pytorch-segmentation-models-trainer 1.1.0

Image segmentation models training of popular architectures.

pytorch_segmentation_models_trainer

A comprehensive PyTorch + PyTorch Lightning framework for training semantic segmentation models on satellite and aerial imagery, with Hydra configuration management and extensive support for multispectral data.

Config Builder (Web Interface)

Open Config Builder

A visual web interface hosted on GitHub Pages for building YAML configuration files without editing text by hand. Supports the Training and Predict workflows.

What it does

• Training tab: configure model architecture and encoder, normalization parameters, class definitions, hyperparameters, loss function, optimizer, PyTorch Lightning trainer, metrics, callbacks, and train/val datasets (including data augmentation pipeline).
• Predict tab: configure checkpoint path, device, hyperparameters, PL trainer, model, inference processor (sliding window shape, optional normalization), image reader (folder, extension, recursive), and export strategy.
• Live YAML preview: the generated YAML is shown side-by-side and updates in real time as you fill the form.
• Import from YAML: paste an existing config file to populate the form fields automatically.
• Searchable dropdowns: all selectors (architecture, encoder, loss, optimizer, metrics, augmentations, etc.) are filterable comboboxes.

How the schema stays up to date

A Python script (scripts/generate_schema.py) introspects the installed versions of segmentation_models_pytorch, albumentations, torchmetrics, and torch at build time, writing web/src/assets/schema.json. The GitHub Actions workflow (.github/workflows/deploy-config-builder.yml) runs on every push to main (when web/** or the schema script changes), on manual dispatch, and on a weekly schedule to pick up library updates automatically.

---

Features

• Multiple Architectures: UNet, UNet++, DeepLabV3+, FPN, PSPNet, PAN, LinkNet, MANet via segmentation_models_pytorch; HRNet+OCR, UPerNet variants, custom UNet implementations
• Foundation Model Integration: HuggingFace Transformers (SegFormer, Mask2Former), TerraTorch multispectral models, TIMM encoders
• Multispectral Support: Native handling of 3, 4, 6, and 12-band satellite imagery with automatic weight adaptation
• Transfer Learning: Automatic weight adaptation from ImageNet pretrained models for multispectral data (mean, random, copy_first strategies)
• Flexible Loss Functions: Compound loss system with dynamic weight scheduling, supporting BCE, Dice, Focal, Label Smoothing, Knowledge Distillation, and custom losses
• Evidential Deep Learning: Built-in uncertainty quantification via Dirichlet-based evidential models (EvidentialWrapper, EDL losses, uncertainty map export)
• Domain Adaptation: Plugin-based domain adaptation infrastructure with feature hooks and multiple DA schedulers
• Fine-tuning Strategies: Full training, freeze backbone, linear probe, and LoRA (Low-Rank Adaptation) via PEFT
• Geometry-Aware Training: Frame field (crossfield) model for boundary and polygon prediction with alignment/smoothness losses
• Polygon Extraction: RNN-based polygon boundary tracing, template-based polygonization, frame field polygon generation
• Mixture of Experts: MoE layers and UPerNet+MoE variants for dynamic expert routing in the decoder
• Advanced Inference: Sliding window inference with configurable overlap and Test-Time Augmentation (TTA)
• Comprehensive Evaluation: Multi-experiment evaluation pipeline with spatial alignment and parallel processing
• Hydra Configuration: Full configuration composition and management with typed YAML dataclasses
• Geospatial Tools: Built-in support for GeoTIFF, coordinate systems, and PostGIS integration
• GPU Augmentations: Kornia-based on-GPU transforms for faster training pipelines

Installation

Using uv (Recommended)

# Clone the repository
git clone https://github.com/dsgoficial/pytorch_segmentation_models_trainer.git
cd pytorch_segmentation_models_trainer

# Install dependencies and create a virtual environment
uv sync

Using pip

pip install pytorch-segmentation-models-trainer

From Source (pip)

# Clone the repository
git clone https://github.com/dsgoficial/pytorch_segmentation_models_trainer.git
cd pytorch_segmentation_models_trainer

# Install in editable mode
pip install -e .

Using Docker

docker pull phborba/pytorch_segmentation_models_trainer:latest

Dependencies

Core dependencies include:

• Python >= 3.12
• PyTorch >= 2.0
• PyTorch Lightning >= 2.4
• Hydra >= 1.3
• segmentation_models_pytorch
• rasterio (for geospatial data)
• albumentations (for augmentations)
• torchmetrics

Quick Start

The framework provides a CLI tool (pytorch-smt) and supports multiple modes:

# Training
pytorch-smt --config-dir /path/to/configs --config-name train +mode=train

# Inference
pytorch-smt --config-dir /path/to/configs --config-name predict +mode=predict

# Evaluation
python -m pytorch_segmentation_models_trainer.evaluate_experiments \
    --config-dir configs/evaluation --config-name pipeline_config

Configuration Examples

1. Basic Training Configuration

# configs/train_unet_resnet34.yaml

# Model Architecture
pl_model:
  _target_: pytorch_segmentation_models_trainer.model_loader.model.Model

backbone:
  name: resnet34
  input_width: 512
  input_height: 512

model:
  _target_: segmentation_models_pytorch.Unet
  encoder_name: resnet34
  encoder_weights: imagenet
  in_channels: 3
  classes: 6

# Hyperparameters
hyperparameters:
  model_name: unet_resnet34
  batch_size: 16
  epochs: 100
  max_lr: 0.001
  classes: 6

# Optimizer
optimizer:
  - _target_: torch.optim.AdamW
    lr: ${hyperparameters.max_lr}
    weight_decay: 0.0001

# Learning Rate Scheduler
scheduler_list:
  - scheduler:
      _target_: torch.optim.lr_scheduler.OneCycleLR
      max_lr: ${hyperparameters.max_lr}
      epochs: ${hyperparameters.epochs}
      steps_per_epoch: 1000  # Auto-computed from dataset
    interval: step
    frequency: 1

# Loss Function
loss_params:
  compound_loss:
    losses:
      - _target_: pytorch_segmentation_models_trainer.custom_losses.seg_loss.SegLoss
        bce_coef: 0.8
        dice_coef: 0.2
        weight: 1.0

# Dataset
train_dataset:
  _target_: pytorch_segmentation_models_trainer.dataset_loader.dataset.SegmentationDataset
  input_csv_path: /data/train.csv
  root_dir: /data
  augmentation_list:
    - _target_: albumentations.HorizontalFlip
      p: 0.5
    - _target_: albumentations.VerticalFlip
      p: 0.5
    - _target_: albumentations.RandomRotate90
      p: 0.5
  data_loader:
    shuffle: true
    num_workers: 8
    batch_size: ${hyperparameters.batch_size}
    pin_memory: true

val_dataset:
  _target_: pytorch_segmentation_models_trainer.dataset_loader.dataset.SegmentationDataset
  input_csv_path: /data/val.csv
  root_dir: /data
  data_loader:
    shuffle: false
    num_workers: 8
    batch_size: ${hyperparameters.batch_size}

# test_dataset is optional. When present, trainer.test() is called after fit,
# logging all metrics with the "test/" prefix.
test_dataset:
  _target_: pytorch_segmentation_models_trainer.dataset_loader.dataset.SegmentationDataset
  input_csv_path: /data/test.csv
  root_dir: /data
  data_loader:
    shuffle: false
    num_workers: 8
    batch_size: ${hyperparameters.batch_size}

# Trainer Configuration
pl_trainer:
  max_epochs: ${hyperparameters.epochs}
  accelerator: gpu
  devices: -1  # Use all available GPUs
  precision: "16-mixed"  # Mixed precision training
  default_root_dir: /experiments/${backbone.name}_${hyperparameters.model_name}

# Metrics
metrics:
  - _target_: torchmetrics.JaccardIndex
    task: multiclass
    num_classes: ${hyperparameters.classes}
  - _target_: torchmetrics.F1Score
    task: multiclass
    num_classes: ${hyperparameters.classes}
    average: macro

# Callbacks
callbacks:
  - _target_: pytorch_lightning.callbacks.ModelCheckpoint
    monitor: val/JaccardIndex
    mode: max
    save_top_k: 3
    filename: "{epoch:02d}-{val/JaccardIndex:.4f}"
  - _target_: pytorch_lightning.callbacks.EarlyStopping
    monitor: val/JaccardIndex
    patience: 20
    mode: max
  - _target_: pytorch_lightning.callbacks.LearningRateMonitor
    logging_interval: step

2. Multispectral Training (12-band Imagery)

# configs/train_multispectral_12band.yaml

backbone:
  name: resnet101
  input_width: 512
  input_height: 512

model:
  _target_: segmentation_models_pytorch.DeepLabV3Plus
  encoder_name: resnet101
  encoder_weights: imagenet
  in_channels: 12  # 12-band multispectral
  classes: 7

# Weight adaptation strategy for multispectral
# The framework automatically adapts ImageNet weights
# Options: "mean", "random", "copy_first"
weight_adaptation_strategy: mean  # Recommended for multispectral

hyperparameters:
  model_name: deeplabv3plus_resnet101_12band
  batch_size: 8  # Smaller batch for 12 bands
  epochs: 150
  max_lr: 0.0005
  classes: 7

# Multispectral augmentations
train_dataset:
  input_csv_path: /data/multispectral_train.csv
  root_dir: /data
  augmentation_list:
    - _target_: albumentations.HorizontalFlip
      p: 0.5
    - _target_: albumentations.VerticalFlip
      p: 0.5
    - _target_: albumentations.RandomRotate90
      p: 0.5
    - _target_: albumentations.RandomBrightnessContrast
      brightness_limit: 0.2
      contrast_limit: 0.2
      p: 0.5

3. Compound Loss Configuration

# configs/loss/compound_loss_example.yaml

loss_params:
  compound_loss:
    losses:
      # Segmentation Loss
      - _target_: pytorch_segmentation_models_trainer.custom_losses.seg_loss.SegLoss
        bce_coef: 0.7
        dice_coef: 0.3
        weight: 10.0
        name: seg_loss

      # Boundary Loss (optional)
      - _target_: pytorch_segmentation_models_trainer.custom_losses.boundary_loss.BoundaryLoss
        weight: 1.0
        name: boundary_loss

    # Dynamic weight scheduling
    weight_schedules:
      seg_loss:
        type: constant
        value: 10.0
      boundary_loss:
        type: epoch_threshold
        epoch_thresholds: [0, 20, 50]
        values: [0.0, 1.0, 2.0]

    # Normalization
    normalize_losses: true
    normalization_params:
      min_samples: 10
      max_samples: 1000

4. Inference Configuration

# configs/predict_sliding_window.yaml

# Checkpoint
checkpoint_path: /experiments/best_model.ckpt
device: cuda:0

# Model config (inherited from training)
pl_model:
  _target_: pytorch_segmentation_models_trainer.model_loader.model.Model

hyperparameters:
  batch_size: 16
  classes: 6

# Image reader
inference_image_reader:
  _target_: pytorch_segmentation_models_trainer.tools.inference.inference_image_reader.InferenceImageReader
  input_folder: /data/test_images
  image_pattern: "*.tif"
  output_folder: /data/predictions

# Inference processor
inference_processor:
  _target_: pytorch_segmentation_models_trainer.tools.inference.inference_processors.MultiClassInferenceProcessor
  num_classes: 6

  # Sliding window parameters
  model_input_shape: [512, 512]
  step_shape: [384, 384]  # 25% overlap (512 - 384 = 128)

  # Export strategy
  export_strategy:
    _target_: pytorch_segmentation_models_trainer.tools.inference.export_strategies.ExportToGeoTiff
    compress: lzw
    tiled: true

  # Normalization (must match training)
  normalize_mean: [0.485, 0.456, 0.406]
  normalize_std: [0.229, 0.224, 0.225]

# Inference parameters
inference_threshold: 0.5
save_inference: true

5. Evaluation Pipeline Configuration

# configs/evaluation/pipeline_config.yaml

# Experiments to evaluate
experiments:
  - name: unet_resnet34_3band
    predict_config: configs/predict_unet_r34.yaml
    checkpoint_path: /experiments/unet_r34/best.ckpt
    output_folder: /evaluations/unet_r34_predictions

  - name: deeplabv3_resnet101_12band
    predict_config: configs/predict_deeplabv3_r101.yaml
    checkpoint_path: /experiments/deeplabv3_r101/best.ckpt
    output_folder: /evaluations/deeplabv3_predictions

# Evaluation dataset
evaluation_dataset:
  # Option 1: Use existing CSV
  input_csv_path: /data/test.csv

  # Option 2: Build CSV from folders
  build_csv_from_folders:
    enabled: true
    images_folder: /data/test/images
    masks_folder: /data/test/masks
    image_pattern: "*.tif"
    mask_pattern: "*.tif"
    output_csv_path: /data/test_dataset.csv

# Metrics to compute
metrics:
  num_classes: 6
  segmentation_metrics:
    - _target_: torchmetrics.JaccardIndex
      task: multiclass
      num_classes: 6
      average: macro
    - _target_: torchmetrics.F1Score
      task: multiclass
      num_classes: 6
      average: macro
    - _target_: torchmetrics.Accuracy
      task: multiclass
      num_classes: 6
      average: macro

# Output configuration
output:
  base_dir: /evaluations/results
  structure:
    experiments_folder: experiments
    comparisons_folder: comparisons
  files:
    per_image_metrics_pattern: "{experiment_name}_per_image_metrics.csv"
    confusion_matrix_data_pattern: "{experiment_name}_confusion_matrix.npy"

# Visualization
visualization:
  enabled: true
  plot_confusion_matrices: true
  plot_comparison_charts: true
  max_samples_to_visualize: 10

# Pipeline options
pipeline_options:
  skip_existing_predictions: false
  skip_existing_metrics: false

  # Parallel inference
  parallel_inference:
    enabled: true
    max_workers: 4
    sequential_experiments: true  # Process experiments sequentially, parallelize within

6. CSV Dataset Format

The framework expects CSV files with the following format:

image,mask
/data/images/tile_001.tif,/data/masks/tile_001.tif
/data/images/tile_002.tif,/data/masks/tile_002.tif

You can also build CSVs automatically:

from pytorch_segmentation_models_trainer.tools.inference.inference_csv_builder import build_csv_from_folders

csv_path = build_csv_from_folders(
    images_folder="/data/images",
    masks_folder="/data/masks",
    image_pattern="*.tif",
    mask_pattern="*.tif",
    output_csv_path="/data/dataset.csv"
)

Supported Architectures

Encoders

• ResNet (34, 50, 101, 152)
• ResNeXt
• EfficientNet (B0-B7)
• DenseNet (121, 161, 169, 201)
• MobileNet
• VGG (11, 13, 16, 19)
• And more via segmentation_models_pytorch

Decoders

• UNet: Classic U-Net architecture
• UNet++: Nested U-Net with dense skip connections
• DeepLabV3+: Atrous Spatial Pyramid Pooling
• FPN: Feature Pyramid Network
• PSPNet: Pyramid Scene Parsing Network
• PAN: Path Aggregation Network
• LinkNet: Efficient architecture for real-time segmentation
• MANet: Multi-scale Attention Network

Custom / Extended Architectures

• HRNet + OCR: High-Resolution Network with Object-Contextual Representations head
• UPerNet: Unified Perceptual Parsing Network with standard, MoE, MedoE, and Dual-Head variants
• SegFormer / Mask2Former: via HuggingFace Transformers
• TerraTorch models: multispectral satellite foundation models
• TIMM encoders: any encoder available in the timm library
• EvidentialWrapper: wraps any segmentation model to produce Dirichlet evidence and uncertainty maps
• PolygonRNN: RNN-based boundary tracing for polygon generation
• ModPolyMapper: polygon-to-map generation pipeline

Fine-tuning Strategies

The framework supports multiple fine-tuning strategies selectable via configuration:

Strategy	Description
full	All parameters are trainable (default)
freeze_backbone	Only the decoder and head are trained
linear_probe	Only the final classification layer is trained
lora	Low-Rank Adaptation (LoRA) via PEFT — efficient parameter fine-tuning

fine_tuning:
  strategy: lora          # full | freeze_backbone | linear_probe | lora
  lora_rank: 16
  lora_alpha: 32
  lora_target_modules: ["query", "value"]

Evidential Deep Learning

The framework includes a full evidential deep learning pipeline for uncertainty quantification based on Dirichlet distributions.

Components

• EvidentialWrapper: wraps any segmentation model — converts logits to evidence, alpha, and uncertainty outputs
• EDL Losses: EvidentialMSELoss (MSE integrated over Dirichlet) and EvidentialKLLoss (KL divergence regularizer)
• EDL Callbacks: monitor uncertainty metrics during training
• EDL Inference Processor: generates uncertainty maps alongside predictions

pl_model:
  _target_: pytorch_segmentation_models_trainer.model_loader.model.Model

model:
  _target_: pytorch_segmentation_models_trainer.custom_models.edl_wrapper.EvidentialWrapper
  base_model:
    _target_: segmentation_models_pytorch.Unet
    encoder_name: resnet34
    encoder_weights: imagenet
    in_channels: 3
    classes: 6

loss_params:
  compound_loss:
    losses:
      - _target_: pytorch_segmentation_models_trainer.custom_losses.edl_loss.EvidentialMSELoss
        weight: 1.0
      - _target_: pytorch_segmentation_models_trainer.custom_losses.edl_loss.EvidentialKLLoss
        weight: 0.1
        annealing_step: 10

Domain Adaptation

A plugin-based domain adaptation infrastructure allows adding DA methods without modifying the model code.

• Feature Hooks: FeatureExtractorHook captures intermediate feature maps from any layer
• DA Schedulers: Constant, Linear, and DANN (adversarial) weight schedulers
• Plugin Architecture: DA methods are decoupled from the main model and injected at training time
• Dual DataLoader Support: handles source and target domain datasets simultaneously

pl_model:
  _target_: pytorch_segmentation_models_trainer.model_loader.domain_adaptation_model.DomainAdaptationModel

domain_adaptation:
  method:
    _target_: pytorch_segmentation_models_trainer.domain_adaptation.methods.MyDAMethod
  scheduler:
    _target_: pytorch_segmentation_models_trainer.domain_adaptation.schedulers.DANNScheduler
    max_epochs: ${hyperparameters.epochs}

Frame Field (Geometry-Aware Boundaries)

The FrameFieldModel produces both a segmentation mask and a crossfield (frame field) output, enabling geometry-aware training and high-quality polygon extraction.

Losses

• CrossfieldAlignLoss — aligns the field with predicted boundaries
• CrossfieldAlign90Loss — enforces 90-degree corner alignment
• CrossfieldSmoothLoss — penalizes field discontinuities
• SegEdgeInteriorLoss — combined segmentation edge and interior loss

Polygon Extraction

Predictions can be post-processed into vector polygons via:

• Template-based polygonization
• Frame field–guided polygon tracing
• Skeletonization for centerline extraction

Dataset Preparation

Creating Masks from Vector Data

# Using the mask builder tool
python -m pytorch_segmentation_models_trainer.tools.mask_building.mask_builder \
    --config-dir configs/mask_building \
    --config-name build_masks

Example mask building configuration:

# configs/mask_building/build_masks.yaml
geo_df:
  _target_: pytorch_segmentation_models_trainer.tools.data_handlers.vector_reader.FileGeoDF
  file_name: /data/vectors/buildings.geojson

root_dir: /data
image_root_dir: images
image_extension: tif

# Mask types to build
build_polygon_mask: true
polygon_mask_folder_name: polygon_masks

build_boundary_mask: true
boundary_mask_folder_name: boundary_masks

build_distance_mask: false
build_size_mask: false

# Options
replicate_image_folder_structure: true
min_polygon_area: 50.0
mask_output_extension: tif

Training

Single GPU Training

pytorch-smt --config-dir configs --config-name train_unet +mode=train

Multi-GPU Training (Distributed Data Parallel)

# Automatic - uses all available GPUs
pytorch-smt --config-dir configs --config-name train_unet +mode=train \
    pl_trainer.devices=-1

# Specific GPUs
pytorch-smt --config-dir configs --config-name train_unet +mode=train \
    pl_trainer.devices=[0,1,2,3]

Mixed Precision Training

pytorch-smt --config-dir configs --config-name train_unet +mode=train \
    pl_trainer.precision="16-mixed"

Resume from Checkpoint

pytorch-smt --config-dir configs --config-name train_unet +mode=train \
    hyperparameters.resume_from_checkpoint=/path/to/checkpoint.ckpt

Override Configuration Parameters

# Override multiple parameters
pytorch-smt --config-dir configs --config-name train_unet +mode=train \
    hyperparameters.batch_size=32 \
    hyperparameters.max_lr=0.001 \
    hyperparameters.epochs=200

Inference

Single Image Inference

pytorch-smt --config-dir configs --config-name predict +mode=predict

Batch Inference with Sliding Window

For large images that don't fit in memory, use sliding window inference:

inference_processor:
  model_input_shape: [512, 512]  # Model's expected input size
  step_shape: [384, 384]  # Overlap: 512 - 384 = 128 pixels (25%)

Performance considerations:

• 0% overlap (step_shape = model_input_shape): Fastest, may have artifacts at tile boundaries
• 25% overlap (step_shape = [384, 384] for 512×512): Good balance
• 50% overlap (step_shape = [256, 256] for 512×512): Higher quality, ~4× slower

Test-Time Augmentation (TTA)

TTA can be enabled in both the training test_step and the inference processor:

inference_processor:
  tta_mode: true  # Enables rotation + flip TTA with averaged outputs

Supported TTA transforms: horizontal flip, vertical flip, 90°/180°/270° rotations, and combinations.

Inference with Normalization

Ensure normalization matches your training configuration:

inference_processor:
  normalize_mean: [0.485, 0.456, 0.406]  # ImageNet stats
  normalize_std: [0.229, 0.224, 0.225]

For custom normalization, compute from your training data:

import numpy as np
from tqdm import tqdm
import rasterio

def compute_normalization_stats(image_paths, bands=[0, 1, 2]):
    """Compute mean and std for dataset normalization."""
    means = []
    stds = []

    for img_path in tqdm(image_paths):
        with rasterio.open(img_path) as src:
            img = src.read(bands)
            means.append(img.mean(axis=(1, 2)))
            stds.append(img.std(axis=(1, 2)))

    mean = np.array(means).mean(axis=0)
    std = np.array(stds).mean(axis=0)

    return mean.tolist(), std.tolist()

Evaluation

Comprehensive Evaluation Pipeline

The evaluation pipeline supports:

• Multiple experiments comparison
• Automatic CSV generation from image folders
• Spatial alignment of predictions and ground truth
• Parallel processing with configurable workers
• Per-image and aggregated metrics
• Confusion matrix computation
• Visualization generation

python -m pytorch_segmentation_models_trainer.evaluate_experiments \
    --config-dir configs/evaluation \
    --config-name pipeline_config

Metrics

Supported metrics via torchmetrics:

• Intersection over Union (IoU / Jaccard Index)
• F1 Score
• Accuracy
• Precision & Recall
• Confusion Matrix
• Per-class metrics

Direct Folder Evaluation

For quick evaluation when you already have predictions:

from pytorch_segmentation_models_trainer.tools.evaluation.direct_folder_evaluator import DirectFolderEvaluator

evaluator = DirectFolderEvaluator(
    pred_folder="/path/to/predictions",
    gt_folder="/path/to/ground_truth",
    num_classes=6
)

# Create evaluation CSV
df = evaluator.create_evaluation_csv("/output/eval.csv")

# Compute metrics
results = evaluator.evaluate(df)

Advanced Features

Custom Loss Functions

Create custom loss functions by extending BaseLoss:

from pytorch_segmentation_models_trainer.custom_losses.base_loss import BaseLoss
import torch
import torch.nn as nn

class CustomLoss(BaseLoss):
    def __init__(self, weight=1.0, **kwargs):
        super().__init__(weight=weight, **kwargs)
        self.criterion = nn.CrossEntropyLoss()

    def forward(self, pred, batch):
        return self.criterion(pred['seg'], batch['mask'])

GPU Augmentations

Apply augmentations on GPU for faster training:

train_dataset:
  gpu_augmentation_list:
    - _target_: kornia.augmentation.RandomHorizontalFlip
      p: 0.5
    - _target_: kornia.augmentation.RandomVerticalFlip
      p: 0.5
    - _target_: kornia.augmentation.ColorJitter
      brightness: 0.2
      contrast: 0.2
      p: 0.5

Custom Callbacks

from pytorch_lightning.callbacks import Callback

class CustomCallback(Callback):
    def on_epoch_end(self, trainer, pl_module):
        # Your custom logic here
        pass

Add to config:

callbacks:
  - _target_: your_module.CustomCallback
    param1: value1

Visualization Callbacks

Built-in visualization during training:

callbacks:
  - _target_: pytorch_segmentation_models_trainer.custom_callbacks.image_callbacks.SegmentationVisualizationCallback
    n_samples: 4
    output_path: /experiments/visualizations
    normalized_input: true
    norm_params:
      mean: [0.485, 0.456, 0.406]
      std: [0.229, 0.224, 0.225]
    log_every_k_epochs: 5
    colormap: tab10
    num_classes: 6
    class_names: ["Background", "Building", "Road", "Tree", "Water", "Car"]

EMA (Exponential Moving Average)

Stabilize training with weight averaging:

callbacks:
  - _target_: pytorch_segmentation_models_trainer.custom_callbacks.training_callbacks.EMACallback
    decay: 0.999

PolyOptimizer with Gradient Centralization

Custom optimizer with polynomial learning rate decay and gradient centralization for improved convergence:

optimizer:
  - _target_: pytorch_segmentation_models_trainer.optimizers.poly_optimizers.PolyOptimizer
    lr: ${hyperparameters.max_lr}
    weight_decay: 0.0001
    max_step: 50000
    momentum: 0.9

Project Structure

pytorch_segmentation_models_trainer/
├── pytorch_segmentation_models_trainer/
│   ├── model_loader/          # Model and Lightning module wrappers
│   │   ├── model.py           # Core Model (segmentation, TTA, metrics)
│   │   ├── frame_field_model.py    # Geometry-aware boundary model
│   │   ├── domain_adaptation_model.py
│   │   └── detection_model.py
│   ├── dataset_loader/        # Dataset classes (CSV-based, raster patches)
│   ├── custom_losses/         # Loss functions
│   │   ├── base_loss.py       # BaseLoss, MultiLoss (compound), SegLoss
│   │   ├── edl_loss.py        # Evidential DL losses
│   │   ├── loss.py            # KD, MixUp, LabelSmoothing, Dual-Head losses
│   │   └── crossfield_losses.py
│   ├── custom_callbacks/      # Training callbacks (visualization, EMA, etc.)
│   ├── custom_models/         # Model architectures
│   │   ├── edl_wrapper.py     # EvidentialWrapper
│   │   ├── huggingface_models.py  # SegFormer, Mask2Former
│   │   ├── terratorch_models.py   # Multispectral foundation models
│   │   ├── timm_models.py     # TIMM encoder wrappers
│   │   ├── hrnet_models/      # HRNet + OCR
│   │   ├── upernet_moe.py     # UPerNet + Mixture of Experts
│   │   └── upernet_dual_head.py
│   ├── custom_metrics/        # Custom metric implementations
│   ├── domain_adaptation/     # Domain adaptation methods and schedulers
│   ├── fine_tuning/           # LoRA and parameter freezing strategies
│   ├── optimizers/            # PolyOptimizer, gradient centralization
│   ├── tools/
│   │   ├── inference/         # Sliding window processors, TTA, export
│   │   ├── evaluation/        # Multi-experiment evaluation pipeline
│   │   ├── mask_building/     # Mask generation from vector data
│   │   ├── polygonization/    # Frame field and RNN polygon extraction
│   │   ├── tta/               # Test-time augmentation
│   │   ├── visualization/     # Plot utilities
│   │   └── data_handlers/     # Raster and vector I/O
│   ├── utils/                 # Utility functions (math, model, OS)
│   ├── config_definitions/    # Typed Hydra dataclass configs
│   ├── train.py               # Training entry point
│   ├── predict.py             # Inference entry point
│   ├── main.py                # CLI entry point
│   └── evaluate_experiments.py  # Evaluation pipeline
├── configs/                   # Configuration files
│   ├── train/
│   ├── predict/
│   └── evaluation/
├── conf/                      # Hydra default configs
├── tests/                     # Unit tests
├── web/                       # Config Builder web interface (React)
│   └── src/assets/schema.json # Auto-generated from installed libraries
├── scripts/
│   └── generate_schema.py     # Schema generation for Config Builder
└── setup.py

Troubleshooting

CUDA Out of Memory

• Reduce batch_size
• Enable gradient_checkpointing in model config
• Use mixed precision: pl_trainer.precision="16-mixed"
• Reduce num_workers in dataloader

Slow Training

• Increase num_workers in dataloader
• Enable mixed precision
• Use GPU augmentations instead of CPU
• Check I/O bottlenecks with profiling

Poor Convergence

• Adjust learning rate
• Increase model capacity
• Add more augmentations
• Check data quality and class balance

Inference Memory Issues

• Reduce batch_size in inference config
• Use smaller sliding window model_input_shape
• Process images one at a time

Citation

If you use this framework in your research, please cite:

@software{philipe_borba_2025_17581320,
  author       = {Philipe Borba},
  title        = {dsgoficial/pytorch\_segmentation\_models\_trainer:
                   Version 1.0.0
                  },
  month        = nov,
  year         = 2025,
  publisher    = {Zenodo},
  version      = {v.1.0.0},
  doi          = {10.5281/zenodo.17581320},
  url          = {https://doi.org/10.5281/zenodo.17581320},
  swhid        = {swh:1:dir:6279d2f90c1b1bde6f7704758ecdfce0a5d3eb14
                   ;origin=https://doi.org/10.5281/zenodo.4573996;vis
                   it=swh:1:snp:68534bb09abd3eadef762f11e7f24038025b4
                   df5;anchor=swh:1:rel:7a642f966fff89a28215316b2f5e2
                   716e4ec5bd4;path=dsgoficial-
                   pytorch\_segmentation\_models\_trainer-e94787b
                  },
}

Contributing

Contributions are welcome! Please:

1. Fork the repository
2. Create a feature branch
3. Add tests for new functionality
4. Submit a pull request

License

This project is licensed under the GNU General Public License v2.0 or later.
