pyvark

Python client for the Anthive single-cell RNA-seq REST API. Sibling of the Go vark CLI — same backend, two front ends.

API surface verified against anthive REST API 2.36.0 (2026-08-07).

Why the dual name?

The Go CLI ships as a binary called vark. To avoid clobbering it on the user's $PATH and to keep the PyPI / Codeberg slug obvious, the distribution name is pyvark but the importable name is vark.

pip install pyvark                                    # distribution
python -c "from vark import AnthiveClient; print('ok')"   # usage

(Both CLI and library live next to each other in the same Anthive setup with no shell collision: vark = the Go binary, vark = the Python import.)

Install

From PyPI:

pip install pyvark          # or: uv add pyvark

Version pin (semver-safe):

pip install "pyvark>=0.4.0,<0.5"

Editable from a local checkout (development):

git clone ssh://git@codeberg.org/mfiers/pyvark.git
cd pyvark
uv pip install -e .
# with pandas for `format='dataframe'` support:
uv pip install -e ".[pandas]"

Pyodide / JupyterLite:

import micropip
await micropip.install("pyvark")
from vark import AnthiveClient
client = AnthiveClient()   # auto-detects {origin}/api/ in the browser

Minimal example

from vark import AnthiveClient

client = AnthiveClient(
    "https://my.anthive.example/api",
    auth=("user", "password"),
)

# What's on this server?
print(client.get_version()["version"])
databases = client.get_databases()
print(f"{len(databases)} datasets available")

# Pick a dataset and show its metadata fields
info = client.get_database_info(databases[0]["id"])
print(info["title"], info["n_cells"], "cells")

# Render a UMAP scatter server-side and write the PNG
plot = client.get_plot(
    info["id"], "scatter",
    color="cell_type",
    palette_categorical="tab20",
    width=6, height=5, dpi=150,
)
open("umap.png", "wb").write(plot["bytes"])

# The X-Plot-Caption header carries anthive's prose figure legend —
# this is the ONLY place the multi-sentence caption exists.
print(plot["caption"])

Reusing vark CLI credentials

Anthive credentials are stored once by the Go vark CLI — username + password are encrypted at rest with age (modern X25519 + ChaCha20-Poly1305) into ~/.config/vark/secrets.age. pyvark reads from that same store, so a notebook or script never needs a password literal, an environment variable, or a getpass() prompt.

One-time setup (Go CLI side)

Install the Go vark binary, then register your server:

vark server login --name myserver \
                  --url https://my.anthive.example/api \
                  --user me
# → prompts for the password; encrypts it into ~/.config/vark/secrets.age
vark server ls          # confirm the entry is there

That writes two files:

• ~/.config/vark/config.yaml — the server registry (name, URL, user, insecure: flag).
• ~/.config/vark/secrets.age — age-encrypted password store.

Install the pyvark extras

pip install "pyvark[vark-config]"   # adds pyrage (age) + PyYAML

The base install of pyvark is unchanged; the extras are only needed for credential discovery.

Use it from Python

Auto-discover by URL — no auth= argument, no password in code:

from vark import AnthiveClient

client = AnthiveClient("https://my.anthive.example/api")
# pyvark matches the URL against `vark server ls`, pulls
# (user, password) from secrets.age, and (if insecure: true is set
# on the entry) demotes `verify` to False automatically.

Look up by registered name — handy when you don't want a URL hard-coded in the notebook:

client = AnthiveClient.from_vark_server("myserver")

The vark_config= constructor knob

Value	Behaviour
None	Default. Auto-discover; silently no-op if the config dir or extras are missing.
True	Require. Raise VarkConfigError if no entry matches the URL.
False	Skip. Never read ~/.config/vark/, even if it exists.
str / Path	Use that directory instead of ~/.config/vark/ (useful for tests / portable setups).

Explicit auth=(user, password) always wins — vark-config discovery never overrides a caller-supplied auth. Pyodide / JupyterLite skip discovery automatically (no filesystem in the browser).

Troubleshooting

• 401 Unauthorized on the first request. Did you actually run vark server login for this server? A fresh vark install lays down a placeholder secrets.age that decrypts cleanly but contains no real password — the server then 401s. Re-run vark server login to overwrite it.
• NoSuchEntryError (or "no matching server entry"). The URL passed to AnthiveClient() doesn't match any entry in vark server ls. URLs are normalised (trailing slash stripped, host case-folded) before matching, so it's almost always a typo or a missing /api suffix — compare vark server ls output against your constructor argument character-for-character.
• ImportError: pyrage or ImportError: yaml. You installed the base pyvark without the extras. Fix: pip install "pyvark[vark-config]".

API coverage (highlights)

• get_root, get_health, get_metrics, get_version, get_changelog — version + latency telemetry (/health exposes mean_response_ms / p50_response_ms / n_samples).
• get_databases, get_database_info, get_group(group_id) — catalog + per-collection landing-page data (API 2.5+).
• get_plot(db_id, geom, ...) — every server-side geom: scatter, hexbin, kde2d, violin, box, bar, histogram, ecdf, kde, heatmap, rolling, volcano, ma, forest, de_heatmap, de_quadrant. Captures the X-Plot-Caption response header (the multi-sentence figure legend — API 2.7.2+). Supports color_scale=auto|sequential| divergent, plot clamps (log2fc_clip, neglog10p_clip, logmean_clip), bar group_by, hexbin auto-clip (vmin_quantile / vmax_quantile), per-axis transforms (transform_x / transform_y, asinh_scale), KDE knobs (kde_n, kde_bw, n_levels, iso_overlay, point_overlay), marginals / regline overlays, and on-the-fly binning of a continuous color field via bin_color=N (2..20) + bin_color_method='quantile'|'width' — wired on scatter, hexbin, rolling (API 2.34+), kde2d (2.35+), histogram / ecdf / kde (2.36+). Data export via format="csv" / "tsv" returns the dataframe the plot was built from (API 2.6+).
• list_de_studies, get_de_study, list_de_contrasts, get_de_rows, get_de_by_gene — DE data flow (API 2.3+).
• analytics_schema, analytics_query, analytics_viz — SELECT-only SQL sandbox + Parquet-backed visualisation.
• module_score, list_module_scores — on-the-fly and pre-computed module scores.
• list_genesets, get_geneset, rescan_genesets.
• list_catalogs, get_catalog, get_catalog_module, get_catalog_score, rescan_catalogs — unified module-catalog view over starCAT (weighted programs, one-segment id like MICROGLIA_V1_0) + genesets (plain gene lists, two-segment id like Sierksma2025/WGCNA). Score recipes let you reproduce binary *_pos calls client-side (API 2.30+).
• pick_fastest(base_urls, ...) — server-selection helper that consumes /health latency telemetry.

Module catalogs (starCAT + genesets)

Anthive REST API 2.30 unifies starCAT programs and genesets behind a single /catalogs view. Both sources answer to the same route templates, so a client can walk every module catalog without branching by kind:

from vark import AnthiveClient
client = AnthiveClient("https://my.anthive.example/api")

# 1. Discover every catalog (or filter by source).
inventory = client.list_catalogs(source="starcat")
for cat in inventory["catalogs"]:
    print(cat["source"], cat["catalog_id"], cat.get("n_modules"))

# 2. Drill into one catalog — module + score summaries.
#    catalog_id is one segment for starcat, two for geneset.
starcat = client.get_catalog("starcat", "MICROGLIA_V1_0")
print(len(starcat["modules"]), "modules")
print(len(starcat["scores"]),  "derived scores")

geneset = client.get_catalog("geneset", "Sierksma2025/WGCNA")

# 3. Fetch one module's gene weights (starcat) or list (geneset).
mod = client.get_catalog_module(
    "starcat", "MICROGLIA_V1_0", "Microglia_Border_CAM", top=20,
)
for row in mod["top_genes"]:
    print(f"{row['rank']:2}  {row['gene']:10}  {row['weight']:+.4f}")

# 4. Fetch a derived-score recipe — enough to reproduce it
#    client-side. Binary `*_pos` calls are just
#    `usage[column] > threshold` on normalised usage.
recipe = client.get_catalog_score(
    "starcat", "MICROGLIA_V1_0", "Border_CAM_pos",
)
# {"name": "Border_CAM_pos", "kind": "discrete",
#  "columns": ["Microglia_Border_CAM"], "threshold": 0.0448, ...}

client.rescan_catalogs() forces a server-side reload after you drop a new starCAT TSV or geneset YAML onto the store.

Recipe — module-score vs gene on the XY plot (API 2.29+)

REST API 2.29 lifted the restriction that made attach_sessions columns unusable as x / y on the XY plot endpoints (they worked as color= already). That unlocks the "score-vs-gene" figure — compute a module score on the fly, then plot it against a single gene's expression:

from vark import AnthiveClient
client = AnthiveClient("https://my.anthive.example/api")
db_id = "Sierksma2025/microglia"

# Compute a Seurat-style module score for a small gene list and
# capture the session id the server hands back.
score = client.module_score(
    db_id,
    genes=["APOE", "TREM2", "CD9", "SPP1"],
    name="DAM_score",
)
session_col = score["column"]   # e.g. "session_1::DAM_score"

# Now use the score as X on an XY scatter, gene expression as Y.
# Pre-2.29 servers reject this with 400; 2.29+ returns a plot.
plot = client.get_plot(
    db_id, "scatter",
    x=session_col, y="SPP1",
    color="cell_type",
    marginals="hist", regline=True,
    width=6, height=5, dpi=150,
)
open("dam_vs_spp1.png", "wb").write(plot["bytes"])
print(plot["caption"])

session_col is dataset-scoped and lives only inside this client's plot-request context — the server re-materialises it from the Parquet sidecar keyed on session_id. Nothing is written back to the duckdb.

Tests

# Offline (no server needed):
uv run --with pytest --with requests python -m pytest tests/test_offline.py -v

# Live smoke (round-trip):
ANTHIVE_TEST_URL=https://my.anthive/api \
ANTHIVE_TEST_USER=user ANTHIVE_TEST_PASSWORD=pass \
uv run --with pytest --with requests --with pandas \
    python -m pytest tests/test_smoke.py -v

Versioning

pyvark starts at 0.1.0 as a clean break from the legacy antclient 1.x history that previously lived under anthive4/antclient/. The Anthive REST API uses its own semver (X.Y.Z) — see client.AnthiveClient.API_TARGET for the version this release was last verified against.

License

MIT — see LICENSE.
