qkdsec 0.3.0

A developer toolkit for Quantum Key Distribution: numerical security proofs, BB84 simulation, and a full ETSI GS QKD 014 client with built-in conformance probe

qkdsec

The developer toolkit for Quantum Key Distribution. Pull keys from any ETSI-compliant KME, prove your vendor actually implements the spec, compute provable key-rate bounds, and simulate BB84 — all from one pip install.

Why qkdsec

Most ETSI GS QKD 014 client libraries implement the happy path and stop there. qkdsec ships the only runnable conformance probe for the standard:

qkdsec doctor https://kme.your-vendor.com --slave-sae-id sae-bob \
    --cert alice.crt --key alice.key

qkdsec doctor — https://kme.your-vendor.com
slave SAE: sae-bob

  PASS  reachability         [§5.2]      45 ms
  PASS  status_fields        [§5.2.2]    12 ms
  PASS  enc_keys_get         [§5.3]     108 ms
  PASS  enc_keys_post        [§5.3]      94 ms
  PASS  enc_keys_caps        [§5.3]      31 ms
  WARN  extensions_accepted  [§5.3.2]    28 ms
        KME returned HTTP 400 with extension_optional present.
  PASS  dec_keys_roundtrip   [§5.4]     142 ms
  PASS  error_contract_404   [§5.4]      19 ms
  PASS  error_contract_400   [§5.3]      18 ms
  PASS  latency                          14 ms

  Summary: 9 pass, 1 warn, 0 fail, 0 skip
  Verdict: CONFORMANT  (511 ms total)

Exit code 0 if conformant, 1 if not — drops straight into CI. Text output for humans, JSON for pipelines, HTML for sharing with your vendor.

The rest of the library is built around the same idea: give developers the pieces they actually need, with each subpackage installable on its own.

Who this is for

qkdsec is built for three kinds of developer. Pick the one that sounds like you — that tells you which subpackage and extras to install.

Ops engineers integrating a real KME

You bought a QKD box from Toshiba, ID Quantique, QuantumCTek, LuxQuanta, or similar. The vendor handed you an ETSI GS QKD 014 endpoint and a client cert. Now you need to pull keys from it and pipe them into TLS / IPsec / your own service.

Use qkdsec.client + qkdsec doctor:

• Pull keys from your KME with a few lines of Python — sync for scripts, async for FastAPI / asyncio services.
• Run qkdsec doctor against your KME in CI to catch spec regressions before they hit production.
• Audit a vendor before signing the PO — point doctor at their demo KME and see what they actually implement vs. claim.

pip install "qkdsec[doctor]"   # CLI + doctor + async client

from qkdsec.client import ETSI014Client

with ETSI014Client(
    "https://kme.example.com",
    client_cert=("alice.crt", "alice.key"),
) as kme:
    keys = kme.get_enc_keys("sae-bob", number=1, size=256)
    psk = keys[0].key   # 32 bytes — feed straight to your TLS/IPsec stack

Async — same surface, sharing parsers:

from qkdsec.client.aio import AsyncETSI014Client

async with AsyncETSI014Client(
    "https://kme.example.com",
    client_cert=("alice.crt", "alice.key"),
) as kme:
    keys = await kme.get_enc_keys("sae-bob", number=1, size=256)

Full ETSI GS QKD 014 v1.1.1 coverage — including multicast key delivery (additional_slave_SAE_IDs), mandatory and optional vendor extensions, and container-level metadata. Read the doctor guide to see every probe and the clause it tests.

Researchers and cryptography students

You are writing a paper, thesis, or course assignment that needs a provable secret-key-rate lower bound — not a hand-waving estimate. You want to plot rate vs. QBER or rate vs. distance for BB84 under realistic channel models without rolling your own SDP.

Use qkdsec.proofs:

• Shor–Preskill asymptotic bound, two-decoy-state estimation, and Tomamichel et al. finite-key correction — all behind one function.
• Swap channel models without rewriting your code.
• Cite the result with confidence: it is a lower bound, not an order-of-magnitude guess.

pip install "qkdsec[proofs]"

from qkdsec.proofs import key_rate, BB84, DepolarizingChannel

result = key_rate(BB84(), DepolarizingChannel(qber=0.03))
print(f"Lower bound: {result.r_lower:.4f} bits/pulse")

Educators and engineers learning QKD

You want to see BB84 work end-to-end without buying single-photon detectors. You are teaching a class, building intuition for the protocol, or demonstrating to a stakeholder why QBER > 11 % means abort.

Use qkdsec.sim:

• Run the full protocol — basis preparation, transmission, sifting, error correction, privacy amplification — and get the final key plus per-stage stats.
• Backend-switch between a fast classical numpy simulator (for parameter sweeps) and Qiskit Aer (for the actual quantum circuits, when you want to teach the underlying physics).
• Inject controlled eavesdropper noise to show why the QBER threshold matters.

pip install "qkdsec[sim]"

from qkdsec.sim import BB84Protocol

result = BB84Protocol(error_rate=0.01).run(n_bits=4096)
if result.secure:
    print(result.final_key.hex())
else:
    print(f"aborted — QBER {result.qber:.3f} above threshold")

The keys produced by the simulator are pedagogical — never use them as a real shared secret. For that, you need real quantum hardware and the qkdsec.client path above.

Install

Pick the extra that matches your role above. Default install is intentionally lightweight (only requests).

# ETSI 014 client only (sync, lightweight)
pip install qkdsec

# + async client
pip install "qkdsec[async]"

# + qkdsec CLI and doctor (recommended for ops)
pip install "qkdsec[doctor]"

# + numerical security proofs (researchers)
pip install "qkdsec[proofs]"

# + BB84 simulator (educators)
pip install "qkdsec[sim]"

# Everything
pip install "qkdsec[all]"

Heavy dependencies (CVXPY, Qiskit, httpx, typer) live behind extras, so ops users do not pay for the simulator stack and educators do not pay for the SDP solver.

What sets it apart

• qkdsec doctor — the only runnable ETSI GS QKD 014 v1.1.1 conformance probe for Python. Catches vendor spec violations before they reach production.
• Full spec coverage — multicast key delivery, vendor extensions, and container-level metadata, not just the happy path.
• Sync and async — ETSI014Client for scripts; AsyncETSI014Client for FastAPI / asyncio services. Same surface, shared parsers.
• Lightweight default — heavy deps behind extras; pay only for what you use.
• One library, three audiences — ops, researchers, educators each get a first-class subpackage.

Standards

• ETSI GS QKD 014 v1.1.1 — REST API for key delivery (full coverage)
• BB84 (Bennett & Brassard, 1984)
• Shor–Preskill asymptotic key rate
• Tomamichel et al. finite-key correction
• Two-decoy state estimation

Documentation

Full docs at qkdsec.readthedocs.io — quickstart, doctor guide, async guide, spec coverage walk-through, and API reference.

Scope and non-goals

• What this is: a developer-facing library for the three roles above.
• What this is not: a complete QKD network, a hybrid QKD+PQC system, or a vendor-specific SDK. QKD itself requires quantum hardware (single-photon sources and detectors over an optical channel). qkdsec helps you build around that hardware, not replace it.

Development

Clone, install with all extras + test deps, and run the suite:

git clone https://github.com/John-Jepsen/qkdsec.git
cd qkdsec
python -m venv .venv
source .venv/bin/activate
pip install --upgrade pip
pip install -e ".[all,test]"
pytest -v

Build the docs:

pip install -e ".[docs]"
sphinx-build -b html docs docs/_build/html

See CONTRIBUTING.md for branching, PRs, and release process, and SECURITY.md for vulnerability reporting.

Contributing

Issues and pull requests are welcome on the canonical repo, github.com/John-Jepsen/qkdsec. See CONTRIBUTING.md to get started.

License

Apache-2.0
