qenvs 0.3.2a1

Physically validated quantum control environments for reinforcement learning and optimal control.

Reusable physics. Reproducible control.

QEnvS (Quantum Environment Suite) is a model zoo of open-quantum-system control problems (transmon gates, quantum batteries, qubit and three-level state transfer; thermal machines later), packaged so that you can plug them into an RL agent or a gradient-based optimiser in a few lines, instead of re-deriving the physics for every paper.

Every model ships with model-specific reference results that run as tests (pi-pulse inversion, exponential decay, ergotropy bounds, collective-charging scaling, ...). The checks combine closed-form results, physical constraints and solver convergence. Models are also cross-checked against QuTiP where an equivalent independent formulation is available; the table below lists the exact coverage.

Built on dynamiqs (JAX): environments are jit-able, vmap-able across thousands of trajectories, and differentiable, so the same model serves RL (PPO/SAC), GRAPE-style optimal control and MPC.

Install

Full instructions, GPU setup and troubleshooting: Getting started. Supported versions and the API stability policy: Stability and versioning.

pip install qenvs            # core: jax + dynamiqs
pip install 'qenvs[gym]'     # + gymnasium adapter (stable-baselines3, CleanRL, ...)

To try the 0.3.2a1 alpha explicitly:

pip install --pre 'qenvs==0.3.2a1'

This alpha adds explicit battery subsystems and endpoint trajectory diagnostics (custom models, trajectory API). The default install continues to select the latest final release.

Quickstart

Functional JAX API (batch 1024 episodes on one GPU):

import jax, jax.numpy as jnp
import qenvs

env = qenvs.make("qubit/StateTransfer-v0", horizon=10, dt=0.2)

keys = jax.random.split(jax.random.PRNGKey(0), 1024)
states, ts = jax.vmap(env.reset)(keys)
actions = jnp.ones((1024, env.action_dim))
states, ts = jax.jit(jax.vmap(env.step))(states, actions)
print(ts.reward.shape, ts.info["fidelity"].shape)  # (1024,) (1024,)

Gradient-based control through the same environment:

def loss(actions):
    _, rewards = env.rollout(actions)
    return -rewards.sum()  # = -(F_final - F_initial)


grad = jax.grad(loss)(jnp.zeros((env.horizon, env.action_dim)))

Gymnasium for classic RL libraries:

from qenvs.wrappers import GymnasiumEnv
from stable_baselines3 import PPO

gym_env = GymnasiumEnv(env)
PPO("MlpPolicy", gym_env).learn(20_000)

Command line, for humans and coding agents (every command has --json; uvx qenvs ... works without installing):

qenvs list --json
qenvs info qubit/StateTransfer-v0 --json       # physics, kwargs, references, usage
qenvs run qubit/StateTransfer-v0 --policy pi-pulse --set gamma1=0.1 --json
qenvs validate                                  # per-check error vs tolerance + versions
qenvs doctor                                    # install / backend / optional extras check

Repository conventions for coding agents are in AGENTS.md; an LLM index of the docs is at /llms.txt.

Architecture

flowchart LR
    M["Model<br/>drift, controls, jump ops,<br/>initial state, observables"] --> E["Environment<br/>reset / step / rollout<br/>jit, vmap, grad"]
    E --> G["GymnasiumEnv<br/>SB3, CleanRL"]
    E --> R["registry.make()<br/>namespace/Name-vN"]
    M --> V["validation.CHECKS<br/>analytic, constraints, numerics"]
    V --> C["qenvs validate / tests"]
    E --> O["GRAPE via jax.grad<br/>PPO via vmap"]

The physics lives only in Model; everything above it is an adapter. A model is merged only with model-specific checks in qenvs.validation that compare it against closed-form results, physical constraints and solver convergence, with QuTiP cross-checks where an equivalent independent formulation is available.

Models and tasks

Each model has a page under docs/models/ with its Hamiltonian, assumptions and validation table.

Realistic RL conditions (0.3): ParameterRandomization draws model parameters per episode, ControlErrors adds gain, offset and step noise, ObservationModel (or qenvs.make(task, observation=..., shots=...)) gives expectation-value observations with exact finite-shot noise, and qenvs.robust.evaluate reports mean and lower-tail performance over a parameter distribution (uncertainty, observation and evaluation).

Bring your own system: HamiltonianModel.from_operators(drift, controls, jump_ops, initial_state) accepts NumPy, JAX, dynamiqs or QuTiP operators, plugs into every environment, and qenvs validate --model my_module:MODEL runs generic physics and numerics checks on it (guide). For RL libraries, GymnasiumEnv(env, normalize_actions=True) and the batched GymnasiumVectorEnv (guide). For hardware toolchains, qenvs.pulses stores pulses with units and provenance (JSON, NPZ), resamples them exactly to an AWG sample period and converts rad/ns to MHz (guide). See the roadmap.

Baselines

examples/grape_jax.py (open-loop Adam, GRAPE-style, through env.rollout), examples/ppo_jax.py (vectorised PPO, equinox + optax) and examples/benchmark.py (table in docs/benchmarks.md). Closed qubit/StateTransfer-v0, 3 seeds, about a minute on CPU: GRAPE 1.0000, PPO 0.9997 +- 0.0002 (optimum 1.0).

examples/benchmark_battery.py charges the battery tasks and compares GRAPE and PPO with a provable optimum (closed resonant Dicke and qubit batteries reduce to a single pulse-area parameter) and a one-pulse physical baseline. GRAPE reaches the optimum on every closed task ($N$ = 2, 4, 8); on the open Dicke batteries no method found more than the best single rectangular pulse, while time-shaped GRAPE pulses win on the open qubit battery. PPO at default settings stays within about 2 percent of the closed optima. Tables in docs/benchmarks.md.

Why not X?

• qutip-qoc / GRAPE / CRAB optimise a pulse for one fixed model; QEnvS gives you the model as a reusable, tested object plus an environment interface.
• qiskit-gym, qgym are circuit-level (synthesis, routing); QEnvS is Hamiltonian/pulse-level with open-system dynamics.
• Paper repositories (e.g. ICML 2025 RL-for-quantum-control code) are reproductions of one paper; QEnvS is the shared, maintained layer under them.

Contributing

See CONTRIBUTING.md. New models must come with analytic validation tests.

Citation

Software DOI (all versions): 10.5281/zenodo.23359969. Version 0.3.0: 10.5281/zenodo.23401877 (0.2.0: 10.5281/zenodo.23374561, 0.1.0: 10.5281/zenodo.23359970). The 0.3.2a1 alpha has no separate Zenodo archive or version DOI. Cite the concept DOI and record the alpha version used. Machine-readable metadata is in CITATION.cff (GitHub shows a "Cite this repository" button).

@software{park_qenvs,
  author  = {Park, Beomdo},
  title   = {{QEnvS}: physically validated quantum control environments for
             reinforcement learning and optimal control},
  year    = {2026},
  version = {0.3.2a1},
  doi     = {10.5281/zenodo.23359969},
  url     = {https://github.com/beomdo-park/QEnvS}
}

License

Apache-2.0. Third-party attributions are listed in NOTICE.
