. Load Map Data ---
try:
    tc = TerrainCalculator(map_name=MAP_NAME, vtol_directory=VTOL_VR_PATH)
    helper = MissionTerrainHelper(tc)
    print(f"Map '{MAP_NAME}' loaded successfully.")
except (FileNotFoundError, ValueError) as e:
    print(f"Error loading map: {e}")
    exit()

# --- 3. Use Helper to find a location ---
# Find a flat landing zone near the map center
map_center_x = tc.total_map_size_meters / 2
map_center_z = tc.total_map_size_meters / 2
landing_zones = helper.find_flat_landing_zones(map_center_x, map_center_z, search_radius=5000, min_area_radius=30)

if not landing_zones:
    print("Could not find a suitable landing zone.")
    target_pos = (map_center_x, tc.get_terrain_height(map_center_x, map_center_z), map_center_z)
else:
    target_pos = landing_zones[0] # Use the first LZ found
    print(f"Found landing zone at: {target_pos}")

# --- 4. Build the Mission ---
mission = Mission(
    scenario_name="Pytol Basic Test",
    scenario_id="pytol_test1",
    description="A simple mission generated by Pytol.",
    vehicle="AV-42C",
    map_id=MAP_NAME,
    vtol_directory=VTOL_VR_PATH
)

# Add a simple objective
mission.add_objective(
    objective_id="obj1",
    name="Go To LZ",
    info="Fly to the designated landing zone.",
    obj_type="WAYPOINT",
    fields={'waypointID': 'wpt_lz'}, # Link to a waypoint ID
    required=True
)

# Add the waypoint for the objective
mission.add_waypoint("wpt_lz", "LZ Alpha", target_pos)

# Add an enemy unit near the LZ (example)
enemy_pos = (target_pos[0] + 500, tc.get_terrain_height(target_pos[0] + 500, target_pos[2] + 500), target_pos[2] + 500)
enemy_rot = (0, 180, 0) # Facing towards LZ
mission.add_unit("AlliedInfantry", "Enemy Soldier", enemy_pos, enemy_rot, unit_fields={'team': 'ENEMY'}) #

# Add a briefing note
mission.add_briefing_note("Proceed to LZ Alpha. Expect light resistance.") #

# --- 5. Save the Mission ---
# Define where to save the mission folder (e.g., VTOL VR's CustomScenarios folder)
SAVE_PATH = os.path.join(VTOL_VR_PATH, "CustomScenarios")
try:
    mission_folder = mission.save_mission(SAVE_PATH) #
    print(f"Mission saved to: {mission_folder}")
except Exception as e:
    print(f"Error saving mission: {e}")

---

---

Examples

Small runnable examples are available in the examples/ directory. They demonstrate common workflows and quick visualizers.

• examples/example_pillow_visualizer.py — shows how to create a simple mission and generate a Pillow-based overview image using MapPillowVisualizer. The visualizer returns a PIL.Image.Image and can optionally save to disk by passing save=True.

Core Components Documentation

TerrainCalculator (pytol.terrain.terrain_calculator)

• Purpose: Loads and interprets VTOL VR map data (.vtm files and associated textures). It calculates terrain height, surface normals, and processes procedural elements like cities and roads, as well as static map objects.
• Initialization:

  tc = TerrainCalculator(
      map_name="hMap2",
      vtol_directory="C:/Path/To/VTOLVR",
      verbose=True  # Optional: Set to False to suppress progress messages (default: True)
  )
  # or
  tc = TerrainCalculator(map_directory_path="path/to/VTOLVR/CustomMaps/hMap2")


• Key Methods:
  • get_terrain_height(world_x, world_z): Returns the terrain altitude (Y-coordinate).
  • get_terrain_normal(world_x, world_z, delta=1.0): Calculates the surface normal vector.
  • get_asset_placement(world_x, world_z, yaw_degrees): Calculates terrain height and surface-aligned rotation.
  • is_on_road(world_x, world_z, tolerance=10.0): Checks if coordinates are near a road segment.
  • get_smart_placement(world_x, world_z, yaw_degrees): Snaps placement to terrain, roads, or building rooftops.
  • get_all_city_blocks(): Returns data on all procedural city blocks.
  • get_all_static_prefabs(): Returns data on all static prefabs.
  • get_city_density(world_x, world_z): Returns city density value.
  • get_city_layout_at(world_x, world_z): Determines city block layout, rotation, and surfaces at coordinates.

---

MissionTerrainHelper (pytol.terrain.mission_terrain_helper)

• Purpose: Builds upon TerrainCalculator to provide a high-level query engine specifically for mission generation tasks. It simplifies finding tactically relevant locations and paths.

• Initialization:

  helper = MissionTerrainHelper(
      tc,  # Requires an initialized TerrainCalculator
      verbose=None  # Optional: Controls messages. None inherits from TerrainCalculator (default)
  )


• Methods:

  • has_line_of_sight(pos1, pos2, steps=20, terrain_offset=0): Checks for terrain obstruction between two 3D points. Returns bool.
  • find_observation_post(target_area, min_dist, max_dist, num_candidates=20): Finds high ground with LoS to a target (e.g., for snipers). Returns tuple (x, y, z) or None.
  • find_artillery_position(target_area, search_radius, standoff_dist=1000): Finds a position hidden from a target's view (e.g., for artillery). Returns tuple (x, y, z) or None.
  • get_nearest_road_point(world_x, world_z): Finds the closest point on the road network. Returns dict {'position': (x,y,z), 'segment_index': int, 'distance': float} or None.
  • get_road_path(start_pos, end_pos, max_segments=100): Generates waypoints following roads between two (x, z) points (greedy search). Returns list of (x, y, z).
  • get_buildings_in_area(center_x, center_z, radius, spawnable_only=False): Finds city blocks and static prefabs within a radius. Returns list of dict.
  • find_city_with_statics(required_prefab_ids, search_all=True): Finds city areas containing specific static prefabs (e.g., airfields). Returns list of dict.
  • find_flat_landing_zones(center_x, center_z, search_radius, min_area_radius, max_slope_degrees=5.0): Locates flat areas suitable for landings. Returns list of (x, y, z).
  • find_highest_point_in_area(center_x, center_z, search_radius): Finds the highest terrain point in an area. Returns tuple (x, y, z) or None.
  • find_lowest_point_in_area(center_x, center_z, search_radius): Finds the lowest terrain point in an area. Returns tuple (x, y, z) or None.
  • find_hidden_position(observer_pos, target_area_center, search_radius): Finds a low-lying point hidden from an observer. Returns tuple (x, y, z) or None.
  • get_terrain_following_path(start_pos, end_pos, steps, altitude_agl=150.0): Generates waypoints at a constant altitude above ground between two (x, z) points. Returns list of (x, y, z).
  • get_circular_formation_points(center_pos, radius, num_points, start_angle_deg=0): Calculates positions for units in a circular formation. Returns list of (x, y, z).
  • get_terrain_type(position, sample_radius=100): Classifies terrain at an (x, z) position (e.g., "Urban", "Mountainous"). Returns str.
  • find_choke_point(road_path, check_width=100): Finds the most constricted point (valley) along a road path. Returns tuple (x, y, z) or None.
  • get_covert_insertion_path(start_pos, end_pos, radar_positions, steps=50): Generates a low-altitude path attempting to avoid radar LoS. Returns list of (x, y, z).
  • get_convoy_dispersal_points(road_position, num_points, radius): Finds nearby off-road hidden positions for a convoy to scatter to. Returns list of (x, y, z).
  • find_riverbed_path(start_pos, end_pos, steps=100): Generates a path following the lowest terrain (simulating valleys). Returns list of (x, y, z).
  • find_bridge_crossing_path(start_pos, end_pos): Generates a road path explicitly using the nearest suitable bridge. Returns list of (x, y, z) or None.
  • find_helicopter_battle_position(target_area, search_radius, min_dist=500, pop_up_alt=30): Finds a hide position for a pop-up helicopter attack. Returns tuple (x, y, z) or None.
  • generate_bombing_run_path(target_pos, entry_heading_deg, run_in_dist=5000, egress_dist=5000, altitude=1000): Creates IP-Target-Egress waypoints for a bombing run. Returns `dict {'ip':(x,y
  • trace_supply_route(start_base_name, end_base_name): Finds a road path between two named bases (static prefabs). Returns list of (x, y, z) or None.
  • analyze_route_vulnerability(road_path, check_width=100): Identifies vulnerable points (bridges, choke points) along a path. Returns dict {'bridges': list, 'choke_points': list}.
  • find_radar_dead_zone(radar_positions, search_area_center, search_radius, altitude): Finds areas hidden from all listed radars at a specific altitude. Returns list of (x, y, z).
  • get_line_formation_points(center_pos, num_units, spacing, angle_deg): Creates points for a straight-line formation on terrain. Returns list of (x, y, z).
  • get_wedge_formation_points(lead_pos, num_units, spacing, angle_deg): Creates points for a V-shaped formation on terrain. Returns list of (x, y, z).
  • get_building_garrison_points(building_info, max_units=10): (Conceptual) Finds spawnable rooftop positions on a building. Returns list of (x, y, z).
  • find_open_area(center_pos, search_radius, min_clear_radius): Finds a large, clear area free of buildings. Returns tuple (x, y, z) or None.
  • get_random_points_in_area(center_pos, radius, num_points): Scatters random points within a radius, snapped to the ground. Returns list of (x, y, z).
  • suggest_objective_locations(num_locations=5, min_city_size=10): Identifies potential points of interest on the map. Returns list of dict.
  • generate_downed_pilot_scenario(search_area_center, search_radius): Creates linked locations (crash site, LZ, patrol spawn) for a CSAR scenario. Returns dict or None.
  • generate_base_defense_positions(base_center, num_positions, min_dist=500, max_dist=2000): Places defensive units on high ground around a base. Returns list of (x, y, z).
  • generate_convoy_ambush_scenario(convoy_path): Finds an ambush spot and places attackers. Returns dict {'ambush_point': tuple, 'attacker_positions': list} or None.
  • generate_reconnaissance_flight_path(num_points=5, altitude_agl=500): Creates a flight path touring points of interest. Returns list of (x, y, z).
  • find_coastal_landing_area(search_area_center, search_radius, min_area_radius=50, sea_level=1.0): Finds a flat beach area for amphibious landings. Returns tuple (x, y, z) or None.
  • get_area_control_points(area_center, radius, num_points): Generates tactically interesting capture points, snapped to features. Returns list of (x, y, z).
  • create_mission_flow(start_location_name, objective_type, target_location_name): Generates waypoints (start, staging, target, egress) based on named locations. Returns dict or None.
  • get_procedural_location_name(position): Gives a descriptive name (e.g., "Northern Mountains", "vicinity of Airbase Alpha") to a location. Returns str.
  • get_map_briefing_data(): Generates a summary of key map features (cities, airbases, landmarks). Returns dict.
  • validate_mission_feasibility(unit_list, max_slope_deg=30): Checks a list of units for impossible placements (e.g., ground units on steep slopes). Returns list of error strings.
  • find_scenic_overlook(point_of_interest, min_dist=1000, max_dist=4000): Finds a point with a dramatic view of a target, favoring height. Returns tuple (x, y, z) or None.
  • get_area_defensibility_score(area_center, radius): Rates an area's defensibility (0-10) based on terrain, cover, and road access. Returns float.
  • calculate_threat_intervisibility(unit_positions): Creates a graph showing which units in a list can see each other. Returns dict {unit_index: [visible_unit_indices]}.

---

Mission (pytol.parsers.vts_builder)

• Purpose: Acts as a builder class to construct the structure and content of a VTOL VR mission file (.vts). You add units, objectives, triggers, waypoints, etc., to this object.

• Initialization:

  mission = Mission(
      scenario_name="Generated Mission",
      scenario_id="PytolGenerated1",
      description="A mission generated by Pytol.",
      vehicle="F/A-26B",
      map_id="hMap2",
      vtol_directory="C:/Path/To/VTOLVR",
      verbose=True  # Optional: Set to False to suppress progress messages (default: True)
  )


• Verbose Mode: The verbose parameter controls whether progress messages are printed during mission creation. When set to False, all print statements from Mission, TerrainCalculator, and MissionTerrainHelper are suppressed, which is useful for batch processing or when you want cleaner output. The verbose flag cascades to all sub-components automatically.

• Key Methods:

  • add_unit(...): Adds a unit spawner.
  • add_unit_at_base_spawn(...): Adds a unit at precise airbase spawn points (hangars, helipads).
  • add_path(...): Defines a path.
  • add_waypoint(...): Defines a waypoint.
  • add_unit_to_group(...): Assigns a unit to a team group.
  • add_objective(...): Adds a mission objective.
  • add_static_object(...): Adds a static map object.
  • add_trigger_event(...): Adds a trigger event (requires EventTarget and ParamInfo helpers).
  • add_base(...): Defines an airbase's team.
  • add_briefing_note(...): Adds text to the briefing.
  • save_mission(base_path): Saves the .vts file and copies the map folder.

---

Supporting Modules

• pytol.parsers.vtm_parser: Low-level function parse_vtol_data for reading .vtm files.
• pytol.parsers.vts_builder: Contains Mission class, EventTarget, ParamInfo helpers, and formatting utilities for .vts creation.
• pytol.resources: Manages loading of packaged data files (JSON databases, noise texture).

---

Dependencies

• NumPy: For numerical operations.
• SciPy: For spatial data structures (KDTree) and interpolation.
• Pillow: For loading texture images.

---

Visualization (Optional)

2D Static Maps (Lightweight)

If you installed pytol[viz-light], you can generate beautiful static mission maps perfect for briefings:

from pytol import Mission, Map2DVisualizer, save_mission_map

# Create mission
mission = Mission(
    scenario_name="Strike Mission",
    scenario_id="strike1",
    description="Test mission",
    map_id="archipielago_1",
    vtol_directory=r"C:\Path\To\VTOL VR"
)
# ... add units, waypoints, objectives ...

# Generate clean mission overview (recommended)
viz = Map2DVisualizer(mission, figsize=(12, 12), dpi=150)
viz.save_mission_overview("mission_clean.png", clean_mode=True)

# Generate with terrain heightmap
viz.save_mission_overview("mission_full.png", terrain_style='contour')

# Generate terrain heatmap
viz.save_terrain_overview("terrain.png", style='heatmap')

# Generate spawn points detail
viz.save_spawn_points_detail("spawn_points.png", base_index=0)

# Quick convenience function
save_mission_map(mission, "overview.png", clean_mode=True)

2D visualization features:

• Clean mode: Professional mission maps without terrain clutter (perfect for briefings)
• Terrain layers: Contour maps or elevation heatmaps
• Infrastructure: Roads, cities, and airbases clearly marked
• Mission elements: Units with team colors, waypoints, objectives, and spawn points
• Multiple formats: PNG, PDF, SVG output with customizable DPI and sizing
• Small file sizes: Clean mode generates compact images (typically 50-100KB)

3D Interactive Exploration

If you installed pytol[viz], you can visualize terrains and missions in 3D:

from pytol import Mission, MissionVisualizer, TerrainVisualizer
from pytol.terrain import TerrainCalculator

# Visualize terrain only
tc = TerrainCalculator("hMap2", verbose=False)  # Optional: suppress progress messages
terrain_viz = TerrainVisualizer(
    tc,
    mesh_resolution=256,  # Terrain mesh detail (default: 256)
    verbose=True  # Optional: Set to False to suppress rendering progress (default: True)
)
terrain_viz.show()

# Or visualize a complete mission
mission = Mission(
    scenario_name="Test Mission",
    scenario_id="test",
    description="Test",
    map_id="hMap2",
    verbose=False  # Suppress mission creation messages
)
# ... add units, objectives, etc ...

mission_viz = MissionVisualizer(mission, verbose=True)  # Show visualization progress
mission_viz.show()

The visualization shows:

• Terrain elevation with color mapping
• City blocks and buildings (green = spawnable, red = obstacles)
• Road network and bridges
• Mission units with team colors
• Waypoints and paths

See examples/example_visualization.py for a complete demo.

---

Developer Resources

Consolidated Frameworks

Pytol includes several consolidated frameworks that eliminate code duplication and provide consistent, well-tested APIs:

• Math Utilities (pytol.misc.math_utils): Distance calculations, angle generation, position manipulation, bounds checking, and more. Eliminates 200+ lines of duplicate math code.

• Position Scoring (pytol.procedural.position_scoring): Specialized scoring systems for evaluating tactical positions (airbase placement, defensive positions, logistics hubs, tactical objectives). Consolidates 400-500 lines of scoring logic.

• Validation Framework (pytol.misc.validation_framework): Comprehensive validation for positions, numeric values, lists, and dictionaries. Provides 300+ lines of reusable validation logic.

• Enhanced Terrain Helper: Safe terrain query functions with error handling and batch processing capabilities.

Benefits: These frameworks reduce maintenance burden by ~75%, improve code consistency, and make the codebase easier to understand and extend.

📖 Consolidated Frameworks Guide - Quick reference with examples
📊 Consolidation Summary - Complete details of the consolidation effort

Code Quality Tools

The tools/ directory contains utilities to help maintain code quality:

• Code Quality Analyzer (tools/code_quality_analyzer.py): Scans for patterns that should use consolidated frameworks, identifies code smells, and provides migration suggestions.

# Analyze code quality
python tools/code_quality_analyzer.py pytol

# Detailed report with line numbers
python tools/code_quality_analyzer.py pytol --verbose

🔧 Tools Documentation - Complete guide to development tools

---

Contributing

Contributions are welcome! Feel free to open issues or submit pull requests.

If you'd like to support the project financially, you can help cover development costs or contribute towards upgrading development hardware (like my Quest 2) by buying me a coffee:

---

Known Issues

• Need to pay attention to the terrain around cities as some city blocks deform terrain.
• Height sampling may have small discrepancies (~1-3m) compared to Unity's terrain mesh on steep slopes.

Not issues but pending

• Support weather presets.
• Support OBJECTIVES_OPFOR.
• Support to add imgs and that kind of stuff to the briefing.
• Support to replay reading. (will be useful to make stateful campaigns or a campaign engine)

---

License

This project is licensed under the GNU General Public License v3.0 only. See the LICENSE file for details.
