pyvark

pyvark is the Python client for Anthive, a browser and REST API for curated single-cell, bulk and spatial transcriptomics datasets (mostly human microglia), the papers behind them and the analysis files made from them. With pyvark you list datasets, read expression and cell metadata, render the server's plots, run donor-level facet tests, search the paper library and download versioned analysis artefacts, from a script, a notebook or JupyterLite. It is the Python sibling of the Go vark command line client; both talk to the same API.

The package is called pyvark on PyPI and is imported as vark.

Supported servers

pyvark	anthive REST API
0.12.x	2.46 and newer; the artefact store and collection listing need 2.47.0+, search and stats 2.48.0+

AnthiveClient.API_TARGET names the API version a release was checked against (0.12.1: 2.47.0, 0.12.2: 2.48.0). On an older server the methods it does not have raise a clear error: artefact and collection calls on a 2.46 server raise ServerTooOldError ("needs anthive REST API 2.47.0+") instead of a bare 404, and search and stats on a server before 2.48 raise it with "needs anthive REST API 2.48.0+". get_version()["compatible_pyvark"] tells you the oldest pyvark a server works with.

Install

pip install pyvark                # or: uv add pyvark
pip install "pyvark[pandas]"      # format="dataframe" results
pip install "pyvark[vark-config]" # reuse the Go vark CLI's stored logins

Python 3.9 to 3.13. The only required dependency is requests.

In JupyterLite (Pyodide):

import micropip
await micropip.install("pyvark")
from vark import AnthiveClient
client = AnthiveClient()   # uses {origin}/api/ of the page

Quick start

import getpass
from vark import AnthiveClient

client = AnthiveClient("https://my.anthive.example/api", auth=("me", getpass.getpass()))
print(client.get_version()["version"])                         # e.g. 2.47.0
datasets = client.get_databases(format="dataframe")             # one row per dataset
db_id = datasets["id"].iloc[0]                                  # e.g. "AL1/CBL"
stats = client.get_gene_stats(db_id, ["TREM2", "APOE"], format="dataframe")
plot = client.get_plot(db_id, "scatter", color="TREM2")         # UMAP coloured by TREM2
open("trem2_umap.png", "wb").write(plot["bytes"])               # plot["caption"]: the legend
client.download_artefact("AT6/_group/atlas-umap", "atlas-umap/")  # sha256-checked files

The last line needs a 2.47 server that holds that artefact; list what exists with client.list_artefacts().

Authentication

Anthive sites run behind a login proxy, and the REST API under /api takes your Anthive user name and password as HTTP basic auth on every kind of site:

• Authelia sites (the default): people log in through a login page in the browser, while scripts, pyvark and vark send the same user name and password as HTTP basic auth on /api. There is no separate API password.
• Basic-auth sites: the same HTTP basic credentials as the browser popup.
• Public mirrors (auth.mode: none): no login; only public datasets are served. Leave auth out.

There are no REST API tokens. The personal MCP token (amcp_..., from the site's MCP page) only works on /mcp for AI clients; it does not open /api. Datasets that are not public are hidden from callers who are not signed in: they are missing from listings and answer 404.

Where the client finds credentials

Never put a password in a notebook or script. The client finds credentials in this order:

1. auth= passed to the constructor, usually (user, password) read from somewhere safe (getpass.getpass(), a secrets manager, the environment). Any requests.auth.AuthBase also works.

2. The ANTHIVE_USER and ANTHIVE_PASSWORD environment variables.

3. The Go vark CLI's encrypted store (next section).

4. ~/.netrc, which requests reads by itself when nothing else gave credentials:

   machine my.anthive.example
   login me
   password ...


   Keep it private with chmod 600 ~/.netrc.

export ANTHIVE_USER=me
read -rs ANTHIVE_PASSWORD && export ANTHIVE_PASSWORD   # not in shell history
python -c "from vark import AnthiveClient; print(AnthiveClient('https://my.anthive.example/api').get_version()['version'])"

Reusing vark CLI credentials

Anthive credentials are stored once by the Go vark CLI: user name and password are encrypted at rest with age (modern X25519 + ChaCha20-Poly1305) into ~/.config/vark/secrets.age. pyvark reads from that same store, so a notebook or script never needs a password literal, an environment variable, or a getpass() prompt.

One-time setup (Go CLI side)

Install the Go vark binary, then register your server:

vark server login --name myserver \
                  --url https://my.anthive.example/api \
                  --user me
# → prompts for the password; encrypts it into ~/.config/vark/secrets.age
vark server ls          # confirm the entry is there

That writes two files:

• ~/.config/vark/config.yaml: the server registry (name, URL, user, insecure: flag).
• ~/.config/vark/secrets.age: the age-encrypted password store.

Install the pyvark extras

pip install "pyvark[vark-config]"   # adds pyrage (age) + PyYAML

The base install of pyvark is unchanged; the extras are only needed for credential discovery.

Use it from Python

Auto-discover by URL, with no auth= argument, no password in code:

from vark import AnthiveClient

client = AnthiveClient("https://my.anthive.example/api")
# pyvark matches the URL against `vark server ls`, pulls
# (user, password) from secrets.age, and (if insecure: true is set
# on the entry) demotes `verify` to False automatically.

Look up by registered name, handy when you don't want a URL hard-coded in the notebook:

client = AnthiveClient.from_vark_server("myserver")

The vark_config= constructor knob

Value	Behaviour
None	Default. Auto-discover; silently no-op if the config dir or extras are missing.
True	Require. Raise VarkConfigError if no entry matches the URL.
False	Skip. Never read ~/.config/vark/, even if it exists.
str / Path	Use that directory instead of ~/.config/vark/ (useful for tests / portable setups).

Explicit auth=(user, password) always wins: vark-config discovery never overrides a caller-supplied auth. Pyodide / JupyterLite skip discovery automatically (no filesystem in the browser).

Troubleshooting

• 401 Unauthorized on the first request. Did you actually run vark server login for this server? A fresh vark install lays down a placeholder secrets.age that decrypts cleanly but contains no real password, and the server then answers 401. Re-run vark server login to overwrite it.
• NoSuchEntryError (or "no matching server entry"). The URL passed to AnthiveClient() doesn't match any entry in vark server ls. URLs are normalised (trailing slash stripped, host case-folded) before matching, so it's almost always a typo or a missing /api suffix. Compare vark server ls output against your constructor argument character-for-character.
• ImportError: pyrage or ImportError: yaml. You installed the base pyvark without the extras. Fix: pip install "pyvark[vark-config]".

API coverage (highlights)

• get_root, get_health, get_metrics, get_version, get_changelog: version + latency telemetry (/health exposes mean_response_ms / p50_response_ms / n_samples).
• get_databases, get_database_info, get_group(group_id): catalog + per-collection landing-page data (API 2.5+). Rows carry the lineage fields designation, reanalysis_of, donor_group and has_donor_uid on current servers.
• Catalogue search (API 2.48.0): search(q, limit=None, kind=None) is the keyword search of the web front page, grouped by kind (datasets, collections, genes, genesets, papers, artefacts, facets, help; AnthiveClient.SEARCH_KINDS). A group the site lacks is None. kind='papers', format='dataframe' gives one group as a DataFrame. stats() returns the front-page numbers for you (datasets, cells, genes, gene sets, papers, artefacts you may see). See Search.
• get_donor_groups: datasets that share a donor pool (do not count them as independent donors).
• get_plot(db_id, geom, ...): every server-side geom: scatter, hexbin, kde2d, violin, box, bar, histogram, ecdf, kde, heatmap, rolling, volcano, ma, forest, de_heatmap, de_quadrant. Captures the X-Plot-Caption response header (the multi-sentence figure legend, API 2.7.2+). Supports color_scale=auto|sequential| divergent, plot clamps (log2fc_clip, neglog10p_clip, logmean_clip), bar group_by, hexbin auto-clip (vmin_quantile / vmax_quantile), per-axis transforms (transform_x / transform_y, asinh_scale), KDE knobs (kde_n, kde_bw, n_levels, iso_overlay, point_overlay), marginals / regline overlays, and on-the-fly binning of a continuous color field via bin_color=N (2..20) + bin_color_method='quantile'|'width', wired on scatter, hexbin, rolling (API 2.34+), kde2d (2.35+), histogram / ecdf / kde (2.36+). Data export via format="csv" / "tsv" returns the dataframe the plot was built from (API 2.6+).
• list_de_studies, get_de_study, list_de_contrasts, get_de_rows, get_de_by_gene: DE data flow (API 2.3+).
• analytics_schema, analytics_query, analytics_viz: SELECT-only SQL sandbox + Parquet-backed visualisation.
• module_score, list_module_scores: on-the-fly and pre-computed module scores.
• list_genesets, get_geneset, rescan_genesets.
• list_catalogs, get_catalog, get_catalog_module, get_catalog_score, rescan_catalogs: unified module-catalog view over starCAT (weighted programs, one-segment id like MICROGLIA_V1_0) + genesets (plain gene lists, two-segment id like Sierksma2025/WGCNA). Score recipes let you reproduce binary *_pos calls client-side (API 2.30+).
• list_facets (full=True for facets_visible and definitions_status), get_facet (definition, per-dataset mapping, exclude_secondary), get_database_facets, get_gene_variance_by_facet, get_module_variability (both per-cell and descriptive, not donor-level evidence), list_geneset_studies, get_genesets_by_gene, get_obs_summary, get_obs_top, get_mus_vocab.
• get_databases rows and get_database_info carry replicate_unit, replicate_column, replicate_basis and disease_basis (DataFrame columns with format='dataframe').
• The APOE facet is apoe4_carrier (column ant_apoe4_carrier); API 2.45.0 removed the apoe_carrier alias (an unknown facet now; REMOVED_FACET_ALIASES maps old names). AnthiveClient.TESTED_FACETS lists the eleven facets with donor-level results (2.45.0 added graft_sex and host_sex for xenografts; sex is human post-mortem only), FACET_SCOPES the facet scopes, DEPRECATED_FACETS the deprecated facets and what replaces them.
• Plain-language help (API 2.44.0): explain("replication") returns the maintainers' text as markdown; get_help, get_help_topic, get_glossary, get_glossary_term and search_help give the parts. Facet and context responses list help_topics to read first.
• Facet scopes (API 2.44.0): get_facet, the facet test views and get_module_variability take scope= (human_postmortem, xenograft_human_in_mouse, in_vitro). Human and mouse never mix.
• Donor-level facet tests (exploratory): get_facet_tests, get_facet_test_genes, get_facet_test_modules, get_facet_test_volcano, get_facet_tests_across_datasets, get_facet_gene_effects, get_facet_recurring_genes, get_gene_facet_effects, get_facet_cohorts. See below.
• API 2.45.0 facet views: forest= (full, anchors, none) on get_facet_gene_effects and get_gene_facet_effects; get_facet_recurring_genes (also get_facet_top_genes) pages with n (up to 100000), offset and fetch_all=True, and filters with effect_gate and strict; get_facet_top_modules, get_facet_effects_overview, get_geneset_facet_effects (module replication next to the member genes), get_gene_detection (the low-detection pill), get_facet_donor_values and get_facet_donor_plot (one value per donor per cohort; optional db_id).
• Donor variability (API 2.45.0, exploratory): get_database_donor_variability, get_gene_donor_variability, get_geneset_donor_variability, get_donor_variability_top.
• Gene set ranks within one dataset (API 2.45.0): get_geneset_rank, get_module_ranks. Never compare ranks or means between datasets.
• get_de_study_summary: significant gene counts of every contrast of a DE study in one call (API 2.45.0).
• Access (API 2.45.0): datasets that are not access: public are invisible to anonymous callers (missing from listings, 404 by id). rescan_databases, rescan_genesets, rescan_module_variability, rescan_catalogs, get_plot_cache_stats, clear_plot_cache, admin_release and admin_restore need an admin account (403 otherwise).
• exclude_secondary (default True) on get_gene_stats_all, get_module_variability, get_facet and the facet test views keeps reanalyses out of pooled numbers.
• list_database_files, download_database_file (the .h5ad), download_static_file (a collection's static/ files).
• Paper library (API 2.39+): list_papers, get_paper, get_related_papers, get_paper_page, get_paper_bibtex, get_library_bibtex, download_paper_pdf, search_literature, get_database_papers, get_database_context, get_library_status.
• Paper upload (API 2.40+, uploaders only): get_paper_upload_requirements, upload_paper, upload_papers, paper_items_from_folder.
• Dataset deposits (API 2.46.0, read-only, for members of the site's upload groups): list_deposits, get_deposit, get_deposit_report, get_deposit_vocab, get_deposit_group. Upload datasets with the Go CLI: vark datasets upload.
• Artefact store (API 2.47.0, read-only): list_artefacts, get_artefact, get_artefact_versions, get_artefact_version, get_artefact_preview, download_artefact_file, download_artefact (sha256 verified), list_artefact_purges, list_collections and list_analysis_collections; see Artefacts. Depositing and purging is the Go CLI (vark artefacts add, vark artefacts purge). wait_for_deposit follows any deposit until it is live and raises DepositHeldError when it waits for an admin.
• A server that was just restarted may answer 503 warming_up on the facet routes (API 2.46.1+). The client waits and retries for up to warmup_max_wait seconds (default 180, a constructor argument), then raises AnthiveWarmingUpError.
• pick_fastest(base_urls, ...): a server-selection helper that consumes /health latency telemetry.

Search

The search box of the web front page, as one call (API 2.48.0+). Every word must match; filler words are dropped and AD, PD, MS, ALS, FTD and APOE4 are expanded. Only what you may see is searched.

hits = client.search("TREM2 microglia Alzheimer", limit=10)
hits["n_datasets"], [row["db_id"] for row in hits["datasets"]]
hits["genes"]                      # [{"gene": "TREM2", "n_datasets": ...}]
hits["papers"][0]["passages"]      # page, section and snippet per hit

# Only some groups (sent as kind=genes,papers).
client.search("TREM2", kind=["genes", "papers"])

# One group as a DataFrame (needs pandas).
datasets = client.search("astrocyte", kind="datasets", format="dataframe")

# The numbers on the front page, for you.
numbers = client.stats()
numbers["n_datasets"], numbers["n_cells"], numbers["n_papers"]

n_genes and n_papers are None on a site without a gene index or a library. Donors are not counted.

Paper library

Every anthive site can hold a library of papers and other documents (articles, preprints, theses, reports, proposals). Each record is BibLaTeX-compatible and can be linked to datasets with a role (source, reanalysis, method, related, background). Everyone who can sign in to the site sees the whole library, and its text may be passed on to AI clients.

from vark import AnthiveClient
client = AnthiveClient("https://my.anthive.example/api")   # credentials as above

# Browse and filter (all filters optional, they combine).
for paper in client.list_papers(disease="Alzheimer disease", year="2020..2026"):
    print(paper["citekey"], paper.get("title"))

paper = client.get_paper("sankowski2019mapping")       # record, notes, datasets
related = client.get_related_papers("sankowski2019mapping", kind=["cohort", "author"])

# Which papers belong to a dataset, and a background pack for an LLM.
papers = client.get_database_papers("S19/SMI")
context = client.get_database_context("S19/SMI", level="brief", budget_tokens=4000)

# Passages from the full text (needs the server's literature index).
hits = client.search_literature("TREM2 microglia", k=5, section="results")
for hit in hits["results"]:
    print(hit)

# BibTeX and PDFs.
open("library.bib", "w").write(client.get_library_bibtex())
open("one.bib", "w").write(client.get_paper_bibtex("sankowski2019mapping"))
client.download_paper_pdf("sankowski2019mapping", dest=".")   # saved under the server's name
pdf_bytes = client.download_paper_pdf("sankowski2019mapping")  # or keep it in memory

Uploading papers

Only members of the site's library_upload_groups (by default the admins) may upload, or even see the upload requirements. Everyone else gets PaperUploadForbiddenError (HTTP 403). On a site whose library is read-only, uploads raise PaperUploadDisabledError (HTTP 503) and nothing is written.

from vark import (AnthiveClient, PaperDuplicateError, PaperInvalidError,
                  PaperUploadDisabledError, PaperUploadForbiddenError)

client = AnthiveClient("https://my.anthive.example/api")

requirements = client.get_paper_upload_requirements()
print(requirements["required"], requirements["default_role"])   # background

record = {
    "entrytype": "article",
    "title": "Mapping microglia states in the human brain",
    "author": ["Sankowski, Roman", "Prinz, Marco"],
    "date": "2019-11-18",
    "doi": "10.1038/s41593-019-0532-y",
}
try:
    result = client.upload_paper(
        record, "sankowski2019.pdf",
        role="source",                    # anthive_role; default background
        papers_for={"S19/SMI": "source"}, # proposed dataset link for a curator
        dry_run=True,                     # validate + enrich, write nothing
    )
    print(result["status"], result["citekey"], result["missing_recommended"])
except PaperDuplicateError as exc:
    print("already there as", exc.existing_citekey, "matched on", exc.matched_on)
except PaperInvalidError as exc:
    print("invalid:", exc.errors, exc.missing_required)
except PaperUploadForbiddenError:
    print("this account may not add papers")
except PaperUploadDisabledError:
    print("uploads are switched off on this site")

metadata can also be the text of a .md record with YAML front matter or a pathlib.Path to one. update=True merges into an existing record instead of raising PaperDuplicateError. Set role="source" or "reanalysis" only when the data in anthive come from the paper.

Documents other than articles work the same way. A report, thesis, unpublished manuscript or misc record needs institution or note instead of a DOI:

client.upload_paper({
    "entrytype": "report", "type": "project proposal",
    "title": "Microglia states in ageing", "author": ["Doe, Jane"],
    "year": 2026, "institution": "KU Leuven",
}, "proposal.pdf")

Bulk upload is a loop on the client (the server takes one paper per request). Point it at a folder of name.md records with sibling name.pdf files:

items = client.paper_items_from_folder("to_upload/")
outcomes = client.upload_papers(items, dry_run=True)
for outcome in outcomes:
    print(outcome["index"], outcome["ok"], outcome["status"], outcome.get("citekey"))

upload_papers records duplicates and invalid records and goes on (stop_on_error=True re-raises the first one). A 403 or 503 stops the whole run at once, since no later paper could succeed either.

Artefacts

An artefact is a versioned, immutable set of analysis files of one dataset or one collection (a DE table, figures, a notebook, a model). Its reference is <group_id>/<scope>/<artefact_id>[@v<N>]: the scope is the dataset's file id (SMI of S19/SMI) or _group for the collection. Without @v<N> it means the latest live version. A published version never changes. Removing one takes two steps: its owner or an admin can purge it (soft: the version is marked withdrawn, with who and why, but its files stay listed and downloadable, and an unpurge makes it live again), and an admin can then delete it for good, which leaves a tombstone.

from vark import AnthiveClient, ArtefactDeletedError, ArtefactIntegrityError

c = AnthiveClient("https://my.anthive/api")

# What exists for one dataset, or a whole collection (every page).
rows = c.list_artefacts(db_id="S19/SMI")["artefacts"]
frame = c.list_artefacts(group_id="AT6", all_pages=True, format="dataframe")

# One artefact: versions, files and the provenance in the manifest.
detail = c.get_artefact("AT6/_group/atlas-umap")
detail["versions"]              # [{version, state, published}, ...]
detail["manifest"]["made_from"]  # datasets and versions it was made from
detail["manifest"]["declared"]   # author, software, code, as stated
c.get_artefact_versions("AT6/_group/atlas-umap")  # purged and deleted ones too

# Download one version into a folder; every file is checked against
# the manifest's sha256 and the manifest is written beside the files.
paths = c.download_artefact("AT6/_group/atlas-umap@v2", "atlas-umap/")
png = c.download_artefact_file("AT6/_group/atlas-umap", "a.png")  # bytes

# Every collection you may see, or only those that hold analyses
# (no datasets of their own).
c.list_collections()["collections"]
[row["group_id"] for row in c.list_analysis_collections()]

# Your purge, unpurge and delete requests (made with the Go CLI).
c.list_artefact_purges(action="soft", state="done")

The download route answers with a 307 to a presigned S3 link that works for a few minutes, or streams a verified local copy. pyvark follows the redirect itself, without your credentials, and keeps the signed URL out of logs and exceptions. A file is written as <name>.part and renamed once its size and sha256 match; otherwise it is removed and ArtefactIntegrityError is raised. Other refusals have their own classes: ArtefactNotFoundError (also for an artefact you may not see), ArtefactFileNotFoundError (the version has no such file), ArtefactDeletedError (a deleted version, with tombstone; ArtefactPurgedError is an older name for it), ArtefactDeletingError, ArtefactNotOnThisSiteError, ArtefactStorageUnavailableError and ArtefactRateLimitedError (both with retry_after). A soft-purged version is not an error: it downloads normally, its version payload has purge ({purged, purged_by, purge_reason}), and the download emits ArtefactPurgedWarning.

Donor-level facet tests

The server serves the output of anthive's donor-level facet tests: for each dataset and cell type, raw counts are summed per donor and genes are tested with limma-voom against sex (m vs f), disease (AD vs control), APOE e4 carrier status and dose, Braak stage (trend per stage, and early versus late), age (per decade, with and without the pathology term in the model) and, in xenograft hosts, App-NL-G-F versus control, with module scores tested by OLS plus label permutations. Everything is counted per facet scope: human post-mortem and xenograft results are never combined (scope=).

Read these results with their limits in mind. They are exploratory. The unit of analysis is the donor, so n is the number of donors, not cells. Each (dataset, cell type) unit is tested on its own; nothing is pooled and there is no meta-analysis, and datasets share donors. The disease contrast is provisional: "control" means different things between studies and the vocabulary is not settled. AnthiveClient.FACET_TESTS_CAVEATS holds the same text.

from vark import AnthiveClient
client = AnthiveClient("https://my.anthive/api")

# One dataset: one unit per (facet, cell type), with flags and the model.
summary = client.get_facet_tests("G24/MMG")
for unit in summary["units"]:
    if unit["tested"]:
        print(unit["facet"], unit["cell_type"], unit["level_counts"],
              unit["flags"]["descriptive_only"],
              unit["model"]["genes"]["formula"])

# Gene rows of one unit (q is BH within the unit); CSV or a DataFrame.
genes = client.get_facet_test_genes("G24/MMG", facet="sex",
                                    cell_type="microglial cell", limit=20)
frame = client.get_facet_test_genes("G24/MMG", facet="braak", q=1,
                                    limit=2000, format="dataframe")
png = client.get_facet_test_volcano("G24/MMG", "sex", "microglial cell")

# One gene across every tested dataset, with the replication count.
card = client.get_facet_gene_effects("sex", "XIST", cell_type="microglia")
for entry in card["replication"]:
    print(entry["celltype_group"], entry["badge"])
for unit in card["units"]:
    print(unit["db_id"], unit["logFC"], unit["q_value"],
          unit["counted"], unit["not_counted_reason"])

# Genes that change in the most independent cohorts.
top = client.get_facet_recurring_genes("sex", cell_type="microglia", n=20)
print(top["ranking"])
for row in top["rows"]:
    print(row["gene"], row["cohorts_sig_same_sign"], "of",
          row["cohorts_tested"], row["agreement"], row["direction"])

# Facet scopes: one answer per scope; without scope, by_scope has all.
cards = client.get_gene_facet_effects("TREM2")
print(cards["strongest_facet"], list(cards["by_scope"]))
xeno = client.get_facet_recurring_genes(
    "app_nlgf", scope="xenograft_human_in_mouse")

# API 2.45.0: page through every replicated gene, then look at the
# donors behind one result before trusting it.
every = client.get_facet_top_genes("braak", cell_type="microglia",
                                   n=500, fetch_all=True)
values = client.get_facet_donor_values("sex", "microglia", gene="XIST")
plot = client.get_facet_donor_plot("sex", "microglia", gene="XIST",
                                   dest="xist_sex.png")
print(plot["caption"])          # effects, intervals and q per cohort
modules = client.get_facet_top_modules("braak", effect_gate=True)

# Which datasets share donors, and the DRAFT cohort table.
groups = client.get_donor_groups()
cohorts = client.get_facet_cohorts()

How to read the fields:

• descriptive_only: the unit has no usable p values (cell-level or below the replicate floor). p, q, t and the CI are null; only the effect estimate is given.
• counted: the unit counts towards replication. not_counted_reason says why not (secondary dataset, descriptive only, dataset not in the cohort table, cohort role not counted, unmapped cell type, or another unit of the same dataset and cell type group has a more direct cell type source).
• replicated is a partial-conjunction call: r_value < 0.05 means the effect is present in at least 2 independent cohorts, same direction (Benjamini and Heller; Simes combination of the one-sided limma p values of one anchor unit per cohort). It says the direction reproduces, not that the effect is large. effect_gate_passed adds the size (at least 2 cohorts with a log2 fold change of at least effect_gate_tau, a 10 percent change); replicated_effect is the stricter tier (r_treat < 0.05, tested against that minimum effect; replicated_strong does the same at 25 percent). k of m is descriptive (cohorts individually at q_value < 0.05 in the replicated direction; k_treat uses the treat q value).
• Small cohorts (a level with fewer than 5 replicates, numeric facets fewer than 10) are tested and counted but flagged small_sample; n_small counts them in a replication entry. Units with analysis_level below_floor (fewer than 4 replicates) or cell are descriptive only. lambda_gc above 1.3 (inflated) means the p values of that unit are too small. get_facet_recurring_genes lists the replicated genes (n_replicated, n_genes_in_family); effect_gate=True keeps those that pass the effect gate (n_effect_gate) and strict=True those that pass the strict tier. Module results (get_facet_top_modules) use a standardised effect gate and have no strict tier. Directionless gene sets (GWAS, MAGMA) are not_tested, never "not replicated". A cohort is a row group of the DRAFT cohort table and counts once. Cell type labels are counted by group (microglial cell, Microglia and Mic P2RY12 are all microglia, with cl_id CL:0000129). When several strata of one dataset fall into one group, their q is multiplied by n_sibling_strata (q_counted). The full rule is in the response's definition.
• composition_flag: the share of a donor's cells in the stratum differs with the facet, so an effect may reflect composition.
• dataset_changed: the dataset changed since the run; results may be stale.

Module catalogs (starCAT + genesets)

Anthive REST API 2.30 unifies starCAT programs and genesets behind a single /catalogs view. Both sources answer to the same route templates, so a client can walk every module catalog without branching by kind:

from vark import AnthiveClient
client = AnthiveClient("https://my.anthive.example/api")

# 1. Discover every catalog (or filter by source).
inventory = client.list_catalogs(source="starcat")
for cat in inventory["catalogs"]:
    print(cat["source"], cat["catalog_id"], cat.get("n_modules"))

# 2. Drill into one catalog: module and score summaries.
#    catalog_id is one segment for starcat, two for geneset.
starcat = client.get_catalog("starcat", "MICROGLIA_V1_0")
print(len(starcat["modules"]), "modules")
print(len(starcat["scores"]),  "derived scores")

geneset = client.get_catalog("geneset", "Sierksma2025/WGCNA")

# 3. Fetch one module's gene weights (starcat) or list (geneset).
mod = client.get_catalog_module(
    "starcat", "MICROGLIA_V1_0", "Microglia_Border_CAM", top=20,
)
for row in mod["top_genes"]:
    print(f"{row['rank']:2}  {row['gene']:10}  {row['weight']:+.4f}")

# 4. Fetch a derived-score recipe, enough to reproduce it
#    client-side. Binary `*_pos` calls are just
#    `usage[column] > threshold` on normalised usage.
recipe = client.get_catalog_score(
    "starcat", "MICROGLIA_V1_0", "Border_CAM_pos",
)
# {"name": "Border_CAM_pos", "kind": "discrete",
#  "columns": ["Microglia_Border_CAM"], "threshold": 0.0448, ...}

client.rescan_catalogs() forces a server-side reload after you drop a new starCAT TSV or geneset YAML onto the store.

Recipe: module score against a gene on the XY plot (API 2.29+)

module_score computes a Seurat-style score on the fly and answers with summary statistics plus a session_id. The per-cell scores stay on the server; attach the session to a plot and the column module_score becomes a plottable field:

from vark import AnthiveClient
client = AnthiveClient("https://my.anthive.example/api")
db_id = "F24/MIC"   # a dataset with module_scoring_available

score = client.module_score(db_id, genes=["APOE", "TREM2", "CD9", "SPP1"])
print(score["genes_found"], score["summary"]["median"])

plot = client.get_plot(
    db_id, "scatter",
    x="module_score", y="SPP1",
    attach_sessions=score["session_id"],
    color="ant_cell_type",
    marginals=True, regline="global",
    width=6, height=5, dpi=150,
)
open("dam_vs_spp1.png", "wb").write(plot["bytes"])
print(plot["caption"])

# The same session as a SQL table called `scores`.
by_type = client.analytics_query(
    db_id,
    "SELECT o.ant_cell_type, AVG(s.module_score) AS mean_score "
    "FROM scores s JOIN obscat o USING (cell_name) GROUP BY 1",
    attach_sessions=score["session_id"],
)

With two attached sessions the second one's column is called session_1::module_score. Sessions are temporary files on the server and expire; nothing is written back to the dataset. The dataset needs a __gene_bins table (built by ant duckdb-check), otherwise the server answers 400.

Tests

# Offline, mocked HTTP (no server needed):
uv run --with pytest --with requests --with pandas --no-project \
    python -m pytest tests/ -v

# Integration: start a throw-away ant-serve from an anthive4 tree on a
# free loopback port, with a temporary state dir, store and a COPY of a
# few library records (nothing is written outside pytest's tmp dir):
git -C /path/to/anthive4 archive main | tar -x -C /tmp/anthive4-main
ANTHIVE4_SOURCE=/tmp/anthive4-main \
ANTHIVE_IT_LIBRARY=/path/to/anthive4/data/library \
ANTHIVE_IT_CITEKEYS=sankowski2019mapping,ayhan2021resolving \
ANTHIVE_IT_COLLECTION=/path/to/h5adstore/Sankowski2019 \
ANTHIVE_IT_DATASET=S19/SMI \
uv run --with pytest --with requests --with pandas --no-project \
    python -m pytest tests/test_integration_server.py -v

# Integration, facets: the same throw-away server, but serving the REAL
# h5adstore read-only through a symlink mirror (caches land in the tmp
# dir; the test fails if any real store file changes):
ANTHIVE4_SOURCE=/tmp/anthive4-main \
ANTHIVE_IT_STORE=/path/to/h5adstore \
uv run --with pytest --with requests --with pandas --no-project \
    python -m pytest tests/test_integration_facets.py -v

# Integration, artefacts: a throw-away ant-serve (API 2.47.0+) on a
# free port in 18700-18799, a temporary store built with anthive4's
# tests/artefact_helpers.py and a fake S3 in the test process:
ANTHIVE4_SOURCE=/path/to/anthive4 \
ANTHIVE_IT_COLLECTION=/path/to/h5adstore/Sankowski2019 \
uv run --with pytest --with requests --with pandas --no-project \
    python -m pytest tests/test_integration_artefacts.py -v

# Live smoke (round-trip):
ANTHIVE_TEST_URL=https://my.anthive/api \
ANTHIVE_TEST_USER=me ANTHIVE_TEST_PASSWORD="$(pass show anthive)" \
uv run --with pytest --with requests --with pandas \
    python -m pytest tests/test_smoke.py -v

Versioning

pyvark starts at 0.1.0 as a clean break from the legacy antclient 1.x history that previously lived under anthive4/antclient/. The Anthive REST API uses its own semver (X.Y.Z); see client.AnthiveClient.API_TARGET for the version this release was last verified against.

Links

• Source: https://gitlab.kuleuven.be/bdslab/anthive/pyvark (mirror: https://codeberg.org/mfiers/pyvark)
• Issues: https://codeberg.org/mfiers/pyvark/issues
• Changelog: https://gitlab.kuleuven.be/bdslab/anthive/pyvark/-/blob/main/CHANGELOG.md
• Anthive server: https://gitlab.kuleuven.be/bdslab/anthive/anthive4
• Go command line client: https://codeberg.org/mfiers/vark

License

MIT; see LICENSE.
