pywce 3.0.0

A templates-driven framework for building complete WhatsApp chatbots

WhatsApp ChatBot Engine

A framework for creating complete WhatsApp chatbots of any scale using a template-driven approach - allowing you to define conversation flows and business logic in a clean and modular way.

[!NOTE] Core chatbot template engine and WhatsApp client library are decoupled - allowing you to use them independently or together.

Features

• Template-Driven Design: Define conversational flows and business logic in a clean, modular way (Support YAML & JSON templates by default).
• Hooks for Business Logic: Attach Python functions to process messages or actions on your hooks.
• Customizable: implement your own session & template storage source.
• Easy-to-use API for WhatsApp Cloud.
• Supports dynamic messages with placeholders.
• Built-in support for common chatbot input phrases like back, retry, report and menu. Also caches default name under wa_name key
• Support WhatsApp Flow endpoint
• Supports all WhatsApp message types

Installation

pip install pywce

---

Why pywce

Most WhatsApp chatbot tutorials or libraries acts as client libraries only or give basic chatbot using a lot of if..else.

This project gives you a complete approach for developing chatbots of any scale, giving you access to full package of whatsapp client library and chatbot development framework.

---

Setup

Summary: Setup in 6 easy steps (with FastAPI)

1. Clone repo and install all dependencies, pip install .
2. Navigate to the example folder and install its dependencies too, pip install -r requirements.txt
3. Setup your whatsapp account configs in .env.example and edit the file to .env only
4. Run the chatbot, fastapi dev main.py and setup tunneling using ngrok or any similar service (if hosted local) and configure your webhook on developer portal
5. Build on top of available example templates in example/ folder to suit your chatbot needs
6. Implement your chatbot logic in example/<project-name>/hooks folder

After you get the hang of it, you can start your new project afresh

---

WhatsApp

Follow the complete step by step WhatsApp Cloud API guide below.

Important settings needed for this library

1. Phone number ID
2. Access Token
3. Webhook callback verification token of your choice
4. App secret

Engine

You can either use .env or add your credentials directly to the WhatsAppConfig class

# config.py
import os
from dotenv import load_dotenv
from pywce import client, Engine, EngineConfig, storage

load_dotenv()

# configure default YAML/JSON templates source
template_storage_manager = storage.YamlJsonStorageManager(
    os.getenv("TEMPLATES_DIR"),
    os.getenv("TRIGGERS_DIR")
)

whatsapp_config = client.WhatsAppConfig(
    token=os.getenv("ACCESS_TOKEN"),
    phone_number_id=os.getenv("PHONE_NUMBER_ID"),
    hub_verification_token=os.getenv("WEBHOOK_HUB_TOKEN")
)

whatsapp = client.WhatsApp(whatsapp_config=whatsapp_config)

engine_config = EngineConfig(
    whatsapp=whatsapp,
    storage_manager=template_storage_manager,
    start_template_stage=os.getenv("START_STAGE")
)

engine = Engine(config=engine_config)

Example ChatBot

Here's a simple example template to get you started:

[!NOTE] Checkout complete working examples in the example folder

1. Define YAML/JSON template (Conversation Flow💬):

# path/to/templates/bot.yaml
"START-MENU":
  type: button
  template: "path.to.hook.username"
  message:
    title: Welcome
    body: "Hi {{ name }}, I'm your assistant, click below to start!"
    footer: pywce
    buttons:
      - Start
  routes:
    "start": "NEXT-STEP"

"NEXT-STEP":
  type: text
  prop: age
  message: Great, What is your age?
  routes:
    "re:.*": "ANOTHER-STEP"

2. Write your hook (Supercharge⚡):

# path/to/hook.py
from pywce import HookArg, TemplateDynamicBody

def username(arg: HookArg) -> HookArg:
    """
     fill message template's dynamic variable: name
     to greet user by their whatsapp name 😎
    """

    template_value = {"name": arg.user.name}

    arg.template_body = TemplateDynamicBody(
        render_template_payload=template_value
    )

    return arg

3. Engine client:

Use fastapi or flask or any python library to create endpoint to receive WhatsApp webhooks

# main.py

# ~ fastapi snippet ~

from .config import engine, whatsapp

def bg_wehbook_handler(payload: dict, headers: dict) -> None:
    engine.process_webhook(payload, headers)

@app.post("/chatbot/webhook")
async def process_webhook(req: Request, bg_task: BackgroundTasks):
    """
        Handle incoming webhook events from WhatsApp
        and process them in the background.
    """
    payload = await req.json()

    bg_task.add_task(bg_wehbook_handler, payload, dict(req.headers))

    return Response(content="ACK", status_code=200)

WhatsApp Client Library

[!NOTE] You can use pywce as a standalone whatsapp client library. See Example

PyWCE provides a simple, Pythonic interface to interact with the WhatsApp Cloud API:

• Send messages (text, media, templates, interactive, etc)
• Receive and process webhooks
• Media management (upload and download)
• Out of the box utilities using the WhatsApp.Utils class.

Example usage:

from pywce import client

config = client.WhatsAppConfig(
    token="ACCESS-TOKEN",
    phone_number_id="PHONE-NUMBER-ID",
    hub_verification_token="WEBHOOK-VERIFICATION-TOKEN"
)

whatsapp = client.WhatsApp(whatsapp_config=config)

# Sending a text message
response = whatsapp.send_message(
    recipient_id="recipient_number",
    message="Hello from pywce!"
)

# verify if request was successful, using utils
is_sent = whatsapp.util.was_request_successful(
    recipient_id="recipient_number",
    response_data=response
)

if is_sent:
    message_id = whatsapp.util.get_response_message_id(response)
    print("Request successful with msg id: ", message_id)

Documentation

Visit the official documentation for a detailed guide.

Changelog

Visit the changelog list for a full list of changes.

Contributing

We welcome contributions! Please check out the Contributing Guide for details.

License

This project is licensed under the MIT License. See the LICENSE file for details.
