qmrpy

Python toolkit for quantitative MRI (qMRI) modeling, fitting, and simulation.

Installation

pip install qmrpy
# Optional real-data I/O helpers (NIfTI / DICOM / qMRI-BIDS)
pip install "qmrpy[io]"
# or
uv add qmrpy

Optional extra: MRzero Bloch simulation

qmrpy.sim.mrzero wraps MRzeroCore for Bloch-based sequence simulation. MRzeroCore is licensed under AGPL-3.0, which is not compatible with combining it into an MIT-licensed distribution, so it is not installed by default:

pip install "qmrpy[mrzero]"

Installing this extra places the resulting combined environment under the AGPL-3.0 terms, including its network-use provisions. Everything else in qmrpy works without it. See THIRD_PARTY_NOTICES.md.

Quickstart

import numpy as np
from qmrpy.models import T2Mono

# Define model
model = T2Mono(te_ms=[10, 20, 40, 80])

# Simulate signal
signal = model.forward(m0=1000, t2_ms=80)

# Fit single voxel
fit = model.fit(signal)
print(fit["t2_ms"])            # params access (dict-like)
print(fit.quality["rmse"])     # quality metadata
print(fit.diagnostics)         # diagnostics metadata

# Fit image with auto-masking and parallel processing
result = model.fit_image(image_data, mask="otsu", n_jobs=-1)

Features

• Models: T1 (VFA, IR, DESPOT1-HIFI, T1MP2RAGE), T1rho, MTR/MTsat, MRF, T2/T2* (mono-exp, EPG, EMC, water/fat, R2*), B0/B1, QSM
• Parallel fitting: n_jobs=-1 for multi-core acceleration
• Auto-masking: mask="otsu" for automatic thresholding
• I/O: TIFF in core; optional NIfTI, DICOM, and BIDS helpers for real-data workflows
• Validation suite: reproducible cross-domain checks for T1/T2/B1/QSM/Simulation

Real-data I/O

from qmrpy.io import load_nifti, save_nifti_map
from qmrpy.models import T2Mono

data, affine, header = load_nifti("sub-01_echoes.nii.gz")
model = T2Mono(te_ms=[10, 20, 40, 80])
maps = model.fit_image(data, mask="otsu", n_jobs=-1)
save_nifti_map("sub-01_t2map.nii.gz", maps, "t2_ms", affine=affine, header=header)

load_dicom_series() returns sorted 3D or 4D arrays plus TE/TR/FA/TI metadata. load_bids_relaxometry() reads minimal qMRI-BIDS NIfTI + JSON sidecar inputs and normalizes timing fields to _ms keys.

CLI

qmrpy info
qmrpy fit t2-mono --input sub-01_echoes.nii.gz --output sub-01_t2map.nii.gz --te-ms 10,20,40,80
qmrpy validate --suite core

Validation (JOSS-friendly, external dependency free)

Run the core validation suite:

uv run --locked -- python scripts/summarize_parity.py \
  --suite core \
  --formats csv,markdown,json \
  --config configs/exp/validation_core.toml \
  --out-dir output/reports/parity_summary

Key outputs:

• output/reports/parity_summary/core_validation.csv
• output/reports/parity_summary/core_validation_metrics.csv
• output/reports/parity_summary/summary.md
• output/reports/parity_summary/summary.json

API

from qmrpy.models import T2Mono, T2EPG, T1VFA, T1InversionRecovery
from qmrpy import save_tiff, load_tiff

# All models follow the same pattern:
model = Model(acquisition_params)
signal = model.forward(**tissue_params)
fit = model.fit(signal)
result = model.fit_image(image, mask="otsu", n_jobs=-1)

License

MIT

---

qmrpy（日本語）

定量MRI（qMRI）のモデリング・フィッティング・シミュレーション用Pythonツールキット。

インストール

pip install qmrpy
# 実データ I/O の optional helper
pip install "qmrpy[io]"
# または
uv add qmrpy

クイックスタート

import numpy as np
from qmrpy.models import T2Mono

# モデル定義
model = T2Mono(te_ms=[10, 20, 40, 80])

# 信号シミュレーション
signal = model.forward(m0=1000, t2_ms=80)

# 単一ボクセルのフィッティング
fit = model.fit(signal)
print(fit["t2_ms"])            # params への辞書互換アクセス
print(fit.quality["rmse"])     # quality メタデータ
print(fit.diagnostics)         # diagnostics メタデータ

# 画像フィッティング（自動マスク＋並列処理）
result = model.fit_image(image_data, mask="otsu", n_jobs=-1)

主な機能

• モデル: T1（VFA, IR, DESPOT1-HIFI, T1MP2RAGE）、T1rho、MTR/MTsat、MRF、T2/T2*（単指数、EPG、EMC、水/脂肪、R2*）、B0/B1、QSM、ノイズ除去
• 並列フィッティング: n_jobs=-1でマルチコア高速化
• 自動マスク: mask="otsu"でOtsu二値化
• I/O: コアのTIFF入出力に加え、optionalでNIfTI/DICOM/BIDSの実データ入出力に対応
• 検証スイート: T1/T2/B1/QSM/Simulation を横断した再現可能な検証

実データ I/O

from qmrpy.io import load_nifti, save_nifti_map
from qmrpy.models import T2Mono

data, affine, header = load_nifti("sub-01_echoes.nii.gz")
model = T2Mono(te_ms=[10, 20, 40, 80])
maps = model.fit_image(data, mask="otsu", n_jobs=-1)
save_nifti_map("sub-01_t2map.nii.gz", maps, "t2_ms", affine=affine, header=header)

load_dicom_series() はソート済みの3D/4D配列とTE/TR/FA/TIメタデータを返します。 load_bids_relaxometry() は最小限の qMRI-BIDS NIfTI + JSON sidecar を読み込み、 時間フィールドを _ms キーへ正規化します。

CLI

qmrpy info
qmrpy fit t2-mono --input sub-01_echoes.nii.gz --output sub-01_t2map.nii.gz --te-ms 10,20,40,80
qmrpy validate --suite core

検証実行（JOSS向け・外部依存なし）

uv run --locked -- python scripts/summarize_parity.py \
  --suite core \
  --formats csv,markdown,json \
  --config configs/exp/validation_core.toml \
  --out-dir output/reports/parity_summary

主要な成果物:

• output/reports/parity_summary/core_validation.csv
• output/reports/parity_summary/core_validation_metrics.csv
• output/reports/parity_summary/summary.md
• output/reports/parity_summary/summary.json

ライセンス

MIT
